Summary of Contents for TYANO TS70-B7136

  • Page 1 TS70-B7136/ TS70A-B7136 Service Engineer’s Manual http://www.tyan.com...
  • Page 2 http://www.tyan.com...
  • Page 3: Trademark Recognition

    PREFACE Copyright This publication, including all photographs, illustrations, and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any material contained herein, may be reproduced without written consent of manufacturer. Copyright 2023 MITAC COMPUTING TECHNOLOGY CORPORATION. All ®...
  • Page 4: Notice For Europe(Ce Mark)

    FCC Declaration ● Notice for the USA Compliance Information Statement (Supplier's Declaration of Conformity, SDoC) FCC Part 15: This device complies with part 15 of the FCC Rules. This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: ‧This device may not cause harmful interference.
  • Page 5 For EU use only: This product is in conformity with the Council Directive 2014/30/EU and 2014/35/EU. Warning This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference. CAUTION Lithium battery included with this board. Do not puncture, mutilate, or dispose of battery in fire.
  • Page 6 About this Manual This manual is intended for skilled person with hardware knowledge of computers. Components inside the compartments should be serviced only by a skilled person. This manual is aimed to provide you with instructions on installing your TYAN TS70(A)-B7136.
  • Page 7: Safety And Compliance Information

    Safety and Compliance Information Before installing and using TYAN TS70(A)-B7136, take note of the following precautions: ·Read all instructions carefully. ·Do not place the unit on an unstable surface, cart, or stand. ·Do not block the slots and opening on the unit, which are provided for ventilation.
  • Page 8: Safety Information

    Safety Information Retain and follow all product safety and operating instructions provided with your equipment. In the event of a conflict between the instructions in this guide and the instructions in equipment documentation, follow the guidelines in the equipment documentation. Observe all warnings on the product and in the operating instructions.
  • Page 9: General Precautions

    General Precautions · Follow all caution and warning instructions marked on the equipment and explained in the accompanying equipment documentation. Machine Room Environment · This device is for use only in a restricted access location, such as a machine room or IT room. ·...
  • Page 10 from the horizontal. · Make sure the rack is properly secured to the floor or ceiling. · Make sure the stabilizing feet are attached to the rack if it is a single-rack installation. · Make sure racks are coupled together if it is a multiple-rack installation. ·...
  • Page 11: Equipment Modifications

    Equipment Power Cords · Use only the power cords and power supply units provided with your system. The system might have one or more power cords. · Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all times.
  • Page 12 Equipment Repairs and Servicing · The installation of internal options and routine maintenance and service of this product should be performed by skilled person who are knowledgeable about the procedures, precautions, and hazards associated with equipment containing hazardous energy levels. ·...
  • Page 13 安全資訊 請保留和遵守隨本設備提供的所有產品安全與操作說明。本指南的說明與設 備文件的說明內容如有沖突,請遵守設備文件中的指導。 遵守產品上和操作說明中的所有警告。為降低人身傷害、電擊、火災及設備 損壞的風險,請遵守本指南中包括的所有注意事項。 在安裝、操作和維修產品之前,您必須先熟悉本指南中的安全資訊。 設備上的符號 請注意。 該符號表示可能存在危險。如果未遵守注意事項,則 可能出現傷害。請查閱設備文件了解詳細資訊。 請注意。 請勿在抽取式儀器上放置物品或將儀器頂部當作工作 檯。 警告。 該符號表示存在高壓電路或電擊危險。所有維修工作 應交由專業人員。 警告。 該符號表示表面或元件高溫。如果接觸到表面,則可 能被燙傷。為降低被高溫元件燙傷的風險,請在接觸 之前,先讓表面冷卻下來。 維修前須切斷所有電源 一般注意事項 遵守設備上標示的以及隨附設備文件中介紹的所有注意事項和警告資訊。  http://www.tyan.com...
  • Page 14 機房環境 本裝置僅適用於機房或資訊室。  確保系統安裝的區域通風良好,溫度濕度等可控制。  確保機房電源的電壓和頻率與設備電力標籤上標示的電壓和頻率相符。  安裝系統時應遠離高壓、排氣管、散熱器等。  切勿在潮濕環境中使用本產品。  設備底座 請勿堵塞或蓋住系統的槽孔。  切勿將任何物件插入設備的槽孔。內部可能存在高壓。  可導電的物件可能造成短路並引起火災、電擊或設備損壞。  雙膝彎曲,用雙手提起設備。  設備機架 避免人身傷害或設備損壞指引: 遵守當地的職業健康和安全規定以及手工物料搬運的指導。  請勿嘗試獨自搬動機架,搬動機架至少需要兩人。  請勿嘗試搬動滿載的機架。從機架上卸下設備後再搬動它。  請勿嘗試在大於 10 度的斜坡上搬動機架,以免造成危險。  確保機架已正確固定到地板或天花板上。  如果是單機架安裝,確保穩定支腳已裝到機架。  如果是多機架安裝,確保各機架已咬合在一起。  將裝置安裝到機架之前,確保機架是水平和穩定的。  確保承重腳已伸展至地板。...
  • Page 15 確保一次只有一個元件被伸展。如果一次伸展一個以上的元件,則機架可  能會不穩定。 避免設備損壞指引: 機架寬度和深度必須保證能夠適當地進行維修和排列纜線。  保證機架內的通風良好。安裝不當或通風不良可能會損壞設備。  機架不能有實心或受限制的通風門。您必須在機架前後使用絲網門,或者  將門卸下以保證系統的良好通風。 如果您在機架中安裝設備,請勿將設備放在裝置上。這會造成通風不暢,  並可能會造成設備損壞。 確保產品與護欄正確咬合。與護欄咬合不良的產品可能會不穩定。  驗證為機架提供電源的交流電源分支電路沒有多載, 以降低人身傷害、  電擊、火災及設備損壞的風險。 機架總負載不應超過分支電路額定值的 80%。請向對您的設備連線和安  裝規定具有管轄權限的電力部門查詢。 設備電源線 只使用隨系統提供的電源線和電源裝置。系統可能配有一條或多條電源  線。 將電源線插入到能方便接觸到的接地電源插座。  在歐洲供電環境中,您必須將電源線上的綠色/ 黃色接頭接地。如果沒有  將綠色/黃色接頭接地,則可能由於大量電流洩露而造成電擊。 請勿在交流電源線或纜線上放置物件。將電源線或纜線放在人們不易踩到  或被絆倒的地方。 請勿拉扯電源線或纜線。從電源插座上斷開電源線時,應抓住電源線插  頭。 為降低電擊風險,請在維修裝置之前,斷開所有電源線連接。...
  • Page 16 設備電池 本系統使用鋰錳電池。如果電池組處理不當,則會有起火風險。  請勿拆解、擠壓、穿刺電池,將其投入火中或水中,或使其與外部短路接  觸。 請勿將電池置於 60 F) 以上的高溫環境中。 C (140 ° °  系統電池不可變更。如果更換不正確的電池,則會有爆炸危險。請換上專  為本產品指定的備用電池。 請勿嘗試給電池充電。  按照製造商的說明處理用過的電池。請勿將電池當作一般家庭垃圾處理。  若要對電池進行回收再用或正確處理,請使用公共收集系統,或將其送回授 權合作夥伴或其代理。 設備改造 不要對本設備進行機械或電氣修改, 以免造成安全問題。對於被改造設備  的認證合格概不負責。 設備維修與維護 安裝內部元件和日常的產品維護應由熟悉程序、注意事項及高壓設備危險  的專業人員執行。 請勿任意拆裝設備. 任何未經授權或認證人員之設備拆裝可能造成嚴重的  安全問題. 任何問題, 請洽您的銷售人員或經銷商尋求協助。 除非安裝手冊或使用手冊中提及, 否則請勿嘗試維修您的設備. 永遠遵守 ...
  • Page 17 卸下或更換系統元件時,請戴上手套,以免被高溫的元件表面燙傷。  如果產品持續發生損壞,需要維修,請從交流電源插座上斷開產品,並交  由授權的服務提供商進行維修。下面是一些需要維修的情況: – 電源線、延長線或插頭損壞。 – 有液體濺到產品上,或異物進入到產品內。 – 產品遭到雨淋或進水。 – 產品跌落或損壞。 – 在您按照操作說明使用時,產品操作不正常。 操作環境溫度升高 如果將此設備安裝在封閉式或具有多個設備的機架上,機架的操作環境溫  度可能會高於設備房間的溫度。因此,在安裝此設備時必須考慮滿足生產廠 商規定的最高環境溫度 (Tma) 要求。 減少通風 將設備安裝於機架上不會造成安全操作設備所需的通風出現通風不良的狀  況。 機械負載 將設備安裝於機架上不會造成因為機械負載不均而出現危險的狀況。  電路過度負荷 必須考量將設備連接到供電電路時的狀況,而過流防護及供電線路可能出  現電路過度負荷的問題。對於這類疑慮,必須妥適考量設備標示牌的額定 值。 http://www.tyan.com...
  • Page 18 牢固的地面固定 務必使安裝於機架上的裝置在地面固定牢固。必須特別注意非直接接上電  源的其他分路供電 (例如使用電源排插座)。 可更換電池 警告使用者: 警告: 為避免電磁干擾,本產品不應安裝或使用於住宅環境。 連絡方式 製造商: 神雲科技股份有限公司 地址: 桃園市龜山區文化二路 200 號 http://www.tyan.com...
  • Page 19: Taiwan Bsmi Rohs Declaration

