Neousys Technology Nuvo-9650AWP Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Neousys Technology Inc.
Nuvo-9650AWP Series
User Manual
Revision 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nuvo-9650AWP Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Neousys Technology Nuvo-9650AWP Series

Summary of Contents for Neousys Technology Nuvo-9650AWP Series

  • Page 1 Neousys Technology Inc. Nuvo-9650AWP Series User Manual Revision 1.0...

  • Page 2: Table Of Contents

    1.2.4 Wall Mount Bracket Dimensions (Optional) ............16 System Overview Unpacking the System ..................... 17 Nuvo-9650AWP Series Front Panel ................. 18 2.2.1 M12 L-coded DC-in Port with Ignition Power Control (Nuvo-9650AWP-PoE) ... 20 2.2.2 M12 A-coded DC-in port with Ignition Power Control (Nuvo-9650AWP) ... 21 2.2.3...
  • Page 3 Table of Contents BIOS Settings COM Port Configuration ..................66 4.1.1 COM Port High Speed Mode ................67 TPM Availability ......................68 Power over Ethernet (PoE) Power Enable .............. 69 C-States ........................71 Wake-on-LAN ......................72 Power On after Power Failure ................. 73 Power &...

  • Page 4: Legal Information

    For questions in regards to hardware/ software compatibility, customers should contact Neousys Technology Inc. sales representative or technical support. To the extent permitted by applicable laws, Neousys Technology Inc. shall NOT be responsible for any interoperability or compatibility issues that may arise when (1) products, software, or options not certified and supported;...

  • Page 5: Contact Information

    Neousys Technology Inc. (Taipei, Taiwan) 15F, No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City, 23586, Taiwan Tel: +886-2-2223-6182 Fax: +886-2-2223-6183 Email, Website Americas Neousys Technology America Inc. 3384 Commercial Avenue, Northbrook, IL 60062, USA (Illinois, USA) Tel: +1-847-656-3298 Email, Website China Neousys Technology (China) Ltd.

  • Page 6: Copyright Notice

    This manual is intended to be used as an informative guide only and is subject to change without prior notice. It does not represent commitment from Neousys Technology Inc. Neousys Technology Inc. shall not be liable for any direct, indirect, special, incidental, or consequential damages arising from the use of the product or documentation, nor for any infringement on third party rights.

  • Page 7: Safety Precautions

    Safety Precautions Safety Precautions ⚫ Read these instructions carefully before you install, operate, or transport the system. ⚫ Install the system or mounting system (eg. DIN rail, wall-mount), at a sturdy location ⚫ Install the power socket outlet near the system where it is easily accessible ⚫...

  • Page 8: Service And Maintenance

    Service and Maintenance/ ESD Precautions Service and Maintenance ⚫ ONLY qualified personnel should service the system ⚫ Shutdown the system, disconnect the power cord and all other connections before servicing the system ⚫ When replacing/ installing additional components (expansion card, memory module, etc.), insert them as gently as possible while assuring proper connector engagement ESD Precautions...

  • Page 9: About This Manual

    About This Manual About This Manual This manual introduces and demonstrates installation procedures of Neousys Nuvo-9650AWP series systems. Revision History Version Date Description Sep. 2024 Initial release...

  • Page 10: Introduction

    Nuvo-9650AWP Series Introduction Nuvo-9650AWP is a cost-effective IP66 waterproof computer with Intel® 13th/12th-Gen Core™ processor designed for harsh and demanding environments. Thanks to its streamlined waterproof chassis and standardized cable kit, Nuvo-9650AWP redefines affordable total cost of ownership (TCO) for industrial computing with significant enhancements including ruggedness against extended operating temperature, intensive shock and vibration, dust, humidity and salinity.

