Summary of Contents for ASROCK 2U1G-B650

  • Page 2: Copyright Notice

    (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock Rack has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 3 • This product is not suitable for use with visual display work place devices according to §2 of the the German Ordinance for Work with Visual Display Units. • Only skilled person and Instructed person can remove the chassis covers to access the inside of the system. ASRock Rack’s Website: www.ASRockRack.com...

  • Page 4: Replaceable Batteries

    Replaceable Batteries CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS Warning When removal of the chassis lid required for servicing: - Turn off power and unplug any power cords/cables, and - Reinstall the chassis lid before restoring power.

  • Page 5: Table Of Contents

    Contents Chapter 1 Introduction Shipping Box Contents Specifications Chapter 2 Server System Overview System Components Internal Features System Front Panel System Rear Panel Front Control Panel Buttons and LEDs Chapter 3 Hardware Installation and Maintenance Server Top Cover Power Supply System Fan Riser cable (PCIe x4 GF to PCIe x16 slot Gen4 cable) Riser Card ( RB2UX16L_G5_RDV )

  • Page 7: Chapter 1 Introduction

    2U1G-B650 Chapter 1 Introduction Thank you for purchasing 2U1G-B650, a reliable barebone system produced under ASRock Rack’s consistently stringent quality control. It delivers excellent performance with robust design conforming to ASRock Rack’s commitment to quality and endurance. This guide provides the instructions of insertion and extraction of chassis components, such as chassis covers, system fans, power supplies, hard disk drive trays, and other main components this system supports.

  • Page 8: Shipping Box Contents

    1.1 Shipping Box Contents Item Quantity 2U1G Series Barebone (2U form factor) Power Supply Unit System Fan Power Distribution Board (PDB) System Board (MB) Front Panel Board (FPB) Riser Card Accessory Box If any items are missing or appear damaged, contact your authorized dealer.

  • Page 9: Specifications

    2U1G-B650 1.2 Specifications 2U1G-B650 System Form Factor 2U Rackmount Dimensions 477.7 x 430.4 x 88 mm (18.8'' x 16.9'' x 3.5'') Support MB B650D4U Front Panel Buttons Power button w/ LED, System Reset button LEDs System Fail LED, LAN1/LAN2 Activity, Power Status LED I/O Ports 2 Type-A (USB3.2 Gen1)
  • Page 10 Ethernet Additional GbE Intel® i210: 2 RJ45 (1GbE) Controller Server Management BMC Controller ASPEED AST2600 IPMI Dedicated 1 Realtek RTL8211F for dedicated management GLAN GLAN Graphics ASPEED AST2600: 1 DB15 (VGA), 1 (15-pin) header Controller AMD Processors with Graphics: 1 HDMI, 1 DisplayPort Rear I/O UID Button/ 1 UID button w/ LED...

  • Page 11: Chapter 2 Server System Overview

    2U1G-B650 Chapter 2 Server System Overview This chapter provides diagrams showing the location of important components of the server system. 2.1 System Components Riser cable (PCIe x4 GF to PCIe x16 slot Gen4 cable) 2 x Power Supply Units Riser card (RB2UX16L_G5_RDV)

  • Page 12: Internal Features

    2.2 Internal Features From Server Board Riser card (RB2UX16L_G5_RDV) Riser cable (PCIe x4 GF to PCIe x16 slot Gen4 cable) 2 x Power Supply Units System Fan (FAN1) System Fan (FAN2) System Fan (FAN3) System Fan (FAN4) Control Panel Buttons and LED Indicators 2 x USB Port...

  • Page 13: System Front Panel

    2U1G-B650 2.3 System Front Panel Description Front Vent Control Panel (depends on the specification of the server board) 2 x USB Ports 2.4 System Rear Panel Description 2 x Power Supply Units (PSU) I/O Shield (depends on the specification of the server board)

  • Page 14: Front Control Panel Buttons And Leds

    2.5 Front Control Panel Buttons and LEDs Front Control Panel Description Power Button Power Status LED Hard Drive Status LED LAN1 Activity LED LAN2 Activity LED System Status LED System Reset Button 2 x USB Port *Please be noted that the functions are supported depending on the type of the server board.