    Taiwan BSMI RoHS Declaration 設備名稱:伺服器 / 型號(型式):TS70-B7136 / TS70A-B7136 Equipment Name:Server / Type:TS70-B7136 / TS70A-B7136 限用物質及其化學符號 Restricted substances and its chemical symbols 單位 六價鉻 多溴聯苯 多溴二苯醚 鉛 汞 鎘 Unit Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium biphenyls diphenyl ethers...
  • Page 20 http://www.tyan.com...
  • Page 21: Table Of Contents

    Table of Contents Chapter 1: Overview............... 25   About the TYAN TS70(A)-B7136 ..........25   Product Model ................26   Features..................28   Standard Parts List ..............39   1.4.1 Box Contents ..............39   1.4.2 Accessories ............... 40   About the Product ..............
  • Page 22 Replacing the Front Panel Board ..........89   3.3.1 Front Panel Board Specifications ........91   3.3.2 FPB LED Definitions ............92   Replacing the USB Board ............93   3.4.1 USB Board Specifications ..........95   Replacing the System Fan ............96  ...
  • Page 23 Advanced Menu ..............166   5.3.1 Network Stack Configuration .......... 168   5.3.2 S5 RTC Wake Settings ........... 170   5.3.3 Serial Port Console Redirection ........171   5.3.4 PCIe Device Configuration ..........179   5.3.5 USB Configuration ............181  ...
  • Page 24 Flash Utility ................293   AMIBIOS Post Code (Aptio) ..........294   Appendix I: How to recover UEFI BIOS ........303   Appendix II: Installing OCP Card ..........305   Appendix III: Installing the M.2 Card........... 307   Appendix IV: Cable Connection Tables ........309  ...
  • Page 25: Chapter 1: Overview

    12G / SATA 6G HDD/SSDs, (8) hot-swap NVMe U.2 and (2) hot-swap 2.5” SATA 6G SSDs at rear. While the TS70-B7136 version supports up to (12) hot-swap 2.5”/3.5” SAS 12G/SATA 6G HDD/SSDs with (4) NVMe U.2 option, and (2) hot-swap 2.5”...
  • Page 26: Product Model

    Product Model The system board within the Tyan Barebone is defined by the following models: B7136T70AV12E8HR-2T  : S7136GM2NRE-2T in TS70A chassis, (10) H-S 2.5” SAS 12G/SATA 6G HDD/SSDs; (8) H-S NVMe U.2; (2) H-S 2.5” SATA 6G HDD/SSDs at rear; (1+1) 1,200W RPSU; 80+ Platinum; (2) 10GbE ports + (1) GbE dedicated for IPMI B7136T70AV12E8HR...
  • Page 27 (1+1) B7136T70V10E4HR-2T (1) GbE for IPMI 1200W (12) 3.5”/2.5” (1+1) SATA/SAS B7136T70V10E4HR (1) GbE for IPMI w/(4) U.2 1200W TS70-B7136 NVMe + (2) 10GbE + (1+1) B7136T70V10E4HR-2T-HE (2) 2.5” (1) GbE for IPMI 1300W SATA/SAS (1+1) B7136T70V10E4HR-HE (1) GbE for IPMI 1300W http://www.tyan.com...
  • Page 28: Features