  • Page 11: Specification Of Nuvo-9650Awp

    Nuvo-9650AWP Series Specification of Nuvo-9650AWP System Core Processor Supports Intel® 14th-Gen Core™ CPU (LGA1700 socket, 65W/ 35W TDP) - Intel® Core™ i9-14900/ i9-14900T - Intel® Core™ i7-14700/ i7-14700T - Intel® Core™ i5-14500/ i5-14400/ i5-14500T - Intel® Core™ i3-14100/ i3-14100T Supporting Intel® 13th-Gen Core™ CPU (LGA1700 socket, 65W/ 35W TDP) - Intel®...
  • Page 12 Nuvo-9650AWP Series 1x reserved USB 3.2 Gen1 Type-A connector (rear side) USB 2.0 2x USB 2.0 (M12 A-coded) 1x USB 2.0 (internal) Video Port 1x DisplayPort in Type-C waterproof connector, supporting 4096 x 2304 resolution (Integrated 1x VGA (M12 A-coded), supporting 1920 x 1200 resolution...
  • Page 13 Nuvo-9650AWP Series With 65W CPU -25°C to 70°C * (configured as 35W TDP mode) -25°C to 50°C * (configured as 65W TDP mode) Storage -40°C to 85°C Temperature Humidity 10%~90% , non-condensing Vibration MIL-STD-810H, Method 514.8, Category 4 Shock MIL-STD-810H, Method 516.8, Procedure I CE/FCC Class A, according to EN 55032 &...

  • Page 14: Dimension

    Nuvo-9650AWP Series Dimension NOTE Nuvo-9650AWP and Nuvo-9650AWP-PoE share the same dimensions. Nuvo-9650AWP will be shown for demonstration purposes. 1.2.1 I/O Panel View 1.2.2 Side View...

  • Page 15: Bottom View

    Nuvo-9650AWP Series 1.2.3 Bottom View...

  • Page 16: Wall Mount Bracket Dimensions (Optional)

    Nuvo-9650AWP Series 1.2.4 Wall Mount Bracket Dimensions (Optional) The system comes with an optional wall mount bracket.

  • Page 17: System Overview

    Nuvo-9650AWP Series System Overview Upon receiving and unpacking your Nuvo-9650AWP series, please check immediately if the package contains all the items listed in the following table. If any item(s) are missing or damaged, please contact your local dealer or Neousys Technology.

  • Page 18: Nuvo-9650Awp Series Front Panel

    Nuvo-9650AWP Series Nuvo-9650AWP Series Front Panel NOTE Nuvo-9650AWP and Nuvo-9650AWP-PoE share the similar I/O ports, therefore Nuvo-9650AWP will be used for demonstration purposes. Additional illustration(s) will be shown to indicate difference(s). The IO panel of Nuvo-9650AWP features M12 connectors that include an isolated COM, DC input, VGA, Gigabit Ethernet, Type-C USB, DisplayPort, and USB2.0...
  • Page 19 Nuvo-9650AWP Series M12 X-coded Port 1: 1Gb Ethernet via Intel I219 Port 2 – 4: 2.5Gb Ethernet via Intel I226 Ethernet M12 A-coded VGA VGA output supports resolution up to 1920x1200@60Hz M12 A-coded USB The USB 2.0 ports offer up to 480Mbit/s bandwidth and are backward compatible with USB 1.1/ 1.0.

  • Page 20: M12 L-Coded Dc-In Port With Ignition Power Control (Nuvo-9650Awp-Poe)

    Nuvo-9650AWP Series 2.2.1 M12 L-coded DC-in Port with Ignition Power Control (Nuvo-9650AWP-PoE) The system accepts a wide range of DC power input from 8V to 48V via a M12 L-coded connector. The M12 L-coded connectors offer COTS availability and ultra-rugged connection reliability when wiring DC power.

  • Page 21: M12 A-Coded Dc-In Port With Ignition Power Control (Nuvo-9650Awp)

    Nuvo-9650AWP Series 2.2.2 M12 A-coded DC-in port with Ignition Power Control (Nuvo-9650AWP) The system accepts a wide range of DC power input from 8V to 48V via a M12 A-coded connector. The M12 A-coded connectors offer COTS availability and ultra-rugged connection reliability when wiring DC power.

  • Page 22: M12 X-Coded 802.3At Gb Poe+ Port

    Nuvo-9650AWP Series 2.2.3 M12 X-coded 802.3at Gb PoE+ Port The system offers four Ethernet ports via an M12 X-coded, 8-pin connector with optional Power over Ethernet (802.3at). Port 1 is Gb and ports 2-4 are 2.5Gb specifications. Connector Pin Definition...

