Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
YZFR1E(C)
LIT-11626-27-40
2SG-28199-10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YZF R1 2013 and is the answer not in the manual?

Questions and answers

Related Manuals for Yamaha YZF R1 2013

Summary of Contents for Yamaha YZF R1 2013

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL YZFR1E(C) LIT-11626-27-40 2SG-28199-10...
  • Page 2 EAU10043 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 Yamaha has met these standards without reducing the performance or economy of operation of the motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention to the recommended maintenance schedules and operating instructions contained within this manual.
  • Page 4 IMPORTANT MANUAL INFORMATION EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10194 YZFR1E(C) OWNER’S MANUAL ©2013 by Yamaha Motor Corporation, U.S.A. 1st edition, June 2013 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS LOCATION OF IMPORTANT Rider footrest position ....4-27 Air filter element......7-18 LABELS ..........1-1 Rear view mirrors ......4-27 Checking the engine idling Adjusting the front fork ....4-27 speed ........7-19 SAFETY INFORMATION ....2-1 Adjusting the shock absorber Checking the throttle grip free assembly........4-29 play..........
  • Page 7 CORPORATION, U.S.A. STREET Checking the front fork....7-31 AND ENDURO MOTORCYCLE Checking the steering ....7-32 LIMITED WARRANTY....10-7 Checking the wheel bearings ..7-33 YAMAHA EXTENDED SERVICE Battery ...........7-33 (Y.E.S.)........10-9 Replacing the fuses.......7-35 Replacing a headlight bulb....7-36 Tail/brake light.......7-37 Replacing a turn signal light bulb ..........7-38...

  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 9 LOCATION OF IMPORTANT LABELS 3 California only NOTICE EMISSION HOSE ROUTING Cleaning with alkaline or acid cleaner, gasoline or FUEL TANK ATMOSPHERE solvent will damage windshield. Use neutral detergent. 4B5-2815K-00 CHARCOAL THROTTLE BODY CANISTER 14B-21686-00 2 California only VACUUM HOSE ROUTING PRESS.
  • Page 10 LOCATION OF IMPORTANT LABELS WARNING BEFORE YOU OPERATE THIS VEHICLE, READ Cold tire normal pressure should be set THE OWNER’S MANUAL AND ALL LABELS. as follows. ALWAYS WEAR AN APPROVED MOTORCYCLE Up to 90 kg (198 lbs) load HELMET, eye protection, and protective clothing. : 250 kPa, {2.50 kgf/cm 36 psi...

  • Page 11: Safety Information

    SAFETY INFORMATION  Never operate a motorcycle with- pears to be very effective in reduc- EAU1028B out proper training or instruction. ing the chance of this type of Take a training course. Beginners accident. Be a Responsible Owner should receive training from a cer- Therefore: As the vehicle’s owner, you are re- tified instructor.
  • Page 12 SAFETY INFORMATION  Many accidents involve inexperi- • Always signal before turning or Protective Apparel enced operators. In fact, many op- changing lanes. Make sure that The majority of fatalities from motorcy- erators who have been involved in other motorists can see you. cle accidents are the result of head in- ...
  • Page 13 SAFETY INFORMATION  Do not run engine outdoors where Avoid Carbon Monoxide Poisoning When loading within this weight limit, All engine exhaust contains carbon engine exhaust can be drawn into keep the following in mind:  Cargo and accessory weight monoxide, a deadly gas.
  • Page 14 Yamaha accessories, which are avail- performed to your vehicle that change able only from a Yamaha dealer, have any of the vehicle’s design or operation should be kept to a minimum. been designed, tested, and approved characteristics can put you and others •...
  • Page 15 SAFETY INFORMATION  Check that the fuel cock (if operator and may limit control ability, therefore, such accesso- equipped) is in the “OFF” position ries are not recommended. and that there are no fuel leaks.  Use caution when adding electri- ...

  • Page 16: Description

    DESCRIPTION EAU10411 Left view 4,5,6 12 11 1. Front fork spring preload adjusting bolt (page 4-27) 8. Shock absorber assembly compression damping force adjusting bolt (for slow compression damping) (page 4-29) 2. Front fork compression damping force adjusting screw (page 4-27) 9.