    Features TS70A-B7136 (B7136T70AV12E8HR-2T) Form Factor 2U Rackmount Chassis Model TS70A Dimension (D x 27.56" x 17.26" x 3.42" (700 x 438.5 x 87mm) System W x H) Motherboard S7136GM2NRE-2T Name Buttons (1) ID / (1) PWR w/ LED / (1) RST Front Panel LEDs (1) HDD / (1) ID / (2) LAN / (1) BMC event...
  • Page 29 Memory 8 Channels per CPU channel Memory voltage 1.1V PCIe (1) PCI-E Gen.5 x4 slot / (2) PCI-E Gen.5 x8 slot / (2) PCI-E Gen.5 x16 slot Pre-installed (1) M7136T70-R24-2F for (1) FH/HL PCIe.5 x16 slot + (1) Expansion TYAN Riser FH/HL PCIe.5 x8 slot (Right) Slots Card (PCIe...
  • Page 30 size Feature Hardware Monitor / FAN speed control automatic / Boot from USB device/PXE via LAN/Storage / Console Redirection / SMBIOS 3.3/PnP/Wake on LAN / ACPI 6.0 / ACPI sleeping states S0, S5 Operating OS supported Please refer to our AVL support lists. System list FCC (SDoC)
  • Page 31 Support System (4) 8cm fans Cooling Configuration Type CRPS Input Range AC 100-127V/13A / AC 200-240V/7A Frequency 50-60 Hz Power Supply Output Watts 1,000 Watts (100-127Vac input) / 1,200 Watts (200-240Vac input) Efficiency 80 plus Platinum Redundancy Q'ty / Socket (2) LGA4677 Type Supported CPU...
  • Page 32 (2) USB3.1 Gen.1 ports (@ rear) (1) DB-9 COM port (1) D-Sub 15-pin port I/O Ports RJ-45 (1) GbE port dedicated for IPMI Button ID Button Others (1) ID LED / (1) ID button TPM Support Please refer to our TPM supported list. (Optional) Interface Chipset...
  • Page 33 TS70-B7136 (B7136T70V10E4HR-2T) Form Factor 2U Rackmount Chassis Model TS70 Dimension (D x 27.56" x 17.26" x 3.42" (700 x 438.5 x 87mm) W x H) System Motherboard S7136GM2NRE-2T Name Board Prop. 14.18" x 12.16" (360.2 x 308.8mm) Dimension Buttons (1) ID / (1) PWR w/ LED / (1) RST...
  • Page 34 Memory 8 Channels per CPU channel Memory voltage 1.1V PCIe (1) PCI-E Gen.5 x4 slot / (2) PCI-E Gen.5 x8 slot / (2) PCI-E Gen.5 x16 slot Pre-installed (1) M7136T70-R24-2F for (1) FH/HL PCIe.5 x16 slot + (1) Expansion TYAN Riser FH/HL PCIe.5 x8 slot (Right) Slots Card (PCIe...
  • Page 35 Non-operating - 40° C ~ 70° C (-40° F ~ 158° F) Environment Temp. In/Non-operatin 90%, non-condensing at 35° C g Humidity 90 Barebone (1) TS70-B7136 Barebone Package Contains Manual (1) Quick Installation Guide RoHS 6/6 RoHS Compliant TS70-B7136 (B7136T70V10E4HR)
  • Page 36 Cooling Configuration Type CRPS Input Range AC 100-127V/13A / AC 200-240V/7A Frequency 50-60 Hz Power Supply Output Watts 1,000 Watts (100-127Vac input) / 1,200 Watts (200-240Vac input) Efficiency 80 plus Platinum Redundancy Q'ty / Socket (2) LGA4677 Type Supported CPU Intel Xeon Scalable Processors Processor Series...
  • Page 37 Operating Non-operating - 40° C ~ 70° C (-40° F ~ 158° F) Environment Temp. In/Non-operatin 90%, non-condensing at 35° C g Humidity 90 Barebone (1) TS70-B7136 Barebone Package Contains Manual (1) Quick Installation Guide RoHS 6/6 RoHS Compliant http://www.tyan.com...
  • Page 38 NOTE: 1. The specifications are subject to change without prior notice. 2. Please visit our website for the latest specifications. http://www.tyan.com...
  • Page 39: Standard Parts List

    Standard Parts List This section describes TS70(A)-B7136 package contents and accessories. Open the box carefully and ensure that all components are present and undamaged. The product should arrive with packaged as illustrated below. 1.4.1 Box Contents If any items are missing or appear damaged, contact your retailer or browse to TYAN’s website for service: http://www.tyan.com TS70(A)-B7136 Box Contents:...
  • Page 40: Accessories

    1.4.2 Accessories If any items are missing or appear damaged, contact your retailer or browse to TYAN’s website for service: http://www.tyan.com TS70(A)-B7136 Accessories: (1) Rail Kit and Screw (2) CPU Heatsink (2) CPU Air Duct (2) US Power Cord (2) EU Power Cord (1) Addendum for China Use Only (2) XCC CPU Carrier (E1A) (2) MCC CPU Carrier (E1B)
  • Page 41: About The Product

    About the Product The following views show you the product. 1.5.1 System Front View http://www.tyan.com...
  • Page 42 M1718T65-FPB Front Panel Board/ M1717T65-USB USB Board LAN1 LED ID Button LAN2 LED Power Button with green LED ID LED USB3.2 Gen1 Port1 Warning LED USB3.2 Gen1 Port2 [M.2: Default, SATA: 3.5” / 2.5” SSD/HDD/NVMe bays Depends on SATA driver (SGPIO)] RESET Button M1718T65-FPB Front Panel LED Control Board Switch and LED Indication...
  • Page 43 http://www.tyan.com...
  • Page 44 HDD LED Definitions Drive Status Activity LED (Green) Status LED (Red) Drive present, no activity Green Solid On Drive present with activity Green Blinking Drive Fail Don’t care Red Solid On Drive identify Don’t care Red Blinking @ 1Hz Drive Rebuild Don’t care Red Blinking @ 4Hz http://www.tyan.com...
  • Page 45: System Rear View

    1.5.2 System Rear View PSU1 LAN2 (optional) PSU0 LAN1 (optional) SATA0 PCIe Gen5 OCP Slot SATA1 ID Button LAN3 (dedicated to IPMI Port) + ID LED (2) USB3.2 Gen1 Ports VGA Port Expansion Card Area Serial Port (COM1) ID LED Definition State Color Description...
  • Page 46 http://www.tyan.com...
  • Page 47: System Top View

    1.5.3 System Top View (1) M1717T65-USB USB Board (pre-installed) (1) M1718T65-FPB Front Panel Board (pre-installed) HDD Bays (1) M1320T70-BP12E-12 HDD Backplane Board (pre-installed, for B7136T70V10E4HR-2T SKU) (1) M1321T70A-BP12-8 +(1) M1322T70A-BPE-8 + (1) M1318T65-BP12E-2 (pre-installed, for B7136T70AV12E8HR-2T SKU) (4) 80*80*38mm System fans (1) M7126T65-PDB, R02 Power Distribution Board (pre-installed) (1) M7063F86-PBP...
  • Page 48 HDD Backplane Board Configuration B7136T70V10E4HR-2T / B7136T70V10E4HR HDD Backplane Board: (1) M1320T70-BP12E-12, SAS/NVMe BP for (12) SAS 12Gb/s or (8) SAS 12Gb/s + (4) 2.5” NVMe (1) M1318T65-BP12E-2, SATA 6G BP for (2) 2.5” SSDs B7136T70AV12E8HR-2T / B7136T70AV12E8H HDD Backplane Board: (1) M1321T70A-BP12-8, SAS/SATA BP for (10) 2.5”...
  • Page 49: Chassis Dimension

    1.5.4 Chassis Dimension http://www.tyan.com...
  • Page 50 NOTE http://www.tyan.com...
  • Page 51: Chapter 2: Setting Up

    Chapter 2: Setting Up 2.0.1 Before you Begin This chapter explains how to install the CPUs, CPU heatsinks, memory modules, and hard drives. Instructions on inserting add on cards are also given. 2.0.2 Work Area Make sure you have a stable, clean working environment. Dust and dirt can get into components and cause malfunctions.
  • Page 52: Precautions

    2.0.4 Precautions Components and electronic circuit boards can be damaged by discharges of static electricity. Working on a system that is connected to a power supply can be extremely dangerous. Follow the guidelines below to avoid damage to TS70(A)-B7136 or injury to yourself. Ground yourself properly before removing the top cover of the ...
  • Page 53: Installing Motherboard Components

    Installing Motherboard Components This section describes how to install components on to the mainboard, including CPUs, memory modules and add on cards. 2.1.1 Removing the Chassis Cover Follow these instructions to remove TS70(A)-B7136 chassis cover. 1. Use a screw driver to loosen screws on both sides of the chassis. 2.
  • Page 54 3. Lift the chassis cover up. http://www.tyan.com...
  • Page 55: Removing The Riser Brackets And Air Ducts