  • Page 23: M12 A-Coded Vga Port

    Nuvo-9650AWP Series 2.2.4 M12 A-coded VGA Port VGA connector is the most common video display connection. The VGA output supports up to 1920x1200@60Hz resolution. To support VGA display output and achieve best VGA output resolution in Windows, you need to install corresponding graphics drivers. Please refer to...
  • Page 24 Nuvo-9650AWP Series VSYNC_CN VGA_SCL NOTE Please make sure your VGA cable includes SDA and SCL (DDC clock and data) signals for correct communication with monitor to get resolution/timing information. A cable without SDA/ SCL can cause blank screen on your VGA monitor due to incorrect resolution/timing output.

  • Page 25: M12 A-Coded Usb 2.0 Port

    Nuvo-9650AWP Series 2.2.5 M12 A-coded USB 2.0 Port The USB2.0 ports are implemented via native xHCI (eXtensible Host Controller Interface) and are backward compatible with USB 1.1 and USB 1.0 devices. UEFI USB support is also provided so you can use USB keyboard/ mouse in UEFI shell environment.

  • Page 26: Usb3.2/ Displayport

    Nuvo-9650AWP Series 2.2.6 USB3.2/ DisplayPort The system’s USB 3.2 Gen1x1 type-C port offers up to 5Gbps of data transfer bandwidth, and is implemented via the native xHCI (eXtensible Host Controller Interface) controller. The port is backward compatible with USB3.2 Gen.1, USB 2.0, USB 1.1 and USB 1.0 devices via a USB hub (not included) to connect to external...

  • Page 27: M12 A-Coded Com Port

    Nuvo-9650AWP Series 2.2.7 M12 A-coded COM Port The system provides two isolated COM ports via an M12 A-coded connector for communicating with external devices. COM 1 is a RS-232 specifications port and provide up to 115200 bps baud rate while COM2 port is RS-422/485 specifications.

  • Page 28: Power Button

    Nuvo-9650AWP Series 2.2.8 Power Button The power button is a non-latched switch for ATX mode on/off operation. Press to turn on the system, the button should light up and to turn off, you can either issue a shutdown command in the OS, or just press the power button. In case of system halts, you can press and hold the power button for 5 seconds to force-shutdown the system.

  • Page 29: Nuvo-9650Awp Series Internal I/O

    Nuvo-9650AWP Series Nuvo-9650AWP Series Internal I/O The system’s internal I/O connectors consist of a M.2 2280 M key PCIe Gen4 x4 interface slot, two mini-PCIe slots with SIM slots, and a M.2 B key slot with SIM slot. 2.3.1 M.2 2280 M Key Slot The system has an M.2 2280 slot Gen4 x4 slot for you to install an M.2 NVMe SSD...
  • Page 30 Nuvo-9650AWP Series M.2 2280 M Key Pin Definition Pin # Signal Pin # Signal +3V3 +3V3 PERN3 PERP3 DAS/DSS_N PETN3 +3V3 PETP3 +3V3 +3V3 PERN2 +3V3 PERP2 PETN2 PETP2 PERN1 PERP1 PETN1 PETP1 PERn0 PERp0 PETn0 PETp0 PERST_N REFCLKN REFCLKP...

  • Page 31: Mini-Pcie Slot With Micro Sim Socket

    Nuvo-9650AWP Series 2.3.2 mini-PCIe Slot with micro SIM Socket The system provides mini-PCIe sockets (indicated in blue) that is in compliance with mini-PCIe specification rev. 1.2. This mini-PCIe socket is designed with SIM card (slot indicated in red) support. With a SIM card installed, your system can access the...
  • Page 32 Nuvo-9650AWP Series mini-PCIe socket definition Signal (mPCIe) Pin # Signal (mPCIe) WAKE# +3.3Vaux +1.5V CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RESET UIM_VPP Mechanical Key Reserved* (UIM_C8) Reserved* (UIM_C4) W_DISABLE# PERST# PERn0 3.3V PERp0 +1.5V SMB_CLK PETn0 SMB_DATA PETp0 USB_D- USB_D+ 3.3V...