  • Page 17: Right View

    DESCRIPTION EAU10421 Right view 1,2,3 4 1. Storage compartment (page 4-26) 9. Radiator cap (page 7-15) 2. Luggage strap holder (page 4-32) 10.Engine oil filler cap (page 7-13) 3. Helmet holder (page 4-25) 11.Engine oil level check window (page 7-13) 4.

  • Page 18: Controls And Instruments

    DESCRIPTION EAU10431 Controls and instruments 1. Clutch lever (page 4-17) 2. Left handlebar switches (page 4-15) 3. Main switch/steering lock (page 4-1) 4. Multi-function meter unit (page 4-6) 5. Front brake fluid reservoir (page 7-25) 6. Right handlebar switches (page 4-15) 7.

  • Page 19: Instrument And Control Functions

    INSTRUMENT AND CONTROL FUNCTIONS To lock the steering EAU10462 Main switch/steering lock The headlights come on automatically when the engine is started and stay on until the key is turned to “OFF”, even if the engine stalls. EAU10662 All electrical systems are off. The key can be removed.

  • Page 20: Indicator Lights And Warning Lights

    “ON”, 9. Fuel level warning light “ ” or if the warning light remains on, have 10.Left turn signal indicator light “ ” a Yamaha dealer check the electrical circuit. EAU11031 Turn signal indicator lights “ ” and “...
  • Page 21 Yamaha dealer check the electrical a Yamaha dealer check the electrical ing on a slope or during sudden circuit.
  • Page 22 INSTRUMENT AND CONTROL FUNCTIONS Display Conditions What to do Under 40 °C Message “Lo” is displayed. OK. Go ahead with riding. (Under 104 °F) 40–116 °C Coolant temperature is dis- OK. Go ahead with riding. (104–242 °F) played. Coolant temperature flash- Above 116 °C Stop the engine and allow it to cool.
  • Page 23 “ON”, or if the and the lights by following the proce- This warning light comes on or flashes light remains on, have a Yamaha dealer dures under “Resetting” on page 4-20. if a problem is detected in the electrical check the electrical circuit.

  • Page 24: Multi-Function Meter Unit

    INSTRUMENT AND CONTROL FUNCTIONS  a self-diagnosis device settings while riding can distract the EAU51835 Multi-function meter unit  a display brightness and shift tim- operator and increase the risk of an ing indicator light control mode accident. multi-function meter unit ...
  • Page 25 INSTRUMENT AND CONTROL FUNCTIONS Tachometer Clock and stopwatch modes To display the stopwatch To change the display to the stop- watch mode, push the “SELECT” but- ton and “RESET” button together. To change the display back to the clock mode, push the “SELECT” button and “RESET”...
  • Page 26 INSTRUMENT AND CONTROL FUNCTIONS 3. Push the start switch “ ” or “RE- Push the “SELECT” button again SET” button to display the final to select the speed mode; “F-20”  To switch between the reverse split time or push the “SELECT” displays on the stopwatch.
  • Page 27 INSTRUMENT AND CONTROL FUNCTIONS Odometer, tripmeter, instantaneous If you do not reset the fuel reserve trip- ODO → TRIP 1 → TRIP 2 → km/L, fuel consumption and average fuel meter manually, it resets itself auto- L/100 km or MPG → AVE_ _._ km/L, matically and the display returns to the consumption modes AVE_ _._ L/100 km or AVE_ _._ MPG →...
  • Page 28 INSTRUMENT AND CONTROL FUNCTIONS  “MPG”: The distance that can be This display shows the average fuel Transmission gear display traveled on 1.0 US gal of fuel un- consumption since it was last reset.  “AVE_ _._ km/L”: The average dis- der the current riding conditions is shown.
  • Page 29 INSTRUMENT AND CONTROL FUNCTIONS This display indicates which drive ECA10022 NOTICE mode has been selected: “STD”, “A” or  Even if the air intake temperature “B”. For more details on the modes Do not continue to operate the en- is set to be displayed, the coolant and on how to select them, refer to gine if it is overheating.
  • Page 30 If the display indicates any error codes, 3. Brightness adjustable displays note the code number, and then have 4. Brightness level display a Yamaha dealer check the vehicle. This mode allows you to make chang- es to five settings by performing the following steps.
  • Page 31 INSTRUMENT AND CONTROL FUNCTIONS 3. Turn the key to “ON”, and then re- This function allows you to se- 5. Push the “SELECT” button to con- lease the “SELECT” button after lect the engine speed at which firm the selected brightness level. five seconds.
  • Page 32 INSTRUMENT AND CONTROL FUNCTIONS 2. Push the “SELECT” button to con- To set the shift timing indicator light To adjust the shift timing indicator light firm the selected indicator light ac- deactivation function brightness tivity. The control mode changes 1. Push the “RESET” button to select to the shift timing indicator light the desired indicator light bright- ...

