TRENDnet TFC-110S40D3 Specifications

FEATURES
• Compliant with IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX, 100Base-FX Standards
• Provides Dip Switch for Fiber(FDX/HDX), UTP (Auto Negotiation/Manual), Speed(10/100M), LLR (Enable/Disable), LLCF
(Enable/Disable)
• Support LLCF (Link Loss Carry Forward, Link Pass Through)
• Supports LLR (Link Loss Return) for FX Port
• Hot Pluggable & Wall-Mountable
• Optional 19" System Chassis (TFC-1600) holds up to 16 Media Converters
• 5-year limited warranty
TEW-503PI (07-28-2005)
10/100Mbps TX to 100Base-FX Dual-
Wavelength Single-Mode Fiber Converter
TFC-110S40D3/D5
TFC-110S40D3 or TFC-110S40D5 Bi-Directional Single-Fiber
Media Converter transforms 10/100Base-TX UTP/STP media to
100Base-FX media and vice versa. The 10/100Base-TX Port Auto-
Negotiating 10 or 100Mbps connection speed with Auto-MDIX
media type, the fiber supports single-mode SC type connection.
This converter will give your Switch/Hub the ability to interface with
fiber connection over a distance up to 40 km.
fiber
TFC-110S40D3/D5
rev: 07. 1 9.2010