  • Page 33: B Key Slot

    Nuvo-9650AWP Series 2.3.3 M.2 B Key Slot The system has an M.2 B key 2242/ 3052 slot (indicated in blue rectangle) with a 5G/ 4G SIM slot (indicated in rectangle). A copper standoff is provided for you to secure onto the motherboard into the red arrow location for an M.2 2242 module, or...
  • Page 34 Nuvo-9650AWP Series M.2 (B Key) Slot Pin Definition Pin # Signal Pin # Signal +3V3 +3V3 FULL_CARD_POWER_OFF_N USB_D+ W_DISABLE_N USB_D- Mechanical Key USB3.0-RX- USB3.0-RX+ UIM1-RESET UIM1-CLK USB3.0-TX- UIM1-DATA USB3.0-TX+ UIM1-PWR PERn0 / SATA-B+ UIM2-DET PERp0 / SATA-B- UIM2-DATA UIM2-CLK PETn0 / SATA-A-...

  • Page 35: Ignition Rotary Switch

    Nuvo-9650AWP Series 2.3.4 Ignition Rotary Switch The ignition power control switch features multiple modes for pre and post ignition settings. Please refer to the section Ignition Power Control for details.

  • Page 36: System Installation

    Nuvo-9650AWP Series System Installation Before disassembling the system enclosure and installing components and modules, please make sure you have done the following: ⚫ It is recommended that only qualified service personnel should install and service this product to avoid injury or damage to the system.

  • Page 37: Disassembling The System Enclosure

    Nuvo-9650AWP Series Disassembling the System Enclosure To install components such as M.2 modules or mPCIe modules, you need to disassemble the Nuvo-9650AWP system enclosure: To disassemble Nuvo-9650AWP, turn the system upside down and place it on a secured flat surface. Unfasten the screws in the following order.
  • Page 38 Nuvo-9650AWP Series Gently open the bottom panel. Accessible user expansion slots after removing the bottom panel.

  • Page 39: Installing Internal Components

    Nuvo-9650AWP Series Installing Internal Components 3.2.1 M.2 2280 M Key Module Installation There is one M.2 2280 M key module expansion slot for Nuvo-9650AWP system. Please follow the procedures below to install the module. Disassemble the system enclosure 2. The M.2 2280 M key slot can be located once the enclosure has been removed.
  • Page 40 Nuvo-9650AWP Series 3. Insert the M.2 M key module on a 45 degree angle. 4. Secure the module by fastening the screw. Reinstall the system enclosure. 6. If you need to install other components, please refer to respective sections.

  • Page 41: Mini-Pcie Module & Sim Card Installation

    NOTE Due to waterproof IP66 rating, for SMA antenna installation, please contact Neousys Technology or your authorized dealer for compatible enclosure panel. There are mini-PCIe slots and SIM card sockets for Nuvo-9650AWP system. Please follow the procedures below for installation.
  • Page 42 Nuvo-9650AWP Series 3. If you need to install a SIM card, please do so before installing the mini-PCIe module. If not, please skip to step 5. To install a SIM card, slide the SIM bracket in the direction indicated and lift the bracket.
  • Page 43 Clip on IPEX-to-SMA cable NOTE Due to waterproof IP66 rating, for SMA antenna installation, please contact Neousys Technology or your authorized dealer for compatible enclosure panel. Reinstall the system enclosure. 8. If you need to install other components, please refer to respective sections.

  • Page 44: B Key Installation

    NOTE Due to waterproof IP66 rating, for SMA antenna installation, please contact Neousys Technology or your authorized dealer for compatible enclosure panel. There is one M.2 2242/ 3052 B key module expansion slot for Nuvo-9650AWP system. Please follow the procedures below to install the module.
  • Page 45 Nuvo-9650AWP Series 3. If you need to install a SIM card, please do so before installing the M.2 module. To install a SIM card, slide the SIM bracket in the direction indicated and lift the bracket. Slide and lift SIM card holder Insert SIM card with pins facing up 4.
  • Page 46 Clip on IPEX-to-SMA cable NOTE Due to waterproof IP66 rating, for SMA antenna installation, please contact Neousys Technology or your authorized dealer for compatible enclosure panel. Reinstall the system enclosureand panel when done. 9. If you need to install other components, please refer to respective sections.