  • Page 33: D-Mode (Drive Mode)

    INSTRUMENT AND CONTROL FUNCTIONS This mode allows the rider to enjoy EAU47633 EAU1234F D-mode (drive mode) Handlebar switches smooth and sporty drivability from the D-mode is an electronically controlled low-speed range to the high-speed Left engine performance system with three range.
  • Page 34 INSTRUMENT AND CONTROL FUNCTIONS Right EAU12501 EAU41701 Horn switch “ ” The engine trouble warning light will Press this switch to sound the horn. come on when the key is turned to “ON” and the start switch is pushed, but this does not indicate a malfunc- EAU51842 Traction control system switch tion.

  • Page 35: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS EAU12821 EAU12872 EAU33854 Clutch lever Shift pedal Brake lever 1. Clutch lever 1. Shift pedal 1. Brake lever 2. Brake lever position adjusting knob The clutch lever is located at the left The shift pedal is located on the left 3.

  • Page 36: Brake Pedal

    INSTRUMENT AND CONTROL FUNCTIONS be sure to set it by aligning a groove on EAU12942 EAU51862 Brake pedal Traction control system the adjusting knob with the “ ” mark The traction control system helps on the brake lever. maintain traction when accelerating. If sensors detect that the rear wheel is starting to slip (uncontrolled spinning), the traction control system assists by...
  • Page 37 INSTRUMENT AND CONTROL FUNCTIONS  “TCS” modes 2 through 6 provide Setting the traction control system for more traction control system EWA16071  The traction control may engage WARNING assist. Mode 6 provides the most when the vehicle travels over a traction control system assist.
  • Page 38 1. Front wheel sensor rotor engine trouble warning light still remain 2. Front wheel sensor on after resetting, the motorcycle may still be ridden; however, have a Yamaha dealer check the motorcycle as soon as possible. ECA17732 1. Traction control system switch “TCS” NOTICE ...

  • Page 39: Fuel Tank Cap

    INSTRUMENT AND CONTROL FUNCTIONS EAU13075 EAU13222 Fuel tank cap Fuel The fuel tank cap cannot be closed un- Make sure there is sufficient gasoline in less the key is in the lock. In addition, the tank. the key cannot be removed if the cap is EWA10882 WARNING not properly closed and locked.
  • Page 40 WARNING as well as to the exhaust system. Gasoline is poisonous and can Your Yamaha engine has been de- cause injury or death. Handle gaso- signed to use premium unleaded gas- line with care. Never siphon gasoline oline with a pump octane number by mouth.

  • Page 41: Fuel Tank Breather Hose And Overflow Hose

    INSTRUMENT AND CONTROL FUNCTIONS  Make sure that the end of each EAU58150 EAU13434 Fuel tank breather hose and Catalytic converter hose is positioned outside of the overflow hose This model is equipped with a catalytic cowling. converter in the exhaust system. ...

  • Page 42: Seats

    INSTRUMENT AND CONTROL FUNCTIONS ECA10702 EAU47272 Seats NOTICE Use only unleaded gasoline. The use Passenger seat of leaded gasoline will cause unre- pairable damage to the catalytic To remove the passenger seat converter. 1. Insert the key into the seat lock, and then turn it clockwise.

