INSTRUCTION BOOK
FOR
MODEL 8282-1
TRANSIENT PULSE GENERATOR
REV. 1.0 DECEMBER 21, 1983
REV. 1.1 MAY 22, 1991
REV. 1.2 APRIL 13, 2021
10866 Chandler Blvd., North Hollywood CA 91601
(800) 952-5302 • (818) 755-1700 • FAX (818) 755-0078
www.solar-emc.com • sales@solar-emc.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 8282-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Solar Electronics 8282-1

Summary of Contents for Solar Electronics 8282-1

  • Page 1 INSTRUCTION BOOK MODEL 8282-1 TRANSIENT PULSE GENERATOR REV. 1.0 DECEMBER 21, 1983 REV. 1.1 MAY 22, 1991 REV. 1.2 APRIL 13, 2021 10866 Chandler Blvd., North Hollywood CA 91601 (800) 952-5302 • (818) 755-1700 • FAX (818) 755-0078 www.solar-emc.com • sales@solar-emc.com...

  • Page 2: Manual Revision History

    Apr. 13, 2021 Moved to pages ii and iii, “TABLE OF CONTENTS”. Added number to page iv, and replaced image in “FIGURE 1 MODEL 8282-1”, also added “FIGURE 2 MODEL 8282-1” to page iv. Added page v, “Preface” text. Added page vi, “CAUTION and SAFETY!” text.

  • Page 3: Table Of Contents

    Adjustment of the Bar-Graph Meter Adjustment of Repetition Rate and Line Sync Circuits 7.10 Check of the Single Pulse Feature 7.11 Check of Pulse Positioning with External Power to the Sync Circuit PARTS LOCATION PARTS LIST 10.0 SCHEMATIC ADDENDUM SOLAR ELECTRONICS COMPANY...

  • Page 4: Low-Voltage Power Supply

    TABLE OF CONTENTS Section Page No. FIGURE 1 MODEL 8282-1 Frontispiece FIGURE 2 LAYOUT OF FRONT PANEL PUSH BUTTONS FIGURE 3 TYPICAL WAVESHAPES FIGURE 4 TEST SETUP FOR PARALLEL INJECTION FIGURE 5 TEST SETUP FOR SERIES INJECTION FIGURE 6 PULSE POSITIONING ON OTHER A.C.
  • Page 5 FIGURE 1 MODEL 8282-1 FIGURE 2 MODEL 8282-1 SOLAR ELECTRONICS COMPANY...

  • Page 6: Notice To Users

    The Solar Model 8282-1 Transient Pulse Generator has no user serviceable components inside and will not work if the top cover is removed. This interlock is part of the safety system designed to prevent electric shock.

  • Page 7: Caution And Safety

    Some of the mechanical parts in the 0.15 µS function must settle to normal attitude before power is applied. If power is applied prematurely, these delicate parts may be damaged. Solar Electronics Company...

  • Page 8: Introduction

    “duration” of the spike. 2.0 APPLICATIONS The spike voltage output of the Model 8282-1 may be connected in parallel with a d.c. power line, or it can be connected in series with either an a.c. or d.c.

  • Page 9: Description

    3.0 DESCRIPTION The Model 8282-1 Transient Pulse Generator is a completely self-contained unit with more than sufficient output power to fully comply with the require- ments of all sections of MIL-STD-461B, Method CS06. The dimensions of the unit are 12.25"W x 8.70"H x 13"Deep. The unit weighs approximately 30 pounds.
  • Page 10 These include: a) Terminals for connecting to a synchronizing power source other than the 50 Hz or 60 Hz which serves the Model 8282-1. b) A three pin connector for cabling to remote controls.

  • Page 11: Specifications

    POWER CURRENT IN SERIES INJECTION MODE – Series output terminals can carry up to 50 amperes of current at power frequencies. POWER REQUIREMENTS – 115/230 volts, 50-400 Hz; 3 amperes at 115 volts, 1.5 amperes at 230 volts. SOLAR ELECTRONICS COMPANY...

  • Page 12: Operation

    5.1 GENERAL – The toggle switch on the rear of the unit must be in the INTERNAL position in all cases except when the power source to the EUT is not common to the 8282-1. This exception is described in Par. 5.4 and illustrated in Fig. 6.

  • Page 13: Interconnection For Series Injection

    The SERIES output terminals of the Model 8282-1 are capable of carrying up to 50 amperes power current, provided that large enough wires can be used with firm connections to the terminals. The wire hole in the terminals will accommodate a #12 A.W.G.

  • Page 14: Pulse Positioning

    EUT. If the line voltage to the EUT is greater than the voltage into the line cord of the Model 8282-1, add a step- down transformer at the points marked X in Fig. 6 to reduce the voltage applied to the rear terminals.

  • Page 15: Repetition Rate

    When the test plan requires both a positive and a negative spike, it is necessary to reverse the connections to the output terminals of the Model 8282-1 Spike Generator. 5.8 REMOTE TRIGGERING – In lieu of the panel button controls for repetition rate adjustment or phase shifting on a.c.
  • Page 16 25 p.p.s., the LED meter will not indicate the actual output level. b) With a remote switch supplying 24 volts d.c. to pins A and C, and with the S/P ENABLE button depressed, the spike can be triggered up to 50 p.p.s. in all three waveshapes. SOLAR ELECTRONICS COMPANY...

