ASROCK B650 PRO RS User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
https://tehnoteka.rs
Uputstvo za upotrebu (EN)
ASRock B650 PRO RS matična ploča
Tehnoteka je online destinacija za upoređivanje cena i karakteristika bele tehnike,
potrošačke elektronike i IT uređaja kod trgovinskih lanaca i internet prodavnica u Srbiji.
Naša stranica vam omogućava da istražite najnovije informacije, detaljne karakteristike
i konkurentne cene proizvoda.
Posetite nas i uživajte u ekskluzivnom iskustvu pametne kupovine klikom na link:
https://tehnoteka.rs/p/asrock-b650-pro-rs-maticna-ploca-akcija-cena/

Advertisement

Table of Contents
loading

Related Manuals for ASROCK B650 PRO RS

Summary of Contents for ASROCK B650 PRO RS

  • Page 1 Uputstvo za upotrebu (EN) ASRock B650 PRO RS matična ploča Tehnoteka je online destinacija za upoređivanje cena i karakteristika bele tehnike, potrošačke elektronike i IT uređaja kod trgovinskih lanaca i internet prodavnica u Srbiji. Naša stranica vam omogućava da istražite najnovije informacije, detaljne karakteristike i konkurentne cene proizvoda.
  • Page 3 Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at https://event.asrock.com/tsd.asp ASRock Incorporation e-mail: info@asrock.com.tw...

  • Page 4: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Motherboard Layout I/O Panel Block Diagram Chapter 2 Installation Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (DIMM) Connecting the Front Panel Header Installing the Motherboard Installing SATA Drives Installing a Graphics Card Connecting Peripheral Devices Connecting the Power Connectors...
  • Page 5 2.16 M.2 SSD Module Installation Guide (M2_2) 2.17 M.2 SSD Module Installation Guide (M2_3)

  • Page 6: Chapter 1 Introduction

    ASRock’s website without further notice. If you require technical support related to this motherboard, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.

  • Page 7: Specifications

    • Supports DDR5 non-ECC, un-buffered memory up to 7200+(OC)* • Max. capacity of system memory: 192GB • Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules * Please refer to Memory Support List on ASRock's website for more information. (http://www.asrock.com/) Expansion CPU: Slot • 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*...
  • Page 8 B650 Pro RS Audio • 7.1 CH HD Audio (Realtek ALC897 Audio Codec) • Nahimic Audio • 2.5 Gigabit LAN 10/100/1000/2500 Mb/s • Dragon RTL8125BG • Supports Dragon 2.5G LAN Software - Smart Auto Adjust Bandwidth Control - Visual User Friendly UI...
  • Page 9 • 1 x 8 pin 12V Power Connector • 1 x 4 pin 12V Power Connector • 1 x Front Panel Audio Connector • 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 4 AIC Card) • 2 x USB 2.0 Headers (Support 3 USB 2.0 ports) • 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
  • Page 10 • ErP/EuP ready (ErP/EuP ready power supply is required) * For detailed product information, please visit our website: http://www.asrock.com Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.

  • Page 11: Motherboard Layout

    1.3 Motherboard Layout...
  • Page 12 B650 Pro RS No. Description 8 pin 12V Power Connector (ATX12V1) 4 pin 12V Power Connector (ATX12V2) Chassis/Water Pump Fan Connector (CHA_FAN3/WP) CPU Fan Connector (CPU_FAN1) 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1) 2 x 288-pin DDR5 DIMM Slots (DDR5_A2, DDR5_B2)

  • Page 13: I/O Panel

    1.4 I/O Panel No. Description No. Description 2.5G LAN RJ-45 Port* USB 3.2 Gen2 Type-C Port (USB32_TC_1) Line In (Light Blue)** USB 2.0 Ports (USB_56) Front Speaker (Lime)** USB 2.0 Ports (USB_1234) Microphone (Pink)** HDMI Port USB 3.2 Gen1 Ports (USB32_23) DisplayPort 1.4 USB 3.2 Gen2 Type-A Port (USB32_1) 12 BIOS Flashback Button...
  • Page 14 B650 Pro RS ** Function of the Audio Ports in 7.1-channel Configuration: Port Function Light Blue (Rear panel) Rear Speaker Out Lime (Rear panel) Front Speaker Out Pink (Rear panel) Central /Subwoofer Speaker Out Lime (Front panel) Side Speaker Out...

  • Page 15: Block Diagram

    1.5 Block Diagram...

  • Page 16: Chapter 2 Installation

    B650 Pro RS Chapter 2 Installation This is an ATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 17: Installing The Cpu

    2.1 Installing the CPU 1. Before you insert the 1718-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found. Otherwise, the CPU will be seriously damaged.
  • Page 18 B650 Pro RS Carefully place the CPU in as flat as possible. Do not drop it.
  • Page 19 Make sure the CPU is aligned with the socket before locking it into place. Make sure the black cover plate is always in place until it pops off when closing the socket lever. Please save the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.