  • Page 43: Helmet Holder

    INSTRUMENT AND CONTROL FUNCTIONS EAU47531 Helmet holder 1. Bolt 1. Projection 2. Seat holder 1. Helmet holder 2. Install the bolts with the hexagon The helmet holder is located on the wrench. bottom of the passenger seat. 3. Insert the hexagon wrench back into its holder on the passenger To secure a helmet to the helmet seat.

  • Page 44: Storage Compartment

    INSTRUMENT AND CONTROL FUNCTIONS  Do not exceed the maximum EAU14464 Storage compartment load of 189 kg (417 lb) for the ve- hicle. To release the helmet from the hel- 1. Storage compartment met holder Remove the passenger seat, remove The storage compartment is located the helmet from the helmet holder, and under the passenger seat.

  • Page 45: Rider Footrest Position

    WARNING one of two positions to suit the rider’s can be folded forward for parking in preference. Have a Yamaha dealer ad- narrow spaces. Fold the mirrors back Always adjust the spring preload on just the position of the rider footrests.
  • Page 46 INSTRUMENT AND CONTROL FUNCTIONS load thereby soften Spring preload setting: suspension, turn the adjusting bolt on Minimum (soft): each fork leg in direction (b). Standard: Maximum (hard): Rebound damping force The rebound damping force is adjust- 1. Rebound damping force adjusting screw ed on the right front fork leg only.

  • Page 47: Adjusting The Shock Absorber Assembly

    INSTRUMENT AND CONTROL FUNCTIONS compression damping force and there- EAU51891 Adjusting the shock absorber by soften the compression damping, Although the total number of clicks of a assembly turn the adjusting screw in direction (b). damping force adjusting mechanism This shock absorber assembly is may not exactly match the above equipped with a spring preload adjust- Be sure to perform this adjustment on...
  • Page 48 INSTRUMENT AND CONTROL FUNCTIONS Compression damping force 1. Spring preload adjusting screw 1. Rebound damping force adjusting screw 1. Compression damping force adjusting bolt (for fast compression damping) Spring preload setting: Rebound damping setting: Minimum (soft): Minimum (soft): 2. Compression damping force adjusting bolt (for slow compression damping) 16 turn(s) in direction (b)* 20 click(s) in direction (b)*...
  • Page 49 To obtain a precise adjustment, it is sembly yourself. Take the shock Minimum (soft): advisable to check the actual total 4 turn(s) in direction (b)* absorber assembly to a Yamaha number of clicks or turns of each Standard: dealer for any service. damping force adjusting mechanism.

  • Page 50: Luggage Strap Holders

    EAU15183 EAU15306 Luggage strap holders Sidestand Yamaha dealer repair it if it does not The sidestand is located on the left function properly. side of the frame. Raise the sidestand or lower it with your foot while holding the vehicle upright.

  • Page 51: Ignition Circuit Cut-Off System

    INSTRUMENT AND CONTROL FUNCTIONS EAU44893 Ignition circuit cut-off system The ignition circuit cut-off system (comprising the sidestand switch, clutch switch and neutral switch) has the following functions.  It prevents starting when the transmission is in gear and the sidestand is up, but the clutch le- ver is not pulled.
  • Page 52 INSTRUMENT AND CONTROL FUNCTIONS WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the engine stop switch is set to “ ”. dealer check the system before riding.

  • Page 53: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 7-15 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 54 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 7-19, 7-29 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate ca- ble and grip housing. • Make sure that operation is smooth. Control cables 7-29 •...
  • Page 55 • Tighten if necessary. Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 4-32 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 56: Operation And Important Riding Points

     a lean angle sensor to stop the en-  The transmission is in the neutral understand, ask your Yamaha dealer. gine in case of a turnover. In this EWA10272 position.

  • Page 57: Shifting

    The neutral indi- quate lubrication may damage cator light should come on. If not, the transmission. 1. Shift pedal ask a Yamaha dealer to check the  Always use the clutch while 2. Neutral position electrical circuit. changing gears to avoid dam- Shifting gears lets you control the 3.

