TYANO HG68-B8016 Service Engineer's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HG68-B8016
Service Engineer's Manual
2024 August_v1.0f

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HG68-B8016 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TYANO HG68-B8016

Summary of Contents for TYANO HG68-B8016

  • Page 1 HG68-B8016 Service Engineer’s Manual 2024 August_v1.0f...
  • Page 2 Preface Copyright This publication, including all photographs, illustrations, and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any material contained herein, may be reproduced without written consent of manufacturer. ® Copyright 2024 MITAC COMPUTING TECHNOLOGY CORPORATION. All rights reserved. TYAN is a registered trademark of MITAC COMPUTING TECHNOLOGY CORPORATION.

  • Page 3: Table Of Contents

    Safety and Compliance Information (Ukrainian) ���������������������������������������������������������������������47 Safety and Compliance Information (Traditional Chinese) ������������������������������������������������������53 Taiwan BSMI RoHS Declaration ���������������������������������������������������������������������������������������������57 Chapter 1: Product Overview ������������������������������������������������������������������������������������������������58 1.1 About the TYAN HG68-B8016 ..................58 1.2 Features ..........................59 1.3 Standard Parts List ......................61 1.3.1 Box Contents ......................61 1.4 About the Product......................62...
  • Page 4 4.4 Board Parts, Jumpers and Connectors ................98 4.5 LED Definitions ......................110 4.6 Installing Add-In Cards ....................112 4.7 Connecting External Devices ..................113 4.8 Installing the Power Supply ..................114 4.9 Finishing Up ........................115 Chapter 5: BIOS Setup ���������������������������������������������������������������������������������������������������������116 5.1 About the BIOS ......................116 5.1.1 Setup Basics .....................116 5.1.2 Getting Help ......................117 5.1.3 In Case of Problems ..................117...
  • Page 5 5.7.1 Secure Boot Configuration ................200 5.8 Boot ..........................204 5.8.1 Delete Boot Option Configuration ..............206 5.9 Save and Exit ......................207 Chapter 6: Diagnostics ��������������������������������������������������������������������������������������������������������208 6.1 Flash Utility ........................208 6.2 AMIBIOS Post Code (Aptio) ..................209 Appendix I: How to recover UEFI BIOS����������������������������������������������������������������������������������215 Appendix II: Fan and Temperature Sensors ��������������������������������������������������������������������������217 Appendix III: How to Enable AMD fTPM �������������������������������������������������������������������������������220 Appendix IV: Cable Connection ��������������������������������������������������������������������������������������������222 Appendix V: FRU Parts Table �����������������������������������������������������������������������������������������������223...
  • Page 6 Figure 5. TYAN HG68-B88016 System Rear Panel ..............64 Figure 6. TYAN HG68-B8016 System Rear Panel ..............64 Figure 7. TYAN HG68-B8016 Power Supply Unit LED ..............65 Figure 8. TYAN HG68-B8016 Node Top View ................66 Figure 9. TYAN HG68-B8016 Product Dimensions ..............67 Figure 10.
  • Page 7 Figure 50. L-shape Rack in Cabinet ...................92 Figure 51. Chassis in Rack ......................93 Figure 52. Secure Screw on Rack ....................93 Figure 53. HG68-B8016 in Rack....................93 Figure 54. S8016 Board Image ....................95 Figure 55. S8016 Block Diagram ....................96 Figure 56. S8016 Mechanical Drawing ..................97 Figure 57.
  • Page 8 Figure 98. Network Connection Screen Page ................161 Figure 99. NIC Configuration Screen Page ................162 Figure 100. VLAN Configuration Screen Page .................163 Figure 101. Enter Configuration Screen Page ................164 Figure 102. IPv4 Network Configuration Screen Page ............165 Figure 103. IPv6 Network Configuration Screen Page ............166 Figure 104.
  • Page 9 Table 2. TYAN HG68-B8016 Product Specifications ..............59 Table 3. TYAN HG68-G8016 Node Front Panel Input and Output Port ........62 Table 4. TYAN HG68-B8016 Front Panel LED Indicator .............63 Table 5. TYAN HG68-B8016 PSU LED Indicator .................65 Table 6. TYAN HG68-B8016 Pre-Installed Components ............66 Table 7.

  • Page 10: Document Revision History

    Document Revision History Table 1� Document and Reference Support Released Date Version Document Update Public release. 1.0a Update Safety Instructions 1.0b Update Safety Instructions 1.0c Update Product Overview June 1.0d Update Taiwan BSMI RoHS Declaration 1.0e Update Product Specifications August 1.0f Update Safety http://www.tyan.com...

  • Page 11: Fcc Declaration

    z FCC Declaration Notice for the USA Compliance Information Statement (Supplier's Declaration of Conformity, SDoC) FCC Part 15: This device complies with part 15 of the FCC Rules. This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: •...

  • Page 12: Regulatory Compliance

    z Notice for Europe(CE Mark) This product is in conformity with the Council Directive 2014/30/EU and 2014/35/EU. Warning This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference. z VCCI z Regulatory Compliance This equipment is compliant with CB/LVD of Safety: IEC/EN 62368-1.

  • Page 13: Safety And Compliance Information (English)

    Safety and Compliance Information (English) Safety Information Retain and follow all safety and operating instructions provided with your equipment. In the event of a conflict between the instructions in this guide and the instructions in equipment documentation, follow the guidelines in the equipment documentation. Observe all warnings on the product and in the operating instructions.
  • Page 14 General Precautions • Follow all caution and warning instructions marked on the equipment and explained in the accompanying equipment documentation. • Do not directly connect this equipment to outdoor power cables. • This equipment is not intended for use in the immediate or direct visual field of the display work place.
  • Page 15 To avoid damage to the equipment: • The rack width and depth must allow for proper serviceability and cable management. • Ensure that there is adequate airflow in the rack. Improper installation or restricted airflow can damage the equipment. • The rack cannot have solid or restricted airflow doors.
  • Page 16 Equipment Repairs and Servicing • The installation of internal options and routine maintenance and service of this equipment should be performed by technicians, authorized service personnel or trained hardware service personnel who are knowledgeable about the procedures, precautions, and hazards associated with equipment containing hazardous energy levels.
  • Page 17 Redundant Power Supply • To provide a fully redundant power supply, connect each power cord to a separate AC circuit. Each power cord requires properly grounded (earthed) connections. Reliable Earthing • Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (for example, use of power strips).

  • Page 18: Safety And Compliance Information (French)

    Safety and Compliance Information (French) Informations relatives à la sécurité Observez et conservez toutes les instructions relatives à l'utilisation et à la sécurité fournies avec votre équipement. En cas de conflit entre les instructions de ce guide et celles comprises dans la documentation de l'équipement, veuillez suivre les directives de la documentation de l'équipement.
  • Page 19 Précautions générales • Veuillez tenir compte de tous les messages de précaution et d'avertissement figurant sur l'équipement et dans la documentation qui l'accompagne. • Ne connectez pas directement ce produit à des câbles électriques situés à l’extérieur. Cet équipement n'est pas conçu pour être utilisé à proximité d'un écran. Pour éviter les réflexions gênantes dans un lieu de travail où...
  • Page 20 Pour éviter l'endommagement de l'équipement : • La largeur et la profondeur du rack doivent permettre une facilité d'entretien et une gestion des câbles appropriées. • Vérifiez que la circulation de l'air est adaptée dans le rack. Une installation incorrecte ou une circulation de l'air limitée peut endommager l'installation.
  • Page 21 Modifications apportées à l'équipement • N'apportez aucune modification mécanique ou électrique au matériel. TYAN décline toute responsabilité quant à la non-conformité éventuelle d'un produit TYAN modifié. Réparations et maintenance de l'équipement • Confiez l'installation des composants internes et l'entretien ordinaire de cet équipement à...
  • Page 22 Chargement mécanique • Le montage de l'équipement dans le rack doit être étudié de sorte à ne pas provoquer de chargement mécanique inégal. Surcharge du circuit • Soyez également vigilant lorsque vous connectez l'équipement au circuit secteur et à l'effet de surcharge que les circuits peuvent provoquer sur la protection contre les surintensités et le câblage d'alimentation.

  • Page 23: Safety And Compliance Information (German)

    Safety and Compliance Information (German) Sicherheits informationen Folgen Sie den beiliegenden Sicherheits- und Betriebsanweisungen. Falls die Anweisungen in diesen Richtlinien und die Anweisungen in der Produktdokumentation Unterschiede aufweisen, folgen Sie den Anweisungen in der Produktdokumentation. Beachten Sie die Warnungen in der Produktdokumentation und den Betriebsanweisungen. Halten Sie die angegebenen Vorsichtsmaßnahmen ein, um das Risiko von Verletzungen, elektrischen Stromschlägen und Beschädigungen des Geräts zu verringern.
  • Page 24 Allgemeine Vorsichtsmaßnahmen • Beachten Sie alle Warnhinweise auf den Geräten und in der beigefügten Produktdokumentation. • Schließen Sie dieses Gerät nicht direkt an Stromkabel im Freien an. • Dieses Gerät ist nicht für die Verwendung im unmittelbaren Gesichtsfeld am Bildschirmarbeitsplatz vorgesehen.
  • Page 25 • Bestücken Sie Racks immer von unten nach oben. Bauen Sie die schwerste Komponente zuerst ein. • Stellen Sie sicher, dass das Rack gerade und stabil steht, bevor Sie ein Gerät aus dem Rack herausnehmen. • Stellen Sie sicher, dass immer nur eine Komponente herausgezogen wird. Das Rack kann instabil werden, wenn mehrere Komponenten gleichzeitig herausgezogen werden.
  • Page 26 • Entsorgen Sie gebrauchte Batterien gemäß den Anweisungen des Herstellers. Entsorgen Sie Batterien nicht im Haushaltsmüll. Um Batterien zu recyceln oder ordnungsgemäß zu entsorgen, bringen Sie diese zu einer öffentlichen Sammelstelle oder geben Sie sie an TYAN oder einen autorisierten TYAN-Händler zurück. Vorsicht: Wenn die Batterie durch einen falschen Typ ersetzt wird, besteht Explosionsgefahr.
  • Page 27 Erhöhte Betriebsumgebungstemperatur • Bei Installation in einem geschlossenen oder mehrere Einheiten umfassenden Racksystem kann die Betriebstemperatur der Rackumgebung über der Raumumgebungstemperatur liegen. Daher ist darauf zu achten, dass das Gerät in einer Umgebung installiert wird, in der die vom Hersteller angegebene maximale Umgebungstemperatur (TMA) nicht überschritten wird.