    2.1.2 Removing the Riser Brackets and Air Ducts 1. Use a screwdriver to loosen two thumb screws. Then lift up the Riser Card Brackets. 2. Lift up the Air Ducts. http://www.tyan.com...
  • Page 56: Replacing The Chassis Cover

    2.1.3 Replacing the Chassis Cover Follow these instructions to replace TS70(A)-B7136 chassis cover. 1. Place the chassis cover on top. 2. Push the latches simultaneously and slide the chassis cover forwards until it clicks. 3. Use a screw driver to fasten the screws on the top cover. http://www.tyan.com...
  • Page 57: Installing The Cpu And Heatsink

    2.1.4 Installing the CPU and Heatsink Follow the steps below on installing CPU and CPU heat sink. The TS70(A)-B7136 supports (2) Intel® Xeon® Eagle Stream (Sapphire Rapids-SP) series CPU. The following installation is based on an Intel LGA4677 socket. 1. Take out the CPU carrier and processor. 2.
  • Page 58 3. Carefully flip over to check if the processor is secured. 4. Align the triangle edge of the carrier with the notch on the edge of the heatsink. Then install the carrier on the bottom of the heatsink and make sure the latches are snapped under the edge of the heatsink.
  • Page 59 6. Align the heatsink with the CPU socket by the guide pins. Make also sure that the triangle edge of the carrier is aligned correctly with the triangle mark on the CPU socket. Then place the heatsink assembly onto the top of the CPU socket. 7.
  • Page 60 8. To secure the heatsink assembly, use a T30 security Torx to tighten the screws in a sequential order (1234). NOTE: When dissembling the heatsink, loosen the screws in reverse order (4321). http://www.tyan.com...
  • Page 61 9. Align the air duct with the guide pin, and then place the air duct on top of the heatsink. Repeat the same procedures to install another air duct. NOTE: A new heatsink comes with pre-installed thermal grease. Once the heatsink has been removed from the processor, you need to clean the processor and heatsink using an alcohol solvent.
  • Page 62: Installing The Pci-E Card

    2.1.5 Installing the PCI-E Card Follow these instructions to install the PCI-E card. 1. Unscrew to lift up the riser card brackets. 2. Unscrew to remove the dummy bracket. 3. Insert the PCI-E card into the slot and screw it firmly to the riser card bracket. 4.
  • Page 63: Installing The Memory

    2.1.6 Installing the Memory Follow these instructions to install the memory modules onto the motherboard. 1. Press the memory slot locking levers in the direction of the arrows as shown in the following illustration. 2. Align the memory module with the slot. When inserted properly, the memory slot locking levers lock automatically onto the indentations at the ends of the module.
  • Page 64: Dimm Location

    DIMM Location http://www.tyan.com...
  • Page 65 Recommended Memory Population Table Quantity of memory installed Single CPU Installed (Reference Intel Memory Population #610826) √ P0_CHA_DIM0 √ √ √ √ √ √ P0_CHB_DIM0 √ √ √ √ √ P0_CHC_DIM0 √ √ √ √ √ √ P0_CHD_DIM0 √ √ √...
  • Page 66 Quantity of memory installed Dual CPU Installed (Reference Intel Memory Population #610826) √ P0_CHA_DIM0 √ √ √ √ √ √ P0_CHB_DIM0 √ √ √ √ √ P0_CHC_DIM0 √ √ √ √ √ √ P0_CHD_DIM0 √ √ √ √ √ P0_CHE_DIM0 √...
  • Page 67: Installing Hard Drives

    2.1.7 Installing Hard Drives The TS70(A)-B7136 supports twelve 3.5”/2.5” hot-swap HDD/SSDs and two 2.5” hot-swap HDD/SSDs at rear. Installing 3.5” Hot-Swap Hard Drives Follow these instructions to install a 3.5” HDD drive. Warning!!! Always install the hard disk drive to the chassis after the chassis has been secured on the rack.
  • Page 68 Pull open the locking lever to install a 3.5” hard disk drive into the HDD drive tray and lock the tray lever to secure the drive. Reinsert the HDD drive tray into the chassis. Push to secure the locking lever until it clicks into place.
  • Page 69 Installing 2.5” Hot-Swap Hard Drives Follow these instructions to install a 2.5” HDD/SSD drive. Warning!!! Always install the hard disk drive to the chassis after the chassis has been secured on the rack. Press the locking lever latch to pull the locking lever open. Slide the drive tray out.
  • Page 70 Place the 2.5” HDD/SSD into the drive tray and align the 2.5” HDD/SSD with its guide pins. Turn over the drive tray and secure the drive to the tray using 4 screws. http://www.tyan.com...
  • Page 71 Reinsert the drive tray into the chassis. Push to secure the locking lever until it clicks into place. http://www.tyan.com...
  • Page 72 Installing 2.5” Hot-Swap Hard Drives at Rear Follow these instructions to install a 2.5” SSD/HDD drive at rear. Warning!!! Always install the hard disk drive to the chassis after the chassis has been secured on the rack. Press the locking lever latch to pull the locking lever open. Pull open the locking lever to install a 2.5”...
  • Page 73 Reinsert the drive tray into the chassis. Push to secure the locking lever until it clicks into place. http://www.tyan.com...
  • Page 74: Installing Ocp3.0 Card

    2.1.8 Installing OCP3.0 Card Follow these instructions to install an OCP3.0 card to the chassis. Use a screw driver to loosen the screw. Remove the dummy cover. http://www.tyan.com...
  • Page 75 3. Insert the OCP 3.0 Card into the OCP 3.0 slot. 4. Make sure the OCP3.0 card is fully inserted. 5. Use a screw driver to fasten the thumb screw. http://www.tyan.com...
  • Page 76: Rack Mounting

    Rack Mounting After installing the necessary components, the TYAN TS70(A)-B7136 can be mounted in a rack using the supplied rack mounting kit. Sliding Rail Kit Sliding Rails x 2  Rail screw Pack x 1  2.2.1 Installing the Server in a Rack Follow these instructions to mount the TYAN TS70(A)-B7136 into an industry standard 19"...
  • Page 77 http://www.tyan.com...
  • Page 78 3. Repeat steps 2 to 4 to secure the sliding rail to the other side of the server. http://www.tyan.com...
  • Page 79 NOTE: Use a screwdriver to slightly push the latch open and then push the inner rail forwards to unlock. http://www.tyan.com...
  • Page 80 Installing the Outer Rails to the Rack 1. Attach the outer rail to the rack. Pull the latch open and align the square stud with the square hole on the rack rail. Please note that the square stud must be fully attached inside the square hole and then close the latch to lock.
  • Page 81 Rear http://www.tyan.com...
  • Page 82: Rack Mounting The Server

    2.2.2 Rack mounting the Server 1. Install the chassis. Draw out the rails half way and then slide the chassis into the rails. Must be done with at least 2 people. Properly place the chassis directly on the rack and install. 2.
  • Page 83 3. Use a screw driver to fasten the chassis ears to the front surface of chassis. http://www.tyan.com...
  • Page 84: Removing The Server From Rack