  • Page 58: Engine Break-In

    OPERATION AND IMPORTANT RIDING POINTS 4. At the recommended shift points 3. Shift the transmission into the EAU16842 Engine break-in shown in the following table, close neutral position when the motor- There is never a more important period the throttle, and at the same time, cycle almost completely...

  • Page 59: Parking

    Yamaha dealer check the vehi- touch them and be burned. cle.  Do not park on a slope or on soft...

  • Page 60: Periodic Maintenance And Adjustment

    To avoid possible burns, let tivities incorrectly may increase brake components cool before your risk of injury or death during touching them. service or while using the vehicle. If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service.

  • Page 61: Owner's Tool Kit

    If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 62: Periodic Maintenance Chart For The Emission Control System

     From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months.  Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer perform the ser- vice.
  • Page 63 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...

  • Page 64: General Maintenance And Lubrication Chart

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU32189 General maintenance and lubrication chart INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months...
  • Page 65 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...
  • Page 66 • Change coolant. Front and rear √ √ √ √ √ √ 27 * • Check operation. brake switches • Apply Yamaha cable lubricant or √ √ √ √ √ √ 28 * Control cables other suitable cable lubricant thoroughly.
  • Page 67 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...

  • Page 68: Removing And Installing Cowlings

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU18782 Removing and installing cowl- ings The cowlings shown need to be re- moved to perform some of the mainte- nance jobs described in this chapter. Refer to this section each time a cowl- ing needs to be removed and installed. 1.
  • Page 69 PERIODIC MAINTENANCE AND ADJUSTMENT 1. Turn signal light lead coupler 1. Slot 1. Cowling C 2. Projection 2. Quick fastener screw To install a cowling 3. Install the quick fasteners and the 3. Slide the cowling forward to un- 1. Connect the turn signal light lead quick fastener screws.

  • Page 70: Checking The Spark Plugs

    3. Install cowling A or B. checked periodically, preferably by a Yamaha dealer. Since heat and depos- its will cause any spark plug to slowly erode, they should be removed and checked in accordance with the peri- odic maintenance and lubrication chart.

  • Page 71: Canister (For California Only)

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU19682 Specified spark plug: Canister (for California only) NGK/LMAR9E-J If a torque wrench is not available when installing a spark plug, a good FUEL TANK ATMOSPHERE Before installing a spark plug, the estimate of the correct torque is 1/4– spark plug gap should be measured 1/2 turn past finger tight.

  • Page 72: Engine Oil And Oil Filter Cartridge

    PERIODIC MAINTENANCE AND ADJUSTMENT 4. Remove the engine oil filler cap, EAU47282 Engine oil and oil filter car- the engine oil drain bolt and its tridge gasket to drain the oil from the The engine oil level should be checked crankcase.
  • Page 73 Make sure that the O-ring is properly 17 Nm (1.7 m·kgf, 12 ft·lbf) An oil filter wrench is available at a seated. Yamaha dealer. 8. Install the engine oil drain bolt and 7. Install the new oil filter cartridge its new gasket, and then tighten 6.

  • Page 74: Coolant

     In order to prevent clutch slip- off and have a Yamaha dealer check the level varies with engine tem- page (since the engine oil also the vehicle.
  • Page 75 If water has been added to the coolant, have a Yamaha dealer check the anti- freeze content of the coolant as soon as possible, otherwise the effectiveness of the coolant will 1.
  • Page 76 PERIODIC MAINTENANCE AND ADJUSTMENT 4. Remove radiator cap. 6. Remove the coolant reservoir cov- 7. Remove the coolant reservoir by WARNING! Never attempt to re- er by removing the bolts, and then removing the bolts, and then turn remove the coolant reservoir cap. the reservoir upside down to emp- move the radiator cap when the engine is hot.

  • Page 77: Air Filter Element

    12. Pour the recommended coolant 16. Install the coolant reservoir cover Have a Yamaha dealer replace the air into the radiator until it is full. by installing the bolts. filter element.

  • Page 78: Checking The Engine Idling Speed

    To prevent this necessary, have it corrected by a from occurring, the valve clearance Yamaha dealer. must be adjusted by a Yamaha dealer at the intervals specified in the periodic Engine idling speed: 1150–1250 r/min maintenance and lubrication chart.