  • Page 28: Safety And Compliance Information (Hebrew)

    Safety and Compliance Information (Hebrew) ‫מידע אודות בטיחות‬ ‫יש לשמור את ההוראות ההפעלה המצורפות לציוד ולפעול בהתאם להן. במקרה של סתירה בין ההוראות‬ .‫שבמדריך זה לבין ההוראות שבתיעוד הציוד, יש לפעול בהתאם להנחיות שבתיעוד הציוד‬ ‫יש לציית לכל האזהרות שעל המוצר ושבהוראות ההפעלה. למניעת פציעה, התחשמלות, שריפה ונזק לציוד, יש‬ .‫לפעול...
  • Page 29 ‫אמצעי זהירות כלליים‬ ‫יש לפעול בהתאם לכל האזהרות והנחיות הזהירות המסומנות על גבי הציוד, והמוסברות בתיעוד המצורף‬  .‫לציוד‬ .‫אין לחבר ציוד זה ישירות לכבל מתח מחוץ למבנה‬  ‫הציוד אינו מיועד לשימוש בקרבה מידית או ישירה במקום התצוגה. למניעת השתקפויות בתצוגה, אין‬ ...
  • Page 30 ‫כבלי חשמל‬ ‫יש להשתמש אך ורק בכבלי חשמל ובספקי כוח שצורפו לציוד. ייתכן שיהיה לציוד כבל חשמל אחד או‬  .‫יותר‬ .‫חבר את כבל החשמל לשקע חשמל מוארק (עם אדמה) אשר הגישה אליו נוחה‬  .‫הקפד לחבר את כבל החשמל לשקע חשמלי עם חיבור הארקה‬ ...
  • Page 31 .‫לצמצום סכנת ההתחשמלות, נתק את כל כבלי החשמל לפני מתן שירות לציוד‬ :‫זהירות‬ .‫ ללא הכיסוי. אי ציות לאמצעי זהירות זה עלול לגרום לפציעה ולנזק לציוד‬Tyan ‫אין להפעיל את מוצרי‬ :‫זהירות‬ :‫זהירות‬ .‫אם הציוד כולל ידיות מדף, אל תשתמש בהן לצורך הרמה או שינוע הציוד‬ ‫טמפרטורת...

  • Page 32: Safety And Compliance Information (Russian)

    Safety and Compliance Information (Russian) Информация о технике безопасности Сохраняйте и соблюдайте все инструкции по технике безопасности и эксплуатации, прилагаемые к вашему оборудованию. В случае обнаружения противоречия между инструкциями в данном руководстве и инструкциями в документации к оборудованию следуйте указаниям в документации к оборудованию. Соблюдайте...
  • Page 33 Общие меры предосторожности • Следуйте всем инструкциям по технике безопасности и предупреждениям, имеющимся на оборудовании и объясненным в сопроводительной документации к оборудованию. • Не подключайте данное оборудование напрямую к наружным силовым кабелям. • Данное оборудование не предназначено для использования в непосредственной или...
  • Page 34 • перед установкой оборудования в стойку убедитесь, что стойка стоит ровно и устойчиво; • убедитесь, что выравнивающие опоры выдвинуты до пола; • убедитесь, что вся масса стойки приходится на выравнивающие опоры; • всегда загружайте стойку в направлении снизу вверх, сначала загрузите в стойку самый...
  • Page 35 Батареи • Батарея, используемая в оборудовании, содержит литий-диоксид марганца. При неправильном обращении с блоком батарей существует риск возгорания и получения ожогов. • Не разбирайте, не раздавливайте, не прокалывайте батарею, не замыкайте ее внешние контакты и не бросайте ее в огонь или воду. •...
  • Page 36 • Обязательно установите крышку на место перед включением системы. ОСТОРОЖНО! Чтобы снизить риск поражения электрическим током, перед выполнением обслуживания оборудования отключите все шнуры питания. ОСТОРОЖНО! Не используйте изделия Tyan без установленной на место крышки. Несоблюдение этой меры предосторожности может привести к травмированию и...
  • Page 37 • Избегайте прямого воздействия лазерного луча. Не открывайте корпус лазерного устройства. Внутри нет компонентов, обслуживаемых пользователем. • Не пользуйтесь элементами управления, не производите корректировку и не выполняйте процедуры с лазерным устройством, кроме указанных в настоящем документе. • Позволяйте ремонтировать лазерное устройство только авторизованным специалистам...

  • Page 38: Safety And Compliance Information (Italian)

    Safety and Compliance Information (Italian) Informations relatives à la sécurité Conservare e attenersi a tutte le istruzioni sulla sicurezza e sull'utilizzo fornite con l'apparecchiatura. In caso di conflitto tra le istruzioni contenute in questa guida e quelle all'interno della documentazione dell'apparecchiatura, attenersi a queste ultime. Osservare tutte le avvertenze riportate sul prodotto e incluse nelle istruzioni di utilizzo.
  • Page 39 Precauzioni generali • Attenersi a tutte le istruzioni associate ai simboli di attenzione e avvertenza riportate sull'apparecchiatura e dettagliate nella relativa documentazione. • Non collegare direttamente il prodotto a cavi di alimentazione esterni. • Questa apparecchiatura non è destinata all'uso nel campo visivo immediato o diretto della postazione di lavoro display.
  • Page 40 Per evitare danni all'apparecchiatura, osservare le seguenti indicazioni: • La larghezza e la profondità del rack devono essere tali da consentire un accesso agevole ai cavi e facilitare gli interventi di manutenzione. • Assicurarsi che il flusso di aria nel rack sia sufficiente. Un'installazione incorretta o un flusso di aria insufficiente può...
  • Page 41 Modifiche all'apparecchiatura • Non modificare i componenti elettrici o meccanici dell'apparecchiatura. TYAN non sarà responsabile della conformità ai regolamenti di un prodotto TYAN modificato. Riparazione e manutenzione delle apparecchiature • L'installazione di componenti opzionali interni, la manutenzione ordinaria e l'assistenza di questa apparecchiatura devono essere eseguite da technicians, authorized service personnel or trained hardware service personnel, con le conoscenze necessarie delle procedure, delle precauzioni e dei rischi associati ad apparecchiature che utilizzano livelli...
  • Page 42 Caricamento meccanico • Il montaggio dell'apparecchiatura in un rack deve avvenire in modo tale che non si verifichino situazioni di rischio dovute a un carico meccanico irregolare. Sovraccarico del circuito • Prestare attenzione al collegamento dell'apparecchiatura al circuito di alimentazione e agli effetti che un sovraccarico dei circuiti potrebbe avere sulla protezione da sovraccarico di corrente e sui cavi di alimentazione.

  • Page 43: Safety And Compliance Information (Spanish)

    Safety and Compliance Information (Spanish) Información sobre seguridad Conserve y siga todas las instrucciones de seguridad y operación del producto que se suministran junto con el equipo. En caso de que las instrucciones de esta guía y las suministradas en la documentación del equipo no coincidan, siga las instrucciones suministradas en la documentación del equipo.
  • Page 44 Precauciones generales • Siga todas las instrucciones de las notas de precaución y de advertencia presentes en el equipo cuya explicación se suministra en la documentación del equipo. • No conecte este producto con cables de alimentación para uso en exteriores directamente. •...
  • Page 45 Para evitar daños en el equipo: • El ancho y la profundidad del bastidor deben permitir la realización de tareas de servicio técnico y tendido de cables con comodidad. • Asegúrese de que haya una correcta circulación del aire en el bastidor. Una instalación incorrecta o una circulación de aire restringida pueden dañar el equipo.
  • Page 46 Modificaciones del equipo • No realice modificaciones de tipo mecánico ni eléctrico en el equipo. TYAN no se hace responsable del cumplimiento de la normativa en caso de que un producto TYAN se haya modificado. Reparación y servicio técnico del equipo •...
  • Page 47 Circulación reducida del aire • La instalación del equipo en un bastidor no debe afectar la cantidad necesaria de aire que debe circular para el funcionamiento seguro del equipo. Carga mecánica • Durante el montaje del equipo en el bastidor se debe evitar llegar a una condición peligrosa debido a un desequilibrio en la carga mecánica.

  • Page 48: Safety And Compliance Information (Ukrainian)

    Safety and Compliance Information (Ukrainian) Інформація про безпеку Зберігайте цей документ та дотримуйтесь всіх інструкцій з техніки безпеки та експлуатації, які надаються разом із вашим обладнанням. У разі наявності конфлікту між інструкціями в цьому посібнику та інструкціями в документації до обладнання дотримуйтеся...
  • Page 49 Загальні запобіжні заходи • Дотримуйтесь всіх застережень і попереджень, зазначених на обладнанні та у супровідній документації до нього. • Не підключайте це обладнання безпосередньо до зовнішніх кабелів живлення. • Це обладнання не призначене для використання поруч або в полі зору екрану робочого...
  • Page 50 • Перш ніж витягувати компонент зі стійки, переконайтеся, що стійка стоїть рівно і стійко. • Переконайтеся, що одночасно збільшується лише один компонент. Стійка може стати нестійкою, якщо збільшити кілька компонентів одночасно. Щоб уникнути пошкодження обладнання: • Ширина та глибина стійки повинні забезпечувати належні умови для зручного обслуговування...
  • Page 51 • Утилізуйте використані батареї відповідно до інструкцій виробника. Не викидайте батареї разом із звичайним офісним сміттям. Для повторної переробки або належної утилізації скористайтеся громадськими установами з переробки або поверніть батарею до MiTAC, свого авторизованого партнера MiTAC або їхніх агентів. УВАГА! Якщо...
  • Page 52 Підвищена робоча температура навколишнього середовища • У разі встановлення в закритій або багато блочній стійці робоча температура навколишнього середовища в середині стійки може перевищувати температуру навколишнього середовища в приміщенні. Тому слід звернути увагу на встановлення обладнання в середовищі, сумісному з максимальною робочою температурою навколишнього...
  • Page 53 Nordic Grounded Socket Cautions English Caution: The appliance must be connected to a grounded socket. Norge Caution: Apparatet må tilkoples jordet stikkontakt. Sverige Caution: Apparaten skall anslutas till jordat uttag. Suomi Caution: Laite on liitettävä suojamaadoitus koskettimilla varustettuun pistorasiaan. Danmark Caution: Apparatets stikprop skal tilstuttes en stikkontakt med jord som giver forbindelse til stikproppens jord.