    2.2.3 Removing the Server from Rack 1. Use a screw driver to unscrew the chassis ears. Press the latches to pull out the chassis. 2. Pull out the chassis half way to the lock position. Push the white locking tabs forwards to slide the chassis all out from the rack.
  • Page 85: Chapter 3: Replacing Pre-Installed Components

    Chapter 3: Replacing Pre-Installed Components Introduction This chapter explains how to replace the pre-installed components, including the Motherboard, M1718T65-FPB Front Panel Board, M1717T65-USB Board, M1320T70-BP12E-12 / M1321T70A-BP12-8 / M1322T70A-BPE-8 HDD Backplane, M1318T65-BP12E-2 Rear HDD Backplane, M7126T65-PDB-1 Power Distribution board, M7063F86-PBP Power Backplane Board, M7136T70-R24-2F / M7136T70-L28-3F...
  • Page 86: Removing The Cover

    3.1.2 Removing the Cover Before replacing any parts you must remove the chassis cover first. Follow Chapter 2.1.1 to remove the cover of the TS70(A)-B7136. 3.1.3 Replacing Motherboard Components Follow these instructions to replace motherboard components, including the motherboard. Replacing the Riser Card Follow these instructions to replace the M7136T70-R24-2F / M7136T70-L28-3F Riser Card.
  • Page 87: Pci-E Riser Card Specification

    3.2.1 PCI-E Riser Card Specification M7136T70-R24-2F Riser Card M7136T70-L28-3F Riser Card M7136T70-R24-2F Riser Card Form Factor M7136T70-R24-2F: 68.47mmx131mm,T=1.6mm  PCI-E Gen5 x16 SLOT x1 Specifications  PCI-E Gen5 x8 SLOT x2  4P PWR Connector x1 http://www.tyan.com...
  • Page 88: Connector Pin Definition

    M7136T70-L28-3F Riser Card Form Factor M7136T70-L28-3F: 73.8mm x 132.99mm,T=1.6mm PCI-E Gen5 x16 SLOT x1   PCI-E Gen5 x8 SLOT x1 Specifications  PCI-E Gen5 x4 SLOT x1  4P PWR Connector x1 3.2.2 Connector Pin Definition M7136T70-R24-2F Riser Card Location Definition J1 (PCI-E#2)
  • Page 89: Replacing The Front Panel Board

    Replacing the Front Panel Board Follow these instructions to replace the M1718T65-FPB Front Panel Board. 1. Unscrew to release the Front Panel Bezel. 2. Remove the Front Panel Bezel. http://www.tyan.com...
  • Page 90 3. Unscrew the Front Panel Board. 4. Disconnect the Front Panel Control Cable and replace the FPB with a new one. 5. Follow the steps described earlier in reverse to reinstall the Front Panel Board and Front Panel Bezel. http://www.tyan.com...
  • Page 91: Front Panel Board Specifications

    3.3.1 Front Panel Board Specifications Front View Rear View M1718T65-FPB Front Panel Board Form Factor 18mmx40mm,T=1.6mm  IO: 2x15-pin Front Panel Header (J4)  3 Buttons: Reset Button (J3), ID Button (J5), Power Specifications Button with LED (J6)  6 LEDs: LAN1 LED, LAN2 LED, ID LED (LED3), Fault LED (LED6), HDD LED, Power LED http://www.tyan.com...
  • Page 92: Fpb Led Definitions

    3.3.2 FPB LED Definitions No. Function LED Behavior Status Button LAN1 LAN1_LED Green Solid on Linking LAN2 LAN2_LED Green Blinking Active Orange Solid on Memory fail Orange Blinking FAN fail System ID_LED Red Solid on PSU alert monitoring (LED3) System over Red Blinking Temp.
  • Page 93: Replacing The Usb Board

    Replacing the USB Board Follow these instructions to replace the M1717T65-USB Front USB Board. 1. Unscrew to release the Front USB Bezel. 2. Remove the Front USB Bezel. http://www.tyan.com...
  • Page 94 3. Disconnect the USB cable and then unscrew the Front USB Board to replace with a new one. 4. Follow the steps described earlier in reverse to reinstall the Front USB Board and Front USB Bezel. http://www.tyan.com...
  • Page 95: Usb Board Specifications

    3.4.1 USB Board Specifications M1717T65-USB USB Board Form Factor 48mmx19mm,T=1.6mm  USB 3.0 Connector (J1, J2) Specifications  20-pin Header Input Connector (J3) http://www.tyan.com...
  • Page 96: Replacing The System Fan

    Replacing the System Fan Follow these instructions to replace the fan module. 1. Lift up the fan module. 3. Use a screwdriver to press the latch and move the latch in the direction as the arrow shows to get off the fan cage. 4.
  • Page 97: Replacing The Hdd Backplane Board

    Replacing the HDD Backplane Board NOTE: Please remove all the drive trays before detaching the HDD BP. Otherwise the HDD BP will be damage when strains at the disassembly. 1. Remove all fan modules. 2. Unscrew and disconnect all cables connected to the HDD Backplane Board. http://www.tyan.com...
  • Page 98 3. Release the HDD Backplane from the hook. 4. Follow the procedures described earlier to reinstall the HDD backplane board bracket into the chassis. http://www.tyan.com...
  • Page 99: Hdd Backplane Board Features

    3.6.1 HDD Backplane Board Features http://www.tyan.com...
  • Page 100: Specifications Overview

    Front View Rear View M1320T70-BP12E-12 HDD Backplane Board (3.5” SKU) Form Factor 431.2mmx 83mm,T=2.7mm, 8 layer  Support (12) 3.5” SAS/SATA storage or (8) 3.5” SAS/SATA HDD + (4) NVMe SSD storage Input:  (2) MCIO Connector Input for NVMe U.2 storage ...
  • Page 101 Location Definition HDD0 SATA + NVMe Connector HDD1 SATA + NVMe Connector HDD2 SATA + NVMe Connector HDD3 SATA + NVMe Connector HDD4 SATA Connector HDD5 SATA Connector HDD6 SATA Connector HDD7 SATA Connector HDD8 SATA Connector HDD9 SATA Connector HDD10 SATA Connector HDD11...
  • Page 102 Front View Rear View http://www.tyan.com...
  • Page 103 M1321T70A-BP12-8 HDD Backplane Board (2.5” SKU) Form Factor 131mm x 76mm x 3mm, 6 layer  Support (8) 2.5” SATA 6GB/s or SAS 12 GB/s storage Input:  (1) ATX 8-pin PWR Connector Specifications  (2) Mini SAS HD Connector Overview ...
  • Page 104 Front View Rear View http://www.tyan.com...
  • Page 105 M1322T70A-BPE-8 HDD Backplane Board (2.5” SKU) Form Factor 131mm x 76mm x 3mm, 8 layers  Support (8) 2.5” NVMe U.2 storage Input:  (4) MCIO Connector  (1) ATX 8-pin Power Connector Specifications  (1) 30-pin Fan Header for system FAN control Overview Output: ...
  • Page 106: Led Definition

