- Page 1 Installers & User guide Keybox Version 0.1 08/19...
- Page 2 Keybox In the meantime, you should follow igloohome on Facebook and Youtube! Like us on Facebook Visit our Youtube As our igloohome app is frequently updated, there may be changes to this manual. Please refer to our website igloohome.co/support for the latest version of the manual.
-
Page 3: Table Of Contents
Table of Contents What’s Included Specifications Features Preparing the Lock App Onboarding Unlocking Locking Lock Installation Lock Behaviour Managing Access in App USB-C Jumpstart Audio and LED Indicators Troubleshoot... -
Page 4: What's Included
What’s Included Keybox 3 Slim Shackle Mounting Seal Rings x2 Screwdriver Screws Anchors x2 Mounting Screws x2... -
Page 5: Specifications
Specifications Model IGK3 Battery Type 4 x AAA Alkaline Batteries Battery Life Up to 12 months Emergency Power USB-C Jumpstart Operation Temp -20°C to 50°C IP Rating IP65 Body Material Zinc Alloy, Aluminium Alloy, Acrylic Shackle Material Hardened Steel, Rubber Weight Net: 1kg, Gross: 1.3kg... -
Page 6: Features
Features PIN / Bluetooth Unlock Master PIN Code Bluetooth Master Key The igloohome Keybox 3 unlocks with The igloohome Keybox 3 unlocks with a permanent Master PIN Code. Bluetooth via the app. User PIN Code Bluetooth Guest Key The igloohome mobile app can... - Page 7 Features Security Keypad Security Lockout Masking Security Code A total of 16 digits including the Lock will dissallow any PIN entries masking digits can be entered to and sound an alarm when there is prevent the PIN code from being a number of incorrect PIN attempt.
-
Page 8: Preparing The Lock
Quick Start Guide Loosen the 2 screws and Insert AAA Batteries remove battery cover Battery Cover Secure battery cover tightly with 4 screws... -
Page 9: App Onboarding
In the factory mode (before pairing), the PIN to unlock the lock is 1 2 3 4 5 6 7 8 9 0 Register as a Lock User a) Download igloohome from the App Store / Play Store b) Create an account and login... -
Page 10: Unlocking
Unlocking Bluetooth Unlock 1. Open your igloohome app 2. Tap on the “Bluetooth Unlock” button 3. The status indicator will flash green twice with 4 short ascending tone once unlocked. Home Keybox 3 PIN Code 1. Press any button on the keypad to wake device up 2. -
Page 11: Locking
Locking Auto Relock Manual Relock Simple close the keybox in place and Press and hold the Unlock icon on the bottom Status Indicator will show green with a right of the keypad for 2 seconds until the long beep. status indicator will show green with a long beep. -
Page 12: Lock Installation
Lock Installation Secure Keybox on a handle or knob 1. Unlock the keybox 2. Push the shackle release to the right 3. Pull out the shackle 4. Secure on a handle or knob 5. Insert back the shackle Shackle Release For door handles, For door knobs, use Regular Shackle... - Page 13 Mount on a surface 1. Unlock the keybox 2. Drill holes on a wall 3. Hammer the screw anchors into the holes 4. Mount the Keybox 3 on the wall with the mounting seal rings and 2 screws Mounting Seal Rings Push Out Rubber...
-
Page 14: Lock Behaviour
Lock Behaviour Note: User is able to Enable and Disable Keypad Security Lockout via Bluetooth. Keypad Security Lockout 5 consecutive PIN Code attempts by default Triggered by (Configurable via Bluetooth) After 1 / 5 / 10 Minutes Disable By Master / Guest Bluetooth Unlock Single flash White LED on keypad and Red LED Behaviour on status indicator when keypad is triggered. - Page 15 Lock Behaviour Note: User is able to Enable and Disable Keypad Security Lockout via Bluetooth. Triggered Security Alarm Keypad Lockout 1st Time 30 Sec 1 Min 2nd Time 60 Sec 5 Min 3rd and 90 Sec 10 Min Consecutive Time...
-
Page 16: Managing Access In App
Bluetooth Guest Key Bluetooth Guest Key can be shared with other users for mobile access. It allows your guests to unlock the igloohome smart lock via Bluetooth. There are 3 steps to using a Shared Bluetooth Key Under [Access], press [New Key] and choose [Bluetooth Key] under [Access Type]. -
Page 17: Usb-C Jumpstart
USB-C Jumstart USB-C Jumpstart Feature USB-C Jumpstart Feature 1. Connect the USB-A to USB-C cable to a power bank then plug it 1. Connect the USB-A to USB-C cable to a power bank then plug it onto the USB-C jumpstart port on the keybox. onto the USB-C jumpstart port on the keybox. -
Page 18: Audio And Led Indicators
Audio and LED indications Actions Indications Bluetooth Connection Status indicator flashes Blue Ascending 4 fast tones after unlocked Successfully Unlocked and flash Green LED 2 times 1 long beep after Padlock is locked and Successfully Locked Green LED for 2 seconds Incorrect PIN 4 short beeps and flash Red 2 times Deleted PIN... -
Page 19: Troubleshoot
FCC Warning Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐‐ Reorient or relocate the receiving antenna. ‐‐ Increase the separation between the equipment and receiver. ‐‐Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐‐ Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following ... - Page 20 For enquiries go to: igloohome.co/support...