  • Page 47: Hdd/ Ssd Installation

    Nuvo-9650AWP Series 3.2.4 HDD/ SSD Installation There are two HDD/ SSD brackets within the system. Please follow the procedures below to install the module. Turn the system upside down and place it on a secured flat surface. Unfasten the screws in the following order.
  • Page 48 Nuvo-9650AWP Series Gently open the bottom panel. The brackets can be found underneath the panel. Place an HDD/ SSD into the bracket and secure with screws (two on each side). Take the SATA/ power cable out of the accessory box, and connect it to the...
  • Page 49 Nuvo-9650AWP Series Repeat the above steps if you need to install another HDD/ SSD. With the system upside down, position it on a secured flat surface, and make sure the O-ring is properly positioned in the groove (indicated in red).
  • Page 50 Nuvo-9650AWP Series Place the panel back onto the enclosure and secure the screws in the order indicated to complete the installation. NOTE Please secure each screw with a torque range of 8.1 – 9.9 kgf for waterproof capability.

  • Page 51: Installing The System Enclosure

    Nuvo-9650AWP Series Installing the System Enclosure With the system upside down, position it on a secured flat surface, and make sure the O-ring is properly positioned in the groove (indicated in red).
  • Page 52 Nuvo-9650AWP Series Place the bottom panel onto the enclosure. NOTE Please make sure the O-ring is seated properly in the groove to ensure the system’s IP66 functionality.
  • Page 53 Nuvo-9650AWP Series Secure the screws on the panel in the following order to complete installing the system enclosure. NOTE Please secure each screw with a torque range of 8.1 – 9.9 kgf for waterproof capability.

  • Page 54: Wall Mount Installation (Optional Accessory)

    Nuvo-9650AWP Series Wall Mount Installation (Optional Accessory) The optional wall mount bracket allows the system to be mounted horizontally. Please refer to the following installation procedure to install the wall mount. To install the optional wall mount bracket, you need to remove the rubber stands (indicated in blue) at the bottom of the system.
  • Page 55 Nuvo-9650AWP Series Secure the two wall mount brackets (indicated in blue) to the bottom of the system enclosure using the M4 screws (indicated in red) provided. Dimension illustration of the installed wall mount bracket for your reference.

  • Page 56: Powering On The System

    Nuvo-9650AWP Series Powering On the System There are various methods to power on the system ⚫ Pressing the power button ⚫ Sending a LAN packet via Ethernet (Wake-on-LAN) ⚫ Using the ignition signal input We will describe the processes and actions involved for most of the methods in this section and the ignition signal input method will be described in its dedicated section.

  • Page 57: Powering On Using Wake-On-Lan

    Nuvo-9650AWP Series 3.5.2 Powering On Using Wake-on-LAN Wake-on-LAN (WOL) is a mechanism to wake up a computer system from a S5 (system off with standby power) state via issuing a magic packet. The system implements the Wake-on-LAN function for the GbE port #1 shown below.
  • Page 58 Nuvo-9650AWP Series ⚫ Wake on Magic Packet The magic packet is a broadcast frame containing anywhere within its payload 6 bytes of all 255 (FF FFFFFFFFFF in hexadecimal), followed by sixteen repetitions of the target computer's 48-bit MAC address. For example, NIC’s 48-bit MAC Address is 78h D0h 04h 0Ah 0Bh 0Ch...

  • Page 59: Ignition Power Control

    Nuvo-9650AWP Series Ignition Power Control The ignition power control module for in-vehicle applications is an MCU-based implementation that monitors the ignition signal and reacts to turn on/off the system according to predefined on/off delay. Its built-in algorithm supports other features such as ultra-low power standby, battery-low protection, system hard-off, etc.

  • Page 60: Additional Features Of Ignition Power Control

    Nuvo-9650AWP Series 3.6.2 Additional Features of Ignition Power Control In addition to the typical timing correlation, the ignition power control module offers additional features to provide additional reliability for in-vehicle applications. ⚫ Low battery detection The ignition power control module continuously monitors the voltage of DC input when the system is operational.

  • Page 61: Wiring Ignition Signal

    Nuvo-9650AWP Series 3.6.3 Wiring Ignition Signal Nuvo-9650AWP M12 A-coded Nuvo-9650AWP-PoE M12 L-coded To have ignition power control for in-vehicle usage, you need to supply IGN signal to the system. The IGN input is located on the M12 L-coded/A-coded connector (shared with DC power input).

