Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
YZFR1D(C)
LIT-11626-26-32
1KB-28199-12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YZFR1 2012 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yamaha YZFR1 2012

Summary of Contents for Yamaha YZFR1 2012

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL YZFR1D(C) LIT-11626-26-32 1KB-28199-12...
  • Page 2 EAU10042 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 Yamaha has met these standards without reducing the performance or economy of operation of the motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention to the recommended maintenance schedules and operating instructions contained within this manual.

  • Page 4: Important Manual Information

    IMPORTANT MANUAL INFORMATION EAU10133 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10193 YZFR1D(C) OWNER’S MANUAL ©2012 by Yamaha Motor Corporation, U.S.A. 1st edition, July 2012 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS LOCATION OF IMPORTANT Rider footrest position ....4-26 Coolant ........7-15 LABELS ..........1-1 Rear view mirrors ......4-26 Air filter element ......7-18 Adjusting the front fork ....4-27 Checking the engine idling SAFETY INFORMATION ....2-1 Adjusting the shock absorber speed ........
  • Page 7 STREET AND ENDURO Checking the wheel bearings ..7-32 MOTORCYCLE LIMITED Battery ..........7-33 WARRANTY ......10-7 Replacing the fuses ......7-34 YAMAHA EXTENDED SERVICE Replacing a headlight bulb ...7-36 (Y.E.S.) ........10-9 Tail/brake light ......7-37 Replacing a turn signal light bulb ...........7-37 Replacing the license plate light bulb ...........7-38...

  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 9 LOCATION OF IMPORTANT LABELS 3 California only NOTICE EMISSION HOSE ROUTING Cleaning with alkaline or acid cleaner, gasoline or FUEL TANK ATMOSPHERE solvent will damage windshield. Use neutral detergent. 4B5-2815K-00 CHARCOAL THROTTLE BODY CANISTER 14B-21686-00 2 California only VACUUM HOSE ROUTING PRESS.
  • Page 10 LOCATION OF IMPORTANT LABELS WARNING BEFORE YOU OPERATE THIS VEHICLE, READ Cold tire normal pressure should be set THE OWNER’S MANUAL AND ALL LABELS. as follows. ALWAYS WEAR AN APPROVED MOTORCYCLE Up to 90 kg (198 lbs) load HELMET, eye protection, and protective clothing. : 250 kPa, {2.50 kgf/cm 36 psi...

  • Page 11: Safety Information

    SAFETY INFORMATION ● EAU1028A Never operate a motorcycle with- yourself conspicuous appears to out proper training or instruction. be very effective in reducing the Take a training course. Beginners chance of this type of accident. Be a Responsible Owner should receive training from a cer- Therefore: As the vehicle’s owner, you are respon- tified instructor.
  • Page 12 SAFETY INFORMATION ● Many accidents involve inexperi- • Always signal before turning or Protective Apparel enced operators. In fact, many op- changing lanes. Make sure that The majority of fatalities from motorcy- erators who have been involved in other motorists can see you. cle accidents are the result of head in- accidents do not even have a cur- ●...
  • Page 13 SAFETY INFORMATION ● Avoid Carbon Monoxide Poisoning Do not run engine outdoors where When loading within this weight limit, All engine exhaust contains carbon engine exhaust can be drawn into keep the following in mind: monoxide, a deadly gas. Breathing car- a building through openings such ●...
  • Page 14 Yamaha accessories, which are avail- formed to your vehicle that change any lightweight as possible and able only from a Yamaha dealer, have of the vehicle’s design or operation should be kept to a minimum. been designed, tested, and approved characteristics can put you and others •...
  • Page 15 SAFETY INFORMATION ● tor and may limit control ability, Check that the fuel cock (if therefore, such accessories are equipped) is in the “OFF” position not recommended. and that there are no fuel leaks. ● Use caution when adding electri- ●...

