TRENDnet TEW-411BRP User Manual

TRENDnet TEW-411BRP User Manual

Wireless 802.11g ap router
Hide thumbs Also See for TEW-411BRP:
Table of Contents

Advertisement

Quick Links

Download this manual
TEW-411BRP
Wireless 802.11g AP Router
User's Manual
Version 1.4
User's Guide
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TEW-411BRP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TRENDnet TEW-411BRP

Summary of Contents for TRENDnet TEW-411BRP

  • Page 1 TEW-411BRP Wireless 802.11g AP Router User’s Manual Version 1.4 User’s Guide...
  • Page 2 User’s Guide...

  • Page 3: Copyright Statement

    Copyright Statement No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, recording, or otherwise without the prior writing of the publisher. July. 2003 User’s Guide...

  • Page 4: Table Of Contents

    Contents 1. Introduction......................4 2. Safety Notification ....................5 3. Hardware Installation ....................6 4 Web Management Settings ..................7 4.1. Primary Setup….. ……………………………………………………………………………………….8 4.2. Security …………………………………………………………………………………………………..13 4.3. System ……………………………………………………………………………………………………15 4.4. DHCP Server …….……………………………………………………………………………………..18 4.5. SNMP Info ……………………………………………………………………………………………….20 4.6. Status …………………………………………………………………………………………………….21 4.7.

  • Page 5: Introduction

    1. Introduction Thank you for purchasing your AP Router Wireless 802.11g AP Router. This user guide will assist you with the installation procedure. The package you have received should contain the following items: AP Router Wireless 802.11g AP Router User Guide Power Supply / Cord Ethernet Cable Note: if anything is missing, please contact your vendor...

  • Page 6: Safety Notification

    2. Safety Notification Your Wireless AP Router should be placed in a safe and secure location. To ensure proper operation, please keep the unit away from water and other damaging elements. Please read the user manual thoroughly before you install the device. The device should only be repaired by authorized and qualified personnel.

  • Page 7: Hardware Installation

    3. Hardware Installation Front Panel The front panel provides LED’s for device status. Refer to the following table for the meaning of each feature. STATUS Description PWR/STAT No power 1. Power on 2. Reset to default 3. Firmware upgrade (first 1 Red On minute) Red Blink 1.

  • Page 8: Web Management Settings

    Web Management Settings TURN ON POWER SUPPLY Quick power cycle can caused system corruption. When power on, be careful not to shut down in about 5 seconds, because data is writing to the flash. START UP & LOGIN In order to configure the Wireless 11g AP Router, you must use your web browser and manually input http://192.168.1.1 into the Address box and press Enter.

  • Page 9: Primary Setup

    4.1. Primary Setup MAKE CORRECT NETWORK SETTINGS OF YOUR COMPUTER To change the configuration, use Internet Explorer (IE) or Netscape Communicator to connect the WEB management 192.168.1.1. Primary Setup This screen contains all of the Router' s basic setup functions. Most users will be able to configure the AP Router and get it working properly using the settings on this screen.
  • Page 10 Host Name: This entry is necessary for some ISPs and can be provided by them. Domain Name: This entry is necessary for some ISPs and can be provided by them. Configuration Type: The Router supports four connection types: Dynamic IP Setting Static IP Address PPPoE (Point-to-Point Protocol over Ethernet) PPTP (Point-to-Point Tunneling Protocol)

  • Page 11: Important Notice

    Period is 30 seconds (in other words, the Router will check the Internet connection every 30 seconds). LAN IP Address and Subnet Mask: This is the Router' s IP Address and Subnet Mask as seen on the internal LAN. The default value is 192.168.1.1 for IP Address and 255.255.255.0 for Subnet Mask. Wireless: This section provide the Wireless Network settings for your WLAN SSID: The service set identifier ( SSID ) or network name.
  • Page 12 -WPA-Preshared key There are two encryption options for WPA Pre-Shared Key, TKIP and AES. TKIP stands for Temporal Key Integrity Protocol. TKIP utilizes a stronger encryption method and incorporates Message Integrity Code (MIC) to provide protection against hackers. AES stands for Advanced Encryption System, which utilizes a symmetric 128-Bit block data encryption.
  • Page 13 -WPA RADIUS WPA RADIUS uses an external RADIUS server to perform user authentication. To use WPA RADIUS, enter the IP address of the RADIUS server, the RADIUS Port (default is 1812) and the shared secret from the RADIUS server. Please choose your algorithms method. You can select between TKIP or AES.

  • Page 14: Security

    4.2. Security Router Password: Changing the password for the AP Router is as easy as typing the password into the Enter New Password field. Then, type it again into the Re-enter to confirm. * Click the Apply button to save the setting. Use the default password when you first open the configuration pages, after you have configured these settings, you should set a new password for the Router (using the Security screen).
  • Page 15 Pass-Through is enabled by default. To disable PPTP Pass-Through, uncheck the box next to PPTP. Web Filters: Using the Web Filters feature, you may enable up to four different filters. Proxy - Use of WAN proxy servers may compromise network security. Denying Proxy will •...

  • Page 16: System

    4.3. System Restore Factory Defaults: Click the Yes button to reset all configuration settings to factory default values. Note: Any settings you have saved will be lost when the default settings are restored. Click the No button to disable the Restore Factory Defaults feature. Click the Apply button to save the setting.
  • Page 17 4. On the Firmware Upgrade screen, click the Browse button to find the firmware upgrade file. 5. Double-click the firmware upgrade file. 6. Click the Upgrade button, and follow the on-screen instructions. Note: Do not power off the Router or press the Reset button while the firmware is being upgraded.
  • Page 18 1. Select Enable. 2. Enter your adapter' s MAC address in the MAC Address field. 3. Click the Apply button. To disable MAC address cloning, keep the default setting, Disable. Remote Management: This feature allows you to manage your Router from a remote location, via the Internet.