  • Page 20: Installing The Cpu Fan And Heatsink

    B650 Pro RS 2.2 Installing the CPU Fan and Heatsink After you install the CPU into this motherboard, it is necessary to install a larger heatsink and cooling fan to dissipate heat. You also need to spray thermal grease between the CPU and the heatsink to improve heat dissipation. Make sure that the CPU and the heatsink are securely fastened and in good contact with each other.
  • Page 22 B650 Pro RS Installing the CPU Cooler (Type 2)
  • Page 24 B650 Pro RS +12V *The illustrations shown here are for reference purposes only and may not exactly match the model you purchase.
  • Page 25 Installing the CPU Cooler (Type 3)
  • Page 26 B650 Pro RS...
  • Page 28 +12V Please note that only one cable should be used at a time in this step. If you select RGB_LED1, please install ASRock utility "ASRock Polychrome SYNC". If you select USB connector, please install AMD utility "SR3 Settings Software". *The illustrations shown here are for reference purposes only and may not exactly match...

  • Page 29: Installing Memory Modules (Dimm)

    2.3 Installing Memory Modules (DIMM) This motherboard provides four 288-pin DDR5 (Double Data Rate 5) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR5 DIMM pairs. 2.
  • Page 30 B650 Pro RS...

  • Page 31: Connecting The Front Panel Header

    2.4 Connecting the Front Panel Header Front Panel Wires System Panel Header Power SW (-) RESET SW (+) Power SW (+) RESET SW (-) Power LED (-) HDD LED (-) Power LED (+) HDD LED (+) PANEL1...

  • Page 32: Installing The Motherboard

    B650 Pro RS 2.5 Installing the Motherboard...

  • Page 33: Installing Sata Drives

    2.6 Installing SATA Drives Optical Drive SATA Drive SATA Data Cable...
  • Page 34 B650 Pro RS SATA Power Connector SATA Data Connector...

  • Page 35: Installing A Graphics Card

    2.7 Installing a Graphics Card CLICK!
  • Page 36 B650 Pro RS Expansion Slots (PCIe Slots) There are 3 PCI Express slots on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.

  • Page 37: Connecting Peripheral Devices

    2.8 Connecting Peripheral Devices...

  • Page 38: Connecting The Power Connectors

    B650 Pro RS 2.9 Connecting the Power Connectors...

  • Page 39: Power On

    2.10 Power On...

  • Page 40: Jumpers Setup

    B650 Pro RS 2.11 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper (CLRCMOS1) (see p.6, No.

  • Page 41: Onboard Headers And Connectors

    2.12 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header (9-pin PANEL1) (see p.6, No.
  • Page 42 B650 Pro RS Power LED and Speaker Header (7-pin SPK_PLED1) (see p.6, No. 19) Please connect the chassis power LED and the chassis speaker to this header. SPK_PLED1 SPEAKER DUMMY DUMMY PLED+ PLED+ PLED- Serial ATA3 Connectors Right Angle: (SATA3_1) (see p.6, No. 15) (Lower) (SATA3_2) (see p.6, No.
  • Page 43 USB 2.0 Headers (9-pin USB_7_8) (see p.6, No. 22) (4-pin USB_9) (see p.6, No. 23) There are two headers on this motherboard. USB_9 P- P+ USB_PWR USB_7_8 USB_PWR DUMMY USB_PWR USB 3.2 Gen1 Header (19-pin USB32_4_5) (see p.6, No. 12) There is one header on this motherboard.
  • Page 44 B650 Pro RS Front Panel Type C USB 3.2 Gen2x2 Header (20-pin USB32_TC_2) (see p.6, No. 13) There is one Front Panel Type C USB 3.2 Gen2x2 Header on this motherboard. This header is used for connecting a USB 3.2 Gen2x2 module for additional USB 3.2 Gen2x2 ports.
  • Page 45 Chassis/Water Pump Fan Connectors (4-pin CHA_FAN1/WP) (see p.6, No. 21) (4-pin CHA_FAN2/WP) (see p.6, No. 17) (4-pin CHA_FAN3/WP) (see p.6, No. 3) (4-pin CHA_FAN4/WP) (see p.6, No. 24) This motherboard provides four 4-Pin water cooling chassis fan connectors. If you plan to connect a 3-Pin chassis water cooler fan, please connect it to Pin 1-3.
  • Page 46 B650 Pro RS CPU Fan Connector (4-pin CPU_FAN1) (see p.6, No. 4) This motherboard provides a 4-Pin CPU fan (Quiet Fan) connector. If you plan to connect a 3-Pin CPU fan, please connect it to Pin 1-3. CPU_FAN1 4 3 2 1...
  • Page 47 ATX Power Connector (24-pin ATXPWR1) (see p.6, No. 11) This motherboard provides a 24-pin ATX power connector. To use a 20-pin ATX power supply, please plug it along Pin 1 and Pin 13. ATXPWR1 ATX 12V Power Connector (8-pin ATX12V1) (see p.6, No. 1) This motherboard provides a 8-pin ATX 12V power connector.
  • Page 48 B650 Pro RS ATX 12V Power Connector (4-pin ATX12V2) (see p.6, No. 2) Please connect an ATX 12V power supply to this connector. *The power supply plug fits into this connector in only one orientation. *Connecting an ATX 12V 4-pin cable to ATX12V2 is optional.
  • Page 49 (5-pin TB1) (see p.6, No. 27) Please connect a Thunderbolt™ add-in card (AIC) to the Thunderbolt AIC connec- tor via the GPIO cable. *Please install the Thunderbolt™ AIC card to PCIE3 (default slot). *For the Thunderbolt compatibility and limitation, please visit www.asrock.com.
  • Page 50 B650 Pro RS RGB LED Header (4-pin RGB_LED1) (see p.6, No. 26) This RGB header is used to connect RGB LED extension cable which allow users to choose from various LED lighting effects. Caution: Never install the RGB LED cable in the wrong orientation; otherwise, the cable may be damaged.
  • Page 51 Addressable LED Headers (3-pin ADDR_LED1) (see p.6, No. 25) (3-pin ADDR_LED2) (see p.6, No. 8) (3-pin ADDR_LED3) (see p.6, No. 9) These headers are used to connect Addressable LED extension cables which allow users to choose from various LED lighting effects. Caution: Never install the Addressable LED cable in the wrong orientation;...
  • Page 52 B650 Pro RS 1. Never install the RGB LED cable in the wrong orientation; otherwise, the cable may be damaged. 2. Before installing or removing your RGB LED cable, please power off your system and unplug the power cord from the power supply. Failure to do so may cause dam- ages to motherboard components.