    3.6.2 LED Definition Color State Description NVME/SATA/SAS HDD fail HDD fail LED No failure found NVME/SATA/SAS HDD ready Green NVME/SATA/SAS HDD access HDD Power/Access LED Blinking activity Power disconnected http://www.tyan.com...
  • Page 107: Jumper Setting For Hdd Bp Led

    3.6.3 Jumper Setting for HDD BP LED   Jumper Setting 3PHD1 3PHD7 Broadcom 9560_16i Pin 2-3 Pin 2-3 Broadcom 9560_8i Pin 1-2 Pin 2-3 Broadcom 9460_16i Pin 2-3 Pin 2-3 3PHD1 Default: pin2-3 closed as 0 (pin1-2 closed as 1) for MODE_SELECT0 3PHD7 Default: pin2-3 closed as 0 (pin1-2 closed as 1) for MODE_SELECT1 MODE_SELECT [1:0] = 00: AMD Mode,...
  • Page 108: Replacing The Rear Hdd Bp Board

    Replacing the Rear HDD BP Board Follow the instructions to replace the M1318T65-BP12E-2 Rear HDD BP Board. 1. Disconnect the Micro-fit 4pin power cable and SATA cable. Use a screwdriver to loosen the thumb screw to remove the Rear HDD BP Board. Follow the procedures described earlier in reverse order to reinstall a new Rear HDD BP Board.
  • Page 109: Rear Hdd Bp Board Features

    3.7.1 Rear HDD BP Board Features Front View Rear View M1318T65-BP12E-2 HDD Backplane Board Form Factor 33.5mmx76mm,T=3mm  (2) 2.5” SATA SSDs  (1) SLIMSAS Connector Integrated I/O  (1) 4pin Power Connector  (2) SATA 7pin Connector http://www.tyan.com...
  • Page 110: Hdd Led Definition

    3.7.2 HDD LED Definition Location Definition SLIMSAS Connector SATA0 2.5” SATA SSD Connector SATA1 2.5” SATA SSD Connector SATA0 SATA 7-pin Connector SATA1 SATA 7-pin Connector 4P Power Connector 3PHD1 Header for PCA9544 SMBUS address Select http://www.tyan.com...
  • Page 111: Replacing The Power Distribution Board

    Replacing the Power Distribution Board Follow these instructions to replace the M7126T65-PDB, R02 Power Distribution Board in your system. 1. Disconnect all cables connected to the power distribution board. 2. Unscrew to take off the power distribution board and replace with a new one. 3.
  • Page 112: Power Distribution Board Features

    3.8.1 Power Distribution Board Features M7126T65-PDB, R02 Power Distribution Board Board Size 82MMx 127.3, MM,T=1.6mm  (1) ATX 24-pin power connector  (1) ATX 20-pin power connector  (3) ATX 8-pin power connector Integrated I/O  (1) ATX 4-pin power connector ...
  • Page 113: Connector Pin Definition

    3.8.2 Connector Pin Definition Location Definition PWR1 ATX Power 12x2 ATX Power 10x2 ATX Power 4x2 ATX Power 4x2 ATX Power 4x2 ATX Power 2x2 HDD Power 4x1 HDD Power 4x1 PMBUS DOM_5V_PW1 DOM Power http://www.tyan.com...
  • Page 114: Replacing The Power Backplane Board

    Replacing the Power Backplane Board Follow these instructions to replace the M7063F86-PBP Power Backplane Board (PBP). 1. Unscrew to remove the bracket from the PBP tray. 2. Unscrew to lift up the PDB. Then push the PBP tray backwards. 3. Push the PBP tray in the direction as the arrow shows to unlock the PBP tray. http://www.tyan.com...
  • Page 115 4. Lift up the PBP tray. 4. Unscrew to replace with a new power backplane board. 5. Follow the steps described earlier in reverse order to reinstall the power backplane board tray into the chassis. http://www.tyan.com...
  • Page 116: Power Backplane Board Features

    3.9.1 Power Backplane Board Features Front View Rear View M7063F86-PBP Power Backplane Board Board Size 70MMx 65MM,T=1.6mm  Support (2) Standard RPSU  (2) FCI golden-finger power connector for Delta Integrated I/O redundant PSU (J1, J3)  (1) FCI golden-finger power connector for M7126T65-PDB (J2) http://www.tyan.com...
  • Page 117: Replacing The Power Supply

    3.10 Replacing the Power Supply Follow these instructions to replace the power supply module in your system. Press the latch to pull the power supply out. After replacing a new power supply, press and hold the latch to push the power supply back into the chassis.
  • Page 118: Replacing The Motherboard

    3.11 Replacing the Motherboard Follow the instructions below to replace the motherboard from the chassis. 1. Remove all components installed on the mainboard if there are any. 2. Disconnect all cables connected to the motherboard. http://www.tyan.com...
  • Page 119 3. Remove ten screws securing the motherboard to the chassis. 4. Carefully lift the motherboard from the chassis. http://www.tyan.com...
  • Page 120 NOTE http://www.tyan.com...
  • Page 121: Chapter 4: Mainboard Information

    Chapter 4: Mainboard Information You are now ready to install your motherboard. How to install our products right… the first time The first thing you should do is reading this user’s manual. It contains important information that will make configuration and setup much easier. Here are some precautions you should take when installing your motherboard: (1) Ground yourself properly before removing your motherboard from the antistatic bag.
  • Page 122: Board Image

    Board Image S7136GMRE This picture is representative of the latest board revision available at the time of publishing. The board you receive may not look exactly like the above picture. http://www.tyan.com...
  • Page 123 S7136GM2NRE-2T This picture is representative of the latest board revision available at the time of publishing. The board you receive may not look exactly like the above picture. http://www.tyan.com...
  • Page 124: Block Diagram

    Block Diagram S7136 Block Diagram http://www.tyan.com...
  • Page 125: Mainboard Mechanical Drawing

    Mainboard Mechanical Drawing http://www.tyan.com...
  • Page 126: Board Parts, Jumpers And Connectors

    Board Parts, Jumpers and Connectors This diagram is representative of the latest board revision available at the time of publishing. The board you receive may not look exactly like the above diagram. But for the DIMM number please refer to the above placement for memory installation. For the latest board revision, please visit our web site at http://www.tyan.com.
  • Page 127: Jumpers And Connectors