  • Page 54: Safety And Compliance Information (Traditional Chinese)

    Safety and Compliance Information (Traditional Chinese) 安全資訊 安全資訊 保留並遵循隨設備提供的所有安全操作說明。若本指南中的說明和設備文件中的說明有所衝突， 請遵循設備文件中的指示。 仔細查看產品上和操作說明中的所有警告。為降低人身傷害、電擊、火災和造成設備損壞的風險， 請遵守本指南中的所有安全注意事項。 安裝、操作或維修產品之前，必須先熟悉本指南中的安全資訊。 設備上的符號 設備上的符號 警告 : : 警告 有對人體造成傷害並損壞設備的風險。請遵照產品文件所提供或產品上 所顯示的指示操作。 請於以下網站讀取電子手冊。 https://www.tyan.com/ 警告 : : 警告 危險的轉動扇葉片，請與轉動中的扇葉片保持距離。 警告 : : 警告 灼熱部件。請勿碰觸。表面溫度很高，碰觸可能對人體造成傷害。請在 接觸之前先讓表面溫度冷卻下來。 警告 : : 警告 存在危險的電壓。為降低觸電和危害人身健康的風險，請遵照說明操作。 警告 : : 警告...
  • Page 55 一般注意事項 一般注意事項 • 請遵循設備上標註以及隨附設備文件中說明的所有注意事項和警告資訊。 • 請勿將本設備直接連接至室外電纜。 • 本設備並非適用於顯示器工作中心的直接視場中。為避免在顯示器工作中心產生反射，本產品 不可置於直接視場中。 • 本設備不適合在兒童可能會出現的場所使用。 機房環境 機房環境 • 本設備僅適用於機房或資訊室。 • 確保系統安裝的區域通風良好，溫度和濕度等可控制。 • 確保機房電源的電壓和頻率與設備電力標籤上標示的電壓和頻率相符。 • 請勿將設備安裝於或靠近高壓、通風管、散熱器的地方。 • 請勿在潮濕的環境中使用本設備。 機殼 機殼 • 請勿堵塞或蓋住設備的開孔。 • 請勿將任何物體插入設備的開孔。內部可能存在危險電壓。 • 導電的異物可能造成短路並引起火災、電擊或設備損壞。 • 雙膝彎曲，用雙手提起設備。 設備機架 設備機架 為避免人身傷害或設備損壞： • 遵守當地的職業健康和安全規定以及人力搬運物料的指導原則。 • 請勿嘗試獨自搬動機架，搬動機架至少需要兩人。 •...
  • Page 56 電源線 電源線 • 僅使用隨設備提供的電源線和電源裝置。 設備可能配有一條或多條電源線。 • 將電源線插入到能隨時方便接觸到的接地電源插座。 • 確保將電源線連接到具有接地連接的插座。 • 在歐洲供電環境中，您必須將電源線上的綠色 / 黃色接頭接地。如果未將綠色 / 黃色接頭接 地，可能會由於大量電流洩漏而造成電擊。 • 請勿在交流電源線或纜線上放置物體。將電源線或纜線放在人們不易踩到或被絆倒的地方。 • 請勿拉扯電源線或纜線。從電源插座拔下電源線時，應抓住電源線插頭。 • 為降低電擊風險，請在維修設備之前，拔除所有電源線。 電池 電池 • 本設備使用鋰錳電池。如果電池組處理不當，則會有起火的風險。 • 請勿拆解、擠壓、穿刺電池，將其投入火中或水中，或使其與外部短路接觸。 • 請勿將電池置於 60° C (140° F) 以上的高溫環境中。 • 請勿嘗試為電池充電。 • 按照製造商的指示處置使用過的電池。切勿將電池當作一般辦公室垃圾處理。若要回收或正確 處置電池，請利用公共收集系統，或將其送回授權合作夥伴或其代理。 警告...
  • Page 57 操作環境溫度升高 操作環境溫度升高 • 如果將此設備安裝在封閉式或具有多個設備的機架上，機架的操作環境溫度可能會高於設備房 間的溫度。因此，在安裝此設備時必須考慮滿足生產廠商規定的最高操作環境溫度 ( Tma ) 要 求。 通風不夠 通風不夠 • 將設備安裝於機架上要注意不會有造成安全操作設備所需的通風出現不良的狀況。 機械負載 機械負載 • 將設備安裝於機架上要注意不會有因為機械負載不均而出現危險的狀況。 電路過載 電路過載 • 將設備連接到供電電路時必須考量一些狀況，還有電路過載可能對過流防護及供電線路的影 響。對於這類疑慮，必須妥善考量設備標示牌上的額定值。 備援式電源供應 備援式電源供應 • 為提供完整的備援電源供應，請將每條電源線分別連接到各的交流電路。每條電源線需要適當 地接地。 可靠的接地 可靠的接地 • 安裝於機架上的設備必須保有可靠的接地連接。請特別注意未直接連接分支電路的電源供應 ( 例如使用延長線 )。 雷射裝置 雷射裝置 本產品可能包含於 IEC60825-1 定義下級別為第 1 類的雷射光。為降低暴露於輻射中的風險，使 用雷射裝置時請遵循這些注意事項：...

  • Page 58: Taiwan Bsmi Rohs Declaration

    Taiwan BSMI RoHS Declaration 設備名稱：伺服器 / / 型號（型式） 型號（型式）: : HG68-B8016 設備名稱：伺服器 Equipment Name: Server / Type: HG68-B8016 限用物質及其化學符號 限用物質及其化學符號 Restricted substances and its chemical symbols 單位 Unit 六價鉻 多溴聯苯 多溴二苯醚 鉛 汞 鎘 Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium...

  • Page 59: Chapter 1: Product Overview

    HG68-B8016 not only empowers your company in nowadays IT demand but also offers a smooth path for future application usage. TYAN® also offers the HG68-B8016 in a version that uses TYAN’s latest chassis featuring a robust structure and a solid mechanical enclosure. All of this provides HG68-B8016 the power and flexibility to meet the needs of nowadays server application.

  • Page 60: Table 2. Tyan Hg68-B8016 Product Specifications

    1�2 Features Table 2� TYAN HG68-B8016 Product Specifications Form Factor 6U Rackmount Chassis Name HG68 System Dimension (D x W x H) 26.85" x 17.60" x 10.44" (682 x 447 x 265.3mm) Motherboard S8016AGM2NR Buttons (1) PWR w/ LED / (1) RST...

  • Page 61: Features

    Operating System OS supported list Please refer to our AVL support lists. RoHS RoHS 6/6 Compliant Barebone (1) HG68-B8016 Barebone Package Contains Manual (1) Quick Installation Guide Note: 1. The specifications are subject to change without prior notice. 2. Please visit our Web site for the latest specifications.

  • Page 62: Standard Parts List

    1�3 Standard Parts List This section describes HG68-B8016 package contents and accessories. Open the box carefully and ensure that all components are present and undamaged. The product should arrive packaged as illustrated below. 1�3�1 Box Contents HG68-B8016 Box Contents •...

  • Page 63: About The Product

    1�4 About the Product The following views show you the product. 1�4�1 System Front Panel Figure 2� TYAN HG68-B8016 Front Panel Figure 3� TYAN HG68-B8016 Node Front Panel Table 3� TYAN HG68-G8016 Node Front Panel Input and Output Port Item Description...

  • Page 64: Figure 4. Tyan Hg68-B8016 Front Panel Board

    Power Button HDD LED with LED Reset Button Reset Button Figure 4� TYAN HG68-B8016 Front Panel Board Table 4� TYAN HG68-B8016 Front Panel LED Indicator Color Description System Power off / off Power LED Green System Power On / solid on...

  • Page 65: System Rear Panel

    1�4�2 System Rear Panel Figure 5� TYAN HG68-B88016 System Rear Panel PSU1 PSU1 PCIe slots PCIe slots PSU0 PSU0 Figure 6� TYAN HG68-B8016 System Rear Panel http://www.tyan.com...

  • Page 66: Figure 7. Tyan Hg68-B8016 Power Supply Unit Led

    Figure 7� TYAN HG68-B8016 Power Supply Unit LED Table 5� TYAN HG68-B8016 PSU LED Indicator LED State Power Supply Status Green Power suppy status is active and normal. There is no AC power supplied to any of the power units.

  • Page 67: Node Top View

    1�4�3 Node Top View Figure 8� TYAN HG68-B8016 Node Top View Table 6� TYAN HG68-B8016 Pre-Installed Components Item Description Front Control Panel (M1723G86-FPB pre-installed) PCIe Riser Extension Cable MiTAC S8016 Serverboard Two 80x38mm Fan Power Distribution Board ( M1634T45-PDB pre-installed)

  • Page 68: Chassis Dimensions

    1�4�4 Chassis Dimensions 265.3mm 685mm 447mm Figure 9� TYAN HG68-B8016 Product Dimensions http://www.tyan.com...

  • Page 69: Chapter 2: Hardware Setup

    Chapter 2: Hardware Setup 2�1 Before you Begin This chapter explains how to install the CPUs, CPU heat sinks, memory modules, and SSD/HDD. Instructions on inserting add on cards are also given. 2�1�1 Work Area Make sure you have a stable, clean working environment. Dust and dirt can get into components and cause malfunctions.

  • Page 70: Precautions

    Components and electronic circuit boards can be damaged by discharges of static electricity. Working on a system that is connected to a power supply can be extremely dangerous. Follow the guidelines below to avoid damage to HG68-B8016 or injury to yourself. •...

  • Page 71: Installing The Processor And Heat Sink

    2�2 Installing the Processor and Heat Sink HG68-B8016 supported AMD® processors. Check our website at http://www.tyan.com latest processor support. Note: MITAC TYAN is not liable for damage as a result of operating an unsupported configuration. 2.2.1 Processor Installation Follow the steps below to install the processors and heat sinks.

  • Page 72: Figure 12. Install Processor Package

    3. Align and seat the processor package on the socket. Make sure the gold arrow is located in the right direction. Figure 12� Install Processor Package 4. Close the load plate. Figure 13� Close Processor Load Plate 5. Remove and save the ILM cover. Figure 14�...

  • Page 73: Figure 15. Close Processor Ilm Lever

    6. Close the ILM lever and latch. Figure 15� Close Processor ILM lever http://www.tyan.com...

  • Page 74: Heat Sink Installation

    2.2.2 Heat Sink Installation After installing the processor, you will need to proceed to install the heat sink. The CPU heat sink will ensure that the processor do not overheat and continue to operate at maximum performance for as long as you own them. An overheated processor is dangerous to the motherboard.

  • Page 75: Figure 18. Secure Heat Sink Screw

    3. Secure the heat sink screws. Figure 18� Secure Heat Sink Screw 4. Connect the heat sink fan cable. Figure 19� Install Fan Cable http://www.tyan.com...

  • Page 76: Thermal Interface Material

    2�2�3 Thermal Interface Material Figure 20� CPU Heat Sink There are two types of thermal interface materials designed for use with the processors. The most common material comes as a small pad attached to the heat sink at the time of purchase.

  • Page 77: Tips On Installing Motherboard In Chassis

    2�2�4 Tips on Installing Motherboard in Chassis Before installing your motherboard, make sure your chassis has the necessary motherboard support studs installed. These studs are usually metal and are gold in color. Usually, the chassis manufacturer will pre-install the support studs. If you are unsure of stud placement, simply lay the motherboard inside the chassis and align the screw holes of the motherboard to the studs inside the case.

  • Page 78: Figure 22. Mounting Serverboard Screw

    Some chassis include plastic studs instead of metal. Although the plastic studs are usable, MiTAC recommends using metal studs with screws that will fasten the motherboard more securely in place. Below is a chart detailing what the most common motherboard studs look like and how they should be installed.