  • Page 19: Dhcp Server

    4.4. DHCP Server The DHCP Server screen allows you to configure the settings for the Router' s Dynamic Host Configuration Protocol (DHCP) server function. The Router can be used as a DHCP server for your network. A DHCP server automatically assigns an IP address to each computer on your network. If you choose to enable the Router' s DHCP server option, you must configure your entire network PCs to connect to a DHCP server, the Router.
  • Page 20 Enter the amount of time, in minutes, that the user will be "leased" this dynamic IP address. The default is 0 minutes, which means one day. Static DNS 1-3: The Domain Name System (DNS) is how the Internet translates domain or website names into Internet addresses or URLs.

  • Page 21: Snmp Info

    4.5. SNMP SNMP: The SNMP INFO screen allows you to customize the Simple Network Management Protocol (SNMP) settings. SNMP is a popular network monitoring and management protocol. SNMPv2c To enable the SNMP support feature, select Enable. Otherwise, select Disable. Identification Contact contact field,...

  • Page 22: Status

    4.6. Status This screen displays the Wireless Router' s current status and settings. This information is read-only. This page will auto re-flash every 5 seconds to keep most update information. Host Name: The Host Name is the name of the Router. This entry is necessary for some ISPs. Domain Name: The Domain Name is the name of the Router' s domain.
  • Page 23 *Click the Refresh button to refresh the Router' s status and settings. User’s Guide...

  • Page 24: Advanced Wireless

    4.7. Advanced Wireless Wireless MAC Filters: This function allow administrator to have access control by enter MAC address of client stations. When Enable this function, two new options will show up. Depend on the filtering propose, it can be selected to Prevent or Permit. User’s Guide...
  • Page 25 Click on Edit MAC Filter List to add the client stations MAC list. The table could store up to 40 different MAC addresses. Please follow the format that it required when an address is input. Authentication Type: Auto: Auto is the default authentication algorithm.It will change its authentication type automatically to fulfill client’s requirement.
  • Page 26 frame. After receiving an RTS, the wireless station responds with a Clear to Send (CTS) frame to acknowledge the right to begin transmission. Fragmentation Threshold: This value specifies the maximum size for a packet before data is fragmented into multiple packets. It should remain at its default setting of 2346. If you experience a high packet error rate, you may slightly increase the Fragmentation Threshold.

  • Page 27: Access Filters

    4.8. Access Filters User’s Guide...
  • Page 28 The Access Filter screen allows you to block or allow specific kinds of Internet usage. You can set up Internet access policies for specific PCs and set up filters by using network port numbers. This feature allows you to customize up to 10 different Internet Access Policies for particular PCs, which are identified by their IP or MAC addresses.
  • Page 29 To add a service, click the Add button. To edit the settings for a service, click the Modify button. To delete a service, select the service from the box on the right of the screen. Click the Delete button. Click the Apply button to save your changes. Click the Cancel button to undo your changes.

  • Page 30: Virtual Server

    4.9. Virtual Server The Virtual Server screen sets up public services on your network, such as web servers, ftp servers, e-mail servers, or other specialized Internet applications. (Specialized Internet applications are any applications that use Internet access to perform functions such as videoconferencing or online gaming. Some Internet applications may not require any forwarding.) When users send this type of request to your network via the Internet, the Router will forward those requests to the appropriate PC.
  • Page 31 Enable Click the Enable checkbox to enable port forwarding for the application. Port Triggering is used for special Internet applications whose outgoing ports differ from the incoming ports. For this feature, the Router will watch outgoing data for specific port numbers. The Router will remember the IP address of the computer that sends a transmission requesting data, so that when the requested data returns through the Router, the data is pulled back to the proper computer by way of IP address and port mapping rules.

  • Page 32: Routing Table

    4.10. Routing Table On the Routing Table screen, you can set the routing mode and settings of the Router. Gateway mode is recommended for most users. The default setting is Gateway. Operating Mode Choose the correct working mode. Keep the default setting, Gateway, if the Router is hosting your network' s connection to the Internet (Gateway mode is recommended for most users).
  • Page 33 Interface 2. Enter the following data: • Destination IP Address - The Destination IP Address is the address of the network or host to which you want to assign a static route. • Subnet Mask - The Subnet Mask determines which portion of an IP address is the network portion, and which portion is the host portion.

  • Page 34: Dynamic Dns

    4.11. Dynamic DNS The Router offers a Dynamic Domain Name System (DDNS) feature. DDNS lets you assign a fixed host and domain name to a dynamic Internet IP address. It is useful when you are hosting your own website, FTP server, or other server behind the Router. Before using this feature, you need to sign up for DDNS service with one of two DDNS service providers, DynDNS.org or TZO.

  • Page 35: Troubleshooting

    . Troubleshooting Basic Functions Note: If you are using a cable or DSL modem and are experiencing problems connecting to the Internet, follow these steps: 1. Power off your cable or DSL modem, PC, and the Router. 2. Power on your modem and wait a few minutes until the modem has established a connection with your ISP.

  • Page 36: Technical Support

    Resolution: Make sure that each computer has a unique IP Address. If using DHCP through the AP Router, makes sure that each computer is enable DHCP function and restart the computer. Make sure that the Link LED is on. If it is not, try a different network cable. Check each computer for correct network settings.