  • Page 16: Description

    DESCRIPTION EAU10410 Left view 4,5,6 12 11 1. Front fork spring preload adjusting bolt (page 4-27) 8. Shock absorber assembly compression damping force adjusting bolt (for slow compression damping) (page 4-29) 2. Front fork compression damping force adjusting screw (page 4-27) 9.

  • Page 17: Right View

    DESCRIPTION EAU10420 Right view 1,2,3 4 1. Storage compartment (page 4-25) 9. Radiator cap (page 7-15) 2. Luggage strap holder (page 4-31) 10.Engine oil filler cap (page 7-13) 3. Helmet holder (page 4-25) 11.Engine oil level check window (page 7-13) 4.

  • Page 18: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 4-16) 2. Left handlebar switches (page 4-15) 3. Main switch/steering lock (page 4-1) 4. Multi-function meter unit (page 4-6) 5. Front brake fluid reservoir (page 7-25) 6. Right handlebar switches (page 4-15) 7.

  • Page 19: Instrument And Control Functions

    INSTRUMENT AND CONTROL FUNCTIONS EAU10461 To lock the steering Main switch/steering lock The headlights come on automatically when the engine is started and stay on until the key is turned to “OFF”, even if the engine stalls. EAU10661 All electrical systems are off. The key can be removed.

  • Page 20: Indicator Lights And Warning Lights

    8. Neutral indicator light “ ” or if the warning light remains on, have 9. Fuel level warning light “ ” a Yamaha dealer check the electrical 10.Left turn signal indicator light “ ” circuit. EAU11030 Turn signal indicator lights “...
  • Page 21 2.5 seconds. If this occurs, cally switch on or off according to then go off for 3.0 seconds. If this oc- have a Yamaha dealer check the the coolant temperature in the ra- curs, have a Yamaha dealer check the vehicle. diator. vehicle. ●...
  • Page 22 INSTRUMENT AND CONTROL FUNCTIONS Display Conditions What to do Under 39 °C Message “Lo” is displayed. OK. Go ahead with riding. (Under 103 °F) 40–116 °C Coolant temperature is dis- OK. Go ahead with riding. (104–242 °F) played. Stop the vehicle and allow it to idle until Above 117 °C Coolant temperature flashes.
  • Page 23 “ON”, or if the and the lights by following the proce- This warning light comes on or flashes light remains on, have a Yamaha deal- dures under “Resetting” on page 4-19. if a problem is detected in the electrical er check the electrical circuit.

  • Page 24: Multi-Function Meter Unit

    INSTRUMENT AND CONTROL FUNCTIONS ● EAU51833 settings while riding can distract the a self-diagnosis device Multi-function meter unit operator and increase the risk of an ● a display brightness and shift tim- accident. ing indicator light control mode multi-function meter unit equipped with the following: ●...
  • Page 25 INSTRUMENT AND CONTROL FUNCTIONS The electric tachometer allows the rider To set the clock 3. Push the “SELECT” button again to monitor the engine speed and keep it 1. Push the “SELECT” button and to reset the stopwatch. within the ideal power range. “RESET”...
  • Page 26 INSTRUMENT AND CONTROL FUNCTIONS Split time history cancel currently selected mode, and then repeat step 1 to ● Reverse chronological order select the desired mode. mode: The split times are shown ● To reset all the recorded times for from the latest to earliest (i.e., L1, the selected split time history, L2, L3, L4).
  • Page 27 INSTRUMENT AND CONTROL FUNCTIONS Push the “SELECT” button to switch The instantaneous fuel consumption TRIP F → km/L, L/100 km or MPG → the display between the odometer display can be set to either “km/L”, mode “ODO”, the tripmeter modes AVE_ _._ km/L, AVE_ _._ L/100 km or “L/100 km”...
  • Page 28 INSTRUMENT AND CONTROL FUNCTIONS Average fuel consumption mode To switch between the average fuel This display shows the selected gear. consumption displays, push the “SE- The neutral position is indicated by “ ” LECT” button for one second when one and by the neutral indicator light.
  • Page 29 INSTRUMENT AND CONTROL FUNCTIONS ● Coolant temperature display Air intake temperature display When the key is turned to “ON”, the coolant temperature is auto- matically displayed, even if the air intake temperature was displayed prior to turning the key to “OFF”. ●...
  • Page 30 This function allows you to se- 4. Brightness level display Yamaha dealer check the vehicle. lect the engine speed at which This mode allows you to make changes the indicator light is activated.
  • Page 31 INSTRUMENT AND CONTROL FUNCTIONS This function allows you to se- 5. Push the “SELECT” button to con- 2. Push the “SELECT” button to con- lect the engine speed at which firm the selected brightness level. firm the selected indicator light ac- the indicator light is deactivat- The control mode changes to the tivity.