  • Page 79: Installing The Memory

    2�3 Installing the Memory Before installing memory, ensure that the memory you have is compatible with the motherboard and processor. Check the TYAN Web site at http://www.tyan.com for details of the type of memory recommended for your motherboard. 2.3.1 DIMM Location Figure 23�...

  • Page 80: Table 7. Recommended Ddr5 Socket Memory Configurations

    Table 7� Recommended DDR5 Socket Memory Configurations http://www.tyan.com...

  • Page 81: Figure 24. Unlock Dimm Socket

    2.3.2 Memory Installation 1. Unlock the DIMM clips. Figure 24� Unlock Dimm Socket 2. Insert the memory module securely into the socket by gently pressing downward until it is level with the socket. Figure 25� Install DIMM 3. Lock the clips to secure the memory module. Figure 26�...

  • Page 82: Chapter 3: Replacing Pre-Installed Components

    Chapter 3: Replacing Pre-Installed Components 3�1 Introduction This chapter provides instructions on replacing the pre-installed components, such as the Motherboard, Front Panel Board,Riser Card, Power Distribution Board, System Fan, and Power Supply Unit. 3�1�1 Disassembly Flow Chart The following flowchart outlines the disassembly procedures. Components Compute Node Front Panel Board...

  • Page 83: Compute Node

    3.2 Compute Node TYAN HG68-B8016 supports 5 compute nodes with tool-less removal support. 1. Identify the compute node in the system rear panel. See section 1.4.2 System Rear Panel. 2. Press the latch and pull the handle to release the compute node from the chassis.

  • Page 84: Power Supply Unit

    3.3 Power Supply Unit TYAN HG68-B8016 supports 80 plus Titanium redundant power supply per node. The power supply unit is fixuated at the rear panel of the chassis. See section 1.4.2 System Rear Panel. Note: The power supply unit can be replaced without requiring the removal of the top cover of the compute node.

  • Page 85: Power Distribution Board

    3.4 Power Distribution Board HG68-B8016 supports 1 PDB (power distribution board) and 1 PBP (Power Backplane Board). See section 1.4.3 Node Top View. Note: Confirm that the cables are disconnected from the power distribution board before proceeding with the installation. 1. Remove the compute node from the chassis. See section 3.2 Compute...

  • Page 86: Figure 35. Power Distribution Board Release Lock

    6. Unlock the bracket and lift it upward. Figure 35� Power Distribution Board Release Lock 7. Disengage 4 screws to remove the power distribution board. Figure 36� Power Distribution Board Screw Placement 8. Disengage 4 screws from the power backplane board. Figure 37�...

  • Page 87: Fan

    3.5 Fan TYAN HG68-B8016 supports 2 easy-swap fans per node with tool-less removal support. Note: Verify that the fan is oriented correctly to ensure proper airflow. 1. Remove the compute node from the chassis. See section 3.2 Compute Node. 2. Lift the fan from the chassis.

  • Page 88: Front Panel Board

    3.6 Front Panel Board TYAN HG68-B8016 supports 1 front panel board per node. The front panel board is fixauted at the front panel of the chassis. See section 1.4.1 System Front Panel. Note: Verify that the cables are disconnected from the front panel board before proceeding with the installation.

  • Page 89: Riser Card

    3.7 Riser Card HG68-B8016 supports 2 riser cards: 1 fixuated near the front panel and 1 fixauted at the rear panel. See section 1.4.3 Node Top View. 3.7.1 Front Riser Card 1. Remove the compute node from the chassis. See section 3.2 Compute Node.

  • Page 90: Rear Riser Card

    3.7.2 Rear Riser Card 1. Remove the compute node from the chassis. See section 3.2 Compute Node. 2. Remove the top cover of the compute node. See section 3.2 Compute Node. 3. Disengage 4 screws on the PCI bracket. Figure 43� Rear PCIe Bracket Screw Placement A 4.

  • Page 91: Figure 44. Rear Pcie Bracket Screw Placement B

    5. Disengage the screw from the PCIe bracket. Figure 44� Rear PCIe Bracket Screw Placement B 6. Insert the PCI card into the bracket. Note: Confirm that the PCIe gold finger is completely inserted into the server board. Figure 45� Riser Card Installation 7.

  • Page 92: Figure 47. Pcie Bracket Installation

    8. Insert the PCIe bracket into the compute node. Figure 47� PCIe Bracket Installation http://www.tyan.com...

  • Page 93: Slide Rail

    3.8 Slide Rail After installing the necessary components, the TYAN HG68-B8016 can be mounted in a rack using the supplied rack mounting kit. Note: Due to the weight of the system, the initial action is to mount it onto the rack, excluding the node.

  • Page 94: Figure 51. Chassis In Rack

    Figure 51� Chassis in Rack 4. Push the chassis completely into the rack cabinent and secure 2 captive screws. Figure 52� Secure Screw on Rack 5. Install the node into the chassis to complete installation. Figure 53� HG68-B8016 in Rack http://www.tyan.com...

  • Page 95: Chapter 4: Mainboard Information

    Chapter 4: Mainboard Information As you prepare to install your motherboard, the initial step is to thoroughly peruse the accompanying user manual. Within its contents lie pertinent details essential for streamlining the configuration and setup procedures. Below are several precautionary measures to adhere to during the installation process: 1.

  • Page 96: Board Image

    4�1 Board Image Figure 54� S8016 Board Image This picture is representative of the latest board revision available at the time of publishing. The board you receive may not look exactly like the above picture. http://www.tyan.com...

  • Page 97: Block Diagram

    4�2 Block Diagram Figure 55� S8016 Block Diagram http://www.tyan.com...

  • Page 98: Mainboard Mechanical Drawing

    4�3 Mainboard Mechanical Drawing Figure 56� S8016 Mechanical Drawing http://www.tyan.com...

  • Page 99: Board Parts, Jumpers And Connectors

    4�4 Board Parts, Jumpers and Connectors This diagram is representative of the latest board revision available at the time of publishing. The board you receive may not look exactly like the above diagram. But for the DIMM number please refer to the above placement for memory installation. For the latest board revision, please visit our web site at http://www.tyan.com.

  • Page 100: Table 8. Jumper And Connector

    Table 8� Jumper and Connector Connectors 1. 8-pin, CPU and CPU MEM Power 10. 24-pin ATX Power Connector (J_PW1) Connector (12V input) (J_PW2) 2. M.2 Connector (J_M2CN2) 11. 3 port audio jack (J_F8) 3. M.2 Connector (J_C2CN1) 12. RJ45 (J_F6) 4.

  • Page 101: Table 10. Fan Connector (J_Cpufan1/J_Sysfan1/J_Sysfan2/J_Sysfan3/J_Sysfan4)

    Table 10� Fan Connector (J_CPUFAN1/J_SYSFAN1/J_SYSFAN2/J_SYSFAN3/J_SYSFAN4) Signal P12V TACHOMETER Use this header to connect the cooling fan to your motherboard to keep the system stable and reliable. Table 11� HDT Header (J2) Signal Signal P1V8_HDT 11 HDT_HDR_AM5_TEST17 APU_TCK 12 HDT_HDR_RST_N 13 HDT_HDR_AM5_TEST16 APU_TMS 14 HDT_HDR_DBRDY 15 HDT_CPU_DBRDY1...

  • Page 102: Table 15. Port80 Debug Header (J_Db1)

    Table 15� Port80 DEBUG Header (J_DB1) Signal Signal P3V3_VCC_DB DBG_ESPI_CS0_N DBG_ESPI_IO_0 DBG_ESPI_IO_1 DBG_ESPI_RST_N DBG_ESPI_IO_2 DBG_ESPI_IO_3 10 DBG_ESPI_CLK 11 DBG_ESPI_ALRT1_N 12 GND Table 16� BMC AST2600 DEBUG Header (J4) Signal Signal P3V3_AUX_ASD_D TP_RST_JTAG JTAG_ASD_TDO_CONN JTAG_ASD_TMS_CONN JTAG_ASD_TDI_CONN JTAG_ASD_NTRST_N_CONN JTAG_ASD_TCK_CONN Table 17� Power Controller SMBus Header (PJ1) Signal Signal SMBUS0_VR_HDR_STBY_LVC3_SCL...

  • Page 103: Table 20. Sata Connector (J_Sata3/J_Sata4)

    Table 20� SATA Connector (J_SATA3/J_SATA4) Signal SATA_PT21_TX_C_DP2 SATA_PT21_TX_C_DN2 SATA_PT21_RX_C_DN2 SATA_PT21_RX_C_DP2 MT1 GND MT2 GND Table 21� Front Panel Header (J_HDFP1) Signal Signal P5V_LED_A GRN_BLNK_HR LED_HDD_ACT_N YLW_BLNK_HR FP_PWR_BTN_R_N FP_RST_BTN_R_N Table 22� Front Panel USB Header (J_USB1) Signal Signal P5V_USB3_HD1 11 USB2_PT21_P2_CMC_P1 USB3_PT21_P2_RX_CMC_N0 12 USB2_PT21_P2_CMC_N1 USB3_PT21_P2_RX_CMS_P0...

  • Page 104: Table 25. Clear Cmos Jumper (J_Cmos_Clr)

    Table 25� Clear CMOS Jumper (J_CMOS_CLR) Signal Signal VBAT VDDBT_RTC_R Pin1-2 closed: Normal Mode (Default) Pin2-3 closed: Clear CMOS Table 26� BIOS Update by USB Header (J_USB_UPDATE) Signal Signal NC_USB_BIOS_UPDATE USB_BIOS_UPDATE_R EN_USB_BIOS_UPDATE Pin1-2 closed: Normal Mode (Default) Pin2-3 closed: Enable BIOS USB Update Table 27�...
  • Page 105 Signal Signal A18 GND B18 GND A19 PD_SLOT6_A19_RSVD_HFF B19 P5E_AM5_SLOT6_TX_C_DP<1> A20 GND B20 P5E_AM5_SLOT6_TX_C_DN<1> A21 P5E_AM5_SLOT6_RX_DP<1> B21 GND A22 P5E_AM5_SLOT6_RX_DN<1> B22 GND A23 GND B23 P5E_AM5_SLOT6_TX_C_DP<2> A24 GND B24 P5E_AM5_SLOT6_TX_C_DN<2> A25 P5E_AM5_SLOT6_RX_DP<2> B25 GND A26 P5E_AM5_SLOT6_RX_DN<2> B26 GND A27 GND B27 P5E_AM5_SLOT6_TX_C_DP<3>...