    Jumpers & Connectors Connectors 1 Dedicated IPMI port + USB3.2 Gen1 x2 24 Rear IO_FAN1 (SYSFA4 (J13) (SYS_FAN_4)) 2 Vertical SATA Connector (SATA5) 25 CPU1_FAN (CPUFAN2 (CPU1_FAN)) 26 Rear IO_FAN2 (SYSFAN3 3 VGA + COM Port (VGA_COM1) (SYS_FAN_3)) 27 22x80mm Connector (M.2#2 4 Vertical SATA Connector (SATA4) (M2_CN2)) 28 22x80mm Connector (M.2#1...
  • Page 128 23 Vertical MCIO Connector (MCIO5 (CN5)) Slots Mini PCIe Slot x24 (J47) Mini PCIe Slot x28 (J8) Jumpers System Reset Jumper (J136) BMC COM Port Jumper (J118) PC BEEP Jumper (J14) BMC COM Port Jumper (J119) Clear CMOS Jumper (J6_PCH) SMBus Select Jumper (3PHD8) ME Recovery Jumper (J3_PCH) LEDs...
  • Page 129 FAN1~6 (CPU_FAN1, CPU_FAN2, SYSFAN1~4): 4-pin FAN Connector Signal P12V FAN_TACH FAN_PWM Use this header to connect the cooling fan to your motherboard to keep the system stable and reliable. FPIO_1: Front Panel Pin Header Signal Signal FP_PW_LED_PW FP_ PWER (P3V3_AUX) FP_ID_LED_PW FP_PW_LED_GND FP_ID_LED_N...
  • Page 130 FAN_HD1: Fan Connector (Reserved for Barebone) Signal Signal BMC_TACH_FRONT1 BMC_BB_TACH_6 BMC_TACH_FRONT2 BMC_BB_TACH_7 BMC_TACH_FRONT3 BMC_BB_TACH_8 BMC_TACH_REAR1 BMC_BB_TACH_9 BMC_TACH_REAR2 BMC_BB_TACH_10 BMC_PWM_FRONT3 BMC_PWM_FRONT12 SMB_TEMP_SML3_STBY_LV BMC_BB_TACH_11 C3_SDA SMB_TEMP_SML3_STBY_LV BMC_BB_TACH_12 C3_SCL P3V3_AUX BMC_PWM_REAR12 P3V3_AUX BMC_BB_TACH_13 BMC_TACH_CPU1 BMC_BB_TACH_14 BMC_TACH_CPU0 BMC_PWM_BB3 BMC_PWM6 BMC_PWM_CPU0 J3: INTRUDER Header   Signal INTRUDER# USB3_FPIO1: Front USB3.2 Gen1 Header...
  • Page 131 SPI_TPM (J16): TPM Module Header Signal Signal SPI_PCH_CLK P3V3_AUX RST_PLTRST_TPM_DEDI_R_N FM_TPM_MOD_PRES_N SPI_PCH_MOSI_IO0 IRQ_TPM_SPI_N SPI_PCH_MISO_IO1 P3V3 SPI_PCH_TPM_CS_R_N SATA_SGPIO1: SATA SGPIO Header for SATA4~5 Signal Signal SDATA OUT SLOAD SCLOCK P3V3_AUX HD_COM2: COM Port Header Signal Signal COM2_DCD COM2_DSR COM2_RXD COM2_RTS COM2_TXD COM2_CTS COM2_DTR COM2_NRI...
  • Page 132 PWR_BTN1: Power Button Signal Signal PWR_BTN1 RST_BTN1: Reset Button Signal Signal FP_RST_BTN_N CLEAR_BTN1: RTC Reset Button for Clear CMOS Pin 1, 2 Pin 3, 4 RST_N You can reset the CMOS settings by using this button, if you have forgotten your system/setup password or need to clear system BIOS setting.
  • Page 133 SATA5: 7-pin Vertical SATA Connector PIN Define SATA9_TXP_C Connects to the Serial SATA9_TXN_C ATA ready drives via the Serial ATA cable. SATA9_RXN_C SATA9_RXP_C J1: OCP Connector (Slot) Signal Signal RST_PERST2_L NIC_PWR_GOOD RST_PERST3_L MAIN_PWR_EN PE_WAKE_L SCAN_LOAD_L RBT_ARB_IN SCAN_DATA_IN RBT_ARB_OUT SCAN_DATA_OUT SLOT_ID<1> SCAN_CLK RMII_TX_EN SLOT_ID<0>...
  • Page 134 CLK_100M_DP<1> CLK_100M_DP<0> PE_HOST_OCP_RX_DN<15> PE_HOST_OCP_TX_DN<15> PE_HOST_OCP_RX_DP<15> PE_HOST_OCP_TX_DP<15> PE_HOST_OCP_RX_DN<14> PE_HOST_OCP_TX_DN<14> PE_HOST_OCP_RX_DP<14> PE_HOST_OCP_TX_DP<14> PE_HOST_OCP_RX_DN<13> PE_HOST_OCP_TX_DN<13> PE_HOST_OCP_RX_DP<13> PE_HOST_OCP_TX_DP<13> PE_HOST_OCP_RX_DN<12> PE_HOST_OCP_TX_DN<12> PE_HOST_OCP_RX_DP<12> PE_HOST_OCP_TX_DP<12> PE_HOST_OCP_RX_DN<11> PE_HOST_OCP_TX_DN<11> PE_HOST_OCP_RX_DP<11> PE_HOST_OCP_TX_DP<11> PE_HOST_OCP_RX_DN<10> PE_HOST_OCP_TX_DN<10> PE_HOST_OCP_RX_DP<10> PE_HOST_OCP_TX_DP<10> PE_HOST_OCP_RX_DN<9> PE_HOST_OCP_TX_DN<9> PE_HOST_OCP_RX_DP<9> PE_HOST_OCP_TX_DP<9> PE_HOST_OCP_RX_DN<8> PE_HOST_OCP_TX_DN<8> PE_HOST_OCP_RX_DP<8> PE_HOST_OCP_TX_DP<8> PRSNTB1_L PRSNTB0_L PE_HOST_OCP_RX_DN<7> PE_HOST_OCP_TX_DN<7> PE_HOST_OCP_RX_DP<7> PE_HOST_OCP_TX_DP<7> PE_HOST_OCP_RX_DN<6>...
  • Page 135 PE_HOST_OCP_RX_DP<0> PE_HOST_OCP_TX_DP<0> USB2_DN USN2_DP PWRBRK_L PRSNTB3_L M2_CN1, M2_CN2: M.2 Connector Signal Signal P3V3 P3V3 CPU0_PE3_M2_RX_R_DN<7> CPU0_PE3_M2_RX_R_DP<7> P3V3_AUX M2_LED_N CPU0_PE3_M2_TX_C_DN<7> P3V3 CPU0_PE3_M2_TX_C_DP<7> P3V3 P3V3 CPU0_PE3_M2_RX_R_DN<6> P3V3 CPU0_PE3_M2_RX_R_DP<6> CPU0_PE3_M2_TX_C_DN<6> CPU0_PE3_M2_TX_C_DP<6> CPU0_PE3_M2_RX_R_DN<5> CPU0_PE3_M2_RX_R_DP<5> CPU0_PE3_M2_TX_C_DN<5> CPU0_PE3_M2_TX_C_DP<5> M2_SMB_CLK CPU0_PE3_M2_RX_R_DN<4> M2_SMB_DAT CPU0_PE3_M2_RX_R_DP<4> M2_SMB_ALERT_N CPU0_PE3_M2_TX_C_DN<4> CPU0_PE3_M2_TX_C_DP<4> M2_PERST_N CLK_100M_M2_DN M2_WAKE_PCIE_N CLK_100M_M2_DP...
  • Page 136 MCIO1~8: Vertical MCIO Connector Signal Signal CPU0_PE0_RX_DP<0> CPU0_PE0_TX_DP<0> CPU0_PE0_RX_DN<0> CPU0_PE0_TX_DN<0> CPU0_PE0_RX_DP<1> CPU0_PE0_TX_DP<1> CPU0_PE0_RX_DN<1> CPU0_PE0_TX_DN<1> BP_TYPEC CPU0_PE0_HD_SCL0 WAKE_PCIE_N CPU0_PE0_HD_SDA0 CLK_100M_CPU0_NVME_ RST_NVME1_CPU0_PERST CLK_100M_CPU0_NVME_ CPRSNTA CPU0_PE0_RX_DP<2> CPU0_PE0_TX_DP<2> CPU0_PE0_RX_DN<2> CPU0_PE0_TX_DN<2> CPU0_PE0_RX_DP<3> CPU0_PE0_TX_DP<3> CPU0_PE0_RX_DN<3> CPU0_PE0_TX_DN<3> http://www.tyan.com...
  • Page 137 SATA_0_3: 36-pin Vertical Mini SAS HD Connector (SATA 3.0 signals) Signal Signal PCH_SSATA_0-3_A1 SGPIO_SATA2_CLOCK_R SGPIO_SATA2_LOAD_R SATA6G_DMI_RX_C_DP<5> SATA6G_DMI_RX_C_DP<4> SATA6G_DMI_RX_C_DN<5> SATA6G_DMI_RX_C_DN<4> SATA6G_DMI_RX_C_DP<7> SATA6G_DMI_RX_C_DP<6> SATA6G_DMI_RX_C_DN<7> SATA6G_DMI_RX_C_DN<6> SGPIO_SATA2_DATOUT_R SSGPIO_DI_0R SAS1_CTYPE SATA6G_DMI_TX_C_DP<5> SATA6G_DMI_TX_C_DP<4> SATA6G_DMI_TX_C_DN<5> SATA6G_DMI_TX_C_DN<4> SATA6G_DMI_TX_C_DP<7> SATA6G_DMI_TX_C_DP<6> SATA6G_DMI_TX_C_DN<7> SATA6G_DMI_TX_C_DN<6> http://www.tyan.com...
  • Page 138 SATA_0_7: 72-pin Vertical Mini SAS HD Connector (SATA 3.0 signals) Signal Signal PCH_SATA_0-7_A1 SGPIO_SATA0_CLOCK_R SGPIO_SATA0_LOAD_R SATA1_RXP_C SATA0_RXP_C SATA1_RXN_C SATA0_RXN_C SATA3_RXP_C SATA2_RXP_C SATA3_RXN_C SATA2_RXN_C SGPIO_SATA0_DATOUT_R SGPIO_DI_0R SAS0_CTYPE SATA1_TXP_C SATA0_TXP_C SATA1_TXN_C SATA0_TXN_C SATA3_TXP_C SATA2_TXP_C SATA3_TXN_C SATA2_TXN_C NC_PCH_SATA_0-7_A1 SGPIO_SATA1_CLOCK_R SGPIO_SATA1_LOAD_R SATA5_RXP_C SATA4_RXP_C SATA5_RXN_C SATA4_RXN_C SATA7_RXP_C SATA6_RXP_C...
  • Page 139 J118: BMC COM Port Jumper Signal Signal BMC_COM2_RXD RXD_2 BMC_COM5_RXD (Default) Pin1-2 closed: BMC COM PORT2 Pin2-3 closed: BMC CONSOLE PORT5 J119: BMC COM Port Jumper Signal Signal BMC_COM2_TXD TXD_2 BMC_COM5_TXD (Default) Pin1-2 closed: BMC COM PORT2 Pin2-3 closed: BMC CONSOLE PORT5 J1_PCH: BIOS Recovery Mode Jumper Pin1 Pin2...
  • Page 140 J4_PCH: Manufacture Mode Jumper Pin1 Pin2 Pin3 1K-Pull hi FM_MFG_MODE 10K-Pull down Pin1-2 closed: MFG DISABLE (Default) Pin2-3 closed: MFG ENABLE J5_PCH: BIOS ADVANCE FUNCTIONS Jumper Pin1 Pin2 Pin3 1K-Pull down FM_BIOS_ADV_FUNCTIONS 10K-Pull hi (Default) Pin1-2 closed: Normal Operation Pin2-3 closed: BIOS CORE EXECUTION TREE J6_PCH: CLEAR CMOS Jumper Pin1 Pin2...
  • Page 141 J14: System Buzzer Jumper Pin1 Pin2 Pin3 Pin4 VCC5_BZ BUZ_1 BUZ_2 (Default) Pin3-4 closed: Normal Mode Pin2-3 closed: Disable PC Beep Pin1-4 closed: Use the external speaker http://www.tyan.com...
  • Page 142: Led Definitions