  • Page 32: D-Mode (Drive Mode)

    INSTRUMENT AND CONTROL FUNCTIONS To set the shift timing indicator light de- To adjust the shift timing indicator light EAU47632 D-mode (drive mode) activation function brightness D-mode is an electronically controlled 1. Push the “RESET” button to select engine performance system with three the desired indicator light bright- ●...

  • Page 33: Handlebar Switches

    INSTRUMENT AND CONTROL FUNCTIONS This mode allows the rider to enjoy EAU1234B Right Handlebar switches smooth and sporty drivability from the low-speed range to the high-speed Left range. Mode “A” Mode “A” offers a sportier engine re- sponse in the low- to mid-speed range compared to mode “STD”.

  • Page 34: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS EAU12500 EAU41700 EAU12820 Clutch lever Horn switch “ ” The engine trouble warning light will Press this switch to sound the horn. come on when the key is turned to “ON” and the start switch is pushed, but this EAU51841 does not indicate a malfunction.

  • Page 35: Shift Pedal

    INSTRUMENT AND CONTROL FUNCTIONS EAU12871 EAU33853 be sure to set it by aligning a groove on Shift pedal Brake lever the adjusting knob with the “ ” mark on the brake lever. 1. Shift pedal 1. Brake lever 2. Brake lever position adjusting knob The shift pedal is located on the left 3.

  • Page 36: Brake Pedal

    INSTRUMENT AND CONTROL FUNCTIONS EAU12941 EAU51861 Brake pedal Traction control system ● The traction control may engage The traction control system helps main- when the vehicle travels over a tain traction when accelerating. If sen- bump. sors detect that the rear wheel is ●...
  • Page 37 INSTRUMENT AND CONTROL FUNCTIONS ● “TCS” modes 2 through 6 provide Setting the traction control system for more traction control system EWA16070 WARNING assist. Mode 6 provides the most traction control system assist. Changing settings while riding can ● “TCS OFF” mode turns the traction distract the operator.

  • Page 38: Fuel Tank Cap

    1/4 turn clockwise. The lock will be re- still be ridden; however, have a leased and the fuel tank cap can be Yamaha dealer check the motorcycle opened. as soon as possible. ECA17731...

  • Page 39: Fuel

    INSTRUMENT AND CONTROL FUNCTIONS EAU13221 Fuel The fuel tank cap cannot be closed un- Make sure there is sufficient gasoline in less the key is in the lock. In addition, the tank. the key cannot be removed if the cap is EWA10881 WARNING not properly closed and locked.

  • Page 40: Fuel Tank Breather Hose And Overflow Hose

    ● Check each hose for cracks or damage, and replace if damaged. Your Yamaha engine has been de- ● Make sure that the end of each signed to use premium unleaded gaso- hose is not blocked, and clean if line with a pump octane number necessary.