  • Page 106: Table 29. Pcie Slot / Gen4 Physical X8 Connector (J_Pcie4)

    Signal Signal A59 GND B59 P5E_AM5_SLOT6_TX_C_DN<10> A60 P5E_AM5_SLOT6_RX_DP<10> B60 GND A61 P5E_AM5_SLOT6_RX_DN<10> B61 GND A62 GND B62 P5E_AM5_SLOT6_TX_C_DP<11> A63 GND B63 P5E_AM5_SLOT6_TX_C_DN<11> A64 P5E_AM5_SLOT6_RX_DP<11> B64 GND A65 P5E_AM5_SLOT6_RX_DN<11> B65 GND A66 GND B66 P5E_AM5_SLOT6_TX_C_DP<12> A67 GND B67 P5E_AM5_SLOT6_TX_C_DN<12> A68 P5E_AM5_SLOT6_RX_DP<12> B68 GND A69 P5E_AM5_SLOT6_RX_DN<12>...
  • Page 107 Signal Signal A15 GND B15 P4E_PT21_SLOT4_TX_C_DN<0> A16 P4E_PT21_SLOT4_RX_DP<0> B16 GND A17 P4E_PT21_SLOT4_RX_DN<0> B17 RST_PCIE4_PRSNT_N_0 A18 GND B18 GND A19 PD_SLOT4_A19_RSVD_HFF B19 P4E_PT21_SLOT4_TX_C_DP<1> A20 GND B20 P4E_PT21_SLOT4_TX_C_DN<1> A21 P4E_PT21_SLOT4_RX_DP<1> B21 GND A22 P4E_PT21_SLOT4_RX_DN<1> B22 GND A23 GND B23 P4E_PT21_SLOT4_TX_C_DP<2> A24 GND B24 P4E_PT21_SLOT4_TX_C_DN<2>...

  • Page 108: Table 30. Pcie Slot / Gen4 Physical X4 Connector (J_Pcie5)

    Table 30� PCIE SLOT / Gen4 Physical x4 Connector (J_PCIE5) Signal Signal A1 GND B1 P12V_CPU A2 P12V_CPU B2 P12V_CPU A3 P12V_CPU B3 P12V_CPU A4 GND B4 GND A5 PD_SLOT5_JTAG2 B5 SMB_SLOT5_SCL A6 PU_SLOT5_JTAG3 B6 SMB_SLOT5_SDA A7 PU_SLOT5_JTAG4 B7 GND A8 PU_SLOT5_JTAG5 B8 P3V3 A9 P3V3...

  • Page 109: Table 31. M.2 Slot/Gen4 X2 M.2 2280 Connector (J_M2Cn1)

    Table 31� M.2 SLOT/Gen4 x2 M.2 2280 Connector (J_M2CN1) Signal Signal P3V3_M2_1 P3V3_M2_1 NC_NGFF1_6 PU_NGFF1_PLN_N 10 M2_1_SLOT_LED_N 11 NC 12 P3V3_M2_1 13 NC 14 P3V3_M2_1 15 GND 16 P3V3_M2_1 17 NC 18 P3V3_M2_1 19 NC 20 NC_NGFF1_20 21 GND 22 P1V8_AUX 23 NC 24 NC_NGFF1_24 25 NC...

  • Page 110: Table 32. M.2 Slot/Gen4 X2 M.2 2280 Connector (J_M2Cn2)

    Table 32� M.2 SLOT/Gen4 x2 M.2 2280 Connector (J_M2CN2) Signal Signal P3V3_M2_2 P3V3_M2_2 NC_NGFF2_6 PU_NGFF2_PLN_N 10 M2_2_SLOT_LED_N 11 NC 12 P3V3_M2_2 13 NC 14 P3V3_M2_2 15 GND 16 P3V3_M2_2 17 NC 18 P3V3_M2_2 19 NC 20 NC_NGFF2_20 21 GND 22 P1V8_AUX 23 NC 24 NC_NGFF2_24 25 NC...

  • Page 111: Led Definitions

    4�5 LED Definitions Figure 58� Server Board LED Table 33� Server Board LED Description LED_BMCHB BMC Heart Signal Beat LED P3V3_STBY State Description The LED shuts off when the BMC controller cannot be detected or properly initiated. The LED blinks per second to indicate that the BMC Green controller is working normally.
  • Page 112 Signal P3V3_AUX LED_ID ID LED State Description Blue LED_M2ACT M.2 #1 active Signal P3V3 State Description The LED shuts off when M.2 is non-active. Blue The LED shuts off when M.2 is active. M.2 #2 active Signal P3V3 State Description P3V3 The LED shuts off when M.2 is non-active.

  • Page 113: Installing Add-In Cards

    4�6 Installing Add-In Cards Before installing add-in cards, it’s helpful to know if they are fully compatible with your motherboard. For this reason, we’ve provided the diagrams below, showing the slots that may appear on your motherboard. Figure 59� TYAN S8016 Add-In Card Location Simply find the appropriate slot for your add-in card and insert the card firmly.

  • Page 114: Connecting External Devices

    4�7 Connecting External Devices Connecting external devices to the motherboard is an easy task. The motherboard supports a number of different interfaces through connecting peripherals. See the following diagrams for the details. LAN1 Port LAN2 Port Figure 60� TYAN S8016 I/O Ports Note: Peripheral devices can be plugged straight into any of these ports but software may be required to complete the installation.

  • Page 115: Installing The Power Supply

    4�8 Installing the Power Supply There are two (2) power connectors on your S8016 motherboard. The S8016 supports EPS 12V power supply. Table 35� ATX 24-pin Main Power Connector (J_PW1) Signal Signal +3.3V_1 13 +3.3V_1 +3.3V_2 14 +3.3V_2 COM_1 15 COM_1 +5V_1 16 +5V_1 COM_2...

  • Page 116: Finishing Up

    4�9 Finishing Up Congratulations on making it this far! You have finished setting up the hardware aspect of your computer. Before closing up your chassis, make sure that all cables and wires are connected properly, especially IDE cables and most importantly, jumpers. You may have difficulty powering on your system if the motherboard jumpers are not set correctly.

  • Page 117: Chapter 5: Bios Setup

    Chapter 5: BIOS Setup 5.1 About the BIOS The BIOS is the basic input/output system, the firmware on the motherboard that enables your hardware to interface with your software. The BIOS determines what a computer can do without accessing programs from a disk. The BIOS contains all the code required to control the keyboard, display screen, disk drives, serial communications, and a number of miscellaneous functions.

  • Page 118: Getting Help

    5�1�2 Getting Help Pressing [F1] will display a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window, press [ESC] or the [Enter] key again. 5�1�3 In Case of Problems If you have trouble booting your computer after making and saving the changes with the BIOS setup program, you can restart the computer by holding the power button down until the computer shuts off (usually within 4 seconds);...

  • Page 119: Main Menu

    5�2 Main Menu In this section, you can alter general features such as the date and time. Note: The options listed below are for options that can directly be changed within the Main Setup screen. Figure 61� Main Screen Page BIOS Information It displays product name, BIOS version and build date and time.

  • Page 120: Advanced Menu

    5.3 Advanced Menu This section facilitates configuring advanced BIOS options for your system. Figure 62� Adanced Screen Page Note: This is a sample screenshot of the Advanced Menu. The HII network drivers displayed here depend on the card(s) you installed and the functions you enabled. Network Stack Configuration Network Stack Settings.
  • Page 121 Onboard Device Configuration Onboard Device and Function Configuration. Hardware Health Configuration Hardware Health Configuration. PCI Subsystem Settings PCI, PCI-X and PCI Express Settings. NVMe Configuration NVMe Device Information. Trusted Computing Trusted Computing settings. Super IO Configuration System Super IO Chip Parameters. CSM Configuration CSM Configuration, Enable/Disable Option ROM execution setting, etc.

  • Page 122: Network Stack Configuration

    5.3.1 Network Stack Configuration Figure 63� Network Stack Screen Page Network Stack Enable/Disable UEFI Network Stack Disabled / Enabled Note: When Network Stack was set to [Enabled], the following item will appear. IPv4 PXE Support Enable/Disable IPv4 PXE boot support. If disabled, IPv4 PXE boot support will not be available. Disabled / Enabled IPv4 HTTPs Support Enable/Disable IPv4 HTTPs boot support.
  • Page 123 IPv6 HTTPs Support Enable/Disable IPv6 HTTPs boot support. If disabled, IPv6 HTTPS boot support will not be available. Disabled / Enabled PXE boot wait time Wait time in seconds to press ESC key to abort the PXE boot. Use either +/- or numeric keys to set the value.

  • Page 124: S5 Rtc Wake Settings

    5.3.2 S5 RTC Wake Settings Figure 64� S5 RTC Wake Settings Screen Page Wake system from S5 Enable or disable System wake on alarm event. Select FixedTime, system will wake on the hr::min::sec specified. Select DynamicTime, system will wake on the current time + Increase minute(s).

  • Page 125: Serial Port Console Redirection

    5.3.3 Serial Port Console Redirection Figure 65� Serial Port Console Redirection Screen Page COM1 Console Redirection Console redirection enable or disable. Disabled / Enabled Legacy Console Redirection Legacy Console Redirection Settings. Serial Port for Out-Of-Band Management/Windows Emergency Services (EMS) Console Redirection Console redirection enable or disable.

  • Page 126: Figure 66. Com1 Console Redirection Settings Screen Page

    5.3.3.1 COM1 Console Redirection Settings Figure 66� COM1 Console Redirection Settings Screen Page Terminal Type Emulation: ANSI: Extended ASCII char set. VT100: ASCII char set. VT100+: Extends VT100 to support color function keys, etc. VT-UTF8: Uses UTF8 encoding to map Unicode chars onto 1 or more bytes. VT-UTF8 / VT100 / VT100+ / ANSI Bits per Second Select serial port transmission speed.
  • Page 127 Parity A parity bit can be sent with the data bits to detect some transmission errors. Even: parity bit is 0 if the num of 1’s in the data bits is even. Odd: parity bit is 0 if the num of 1’s in the data bits is odd.

  • Page 128: Figure 67. Legacy Console Redirections Settings Screen Page

    5.3.3.2 Legacy Console Redirection Settings Figure 67� Legacy Console Redirections Settings Screen Page Redirection COM Port Select a COM port to display redirection of Legacy OS and Legacy OPROM Messages. COM1 Resolution On Legacy OS, the Number of Rows and Columns supported redirection. 80x24 / 80x25 Redirect After POST When Bootloader is selected, then Legacy Console Redirection is disabled before booting to...

  • Page 129: Figure 68. Serial Port Screen Page

    5.3.3.3 Serial Port for Out-Of-Band Management/Windows Emergency Services (EMS) Console Redirection Settings Figure 68� Serial Port Screen Page Out-of Band Mgmt Port Microsoft Windows Emergency Management Services (EMS) allows for remote management of a Windows Server OS through a serial port. COM1 Terminal Type VT-UTF8 is the preferred terminal type for out-of-band management.
  • Page 130 Flow Control Flow Control can prevent data loss from buffer overflow. When sending data, if the receiving buffers are full, a ‘stop’ signal can be sent to stop the data flow. Once the buffers are empty, a ‘start’ signal can be sent to restart the flow. Hardware flow control uses two wires to send start/stop signal.

