- Page 1 Assembly and operating manual SST Sensor tester Original operating manual...
- Page 2 Imprint Imprint Copyright: This manual is protected by copyright. The author is SCHUNK SE & Co. KG. All rights reserved. Technical changes: We reserve the right to make alterations for the purpose of technical improvement. Document number: 389581 Version: 06.00 | 16/10/2024 | en...
-
Page 3: Table Of Contents
9 Translation of the original declaration of conformity........13 10 UKCA Declaration of Conformity ..............14 11 Information on the RoHS Directive, REACH Regulation and Substances of Very High Concern (SVHC) ..................15 06.00 | SST | Assembly and operating manual | en | 389581... -
Page 4: General
Parts touching the workpiece and wear parts are not included in the warranty. 1.3 Scope of delivery The scope of delivery includes Sensor tester SST Safety information (product-specific instructions available online) 06.00 | SST | Assembly and operating manual | en | 389581... -
Page 5: Basic Safety Notes
Basic safety notes 2 Basic safety notes 2.1 Intended use The SST sensor tester is used to test and adjust proximity switches from SCHUNK, i.e. the IN, INK, MMS and RMS products. The product is designed for industrial use. To use this unit as intended, it is also essential to observe the technical data and installation and operation notes in this manual and to comply with the maintenance intervals. -
Page 6: Technical Data
Connection options Inductive, capacitive and optoelectronic sensors (3-conductor DC, 2-conductor DC and NAMUR) More technical data is included in the catalog data sheet. Whichever is the latest version. 06.00 | SST | Assembly and operating manual | en | 389581... -
Page 7: Design And Description
The switching function is signaled by an LED and an additional acoustic signal. When not in use, the sensor tester automatically switches itself off after approx. 30 seconds. The necessary power is supplied by a 9 V compound battery 06.00 | SST | Assembly and operating manual | en | 389581... -
Page 8: Assembly
Assembly 5 Assembly The Sensor tester SST can be fastened by means of the lateral through-bores if necessary. Through-bores Ø 5.5 5.1 Insert battery Using a screwdriver, press against the lock on the cover of the battery compartment and open the battery compartment cover. -
Page 9: Operation
Blue (– MINUS) Supply voltage of the GND sensor Check whether the wire colors of the sensor correspond to the descriptions in the table. Connect wires to the spring-type terminals. 06.00 | SST | Assembly and operating manual | en | 389581... -
Page 10: Operation Of The Sst With A Sensor
ð If the LED (3) lights up in red, the battery needs to be changed. If the sensor is damped, the SST emits a signal and the LED (4) lights up in orange. If the status of the sensor changes from damped to undamped, the SST emits a signal again and the LED (4) goes... -
Page 11: Maintenance And Care
Remove old batteries and dispose of them properly. Insert new battery. Battery type: 9V compound battery 6LR61 (not included in the scope of delivery) Close the battery compartment cover and snap the lock in place. 06.00 | SST | Assembly and operating manual | en | 389581... -
Page 12: Troubleshooting
The battery is empty or does not have contact. The red LED lights up. The battery is almost empty. Change the battery. Orange LED lights up PNP/NPN switch is set incorrectly. continuously. 06.00 | SST | Assembly and operating manual | en | 389581... -
Page 13: Translation Of The Original Declaration Of Conformity
Reed switches - Part 1: Generic specification (IEC 62246-1:2015) Signed for and on behalf of: SCHUNK SE & Co. KG Lauffen/Neckar, October 2024 i.V. Nico Peper; Director Software and Electronics; Technology & Innovation 06.00 | SST | Assembly and operating manual | en | 389581... -
Page 14: Ukca Declaration Of Conformity
Marcel Machado, address: refer to manufacturer's address Signed for and on behalf of: SCHUNK SE & Co. KG Lauffen/Neckar, October 2024 i.V. Nico Peper; Director Software and Electronics; Technology & Innovation 06.00 | SST | Assembly and operating manual | en | 389581... -
Page 15: Information On The Rohs Directive, Reach Regulation And Substances Of Very High Concern (Svhc)
"on the restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS)", or fulfill their intended function only as part of one. Therefore products from SCHUNK do not fall within the scope of the directive at this time. REACH Regulation Products from SCHUNK fully comply with the regulations of Regulation (EC) No. 1907/2006... - Page 16 SCHUNK SE & Co. KG Spanntechnik | Greiftechnik | Automatisierungstechnik Bahnhofstr. 106 – 134 D-74348 Lauffen/Neckar Tel. +49-7133-103-0 info@de.schunk.com schunk.com Folgen Sie uns I Follow us Wir drucken nachhaltig I We print sustainable...