  • Page 79: Tires

    290 kPa (2.90 kgf/cm², 42 psi) in it, or if the sidewall is cracked, con- proper tire pressure may cause se- Maximum load*: tact a Yamaha dealer immediately and vere injury or death from loss of 189 kg (417 lb) have the tire replaced.
  • Page 80 Tires age, even if they have not been characteristics. model by Yamaha Motor Co., Ltd. used or have only been used occasion- ally. Cracking of the tread and sidewall rubber, sometimes accompanied by carcass deformation, is an evidence of ageing.

  • Page 81: Cast Wheels

    DUNLOP/Qualifier II ride. If any damage is found, have FRONT and REAR: Tire air valve: a Yamaha dealer replace the TR412 wheel. Do not attempt even the Valve core: smallest repair to the wheel. A de-...

  • Page 82: Adjusting The Clutch Lever Free Play

    The clutch lever free play should mea- brake lever end. If there is free play, rection (b). sure 10.0–15.0 mm (0.39–0.59 in) as have a Yamaha dealer inspect the shown. Periodically check the clutch brake system. lever free play and, if necessary, adjust...

  • Page 83: Brake Light Switches

    1. Brake pad wear indicator groove adjusted by a Yamaha dealer. The front brake calipers are equipped Turn the rear brake light switch adjust- with two sets of brake pads.

  • Page 84: Checking The Brake Fluid Level

    Rear brake EAU22582 Checking the brake fluid level most appears, have a Yamaha dealer Before riding, check that the brake fluid replace the brake pads as a set. is above the minimum level mark.

  • Page 85: Changing The Brake Fluid

    EAU22733 Changing the brake fluid id; otherwise, the rubber seals Yamaha dealer check the cause before Have a Yamaha dealer change the further riding. may deteriorate, causing leak- brake fluid at the intervals specified in age.

  • Page 86: Drive Chain Slack

    2. Shift the transmission into the To adjust the drive chain slack neutral position. 1 2 3 4 Consult a Yamaha dealer before ad- 3. Measure the drive chain slack as justing the drive chain slack. shown. 1. Loosen the axle nut and the lock- nut on each side of the swingarm.

  • Page 87: Cleaning And Lubricating The Drive Chain

    PERIODIC MAINTENANCE AND ADJUSTMENT 3. Tighten the axle nut, then the lock- may contain substances that EAU23026 Cleaning and lubricating the nuts to their specified torques. could damage O-rings. drive chain [ECA11112] The drive chain must be cleaned and Tightening torques: Axle nut: lubricated at the intervals specified in 150 Nm (15 m·kgf, 108 ft·lbf)

  • Page 88: Checking And Lubricating The Cables

    Yamaha dealer at the intervals bricated if necessary. cated if necessary. If a cable is specified in the periodic maintenance...

  • Page 89: Checking And Lubricating The Brake And Clutch Levers

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU23144 Recommended lubricant: Recommended lubricants: Checking and lubricating the Lithium-soap-based grease Brake lever: brake and clutch levers Silicone grease The operation of the brake and clutch Clutch lever: Lithium-soap-based grease levers should be checked before each ride, and the lever pivots should be lu- bricated if necessary.

  • Page 90: Checking And Lubricating The Sidestand

    The swingarm pivots must be lubricat- face and hold it in an upright posi- be checked before each ride, and the ed by a Yamaha dealer at the intervals tion. WARNING! To avoid injury, sidestand pivot and metal-to-metal specified in the periodic maintenance...

  • Page 91: Checking The Steering

    If any damage is found or the front the vehicle so there is no danger fork does not operate smoothly, of it falling over. have a Yamaha dealer check or re- [EWA10752] 2. Hold the lower ends of the front pair it.

  • Page 92: Checking The Wheel Bearings

    6. Negative battery lead (black) • EYES: Flush with water for 15 smoothly, have a Yamaha dealer minutes and seek prompt The battery is located under the rider check the wheel bearings.
  • Page 93 “OFF”, then discon- To charge the battery nect the negative lead before Have a Yamaha dealer charge the bat- disconnecting the positive lead. tery as soon as possible if it seems to [ECA16303] have discharged.