  • Page 62: Configure Your Windows System

    Nuvo-9650AWP Series 3.6.4 Configure your Windows system When applying ignition power control to your system, please make sure you’ve configured your Windows system to initiate a shutdown process when pressing the power button. By default, Windows 10 goes to sleep (S3) mode when power button is pressed.

  • Page 63: Operation Modes Of Ignition Power Control

    Nuvo-9650AWP Series 3.6.5 Operation Modes of Ignition Power Control You can use the rotary switch to configure the operation mode. The system offers 16 (0~15) operation modes with different power-on/power-off delay configurations. The ignition control rotary switch can be located on the motherboard. Please refer to the “Disassembling the enclosure”...
  • Page 64 Nuvo-9650AWP Series Mode Power-on Delay Power-off Delay Hard-off Timeout 160ms 160ms 10 minutes ⚫ Mode 3 ~ Mode 12 Mode 3 ~ Mode 12 have various power-on delay and power-off delay. Each mode supports a hard-off timeout of 10 minutes.

  • Page 65: Bios Settings

    Nuvo-9650AWP Series BIOS Settings The system is shipped with factory-default BIOS settings optimized for best performance and compatibility. In this section, we’ll illustrate some BIOS settings you may need to set or change prior to operating system installation. Please always make sure you understand the effect of change before you proceed with any changes.

  • Page 66: Com Port Configuration

    Nuvo-9650AWP Series COM Port Configuration The system’s COM1 port supports isolated RS-232 while COM2 supports isolated RS-422/485 communication. The “RS-422/485 Termination” option determines whether to enable/ disable internal termination of RS-422/485 transceiver according to your wiring configuration (e.g. with or without external termination).

  • Page 67: Com Port High Speed Mode

    Nuvo-9650AWP Series 4.1.1 COM Port High Speed Mode The high speed mode of each COM port effectively allows for the port's baud rate generator to operate at 8x the speed with an effective baud rate of 921,600 bps (115,200 x 8). Please refer to the following instructions on how to enable the highspeed mode for your COM port (COM1 used as an example).

  • Page 68: Tpm Availability

    Nuvo-9650AWP Series TPM Availability Trusted Platform Module (TPM) is a hardware-based cryptoprocessor to secure hardware by integrating cryptographic keys into devices. The system is designed with on-board TPM 2.0 module. As TPM 2.0 requires 64-bit Windows 10 with UEFI boot mode, it is enabled in BIOS by default.

  • Page 69: Power Over Ethernet (Poe) Power Enable

    Nuvo-9650AWP Series Power over Ethernet (PoE) Power Enable Power over Ethernet (PoE) supplies electrical power and data on a standard CAT-5/CAT-6 Ethernet cable. Acting as a PoE PSE (Power Sourcing Equipment), compliant with IEEE 802.3at, each PoE port delivers up to 25W to a Powered Device (PD).
  • Page 70 Nuvo-9650AWP Series 4. You can also enable/ disable each port, individually. Simply use the arrow key to highlight the port, press ENTER to bring up options (Enabled/ Disabled), press ENTER again to select the option. Nuvo-9650AWP-PoE LAN ports 5. Press F10 to “Exit Saving Changes.

  • Page 71: C-States

    Nuvo-9650AWP Series C-States C-States is a power-saving technique implemented in modern Intel processors. It shuts down the clock signals and power for idle logic units inside the CPU to save the energy consumed. The trade-off, however, is a longer latency for CPU to wake up and be 100% operational.

  • Page 72: Wake-On-Lan

    Nuvo-9650AWP Series Wake-on-LAN Wake-on-LAN (WOL) is a mechanism which allows you to turn on your system via Ethernet connection. To utilize Wake-on-LAN function, you have to enable this option first in BIOS settings. Please refer to Powering on via Wake-on-LAN function.

  • Page 73: Power On After Power Failure

    Nuvo-9650AWP Series Power On after Power Failure This option defines the system’s behavior when DC power is supplied. Value Description S0 – Power On System is powered on when DC power is supplied. S5 – Power Off System is kept in off state when DC power is supplied.

