Trane TM50 Manual

TM50 series controler applys to industrial, commercial and family room temperature control,
control(the two control of a fan-coil equipped with hot and cold water springs reset electric valve,
four control with the fan-coil and include one cold water and one hot water). Through the keys
may choose to heating,cooling or ventilation function (four control automatic mode).
TM50 use electronic control technology, large-screen LCD. LCD status: work status
(automatic, refrigeration, heating, ventilation), fan speed, indoor temperature, set temperature,
clock, the timing of switching time, weeks, sleep, an so on. Keys are: ON/OF
conversion (M), timing ( ), windspeed options ( ) and the temperature adjustment (56)
Can be equipped with remote control (option), ABS shell for the fire-retardant materials.
AppearanceSize of 86×86mm, thickness of 16 mm.
Appearance
Features： ： ： ：
▼indoor temperature settings
▼indoor temperature measurement and display
▼control fan coil three-speed manual or automatic
transmission
▼electric hot and cold water control valve
▼continuous clock function (optional)
▼regularly switch-function (optional)
▼sleep function
▼white backlight
▼infrared remote control function (optional)
▼temperature calibration
▼degrees Celsius degrees Fahrenheit temperature
switch
▼auxiliary electric heater function (two control
optional ）
Install Specification
1.Use Screwdrivers connect all the exeternal wirings,use screwdriver open the two blocks out of the box!
2.From the inside to open the block and separate the display control panel on the up shell(internal link please do not
disconnect).
3.Install the bottom shell into the wiring boxes,fixed two screw tight.
4.Let the top pillar which inside the up shell fix into the two holes on the bottom shell, press the two shells and make sure it is
close enough
1
TM50 LCD Thermostat
1:power supply :50/60 Hz,100~240V±10
H: an auxiliary electric heater or four control
functions,allocated by the code switch
settings,spacce means no this functions
T: a regular feature, and air that there is no
R: a remote-control function
Replacement
： ： ： ：
2
specification
such function （ c lock,timing,weeks do not
show ）
）
,space means no this functions
Technique index： ： ： ：
▼Setting Temperature range
▼Temperature precision
▼Current load ：
▼Self consumption power
▼Display ： L CD
▼Temperature sensor
▼Key t ouch key
：
▼Power voltage
▼Size 8 6 × 86 × 16 mm
：
▼Distance of fixing
▼Fittings list o ne box for PCBA, one specification,
:
two screw
1
TM50-1□□□
％
（ r emote control
5 ~35
： ℃ （
± 1
： ℃
< 3A
< 1W
：
： N TC
： 5 0/60Hz 、 1 00~240V ± 10
： 6 0 mm (standard)
3
model
□□□ □□□ □□□
4 1~95
℉ ）
％
4