  • Page 131: Pcie Device Configuration

    5.3.4 PCIe Device Configuration Figure 69� PCIe Device Configuration Screen Page http://www.tyan.com...

  • Page 132: Figure 70. Option Rom Dispatch Policy Screen Page

    5.3.4.1 Option ROM Dispatch Policy Figure 70� Option ROM Dispatch Policy Screen Page PCIE #1 Option ROM Enable or Disable Option ROM execution for selected Slot. Enabled / Disabled PCIE #2 Enable or Disable Option ROM execution for selected Slot. Enabled / Disabled http://www.tyan.com...

  • Page 133: Usb Configuration

    5.3.5 USB Configuration Figure 71� USB Configuration Screen Page Legacy USB Support Enables USB legacy support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications. Enabled / Disabled / Auto XHCI Hand-off This is a workaround for OSes without XHCI hand-off support.
  • Page 134 USB transfer time-out The time-out value for Control, Bulk and Interrupt transfers. 1 sec / 5 sec / 10 sec / 20 sec Device reset time-out USB mass storage device Start Unit command time-out. 10 sec / 20 sec / 30 sec / 40 sec Device power-up delay Maximum time the device will take before it properly reports itself to the Host Controller.

  • Page 135: Onboard Device Configuration

    5.3.6 Onboard Device Configuration Figure 72� Onboard Device Configuration Screen Page Onboard VGA Enable/Disable ASPEED VGA. Disabled / Enabled LAN1 LAN Enable/Disable control function. Disabled / Enabled LAN2 LAN Enable/Disable control function. Disabled / Enabled Primary Disaply Select active Video type. Onboard / External http://www.tyan.com...

  • Page 136: Hardware Health Configuration

    5.3.7 Hardware Health Configuration Figure 73� Hardware Health Configuration Screen Page Fan Speed Control Fan Speed Control help. Automatic / Manual / Full Speed Note: When Auto Fan Control is set to [Manual], PWM Minimal Duty Cycle item will appear. PWM Minimal Duty Cycle PWM Minimal Duty Cycle.

  • Page 137: Figure 74. Sensor Data Register Monitoring Screen

    Number of PSU (available when PMBUS is set to [Enabled]) User can select PSU number for needed. 1 / 2 5.3.7.1 Sensor Data Register Monitoring When you enter the Sensor Data Register Monitoring submenu, you will see the following dialog window pop out. Please wait 8~10 seconds. Figure 74�...

  • Page 138: Figure 75. Sensor Data Register Monitoring Screen

    Figure 75� Sensor Data Register Monitoring Screen Page 2 Note: SDR cannot be modified. Read only. http://www.tyan.com...

  • Page 139: Pci Subsystem Settings

    5.3.8 PCI Subsystem Settings Figure 76� PCI Subsystem Settings Screen Page Above 4G Decoding Enables or Disables 64bit capable Devices to be decoded in Above 4G Address Space(Only if System supports 64 bit PCI Decoding). Enabled / Disabled SR-IOV Support If system has SR-IOV capable PCIe devices, this option Enables or Disables Single Root IO virtualization Support Enabled / Disabled PCI Express Settings...

  • Page 140: Figure 77. Pci Express Subsystem Screen Page

    5.3.8.1 PCI Express Subsystem Figure 77� PCI Express Subsystem Screen Page Maximum Payload Set Maximum Payload of PCI Express Device or allow System BIOS to select the value. Auto / 128 Bytes / 256 Bytes / 512 Bytes / 1024 Bytes / 2048 Bytes / 4096 Bytes http://www.tyan.com...

  • Page 141: Nvme Configuration

    5.3.9 NVMe Configuration Figure 78� NVMe Configuration Screen Page 1 It displays the information of the NVMe device you have installed. If no device is installed, it shows NO NVME Device found. Figure 79� NVMe Configuration Screen Page 2 http://www.tyan.com...

  • Page 142: Trusted Computing

    5.3.10 Trusted Computing Figure 80� Trusted Computing Screen Page Security Device Support Enables or disables BIOS support for security device. O.S. will not show Security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. Enabled / Disabled http://www.tyan.com...

  • Page 143: Super Io Configuration

    5.3.11 Super IO Configuration Figure 81� Super IO Configuration Screen Page Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA) . http://www.tyan.com...

  • Page 144: Figure 82. Serial Port 1 Configuration Screen Page

    5.3.11.1 Serial Port 1 Configuration Figure 82� Serial Port 1 Configuration Screen Page Serial Port Enable or Disable Serial Port (COM). Disabled / Enabled Note: Serial Port has set to Enabled, the following items will be appear. Change Settings Allows the user to change the device resource settings. New settings will be reflected on this setup page after system restarts.

  • Page 145: Csm Configuration

    5.3.12 CSM Configuration Figure 83� CSM Configuration Screen Page CSM support Enable/Disable CSM Support. Enabled / Disabled Note: When CMS Support is set to [Enabled], the following items are available. Option ROM Messages Set display mode for Option ROM. Force BIOS / Keep Current Network Controls the execution of UEFI and legacy PXE OpROM.
  • Page 146 Video Controls the execution of UEFI and legacy Video OpROM. UEFI / legacy Other PCI devices Determines OpRom execution policy for devices other than network, storage, or video. UEFI / legacy http://www.tyan.com...

  • Page 147: Amd Ftpm Configuration

    5.3.13 AMD fTPM Configuration Figure 84� AMD fTPM Configuration Screen Page Trusted Platform Module Enable/Disable TPM physical presence. Auto / Disabled / Enable fTPM / Enable PSP fTPM Erase fTPM NV for factory reset When New CPU is installed, Select “Enabled” to reset fTPM, if you have BitLocker or encryption- enabled system, the system will not boot without a recovery key.

  • Page 148: Redfish Host Interface Settings

    5.3.14 Redfish Host Interface Settings Figure 85� Redfish Host Screen Page Redfish Enable/Disable AMI Redfish. Disabled / Enabled http://www.tyan.com...

  • Page 149: T1S Auth Configuration

    5.3.15 T1s Auth Configuration Figure 86� T1s Auth Configuration Screen Page Server CA Configuration Press Enter to configure Server CA. Client Cert Configuration Press Enter to configure Client Cert. http://www.tyan.com...

  • Page 150: Figure 87. Server Ca Configuration Screen Page

    5.3.15.1 Server CA Configuration Figure 87� Server CA Configuration Screen Page Enroll Cert Press Enter to enroll cert. Delete Cert Press Enter to delete cert. http://www.tyan.com...

  • Page 151: Figure 88. Enroll Cert Screen Page

    5.3.15.1.1 Enroll Cert Figure 88� Enroll Cert Screen Page Enroll Cert Using File Enroll Cert Using File. Cert GUID Input digit character in 11111111-2222-3333-4444-1234567890ab format. Commit Changes and Exit Commit Changes and Exit. Discard Changes and Exit Discard Changes and Exit. http://www.tyan.com...

  • Page 152: Figure 89. Delete Cert Screen Page

    5.3.15.1.2 Delete Cert Figure 89� Delete Cert Screen Page http://www.tyan.com...

  • Page 153: Intel® I210 Gigabit Network Connection - Xx:xx:xx:xx:xx:xx

    5.3.16 Intel® I210 Gigabit Network Connection – xx:xx:xx:xx:xx:xx Figure 90� Network Connection Screen Page NIC Configuration Click to configure the network device port. Blink LEDs Blink LEDs for a duration up to 15 seconds. http://www.tyan.com...

  • Page 154: Figure 91. Nic Configuration Screen Page

    5.3.16.1 NIC Configuration Figure 91� NIC Configuration Screen Page Link Speed Specifies the port speed used for the selected boot protocol. Auto Negotiated / 10 Mbps Half / 10Mbps Full / 100Mbps Half / 100Mbps Full Wake On LAN Enables power on of the system via LAN. Note that configuring Wake on LAN in the operating system does not change the value of this setting, but does override the behavior of Wake on LAN in OS controlled power states.

  • Page 155: Vlan Configuration (Mac:xxxxxxxxxxxx)

    5.3.17 VLAN Configuration (MAC:xxxxxxxxxxxx) Figure 92� VLAN Configuration Screen Page Enter Configuration Menu Press ENTER to enter configuration menu for VLAN configuration. http://www.tyan.com...

  • Page 156: Figure 93. Enter Configuration Menu Screen Page

    5.3.17.1 Enter Configuration Menu Figure 93� Enter Configuration Menu Screen Page VLAN ID VLAN ID of new VLAN or existing VLAN, valid value is 0~4094. Priority 802.1Q Priority, valid value is 0~7. Add VLAN Create a new VLAN or update existing VLAN. Remove VLAN Remove selected VLANs.

  • Page 157: Mac:xxxxxxxxxxxx - Ipv4 Network Configuration

    5.3.18 MAC:xxxxxxxxxxxx - IPv4 Network Configuration Figure 94� IPv4 Network Configuration Screen Page Configured Indicate whether network address configured successfully or not. Disabled / Enabled Save Changes and Exit Save Changes and Exit. http://www.tyan.com...

  • Page 158: Mac:xxxxxxxxxxxx - Ipv6 Network Configuration

    5.3.19 MAC:xxxxxxxxxxxx - IPv6 Network Configuration Figure 95� IPv6 Network Configuration Screen Page Enter Configuration Menu Press ENTER to enter configuration menu for IPv6 configuration. http://www.tyan.com...

  • Page 159: Figure 96. Enter Configuration Menu Screen Page

    5.3.19.1 Enter Configuration Menu Figure 96� Enter Configuration Menu Screen Page Interface ID The 64 bit alternative interface ID for the device. The string is colon separated, e.g. ff:dd:88:66:cc:1:2:3 xx:xx:x:xx:xx:xx:xx:xx DAD Transmit Count The number of consecutive Neighbor Solicitation messages sent while performing Duplicate Address Detection on a tentative address.
  • Page 160 Advanced Configuration Configure the interface manually. IP address, gateway address, and DNS server address can be configured. Save Changes and Exit Save Changes and Exit. http://www.tyan.com...

  • Page 161: Figure 97. Advanced Configuration Screen Page

    5.3.19.1.1 Advanced Configuration Figure 97� Advanced Configuration Screen Page New IPv6 address Manual IP address can only be configured under manual policy. Separate the IP address with blank space to configure more than one address. e.g. 2002::1/64 2002::2/64 New Gateway addresses Gateway IP address can only be configured under manual policy.

  • Page 162: Intel® I210 Gigabit Network Connection - Xx:xx:xx:xx:xx:xx

    5.3.20 Intel® I210 Gigabit Network Connection – xx:xx:xx:xx:xx:xx Figure 98� Network Connection Screen Page NIC Configuration Click to configure the network device port. Blink LEDs Blink LEDs for a duration up to 15 seconds. http://www.tyan.com...