  • Page 53: Smart Switches

    2.13 Smart Switches The motherboard has one smart switch: BIOS Flashback Button, allowing users to flash the BIOS. BIOS Flashback Button (BIOS_FB1) (see p.8, No. 12) BIOS Flashback Button allows users to flash the BIOS. BIOS_FB1 USB BIOS Flashback port...
  • Page 54 B650 Pro RS ASRock BIOS Flashback feature allows you to update BIOS without powering on the system, even without CPU. Before using the BIOS Flashback function, please suspend BitLocker and any encryp- tion or security relying on the TPM. Make sure that you have already stored and backup-ed the recovery key.

  • Page 55: Post Status Checker

    2.14 Post Status Checker Post Status Checker (PSC) diagnoses the computer when users power on the machine. It emits a red light to indicate whether the CPU, memory, VGA or storage is dysfunctional. The lights go off if the four mentioned above are functioning normally. It is normal for the DRAM status LED to blink during memory training.
  • Page 56 B650 Pro RS 2.15 M.2 SSD Module Installation Guide (M2_1) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Blazing M.2 Socket (M2_1, Key M) supports type 2280 PCIe Gen5x4 (128 Gb/s) mode.
  • Page 57 Step 3 Before installing a M.2 SSD module, please loosen the screws to remove the M.2 heatsink. *Please remove the protective films on the bottom side of the M.2 heatsink before you install a M.2 SSD module. Step 4 Align and gently insert the M.2 SSD module into the M.2 slot.
  • Page 58 B650 Pro RS Step 5 Before securing the M.2 heatsink, make sure to align the notch on the SSD to the standoff on the motherboard; otherwise, the SSD module may be damaged. Correct Installation: The SSD's PCB is in proper place, and the M.2 heatsink can be screwed in.
  • Page 59 M.2 connector (3). *Please do not overtighten the screw as this might damage the module and M.2 heatsink. For the latest updates of M.2 SSD module support list, please visit our website for details: http://www.asrock.com...

  • Page 60: Ssd Module Installation Guide (M2_1)

    B650 Pro RS 2.16 M.2 SSD Module Installation Guide (M2_2) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The M.2 Socket (M2_2, Key M) supports type 2242/2260/2280 SATA3 6.0 Gb/s &...
  • Page 61 Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw as this might damage the module. NUT2 NUT1 For the latest updates of M.2 SSD module support list, please visit our website for details: http://www.asrock.com...
  • Page 62 B650 Pro RS 2.17 M.2 SSD Module Installation Guide (M2_3) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_3, Key M) supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode.
  • Page 63 Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw NUT2 NUT1 as this might damage the module. For the latest updates of M.2 SSD module support list, please visit our website for details: http://www.asrock.com...
  • Page 64 In no event shall ASRock, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
