OPERATION MANUAL
VRF system indoor unit (Cassette type)
Keep this manual for future reference.
BEDIENUNGSANLEITUNG
VRF-System Innengerät (Kassettentyp)
Bewahren Sie dieses Handbuch für eine spätere Bezugnahme auf.
MODE D'EMPLOI
Unité intérieure à système VRF (Type cassette)
Conservez ce manuel pour pour toute référence ultérieure.
MANUAL DE FUNCIONAMIENTO
Unidad interior del sistema VRF (Tipo casete)
Conserve este manual para posibles consultas futuras.
MANUALE DI ISTRUZIONI
Unità interna del sistema VRF (tipo a cassetta)
Conservare questo manuale per consultazione futura.
ΕΓΧΕΙΡΙΔΙΟ ΛΕΙΤΟΥΡΓΙΑΣ
Εσωτερική μονάδα συστήματος VRF (Τύπος κασέτας)
Διατηρήστε το παρόν εγχειρίδιο για μελλοντική αναφορά.
MANUAL DE FUNCIONAMENTO
Unidade interior do sistema VRF (Tipo cassete)
Guarde este manual para consulta futura.
KULLANIM KILAVUZU
VRF sistemi iç ünitesi (Kaset tipi)
Bu kılavuzu ileride başvurmak üzere saklayın.
PART No. 9369313394-01
MADE IN P.R.C.
Advertisement
Table of Contents
Related Manuals for Fujitsu AUXB004HLAH
Summary of Contents for Fujitsu AUXB004HLAH
- Page 1 Bewahren Sie dieses Handbuch für eine spätere Bezugnahme auf. MODE D’EMPLOI Unité intérieure à système VRF (Type cassette) Conservez ce manuel pour pour toute référence ultérieure. R410A MANUAL DE FUNCIONAMIENTO AUXB004HLAH AUXB005HLAH Unidad interior del sistema VRF (Tipo casete) Conserve este manual para posibles consultas futuras. AUXB007HLAH AUXB009HLAH...
-
Page 2: Table Of Contents
OPERATION MANUAL [Original instructions] WARNING PART No. 9369313394-01 VRF system indoor unit (Cassette type) • The appliance shall be installed, operated and stored in a room with a floor area larger than X m². CONTENTS Minimum room area (m²) Amount of refrigerant Installation height H (m) charge M (kg) SAFETY PRECAUTIONS ................ -
Page 3: Name Of Parts
NAME OF PARTS WARNING • Do not install the unit in area filled with mineral oil such as a factory or area containing a large amount of splashed oil or steam such as a kitchen. • Do not start or stop the operation of this product by turning on or off the circuit breaker. -
Page 4: Adjusting The Direction Of Air Circulation
ADJUSTING THE DIRECTION OF Operable conditions of temperature and humidity AIR CIRCULATION ● The temperature and humidity required for operating this product is as shown in the following table. The vertical wind direction can be controlled with the control unit. Cooling/Dry Mode Heating Mode Outdoor... -
Page 5: Troubleshooting
4. Re-attach the air fi lter to the intake grille. ● The OPERATION indicator lamp (green) lights up and the TIMER indicator lamp (orange) fl ashes: (1) Replace the air fi lter into its holder. This is the standby state. (See page 2) (2) Make sure that the air fi... -
Page 6: Specifications
SPECIFICATIONS AUXB AUXB AUXB AUXB AUXB AUXB AUXB MODEL HLAH HLAH HLAH HLAH HLAH HLAH HLAH POWER SOURCE 220 - 240 V ~ 50 Hz AVAILABLE VOLT- 198 to 264 V AGE RANGE [kW] COOLING CAPACITY [BTU/h] 3,800 5,800 7,500 9,600 12,300 15,400 19,100 [kW] HEATING...