  • Page 94: Replacing The Fuses

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU49825 Replacing the fuses The main fuse, the fuel injection sys- tem fuse, and the fuse boxes, which contain the fuses for the individual cir- cuits, are located under the rider seat. (See page 4-24.) 6 5 4 3 2 1 1.

  • Page 95: Replacing A Headlight Bulb

     Headlight lens 4. If the fuse immediately blows Do not affix any type of tinted again, have a Yamaha dealer film or stickers to the headlight check the electrical system. 1. Headlight bulb cover lens.

  • Page 96: Tail/Brake Light

    6. Install the headlight bulb cover by This model is equipped with an LED- turning it clockwise. type tail/brake light. 7. Have a Yamaha dealer adjust the If the tail/brake light does not come on, headlight beam if necessary. have a Yamaha dealer check it.

  • Page 97: Replacing A Turn Signal Light Bulb

    PERIODIC MAINTENANCE AND ADJUSTMENT 6. Install the turn signal light unit by EAU43006 Replacing a turn signal light installing the screw. NOTICE: Do bulb not overtighten the screw, oth- 1. Remove the turn signal light unit erwise the lens may break. by removing the screw.

  • Page 98: Replacing The License Plate Light Bulb

    If an auxiliary light does not come on, 5. Install the socket (together with 2. Screw have a Yamaha dealer check it. the bulb) by pushing it in. 2. Remove the license plate light 6. Install the license plate light unit by bulb socket (together with the installing the screws.

  • Page 99: Supporting The Motorcycle

    However, should your motorcycle To service the front wheel require any repair, take it to a Yamaha 1. Stabilize the rear of the motorcy- dealer, whose skilled technicians have cle by using a motorcycle stand...
  • Page 100 PERIODIC MAINTENANCE AND ADJUSTMENT heaters or furnaces. Gasoline or gasoline vapors can ignite or ex- plode, causing severe injury or prop- erty damage. 7-41...

  • Page 101: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 102 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended cool- ant as soon as possible.

  • Page 103: Motorcycle Care And Storage

    Some models are equipped with matte colored finished parts. Be ble. Rust and corrosion can develop Cleaning sure to consult a Yamaha dealer for even if high-quality components are ECA15093 NOTICE used. A rusty exhaust pipe may go un-...
  • Page 104 For additional during winter are extremely corrosive  For motorcycles equipped with cleaning, use Yamaha Windshield in combination with water, carry out Cleaner or another high-quality wind- a windshield: Do not use strong the following steps after each ride in shield cleaner.
  • Page 105 MOTORCYCLE CARE AND STORAGE  Note that the thermally induced using such cleaners, test an area of the EWA11132 WARNING windshield which does not affect your discoloring of the portion of the visibility and which cannot be easily exhaust pipe leading into the tita- Contaminants on the brakes or tires recognized.

  • Page 106: Storage

    2. Fill up the fuel tank and add fuel EAU26204 Storage stabilizer (if available) to prevent  Consult a Yamaha dealer for ad- the fuel tank from rusting and the vice on what products to use. Short-term fuel from deteriorating.
  • Page 107 MOTORCYCLE CARE AND STORAGE e. Remove the spark plug caps from the spark plugs, and then Make any necessary repairs before install the spark plugs and the storing the motorcycle. spark plug caps. 4. Lubricate all control cables and the pivoting points of all levers and pedals as well as of the side- stand/centerstand.