  • Page 163: Figure 99. Nic Configuration Screen Page

    5.3.20.1 NIC Configuration Figure 99� NIC Configuration Screen Page Link Speed Specifies the port speed used for the selected boot protocol. Auto Negotiated / 10 Mbps Half / 10Mbps Full / 100Mbps Half / 100Mbps Full Wake On LAN Enables power on of the system via LAN. Note that configuring Wake on LAN in the operating system does not change the value of this setting, but does override the behavior of Wake on LAN in OS controlled power states.

  • Page 164: Vlan Configuration (Mac:xxxxxxxxxxxx)

    5.3.21 VLAN Configuration (MAC:xxxxxxxxxxxx) Figure 100� VLAN Configuration Screen Page Enter Configuration Menu Press ENTER to enter configuration menu for VLAN configuration. http://www.tyan.com...

  • Page 165: Figure 101. Enter Configuration Screen Page

    5.3.21.1 Enter Configuration Figure 101� Enter Configuration Screen Page VLAN ID VLAN ID of new VLAN or existing VLAN, valid value is 0~4094. Priority 802.1Q Priority, valid value is 0~7. Add VLAN Create a new VLAN or update existing VLAN. Remove VLAN Remove selected VLANs.

  • Page 166: Mac:xxxxxxxxxxxx - Ipv4 Network Configuration

    5.3.22 MAC:xxxxxxxxxxxx - IPv4 Network Configuration Figure 102� IPv4 Network Configuration Screen Page Configured Indicate whether network address configured successfully or not. Disabled / Enabled Save Changes and Exit Save Changes and Exit. http://www.tyan.com...

  • Page 167: Mac:xxxxxxxxxxxx - Ipv6 Network Configuration

    5.3.23 MAC:xxxxxxxxxxxx - IPv6 Network Configuration Figure 103� IPv6 Network Configuration Screen Page Enter Configuration Menu Press ENTER to enter configuration menu for IPv6 configuration. http://www.tyan.com...

  • Page 168: Figure 104. Enter Configuration Menu Screen Page

    5.3.23.1 Enter Configuration Menu Figure 104� Enter Configuration Menu Screen Page Interface ID The 64 bit alternative interface ID for the device. The string is colon separated, e.g. ff:dd:88:66:cc:1:2:3 xx:xx:x:xx:xx:xx:xx:xx DAD Transmit Count The number of consecutive Neighbor Solicitation messages sent while performing Duplicate Address Detection on a tentative address.
  • Page 169 Advanced Configuration Configure the interface manually. IP address, gateway address, and DNS server address can be configured. Save Changes and Exit Save Changes and Exit. http://www.tyan.com...

  • Page 170: Figure 105. Advanced Configuration Screen Page

    5.3.23.1.1 Advanced Configuration Figure 105� Advanced Configuration Screen Page New IPv6 address Manual IP address can only be configured under manual policy. Separate the IP address with blank space to configure more than one address. e.g. 2002::1/64 2002::2/64 New Gateway addresses Gateway IP address can only be configured under manual policy.

  • Page 171: Cpu Configuration

    5.4 CPU Configuration Figure 106� CPU Configuration Screen Page CPU Configuration CPU Configuration Parameters. http://www.tyan.com...

  • Page 172: Cpu Configuration

    5.4.1 CPU Configuration Figure 107� CPU Configuration Screen Page SVM Mode Enable/disable CPU Virtualization. Enabled / Disabled CPU0 Information View Information related to CPU 0. http://www.tyan.com...

  • Page 173: Figure 108. Cpu0 Information Screen Page

    5.4.4.1 CPU0 Information Figure 108� CPU0 Information Screen Page Read only. http://www.tyan.com...

  • Page 174: Chipset

    5.5 Chipset Figure 109� Chipset Screen Page AMD CBS AMD CBS Setup Page. North Bridge North Bridge Parameters. http://www.tyan.com...

  • Page 175: Amd Cbs

    5.5.1 AMD CBS Figure 110� AMD CBS Screen Page CPU Common Options CPU Common Options. DF Common Options DF Common Options. UMC Common Options UMC Common Options. NBIO Common Options NBIO Common Options. FCH Common Options FCH Common Options. SMU Common Options SMU Common Options.

  • Page 176: Figure 111. Cpu Common Options Screen Page

    5.5.1.1 CPU Common Options Figure 111� CPU Common Options Screen Page Core Performance Boost Disable CPB. Disabled / Auto Global C-state Control Controls IO based C-state generation and DF C-states. Disabled / Enabled / Auto MCA error thresh enable Enable MCA error thresholding. False / True / Auto SMT Control Can be used to disable symmetric multithreading.

  • Page 177: Figure 112. Df Common Options Screen Page

    5.5.1.2 DF Common Options Figure 112� DF Common Options Screen Page DF Cstates Enable or Disable Data Fabric to go to a low-power state when the processor has entered Cx states. Disabled / Enabled / Auto PSP error injection support Enable EINJ support False / True http://www.tyan.com...

  • Page 178: Figure 113. Umc Common Options Screen Page

    5.5.1.3 UMC Common Options Figure 113� UMC Common Options Screen Page DDR Timing Configuration DDR Timing Configuration. DDR RAS DDR RAS. DDR Security DDR Security. http://www.tyan.com...

  • Page 179: Figure 114. Dram Time Configuration Screen Page

    5.5.1.3.1 DRAM Time Configuration Figure 114� DRAM Time Configuration Screen Page Active Memory Timing Settings Active Memory Timing Settings. Auto / Enabled Memory Target Speed Specifies the memory target speed in MT/s. The valid input is 3200, 3600, 4000, 4400, 4800, 5200, 5600.

  • Page 180: Figure 115. Ddr Ras Screen Page

    5.5.1.3.2 DDR RAS Figure 115� DDR RAS Screen Page Disable Memory Error Injection True: UMC::CH:: MiscCfg[DisErrInj]=1 False / True / Auto Use this option to enable/disable ECC. Auto will set ECC to enable. Disabled / Enabled / Auto http://www.tyan.com...

  • Page 181: Figure 116. Ddr Security Screen Page

    5.5.1.3.3 DDR Security Figure 116� DDR Security Screen Page TSME Transparent Secure Memory Encryption. Auto / Disabled / Enabled Data Scramble Data Scrambling. Disabled / Enabled / Auto http://www.tyan.com...

  • Page 182: Figure 117. Nbio Common Options Screen Page

    5.5.1.4 NBIO Common Options Figure 117� NBIO Common Options Screen Page IOMMU Enable/Disable IOMMU. Disabled / Enabled / Auto PCIe ARI Support Enables Alternative Routing-ID Interpretation. Disabled / Enabled / Auto PCIe All Port ECRC Enable/Disable PCIE all port ECRC. Enabled / Disabled / Auto Advanced Error Reporting (AER) Enable/Disable support for Advanced Error Reporting (AER).

  • Page 183: Figure 118. Fch Common Options Screen Page

    5.5.1.5 FCH Common Options Figure 118� FCH Common Options Screen Page SATA Mode Select Promontory 21 SATA Type. AHCI / RAID / Auto NVMe RAID Mode Enable or disable NVMe RAID mode. Please setting the ‘PCIe/GFx Lanes Configuration’ item according to the RIAD configuration. Disabled / Enabled Ac Power Loss Options Ac Power Loss Options.

  • Page 184: Figure 119. Ac Power Loss Options Screen Page

    5.5.1.5.1 AC Power Loss Options Figure 119� AC Power Loss Options Screen Page AC Loss Control Select Restore AC Power Loss Method. Power Off / Power On / Last State http://www.tyan.com...

  • Page 185: Figure 120. Sata Configuration Screen Page

    5.5.1.5.2 SATA Configuration Figure 120� SATA Configuration Screen Page Read only. http://www.tyan.com...

  • Page 186: Figure 121. Smu Common Options Screen Page

    5.5.1.6 SMU Common Options Figure 121� SMU Common Options Screen Page TDP Control Auto: Use the default sustained power limit Manual: User can set customized sustained power limit Manual / Auto Note: When TDP Control is set to [Manual], the following item is available. Sustained power limit [mW].

  • Page 187: Figure 122. Soc Miscellaneous Control Screen Page

    5.5.1.7 SOC Miscellaneous Control Figure 122� SOC Miscellaneous Control Screen Page ABL Console Out Control Enable: Enable ConsoleOut Function for ABL Disable: Disable ConsoleOut Function for ABL Auto: Keep default behavior. Note: Need to enable ESPI ABL Init. Auto / Enable / Disable Note: When ABL Console Out Control is set to [Enable], the following items are available.
  • Page 188 ABL PMU Message Control To control the total number of PMU debug messages. Several Major controls are listed below: 1. Detailed debug messages (e.g. Eye delays) 2. Coarse debug messages (e.g. rank information) 3. Stage Completion 4. Firmware completion messages only Auto / Detailed debug message / Coarse debug message / Stage Completion / Assertion message / Firmware completion message only http://www.tyan.com...

  • Page 189: North Bridge Configuration

    5.5.2 North Bridge Configuration Figure 123� North Bridge Configuration Screen Page Above 4GB MMIO Limit Select Above 4GB MMIO Limit. This option works only when ‘Above 4G decoding’ is enabled. 40bit (1TB) / 41bit (2TB) / 42bit (4TB) / 43bit (8TB) / 44bit (16TB) / 45bit (32TB) / 46bit (64TB) / 47bit (126TB) / 48bit (256TB) Memory Information Total Memory: xxxxx MB...

  • Page 190: Figure 124. Cpu O Information Screen Page

    5.5.2.1 CPU 0 Information Figure 124� CPU O Information Screen Page Read only. http://www.tyan.com...

  • Page 191: Server Management

    5.6 Server Management Figure 125� Server Management Screen Page FRB-2 Timer Enable or Disable FRB-2 timer (POST timer) Disabled / Enabled Note: When FRB-2 Timer is set to [Enabled], the following items will be available. FRB-2 Timer timeout Enter value Between 3 to 6 min for FRB-2 Timer Expiration value. 3 minutes / 4 minutes / 5 minutes / 6 minutes / 12 minutes FBR-2 Timer Policy Configure how the system should respond if the FRB-2 Timer expires.
  • Page 192 OS Watchdog Timer If enabled, starts a BIOS timer which can only be shut off by management Software after the OS loads. Helps determine that the OS successfully loaded or follows the OS Boot Watchdog Timer policy. Disabled / Enabled Note: When OS Watchdog Timer is set to [Enabled], the following items will be available.

  • Page 193: System Event Log

    5.6.1 System Event Log Figure 126� System Event Log Screen Page SEL Components Change this to enable or disable event logging for error/progress codes during boot. Enabled / Disabled Erase SEL Choose options for erasing SEL. No / Yes, on next reset / Yes, on every reset Log EFI Status Codes Disable the logging of EFI Status Codes or log only error code or only progress code or both.