  • Page 15: Power Button

    2U1G-B650 Power Button Press the power button to power on or power off the system. To remove all power from the system completely, disconnect the power cord from the server. UID Button Press the ID button to toggle the front panel UID LED and the baseboard UID LED on and off.

  • Page 16: Before You Begin

    Chap te r 3 H ar d w ar e I ns t all atio n a n d Maintenance This chapter helps you assemble the chassis and install components. Before You Begin Before you work with the server, pay close attention to the “Important Safety Instructions” at the beginning of this manual.

  • Page 17: Server Top Cover

    2U1G-B650 3.1 Server Top Cover Removing the Server Top Cover 1. Before removing the top cover, power off the server and unplug the power cord. 2. The system must be operated with the chassis top cover installed to ensure proper cooling.
  • Page 18 Installing the Server Top Cover 1. Lower the top cover on the chassis, making sure the side latches align with the cutouts. Slide the top cover toward the front side 2. Hand-tighten the thumbscrew on the rear side of the chassis.

  • Page 19: Power Supply

    2U1G-B650 3.2 Power Supply The system can accommodate four AC or two DC power supplies in the bay at the rear of the chassis. One power supply is required for full load operation, with the other power supply purely as a redundant, load-sharing backup. It can be removed without affecting system operation.
  • Page 20 Installing the Power Supply Unit To install a new power supply, please follow the steps below. 1. Carefully slide the PSU all the way into the power supply bay. 2. Make sure the power supply clicks into place and is well installed.

  • Page 21: System Fan

    2U1G-B650 3.3 System Fan The system supports hot-swappable system fans. Replacing the System Fan 1. Lift to remove the failed fan. 2. Align the mounting holes on the replacement fan corners with the fan mounts on the fan bracket. 3. Gently place the fan onto the mounts.

  • Page 22: Riser Cable (Pcie X4 Gf To Pcie X16 Slot Gen4 Cable)

    3.4 Riser cable (PCIe x4 GF to PCIe x16 slot Gen4 cable) 1. You can install an add-in card to the chassis only when you have a riser cable installed on the server board. 2. Before installing the add-in card, power off the server and unplug the power cord. Removing the Riser Cable Bracket from the Chassis 1.
  • Page 23 2U1G-B650 3. Remove the screw securing the blanking plate on the riser cable bracket. 4. Slide the blanking plate out sideways.
  • Page 24 Installing the Add-in Card 1. Install the add-in card to the riser cable bracket. 2. Secure the add-in card to the bracket with a screw. 3. Align the riser cable assembly with the openings of the chassis. Place it into the chassis. 4.

  • Page 25: Riser Card ( Rb2Ux16L_G5_Rdv )

    2U1G-B650 3.5 Riser Card ( RB2UX16L_G5_RDV ) 1. You can install an add-in card to the chassis only when you have a riser card installed on the server board. 2. Before installing the add-in card, power off the server and unplug the power cord.
  • Page 26 1. Remove the screws securing the blanking plates on the riser-card bracket. 2. Slide the blanking plates out sideways.
  • Page 27 2U1G-B650 Installing the Add-in Card 1. Install the add-in card to the riser-card bracket. 2. Secure the add-in card to the bracket with screws. 3. Align the riser-card assembly with the openings of the chassis. Place it into the chassis.

  • Page 28: Installing The Cpu

    Appendix A Installing the CPU 1. Before you insert the 1718-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 29 2U1G-B650 Carefully place the CPU in as flat as possible. Do not drop it.
  • Page 30 Make sure the CPU is aligned with the socket before locking it into place. Make sure the black cover plate is always in place until it pops off when closing the socket lever. Please save the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.

  • Page 31: Installation Of Memory Modules (Dimm)

    2U1G-B650 Appendix B Installation of Memory Modules (DIMM) The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation. For more information about DIMM installation, please refer to the User Manual that comes with the serverboard you use.
  • Page 32 Type B (Two Clips)

  • Page 33: Block Diagram (B650D4U)

    2U1G-B650 Appendix C Block Diagram (B650D4U)

  • Page 34: Contact Information

    Contact Information Contact ASRock Rack or want to know more about ASRock Rack, you’re welcome to visit ASRock Rack’s website at http://www.asrockrack.com; or contact the dealer for further information. For technical questions, please submit a support request form at https://event.