  • Page 108: Specifications

    SPECIFICATIONS Dimensions: Engine oil: Fuel: Overall length: Recommended brand: Recommended fuel: 2070 mm (81.5 in) YAMALUBE Premium unleaded gasoline (Gasohol (E10) Overall width: Type: acceptable) 715 mm (28.1 in) SAE 10W-40, 10W-50, 15W-40, 20W-40 or Fuel tank capacity: Overall height: 20W-50 18.0 L (4.76 US gal, 3.96 Imp.gal) 1130 mm (44.5 in)
  • Page 109 SPECIFICATIONS Gear ratio: Loading: Front brake: 1st: Maximum load: Type: 2.533 (38/15) 189 kg (417 lb) Dual disc brake 2nd: (Total weight of rider, passenger, cargo Operation: 2.063 (33/16) and accessories) Right hand operation 3rd: Tire air pressure (measured on cold Specified brake fluid: 1.762 (37/21) DOT 4...
  • Page 110 SPECIFICATIONS Battery: Coolant temperature warning light: Model: Engine trouble warning light: YTZ10S Voltage, capacity: Shift timing indicator light: 12 V, 8.6 Ah Headlight: Traction control system indicator/warning Bulb type: light: Halogen bulb Bulb voltage, wattage × quantity: Fuses: Headlight: 12 V, 55.0 W × 2 Main fuse: 50.0 A Tail/brake light:...

  • Page 111: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1.
  • Page 112 This infor- cover. This label shows specifications mation will be needed when ordering related to exhaust emissions as re- spare parts from a Yamaha dealer. quired by federal law, state law and En- vironment Canada. 10-2...

  • Page 113: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immedi- ately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Yamaha Motor Corporation, U.S.A. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 114: Motorcycle Noise Regulation

    CONSUMER INFORMATION EAU26561 Motorcycle noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new vehicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.

  • Page 115: Maintenance Record

    CONSUMER INFORMATION EAU26633 Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required.
  • Page 116 CONSUMER INFORMATION Maintenance Date of Servicing dealer Mileage Remarks interval service name and address 36000 mi (55000 km) or 54 months 40000 mi (61000 km) or 60 months 10-6...

  • Page 117: Yamaha Motor Corporation, U.s.a. Street And Enduro Motorcycle Limited Warranty

    CONSUMER INFORMATION EAU26664 YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY Yamaha Motor Corporation, U.S.A. hereby warrants that THE CUSTOMER’S RESPONSIBILITY under this Engine new Yamaha motorcycles will be free from defects in warranty shall be to: Displacement...
  • Page 118 CUSTOMER SERVICE What costs are my responsibility during the warranty period? If your machine requires warranty service, you must take it to any authorized Yamaha The customer’s responsibility includes all costs of normal maintenance services, motorcycle dealer within the continental United States. Be sure to bring your warranty non-warranty repairs, accident and collision damages, and oil, oil filters, air filters, registration card or other valid proof of the original date of purchase.

  • Page 119: Yamaha Extended Service (Y.e.s.)

    This excellent Y.E.S. plan coverage is only available to dealer to see how comforting uninterrupted factory- Yamaha owners like you, and only while your Yamaha is still backed protection can be. within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts.
  • Page 120 Yamaha Limited Warranty expires. A special note: If visiting your dealer isn’t convenient, contact Yamaha with your Primary ID number (your frame number). We’ll be happy to help you get the Y.E.S. coverage you need.
  • Page 121 INDEX Engine stop switch....... 4-16 Matte color, caution........ 8-1 Engine trouble warning light ....4-5 Model label ........... 10-2 Air filter element........7-18 Multi-function meter unit ......4-6 Auxiliary light ........7-39 Front and rear brake pads, checking ... 7-24 Front fork, adjusting ......
  • Page 122 INDEX Tail/brake light ........7-37 Throttle grip and cable, checking and lubricating ....7-29 Throttle grip free play, checking ...7-19 Tires ............7-20 Tool kit ............7-2 Traction control system ......4-18 Traction control system indicator/ warning light .........4-5 Traction control system switch.....4-16 Troubleshooting ........7-40 Troubleshooting charts......7-42 Turn signal indicator lights......4-2 Turn signal light bulb, replacing....7-38...
  • Page 123 Yamalube – Take care of your Yamaha with legendary Yamalube oils, lubricants, and care products. They’re formulated and approved by the toughest judges we know: the Yamaha engineering teams that know your Yamaha from the inside out.
  • Page 124 PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2013.07-0.9×1 CR...

This manual is also suitable for:

Yzfr1e(c)

Table of Contents

Save PDF