  • Page 41: Catalytic Converter

    INSTRUMENT AND CONTROL FUNCTIONS EAU13433 ECA10701 EAU47271 Catalytic converter Seats NOTICE This model is equipped with a catalytic Use only unleaded gasoline. The use converter in the exhaust system. Passenger seat of leaded gasoline will cause unre- EWA10862 pairable damage to the catalytic WARNING To remove the passenger seat converter.
  • Page 42 INSTRUMENT AND CONTROL FUNCTIONS 1. Projection 1. Bolt 1. Projection 2. Seat holder 2. Seat holder 2. Remove the key. 2. Install the bolts with the hexagon wrench. Rider seat 3. Insert the hexagon wrench back into its holder on the passenger To remove the rider seat seat.

  • Page 43: Helmet Holder

    INSTRUMENT AND CONTROL FUNCTIONS EAU47530 EAU14463 Helmet holder Storage compartment To release the helmet from the hel- 1. Helmet holder 1. Storage compartment met holder Remove the passenger seat, remove The helmet holder is located on the bot- The storage compartment is located the helmet from the helmet holder, and tom of the passenger seat.

  • Page 44: Rider Footrest Position

    Have a Yamaha dealer ad- spaces. Fold the mirrors back to their just the position of the rider footrests. original position before riding.

  • Page 45: Adjusting The Front Fork

    INSTRUMENT AND CONTROL FUNCTIONS EAU47621 load thereby soften Spring preload setting: Adjusting the front fork suspension, turn the adjusting bolt on Minimum (soft): EWA14670 each fork leg in direction (b). WARNING Standard: Always adjust the spring preload on Maximum (hard): both fork legs equally, otherwise poor handling and loss of stability may result.
  • Page 46 INSTRUMENT AND CONTROL FUNCTIONS pression damping force and thereby soften the compression damping, turn Although the total number of clicks of a the adjusting screw in direction (b). damping force adjusting mechanism may not exactly match the above spec- Be sure to perform this adjustment on ifications due to small differences in the left front fork leg.

  • Page 47: Adjusting The Shock Absorber Assembly

    INSTRUMENT AND CONTROL FUNCTIONS EAU51890 Adjusting the shock absorber assembly This shock absorber assembly is equipped with a spring preload adjust- ing screw, a rebound damping force adjusting screw, a compression damp- ing force adjusting bolt (for fast com- pression damping) and a compression damping force adjusting bolt (for slow 1.
  • Page 48 INSTRUMENT AND CONTROL FUNCTIONS Compression damping force Compression damping setting (for fast compression damping): To obtain a precise adjustment, it is ad- Minimum (soft): visable to check the actual total number 4 turn(s) in direction (b)* of clicks or turns of each damping force Standard: adjusting mechanism.

  • Page 49: Luggage Strap Holders

    The sidestand is located on the left side sembly yourself. Take the shock of the frame. Raise the sidestand or absorber assembly to a Yamaha lower it with your foot while holding the dealer for any service. vehicle upright.

  • Page 50: Ignition Circuit Cut-Off System

    INSTRUMENT AND CONTROL FUNCTIONS this system regularly and have a EAU44892 Ignition circuit cut-off system Yamaha dealer repair it if it does not The ignition circuit cut-off system (com- function properly. prising the sidestand switch, clutch switch and neutral switch) has the fol- lowing functions.
  • Page 51 INSTRUMENT AND CONTROL FUNCTIONS WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the engine stop switch is set to “ ”. dealer check the system before riding.

  • Page 52: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 7-15 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 53 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 7-19, 7-29 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 7-29 •...
  • Page 54 • Tighten if necessary. Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 4-31 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 55: Operation And Important Riding Points

    ● a lean angle sensor to stop the en- understand, ask your Yamaha dealer. ● The transmission is in the neutral gine in case of a turnover. In this EWA10271 position.

  • Page 56: Shifting

    The neutral indicator quate lubrication may damage light should come on. If not, ask a the transmission. 1. Shift pedal Yamaha dealer to check the elec- 2. Neutral position ● Always use the clutch while trical circuit. changing gears to avoid damag- Shifting gears lets you control the 3.