  • Page 194: Bmc Network Configuration

    5.6.2 BMC Network Configuration Figure 127� BMC Network Configuration Screen Page Configure IPV4 support Management Port 1 Configuration Address Source Select the configure LAN channel parameters statically or dynamically (by BIOS or BMC). Unspecified option will not modify any BMC network parameters during BIOS phase. Unspecified / Static / DynamicBmcDhcp / DynamicBmcNonDhcp Management Port 2 Enable/Disable BMC Share NIC.
  • Page 195 Configure IPV6 support Management Port 1 IPV6 Support Enable or Disable LAN1 IPV6 Support. Disabled / Enabled Configuration Address Source Select the configure LAN channel parameters statically or dynamically (by BIOS or BMC). Unspecified option will not modify any BMC network parameters during BIOS phase. Unspecified / Static / DynamicBmcDhcp / DynamicBmcNonDhcp Management Port 2 IPV6 Support...

  • Page 196: Bmc User Configuration

    5.6.3 BMC User Configuration Figure 128� BMC User Configuration Screen Page Add User Press Enter to Add a User. Delete User Press Enter to Delete a User. Change User Settings Press Enter to Change User Settings. http://www.tyan.com...

  • Page 197: Figure 129. Bmc User Configuration Screen Page

    5.6.3.1 BMC User Configuration Figure 129� BMC User Configuration Screen Page User Name Enter BMC User Name. User Password Enter New Password to change. Password at least 8 characters. User Access Enable/Disable the BMC User’s Access. Enabled / Disabled Channel No Enter BMC Channel Number.

  • Page 198: Figure 130. Delete User Configuration Screen Page

    5.6.3.2 Delete User Configuration Figure 130� Delete User Configuration Screen Page User Name Enter BMC User Name. User Password Enter New Password to change. Password at least 8 characters. http://www.tyan.com...

  • Page 199: Figure 131. Change User Configuration Screen Page

    5.6.3.3 Change User Configuration Figure 131� Change User Configuration Screen Page User Name Enter BMC User Name. User Password Enter New Password to change. Password at least 8 characters. Change User Password Enter New Password to change. Password at least 8 characters. User Access Enable/Disable the BMC User’s Access.

  • Page 200: Security

    5.7 Security Figure 132� Security Screen Page Administrator Password Set Administrator Password. User Password Set User Password. Security Frozen Mode Enable or disable HDD security freeze lock. Disable to support secure erase function. Disabled / Enabled Secure Boot Customizable Secure Boot settings. http://www.tyan.com...

  • Page 201: Secure Boot Configuration

    5.7.1 Secure Boot Configuration Figure 133� Secure Boot Configuration Screen Page Secure Boot Secure boot feature is Active if Secure Boot is Enabled, Platform Key (PK) is enrolled and the System is in User mode. The mode change requires platform reset. Enabled / Disabled Secure Boot Mode Secure Boot mode options: Standard or Custom.

  • Page 202: Figure 134. Key Management Screen Page

    5.7.1.1 Key Management Figure 134� Key Management Screen Page Factory Keys Provision Install factory default Secure Boot Keys after the platform reset and while the System is in Setup Mode. Enabled / Disabled Restore Factory Keys Force System to User Mode. Install Factory Default Secure Boot key databases. Press Yes to proceed No to cancel.
  • Page 203 Platform Key (PK) Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER encoded) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHA256,384,512 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, External, Mixed Options: Update Key Exchange Keys Enroll Factory Defaults or load certificates from a file:...
  • Page 204 Authorized TimeStamps Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER encoded) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, External, Mixed Options: Update / Append OsRecovery Signatures Enroll Factory Defaults or load certificates from a file:...

  • Page 205: Boot

    5.8 Boot Figure 135� Boot Screen Page Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535 (0xFFFF) means indefinite waiting. Bootup NumLock State Select the keyboard NumLock state. Off / On Quiet Boot Enable or disable Quiet Boot option. Enabled / Disabled Wait for ‘ESC’...
  • Page 206 Boot Option Priorities Boot Option #1~#3 Select the system boot order. Device Name / Disabled Delete Boot Option Remove an EFI boot option from the boot order. http://www.tyan.com...

  • Page 207: Delete Boot Option Configuration

    5.8.1 Delete Boot Option Configuration Figure 136� Delete Boot Option Configuration Screen Page Delete Boot Option Remove an EFI boot option from the boot order. Device Name / Select one to Delete http://www.tyan.com...

  • Page 208: Save And Exit

    5�9 Save and Exit Figure 137� Save and Exit Screen Page Save Changes and Exit Exit system setup after saving the changes. Discard Changes and Exit Exit system setup without saving any changes. Save Changes and Reset Reset the system after saving the changes. Discard Changes and Reset Reset system setup without saving any changes.

  • Page 209: Chapter 6: Diagnostics

    Chapter 6: Diagnostics Note: If you experience problems with setting up your system, always check the following things in the following order: Memory, Video, CPU. By checking these items, you will most likely find out what the problem might have been when setting up your system.

  • Page 210: Amibios Post Code (Aptio)

    6.2 AMIBIOS Post Code (Aptio) The POST code checkpoints are the largest set of checkpoints during the BIOS pre-boot process. The following table describes the type of checkpoints that may occur during the POST portion of the BIOS: Table 38� Checkpoint Ranges Status Code Range Description 0x01 –...
  • Page 211 SEC Beep Codes None PEI Phase Status Code Description Progress Codes SEC execution 0x10 PEI Core is started 0x11 Pre-memory CPU initialization is started 0x12 Pre-memory CPU initialization (CPU module specific) 0x13 Pre-memory CPU initialization (CPU module specific) 0x14 Pre-memory CPU initialization (CPU module specific) 0x15 Pre-memory North Bridge initialization is started 0x16...
  • Page 212 PEI Error Codes Description 0x53 Memory initialization error. No usable memory detected 0x54 Unspecified memory initialization error 0x55 Memory not installed 0x56 Invalid CPU type or speed 0x57 CPU mismatch 0x58 CPU self test failed or possible CPU cache error 0x59 CPU microcode is not found or microcode update is failed 0x5A...
  • Page 213 DXE Phase Status Code Description 0x60 DXE Core is started 0x61 NVRAM initialization 0x62 Installation of the South Bridge Runtime Services 0x63 CPU DXE initialization is started 0x64 CPU DXE initialization (CPU module specific) 0x65 CPU DXE initialization (CPU module specific) 0x66 CPU DXE initialization (CPU module specific) 0x67...
  • Page 214 Status Code Description 0x9D USB Enable 0x9E -0x9F Reserved for future AMI codes 0xA0 IDE initialization is started 0xA1 IDE Reset 0xA2 IDE Detect 0xA3 IDE Enable 0xA4 SCSI initialization is started 0xA5 SCSI Reset 0xA6 SCSI Detect 0xA7 SCSI Enable 0xA8 Setup Verifying Password 0xA9...

  • Page 215: Table 40. Acpi/Asl Checkpoints

    Table 40� ACPI/ASL Checkpoints Status Code Description 0x01 System is entering S1 sleep state 0x02 System is entering S2 sleep state 0x03 System is entering S3 sleep state 0x04 System is entering S4 sleep state 0x05 System is entering S5 sleep state 0x10 System is waking up from the S1 sleep state 0x20...

  • Page 216: Appendix I: How To Recover Uefi Bios

    Appendix I: How to recover UEFI BIOS Important Notes: The emergency UEFI BIOS Recovery process is only used to rescue a system with a failed or corrupted BIOS image that fails to boot to an OS. It is not intended to be used as a general purpose BIOS flashing procedure and should not be used as such.

  • Page 217: Figure 139. Bios Recovery Screen Page

    5. The system will boot to BIOS setup. A new menu item will appear at the far right of the screen. Scroll to the 'Recovery' tab, move the curser to Proceed with flash update and press the Enter key on the keyboard to start the BIOS recovery process. Figure 139�...

  • Page 218: Appendix Ii: Fan And Temperature Sensors

    Appendix II: Fan and Temperature Sensors This section aims to help readers identify the locations of some specific FAN and Temp Sensors on the motherboard. A table of BIOS Temp sensor name explanation is also included for readers’ reference. Figure 140� Fan and Temperature Sensor Note: The red dot indicates the sensor.

  • Page 219: Figure 141. Bios Temp Sensor Name Screen Page

    BIOS Temp Sensor Name Explanation: Figure 141� BIOS Temp Sensor Name Screen Page http://www.tyan.com...

  • Page 220: Table 41. Bios Temperature Sensor

    Table 41� BIOS Temperature Sensor BIOS Temp Sensor Name Explanation P0_Temp Temperature of CPU0 P0_MOSFET_1 Temperature of the P0_MOSFET_1Area SYS_Air_Outlet Temperature of the System Air Outlet Area MB_Air_Inet Temperature of the M/B Air Inlet Area M.2_NVMe_1 Max Temperature of M.2 NVMe device 1 M.2_NVMe_2 Max Temperature of M.2 NVMe device 2 CPU_FAN...

  • Page 221: Appendix Iii: How To Enable Amd Ftpm

    Appendix III: How to Enable AMD fTPM Step 1: Advanced  Trusted Computing  Security Device Support [Enabled]. Figure 142� Enable AMD fTPM Screen Page 1 Step 2: Advanced  Trusted Computing  Security Device Support [Enabled]  AMD fTPM Configuration ...

  • Page 222: Figure 144. Tpm Management Screen

    Step 3: Check the Trusted Platform Module (TPM) Management on local computer. Example: Windows 11 Figure 144� TPM Management Screen Page 1 Example: Windows 10 Figure 145� TPM Management Screen Page 2 http://www.tyan.com...

  • Page 223: Appendix Iv: Cable Connection

    Appendix IV: Cable Connection Table 42� Front Panel Control Cable M1723G86-FPB to S8016 Serverboard M1723G86-FPB Connect to S8016 Serverboard J_HDFP1 FP ctrl cable J5 → P/N: 422B06300001 Table 43� PWR & PSMI Cable M1634T45-PDB to S8016 Serverboard M1634T45-PDB Connect to S8016 Serverboard 2x12P Power Cable J_PW1...

  • Page 224: Appendix V: Fru Parts Table

    Appendix V: FRU Parts Table HG68-B8016 FRU Parts Item Model Number Part Number Picture Description 800W,ACBEL,FSG032-180G,(01) ,1U Power Supply FRU-PS-0480 471100000537 MODULE Active,SBU,AMD 5th CPU Heat Sink FRU-TH-0720 343B06300002 EPYC,1U<H≤2U,107 x 78 x 67mm,Al Fin,Base_Al extrusion 2 in one pack the 342T53400006...

  • Page 225: Appendix V: Technical Support

    Return Merchandise Authorization (RMA) number. The RMA number should be prominently displayed on the outside of the shipping carton and the package should be mailed prepaid. TYAN will pay to have the board shipped back to you. TYAN® HG68-B8016 Service Engineer’s Manual V1.0f Document No.: D2610 - 100 http://www.tyan.com...

This manual is also suitable for:

B8016h68d5

Table of Contents
