Wireless Bridge II Serial™ Connector and Cable - Quick Guide
RS422 Typical Connection
RS485 Typical Connection
NOTE
The resistors on the Bridge II Serial side are termination resistors which form an active termination of
the RS485 line.
NOTE
Termination and biasing are inside the Bridge II Serial.
Page 2 of 2
© 2022 HMS Networks
SP3019 / 1.1 / 2022-02-23