  • Page 57: Engine Break-In

    OPERATION AND IMPORTANT RIDING POINTS 4. At the recommended shift points 3. Shift the transmission into the neu- EAU16841 Engine break-in shown in the following table, close tral position when the motorcycle There is never a more important period the throttle, and at the same time, is almost completely stopped.

  • Page 58: Parking

    Yamaha dealer check the vehi- touch them and be burned. cle. ● Do not park on a slope or on soft...

  • Page 59: Periodic Maintenance And Adjustment

    – possibly leading to pending on the weather, terrain, geo- that is certified (if applicable). Yamaha death. See page 2-3 for more in- graphical location, and individual use, dealers are trained and equipped to...

  • Page 60: Owner's Tool Kit

    If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 61: Periodic Maintenance Chart For The Emission Control System

    From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months. ● Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer perform the service. EAU17601 Periodic maintenance chart for the emission control system...
  • Page 62 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months Evaporative emis-...

  • Page 63: General Maintenance And Lubrication Chart

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU32188 General maintenance and lubrication chart INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months...
  • Page 64 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...
  • Page 65 • Change coolant. Front and rear brake √ √ √ √ √ √ 27 * • Check operation. switches • Apply Yamaha chain and cable √ √ √ √ √ √ 28 * Control cables lube or engine oil thoroughly.
  • Page 66 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...

  • Page 67: Removing And Installing Cowlings

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU18781 Removing and installing cowl- ings The cowlings shown need to be re- moved to perform some of the mainte- nance jobs described in this chapter. Refer to this section each time a cowl- ing needs to be removed and installed. 1.
  • Page 68 PERIODIC MAINTENANCE AND ADJUSTMENT 1. Turn signal light lead coupler 1. Slot 1. Cowling C 2. Projection 2. Quick fastener screw To install a cowling 3. Install the quick fasteners and the 3. Slide the cowling forward to un- 1. Connect the turn signal light lead quick fastener screws.

  • Page 69: Checking The Spark Plugs

    Do not attempt to diagnose such problems yourself. Instead, have a Yamaha dealer check the vehicle. If a spark plug shows signs of electrode erosion and excessive carbon or other deposits, it should be replaced.

  • Page 70: Canister (For California Only)

    PERIODIC MAINTENANCE AND ADJUSTMENT Before installing a spark plug, the spark EAU19681 Canister (for California only) plug gap should be measured with a If a torque wrench is not available when wire thickness gauge and, if necessary, installing a spark plug, a good estimate FUEL TANK ATMOSPHERE adjusted to specification.

  • Page 71: Engine Oil And Oil Filter Cartridge

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU47281 4. Remove the engine oil filler cap, Engine oil and oil filter car- the engine oil drain bolt and its tridge gasket to drain the oil from the The engine oil level should be checked crankcase.
  • Page 72 Make sure that the O-ring is properly 17 Nm (1.7 m·kgf, 12 ft·lbf) An oil filter wrench is available at a seated. Yamaha dealer. 8. Install the engine oil drain bolt and 7. Install the new oil filter cartridge its new gasket, and then tighten 6.

  • Page 73: Coolant

    NOTICE correct, immediately turn the engine on a cold engine since the level ● In order to prevent clutch slip- off and have a Yamaha dealer check varies with engine temperature. page (since the engine oil also the vehicle. ●...
  • Page 74 If water has been added to the coolant, have a Yamaha dealer check the anti- freeze content of the coolant as soon as possible, otherwise the effectiveness of the coolant will 1.
  • Page 75 PERIODIC MAINTENANCE AND ADJUSTMENT 4. Remove radiator cap. 6. Remove the coolant reservoir cov- 7. Remove the coolant reservoir by WARNING! Never attempt to re- er by removing the bolts, and then removing the bolts, and then turn move the radiator cap when the remove the coolant reservoir cap.

