- Page 1 TD80 Laser Distance Meter USER MANUAL...
- Page 3 ●Introduction Firstly thank you for your choice on our handhold laser distance meter.Please carefully read the safety instructions and the user manual before using this product, otherwise it may result in hazardous laser radiation and electric shock. ●Safety Instructions 1. This product is a class II laser product. Please DO NOT stare into beam at any time when operating this product! 2.
- Page 4 ●Basic Function 40m：0.05m~40m 50m：0.05m~50m 60m：0.05m~60m Measuring Range 70m：0.05m~70m 80m：0.05m~80m 100m：0.05m~100m 120m：0.05m~120m Measuring Accuracy ±2.0mm (Standard Deviation) Angle Range ±50 Single Measurement √ Angle Measurement √ Continuous Measurement (Max/Min) √ Area/Volume/Pythagoras √ Plus and Minus √ Unit Conversion √ Measuring Reference √...
- Page 5 Area Unit m²,ft² Volume Unit m³,ft³ Laser Type 620~690nm Laser Class class II ,<1mW Single Measurement Time 0.25s Operating Temperature 0~+40℃ -20~+65℃ Storage Temperature RH 20%~80 Store Humidity Batteries AAA(Alkaline),2×1.5V Working time(Fully charged) >5000 times Weight (Without batteries) Approximate 72g Dimension (L*W*H) 110X46X25mm Comment:...
- Page 6 5. Cleaning the lens using alcohol or any other organic solvent. 6. Wiping the lens directly with fingers or other rough surfaces. 7. Powering the equipment beyond the rated DC voltage. Battery Installation: According to figures, remove battery compartment lid and insert 2*AAA batteries (alkaline).
-
Page 7: Operation
1. Laser receiver 6.Minus key/Backward key 2. Laser emitter 7. Clear key/Exit key/OFF key 3. Display screen 8. Mode switch key 4. Power key/Measuring key 9. Plus key/Forward key 10. Sound key/Reference switch key 5. Historical Data Review key/ Unit switch key 11. - Page 8 Figure 1.1 Figure 1.2 Figure 1.3 2.Change Measurement Reference Default measuring reference is the bottom of meter, indication as shown as figure 2.1. Long-time press to change the measuring reference to the top of meter, indication as shown as figure 2.2. Figure 2.1 Figure 2.2 3.Unit Conversion...
- Page 9 time if there is value of measurement.) When the unit is m , Long-time press , the unit will switch unit m to in When the unit is m , Long-time press , the unit will switch unit m to in Figure 3.1 Figure 3.2 Figure 3.3...
- Page 10 Short-time press again to switch Single Pythagorean Theorem Measurement Mode with angle measuring, indication as shown as figure 4.5. Short-time press again to switch Dual Pythagorean Theorem Measurement Mode with angle measuring, indication as shown as figure 4.6. Short-time press again to switch Dual Pythagorean Theorem Addition Measurement Mode, indication as shown as figure 4.7.
- Page 11 5.Storage Mode Short-time press to switch Historical Data Review Mode, the last measuring data will be displayed, indication as shown as figure 5. (Note: At this Historical Data Review Mode, there will be some measure data that factory tested. It do not means this equipment has been used) Figure 5 6.Switch off The equipment can be switched off at any time by long-time press...
- Page 12 2.Continuous measurement At the Single Measurement Mode only, aim the laser onto target. long-time press to enter the continuous measurement, indication as shown as figure 7. Max value Min value Current value Figure 7 3.Area Measurement At the Area Measurement Mode, aim the laser onto target. Short-time press to measure the two side lengths of the target respectively, area measurement results will be displayed as shown as figure 8.
- Page 13 press and measure the three side lengths of the target respectively. The result will be displayed immediately as shown as figure 9. First measured value Second measured value Third measured value Volume calculated value Figure 9 5.Single Pythagorean Theorem Measurement At Single Pythagorean Theorem Measurement Mode, aim the laser onto target.
- Page 14 the height of the right triangle is displayed immediately on the screen as shown as figure 11. measured value Right-angle side measured value Height calculated value Figure11 7.Dual Pythagorean Theorem Measurement with angle measuring At Dual Pythagorean Theorem Measurement Mode with angle measuring, aim the laser onto target.
- Page 15 The height is displayed immediately on the screen as shown as figure 13. first measured value second measured value Third measured value Height calculated value Figure13 9.Dual Pythagorean Theorem Subtraction Measurement At Dual Pythagorean Theorem Subtraction Measurement Mode, aim the laser onto target.
- Page 16 11.Plus and Minus Functions At the Single Measurement Mode, aim the laser onto target. Short-time press to get a measurement, indication as shown as figure 15.1, Then Short-time press , indication as shown as figure 15.2, Then short-time press to get another measurement, The summation will be displayed immediately, indication as shown as figure 15.3.
- Page 17 13.Silence Function At any state, long-time press to switch on or switch off the Buzzer. 11.Error Code Code Possible cause Remedy Err 10 Battery too low Change batteries Err 15 Out of measuring range Measure target within the range Measuring high reflectance target or Err 16 Received signal too weak use high reflectance reflector...
-
Page 18: Warranty Card
Warranty Card 1.We guarantee ONE years warranty for laser distance meter. 2.Warranty begins from purchase date and it is subject to the following conditions: (1).Within warranty,we shall deal with complaints based on faulty equipment by repair,replacement of defective parts or replace an identical flawless product at our discretion.
