Lift-Off Oven Door

The door is very heavy. Be careful when removing and lifting the door. Do not lift door by the handle.
To Remove the Door:
1. Fully open the oven door.
2. With thumb and forefinger, pull the hinge lock on
each hinge up to the unlocked position.
3. Firmly grasp both sides of the door at near the top.
4. Close door until the top of the door is approximately
3" from the range frame.
5. Lift door up and away from the range until both hinge
arms are clear of the slots in the range frame.
To Replace the Door:
1. Firmly grasp both sides of the door near the top.
2. With the door at the same angle as the removal
position, rest the notch in the bottom of the left hinge
arm on the bottom edge of the left hinge slot. The
notch in the hinge arm must be fully seated onto the
bottom of the slot. Repeat for the right side.
3. Fully open the door. If the door will not fully open,
the notches in the bottoms of the hinge arms are not
seated correctly onto the bottom edge of the slot. Lift
the door off the range and repeat Step 2.
4. Push the hinge locks down to the locked position
5. Close the oven door.
Lift-Off Oven Door
(on some models)
The oven door is removable for cleaning.
Do not lift the door by the handle. Make sure
the oven is completely cool.
To remove the door, open it to the special
stop position. Grasp firmly on each side and
lift the door straight up and off the hinges.
Do not place hands between the hinge
and the oven door frame.
To replace the door, make sure the hinges
are in the special stop position. Position
the slots in the bottom of the door squarely
over the hinges and slowly lower it over both
hinges.
To clean the inside of the door:
Do not allow excess water to run into
Pull hinge locks up to unlock
Notch
GEAppliances.ca
Removal position
Push hinge locks down to lock
17