  • Page 76: Air Filter Element

    12. Pour the recommended coolant 16. Install the coolant reservoir cover Have a Yamaha dealer replace the air into the radiator until it is full. by installing the bolts. filter element.

  • Page 77: Checking The Engine Idling Speed

    To prevent this necessary, have it corrected by a from occurring, the valve clearance Yamaha dealer. must be adjusted by a Yamaha dealer at the intervals specified in the periodic Engine idling speed: 1150–1250 r/min maintenance and lubrication chart.

  • Page 78: Tires

    Maximum load*: vere injury or death from loss of tact a Yamaha dealer immediately and 189 kg (417 lb) control. have the tire replaced. * Total weight of rider, passenger, car- ●...
  • Page 79 Tires age, even if they have not been characteristics. model by Yamaha Motor Co., Ltd. used or have only been used occasion- ally. Cracking of the tread and sidewall rubber, sometimes accompanied by carcass deformation, is an evidence of ageing.

  • Page 80: Cast Wheels

    Manufacturer/model: er damage before each ride. If any DUNLOP/Qualifier II damage is found, have a Yamaha FRONT and REAR: Tire air valve: dealer replace the wheel. Do not TR412 attempt even the smallest repair to Valve core: the wheel.

  • Page 81: Adjusting The Clutch Lever Free Play

    The clutch lever free play should mea- brake lever end. If there is free play, (b). sure 10.0–15.0 mm (0.39–0.59 in) as have a Yamaha dealer inspect the shown. Periodically check the clutch le- brake system. ver free play and, if necessary, adjust it...

  • Page 82: Brake Light Switches

    1. Brake pad wear indicator groove by a Yamaha dealer. The front brake calipers are equipped Turn the rear brake light switch adjust- with two sets of brake pads.

  • Page 83: Checking The Brake Fluid Level

    EAU22581 Rear brake Checking the brake fluid level have a Yamaha dealer replace the Before riding, check that the brake fluid brake pads as a set. is above the minimum level mark. Check the brake fluid level with the top...

  • Page 84: Changing The Brake Fluid

    EAU22732 Changing the brake fluid id; otherwise, the rubber seals Yamaha dealer check the cause before Have a Yamaha dealer change the may deteriorate, causing leak- further riding. brake fluid at the intervals specified in age.

  • Page 85: Drive Chain Slack

    2. Shift the transmission into the neu- 1 2 3 4 To adjust the drive chain slack tral position. Consult a Yamaha dealer before ad- 3. Measure the drive chain slack as justing the drive chain slack. shown. 1. Loosen the axle nut and the lock- nut on each side of the swingarm.

  • Page 86: Cleaning And Lubricating The Drive Chain

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU23025 may contain substances that Tightening torques: Cleaning and lubricating the could damage O-rings. Axle nut: drive chain 150 Nm (15 m·kgf, 108 ft·lbf) [ECA11111] The drive chain must be cleaned and Locknut: 16 Nm (1.6 m·kgf, 12 ft·lbf) lubricated at the intervals specified in the periodic maintenance and lubrica- 4.

  • Page 87: Checking And Lubricating The Cables

    Yamaha dealer at the intervals speci- bricated if necessary. ed if necessary. If a cable is damaged fied in the periodic maintenance chart.

  • Page 88: Checking And Lubricating The Brake And Clutch Levers

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU23143 Recommended lubricant: Recommended lubricants: Checking and lubricating the Lithium-soap-based grease Brake lever: brake and clutch levers Silicone grease The operation of the brake and clutch Clutch lever: Lithium-soap-based grease levers should be checked before each ride, and the lever pivots should be lu- bricated if necessary.

  • Page 89: Checking And Lubricating The Sidestand

    The swingarm pivots must be lubricat- face and hold it in an upright posi- be checked before each ride, and the ed by a Yamaha dealer at the intervals tion. WARNING! To avoid injury, sidestand pivot and metal-to-metal specified in the periodic maintenance...