  • Page 17: Application Information

    SERIES terminals. The Type 7115-2 High Voltage Pulse Transformer can be used to step up the output voltage of the Model 8282-1 to as much as 15 kilovolts. The secondary of this SOLAR ELECTRONICS COMPANY...
  • Page 18 SERIES output terminals to provide a step- up of the spike amplitude into higher impedance loads. The com- bination of the 8282-1 and the 8527-2 enables adjustment of the spike amplitude up to 2000 volts into a 50 ohm resistive load.

  • Page 19: Maintenance And Calibration

    Adjust the voltage out of the autotransformer to exactly 115 volts or 230 volts as required. The correct voltage is indicated below the power connector on the rear panel of the Model 8282-1. Be sure to maintain the exact line voltage throughout these tests.

  • Page 20: Check Of Low Voltage Power Supply

    R5 and R6, on the left side as viewed from the front. USE EXTREME CAUTION IN PERFORMING THE FOLLOWING STEP, SINCE THE VOLTAGES ENCOUNTERED CAN BE DANGEROUS! 7.5.2 Connect the negative probe of the digital d.c. voltmeter to the black wire on R5. SOLAR ELECTRONICS COMPANY...

  • Page 21: Adjustment Of High Voltage To

    (2 µS/Div) and note the peak amplitude. If it is not 600 volts, adjust the tap on R8, the resistor located in step 7.7.1, to exactly 600 volts, peak, on the oscilloscope. SOLAR ELECTRONICS COMPANY...

  • Page 22: Adjustment Of The Bar-Graph Meter

    External Sync. Apply 115 or 230 volts 400 Hz to the EXTERNAL SYNC termi- nals on the rear panel and move the toggle switch down. Connect a small 400 Hz voltage (6 to 10 volts) to the external sync input of the oscilloscope. SOLAR ELECTRONICS COMPANY...

  • Page 23: Check Of The Single Pulse Feature

    Paragraph 7.9. Due to phase differences existing in the test setup, it is not possible to predict the exact knob position at which the spike will reach zero crossover on the a.c. sine wave. SOLAR ELECTRONICS COMPANY...

  • Page 24: Parts Location

    8.0 PARTS LOCATION SOLAR ELECTRONICS COMPANY...
  • Page 25 SOLAR ELECTRONICS COMPANY...
  • Page 26 SOLAR ELECTRONICS COMPANY...
  • Page 27 SOLAR ELECTRONICS COMPANY...
  • Page 28 SOLAR ELECTRONICS COMPANY...
  • Page 29 SOLAR ELECTRONICS COMPANY...
  • Page 30 SOLAR ELECTRONICS COMPANY...
  • Page 31 SOLAR ELECTRONICS COMPANY...

  • Page 32: Parts List

    9.0 PARTS LIST SOLAR ELECTRONICS COMPANY...
  • Page 33 Capacitor, .18 µF ± 10% 200V Met. Mylar Electrocube 230B1 B184J CR1,CR10,CR11, CR12,CR13,CR14, CR15,CR16 Diode Motorola IN4007 CR2,CR3 Rectifier Bridge Diodes Inc. DB-102 Deleted CR5,CR6,CR7, CR8,CR9,CR17, CR18,CR19 Diode Diodes Inc. J2 DS1 thru DS11 Lamp Sylvania No 327 SOLAR ELECTRONICS COMPANY...
  • Page 34 Resistor, 1.2K ohm ± 5% 5W Wirewound Ohmite 95J1 K2 Resistor, 4.7K ohm ± 5% 2W Carbon Allen-Bradley RCR42GF472J R16,R44 Resistor, 470 ohm ± 5% 5W Wirewound Ohmite 95J470 R17,R18 Resistor, 1.5 megohm ± 5% 1 W Carbon Allen-Bradley RCR32GF155J SOLAR ELECTRONICS COMPANY...
  • Page 35 Switch, 3 Station (2 Push-Lock/Release 4 Pole One Non-Lock 2 Pole) Switchcraft 67037-512 Switch, Toggle DPDT Arrowhart 81027CE Transformer, Variable for 115V unit Superior 10C for 230V unit Superior 12 Transformer Solar 828235 Transformer Solar 828234 Transformer, Pulse Solar 828236 Transformer Solar 828271 SOLAR ELECTRONICS COMPANY...
  • Page 36 Molex 22-23-2041 2 Terminal Header(3) Molex 22-23-2021 4 Socket Receptacle(2) Molex 22-01-2047 2 Socket Receptacle(3) Molex 22-01-2027 . Harness I Solar 828245 Harness II Solar 828246 Harness III Solar 828247 Harness IV Solar 828269 Instruction Manual Solar 828270 SOLAR ELECTRONICS COMPANY...
  • Page 37 OPTIONAL ACCESSORIES: Type 7115-2 Transient Pulse Transformer Steps up voltage to 15 KV. (Use with 7510-1 Spark Gap) Type 8282-1 Transient Pulse Transformer For 150 ampere loads Type 8525-1 Resistive Load 5 ohms, 5%, 2 watt Type 8527-2 Pulse Transformer...

  • Page 38: Schematic

    10.0 SCHEMATIC SOLAR ELECTRONICS COMPANY...

  • Page 41: Addendum

    Model 8282-1 Addendum Digital Display This Model 8282-1 features a Digital Display in place of horizontal bar graph meter. It still represents the level of the spike as it would appear across a five ohm load. The accuracy of the Digital Display is approximately 10%. The display is for reference only.
