Toro 79158 Instruction Sheet

Parts List:
Item Part No. Description
1 109-6485-03 Wld, LH Light Mount.................................... 1
2 109-6489-03 Wld, RH Light Mount ................................... 1
3 109-6488-03 Tube, Light Mount ....................................... 2
4 103-6300 Light, 35Watt Halogen................................. 2
5 321-9 Screw, HH 1/4-20 x 1 1/2 ............................ 2
6 104-7201 Nut, Nyloc 1/4-20 Flg .................................. 2
7 104-8301 Nut, Nyloc 3/8-16 Flg .................................. 4
8 3234-12 Screw, HH FLG 3/8-16 x 3/4 ....................... 4
9 92-8875 Switch, Rocker ............................................ 1
10 109-6500 Harness, Light Kit........................................ 1
11* 1-303335 Tie, Cable 7 15/16 (Large) .......................... 6
12 109-6708 Guard.......................................................... 2
13 3256-78 Washer ....................................................... 2
* Items not shown
Installation Instructions:
(Refer to Figure 1 for all item callouts and hardware)
This SAFETY ALERT SYMBOL
both in this manual and on the machine to
identify important safety messages which must
be followed to avoid accidents. This symbol
means:
ATTENTION! BECOME ALERT!
YOUR SAFETY IS INVOLVED!
INSTRUCTION SHEET
LIGHT KIT
Qty.
is used
FIGURE 1
WARNING
POTENTIAL HAZARD
♦ While maintenance or adjustments are
being made, someone could start the
engine.
WHAT CAN HAPPEN
♦ Accidental starting of the engine could
seriously injure you or other bystanders.
HOW TO AVOID THE HAZARD
♦ Remove the key from the ignition switch
and/or pull the wire(s) off the spark plug(s)
before you do any maintenance. Also push
the wire(s) aside so it does not accidentally
contact the spark plug(s).
Page 1 of 2
Part #109-6386 Rev. B
Kit # 109-6240