  • Page 90: Checking The Steering

    Yamaha dealer check or re- [EWA10751] tion chart. If there is play in the wheel 2. Hold the lower ends of the front pair it.

  • Page 91: Battery

    6. Negative battery lead (black) To charge the battery • EYES: Flush with water for 15 Have a Yamaha dealer charge the bat- minutes and seek prompt The battery is located under the rider tery as soon as possible if it seems to medical attention.

  • Page 92: Replacing The Fuses

    PERIODIC MAINTENANCE AND ADJUSTMENT ECA16521 nect the positive lead before EAU49823 Replacing the fuses NOTICE connecting the negative lead. The main fuse, the fuel injection system To charge a VRLA (Valve Regulated [ECA16840] fuse, and the fuse boxes, which contain 4.
  • Page 93 4. If the fuse immediately blows fuse, remove the starter relay cover by avoid causing extensive dam- again, have a Yamaha dealer age to the electrical system and pulling it upward. check the electrical system. possibly a fire.

  • Page 94: Replacing A Headlight Bulb

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU39013 Replacing a headlight bulb This model is equipped with halogen bulb headlights. If a headlight bulb burns out, replace it as follows. ECA10650 NOTICE Take care not to damage the follow- ing parts: ● Headlight bulb 1.

  • Page 95: Tail/Brake Light

    1. Remove the turn signal light unit 7. Have a Yamaha dealer adjust the If the tail/brake light does not come on, by removing the screw. headlight beam if necessary. have a Yamaha dealer check it.

  • Page 96: Replacing The License Plate Light Bulb

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU24313 Replacing the license plate light bulb 1. Remove the license plate light unit by removing the screws. 1. Turn signal light bulb socket 1. License plate light bulb 2. License plate light bulb socket 3. Remove the burnt-out bulb by pull- 3.

  • Page 97: Auxiliary Light

    1. Stabilize the rear of the motorcycle If the auxiliary light does not come on, by using a motorcycle stand or, if have a Yamaha dealer check it. an additional motorcycle stand is not available, by placing a jack un- der the frame in front of the rear wheel.

  • Page 98: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 99: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 100 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 101: Motorcycle Care And Storage

    Some models are equipped with ble. Rust and corrosion can develop matte colored finished parts. Be Cleaning sure to consult a Yamaha dealer for even if high-quality components are ECA15092 advice on what products to use be- used. A rusty exhaust pipe may go un-...
  • Page 102 MOTORCYCLE CARE AND STORAGE off any detergent residue using pounds for plastic may leave plenty of water, as it is harmful scratches on the windshield. Salt sprayed on roads in the winter may to plastic parts. Test the product on a small hid- remain well into spring.
  • Page 103 WARNING mufflers is normal and cannot be removed. ● Contaminants on the brakes or tires Consult a Yamaha dealer for ad- can cause loss of control. vice on what products to use. ● After cleaning Make sure that there is no oil or ●...

  • Page 104: Storage

    MOTORCYCLE CARE AND STORAGE EAU26203 2. Fill up the fuel tank and add fuel e. Remove the spark plug caps Storage stabilizer (if available) to prevent from the spark plugs, and then the fuel tank from rusting and the install the spark plugs and the Short-term fuel from deteriorating.
  • Page 105 MOTORCYCLE CARE AND STORAGE Make any necessary repairs before storing the motorcycle.