  • Page 74: Power & Performance (Cpu Sku Power Configuration)

    Nuvo-9650AWP Series Power & Performance (CPU SKU Power Configuration) The system supports Intel 14 / 13 / 12 Gen LGA 1700 CPUs from 35W to 65W TDP. A unique feature, “SKU Power Config” is implemented in BIOS to allow users to specific user-defined SKU power limit.

  • Page 75: Position New Boot Device

    Nuvo-9650AWP Series Position New Boot Device The “Add Boot Options” allow you to determine whether a newly added device (eg. USB flash disk) is to boot as the first device to boot or the last in the boot sequence. To set the newly-installed boot device as the first or last boot device: Press F2 when the system boots up to enter the BIOS setup utility.

  • Page 76: Watchdog Timer For Booting

    Nuvo-9650AWP Series Watchdog Timer for Booting The watchdog timer secures the boot process by means of a timer. Once the timer expires, a reset command is issued to initiate another booting process. There are two options in BIOS menu, “Automatically after POST” and “Manually after Entering OS”.

  • Page 77: Os Support And Driver Installation

    OS Support and Driver Installation Operating System Compatibility Due to Intel’s policy, Nuvo-9650AWP series only provide driver support for the following Windows operating systems. For Linux support, please use Linux kernel versions no later than 5.15. The following list contains the operating systems which have been tested in Neousys Technology Inc.

  • Page 78: Driver Installation

    Nuvo-9650AWP Series Driver Installation The system drivers are available online, please click on this link to download the drivers. 5.2.1 Install Drivers Automatically Neousys provides a driver package which contain function APIs for Watchdog Timer control function. You should install the driver package (WDT_DIO_Setup.exe) in prior to use these functions.

  • Page 79: Appendix A Using Wdt

    In this section, we’ll illustrate how to use the function library provided by Neousys to program the WDT functions. Currently, WDT driver library supports Windows 10 x64 and WOW64 platform. For other OS support, please contact Neousys Technology for further information.

  • Page 80: Wdt And Dio Library Installation

    Nuvo-9650AWP Series WDT and DIO Library Installation To setup WDT & DIO Library, please follow instructions below. 1. Execute WDT_DIO_Setup.2.4.0.0.exe. and the following dialog appears. 2. Click “Next >” and specify the directory of installing related files. The default directory is C:\Neousys\WDT_DIO.
  • Page 81 Nuvo-9650AWP Series 3. Once the installation has finished, a dialog will appear to prompt you to reboot the system. The WDT & DIO library will take effect after the system has rebooted. 4. When programming your WDT or DIO program, the related files are located in...

  • Page 82: Wdt Function Reference

    Nuvo-9650AWP Series WDT Function Reference InitWDT Syntax BOOL InitWDT(void); Description: Initialize the WDT function. You should always invoke InitWDT() before set or start watchdog timer. Parameter None Return Value TRUE: Successfully initialized FALSE: Failed to initialize Usage BOOL bRet = InitWDT()

  • Page 83: Startwdt

    Nuvo-9650AWP Series StartWDT Syntax BOOL StartWDT(void); Description Starts WDT countdown. Once started, the WDT LED indicator will begin blinking. If ResetWDT() or StopWDT is not invoked before WDT countdowns to 0, the WDT expires and the system resets. Parameter None...

  • Page 84: Appendix B Poe On/ Off Control

    Nuvo-9650AWP Series Appendix B PoE On/ Off Control Nuvo-9650AWP-PoE offers 802.3at PoE+ ports and users are allowed to manually turn on or off the power supply of each PoE port. This can be useful in power device (PD) fault-recovery or power reset. The APIs are part of Neousys WDT_DIO driver package.

  • Page 85: Enablepoeport

    Nuvo-9650AWP Series EnablePoEPort Syntax BOOL EnablePoEPort (BYTE port); Description Turn on PoE power of designated PoE port. Parameter port BYTE value specifies the index of PoE port. Please refer to the following illustration, port should be a value of 1 ~ 4...

  • Page 86: Disablepoeport

    Nuvo-9650AWP Series DisablePoEPort Syntax BOOL DisablePoEPort (BYTE port); Description Turn off PoE power of designated PoE port Parameter port BYTE value specifies the index of PoE port. Please refer to the following illustration, port should be a value of 1 ~ 4...