  • Page 106: Specifications

    SPECIFICATIONS Dimensions: Engine oil: Fuel: Overall length: Recommended brand: Recommended fuel: 2070 mm (81.5 in) YAMALUBE Premium unleaded gasoline only Overall width: Type: Fuel tank capacity: 715 mm (28.1 in) SAE 10W-40, 10W-50, 15W-40, 20W-40 or 18.0 L (4.76 US gal, 3.96 Imp.gal) Overall height: 20W-50 Fuel reserve amount:...
  • Page 107 SPECIFICATIONS 2nd: (Total weight of rider, passenger, cargo and Operation: 2.063 (33/16) accessories) Right hand operation 3rd: Tire air pressure (measured on cold Specified brake fluid: 1.762 (37/21) DOT 4 tires): 4th: Rear brake: Loading condition: 1.522 (35/23) Type: 0–90 kg (0–198 lb) 5th: Single disc brake Front:...
  • Page 108 SPECIFICATIONS Voltage, capacity: Shift timing indicator light: 12 V, 8.6 Ah Headlight: Traction control system indicator/warning light: Bulb type: Halogen bulb Bulb voltage, wattage × quantity: Fuses: Main fuse: Headlight: 12 V, 55.0 W × 2 50.0 A Headlight fuse: Tail/brake light: 20.0 A Signaling system fuse:...

  • Page 109: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1.
  • Page 110 This informa- cover. This label shows specifications tion will be needed when ordering related to exhaust emissions as re- spare parts from a Yamaha dealer. quired by federal law, state law and En- vironment Canada. 10-2...

  • Page 111: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Yamaha Motor Corporation, U.S.A. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 112: Motorcycle Noise Regulation

    CONSUMER INFORMATION EAU26560 Motorcycle noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new ve- hicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.

  • Page 113: Maintenance Record

    CONSUMER INFORMATION EAU26632 Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required.
  • Page 114 CONSUMER INFORMATION Maintenance Date of Servicing dealer Mileage Remarks interval service name and address 36000 mi (55000 km) or 54 months 40000 mi (61000 km) or 60 months 10-6...

  • Page 115: Yamaha Motor

    CONSUMER INFORMATION EAU26663 YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY Yamaha Motor Corporation, U.S.A. hereby warrants that CUSTOMER’S RESPONSIBILITY under this Engine new Yamaha motorcycles will be free from defects in warranty shall be to: Displacement Period...
  • Page 116 CUSTOMER SERVICE What costs are my responsibility during the warranty period? If your machine requires warranty service, you must take it to any authorized Yamaha The customer’s responsibility includes all costs of normal maintenance services, motorcycle dealer within the continental United States. Be sure to bring your warranty non-warranty repairs, accident and collision damages, and oil, oil filters, air filters, registration card or other valid proof of the original date of purchase.

  • Page 117: Yamaha Extended Service (Y.e.s.)

    This excellent Y.E.S. plan coverage is only available to dealer to see how comforting uninterrupted factory- Yamaha owners like you, and only while your Yamaha is still backed protection can be. within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts.
  • Page 118 Yamaha Limited Warranty expires. A special note: If visiting your dealer isn’t convenient, contact Yamaha with your Primary ID number (your frame number). We’ll be happy to help you get the Y.E.S. coverage you need.
  • Page 119 INDEX Engine stop switch ........4-16 Model label ........... 10-2 Engine trouble warning light ....4-5 Multi-function meter unit ......4-6 Air filter element........7-18 Auxiliary light ........7-39 Front and rear brake pads, checking ..7-24 Neutral indicator light ......4-2 Front fork, adjusting ......4-27 Noise regulation........
  • Page 120 INDEX Throttle grip and cable, checking and lubricating ..... 7-29 Throttle grip free play, checking.... 7-19 Tires ............7-20 Tool kit ............ 7-2 Traction control system......4-18 Traction control system indicator/warning light......4-5 Traction control system switch....4-16 Troubleshooting ........7-40 Troubleshooting charts ......
  • Page 121 Yamalube – Take care of your Yamaha with legendary Yamalube oils, lubricants, and care products. They’re formulated and approved by the toughest judges we know: the Yamaha engineering teams that know your Yamaha from the inside out.
  • Page 122 PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2012.07-0.3×1 CR...

This manual is also suitable for:

Yzfr1d 2012Yzfr1c 2012

Table of Contents