    LED Definitions Signal P3V3 On board HDD_LED1 HDD LED State Description Blue HDD active blinking Signal P3V3_STBY State Description BMC_LED The LED shuts off when the BMC Heartbeat (D1_BMC) controller cannot be detected or properly initiated The LED blinks per second to Blinking Green indicate that the BMC controller...
  • Page 143 Signal P3V3_AUX State Description CPLD CPLD_LED The LED shuts off when the HeartBeat (D33) CPLD controller cannot be detected or properly initiated. The LED blinks per second to Green indicate that the BMC controller is working normally. Signal P3V3_AUX PSU Alert State Description PSMI_LED1...
  • Page 144: Installing The Processor And Heat Sink

    Installing the Processor and Heat sink Check our website at http://www.tyan.com for latest processor support. NOTE: MITAC TYAN is not liable for damage as a result of operating an unsupported configuration. Processor Installation for Intel LGA4677 Socket Follow the steps below to install the processors and heat sinks. NOTE: Please save and replace the CPU protection cap when returning for service.
  • Page 145 1. Align the triangle edge of the carrier with the notch on the edge of the heatsink. Then install the carrier on the bottom of the heatsink and make sure the latches are snapped under the edge of the heatsink. 2.
  • Page 146 4. Carefully flip the heatsink assembly. Align the heatsink with the CPU socket by the guide pins. Make also sure that the triangle edge of the carrier is aligned correctly with the triangle mark on the CPU socket. Then place the heatsink assembly onto the top of the CPU socket. 5.
  • Page 147 6. To secure the heatsink assembly, use a T30 Security Torx to tighten the screws in a sequential order (1234). NOTE: When disassembling the heatsink, loosen the screws in reverse order (4321). NOTE: A new heatsink comes with pre-applied thermal grease. Once the heatsink has been removed from the processor, you need to clean the processor and heatsink using an alcohol solvent.
  • Page 148: Tips On Installing Motherboard In Chassis

    Tips on Installing Motherboard in Chassis Before installing your motherboard, make sure your chassis has the necessary motherboard support studs installed. These studs are usually metal and are gold in color. Usually, the chassis manufacturer will pre-install the support studs. If you are unsure of stud placement, simply lay the motherboard inside the chassis and align the screw holes of the motherboard to the studs inside the case.
  • Page 149 http://www.tyan.com...
  • Page 150: Installing The Memory

    Installing the Memory Before installing memory, ensure that the memory you have is compatible with the motherboard and processor. Check the TYAN Web site at http://www.tyan.com details of the type of memory recommended for your motherboard.  Supports up to 128GB of ECC UDIMM DDR4 2666/2400MHz memory. ...
  • Page 151 Recommended Memory Population Table Quantity of memory installed Single CPU Installed (Reference Intel Memory Population #610826) √ P0_CHA_DIM0 √ √ √ √ √ √ P0_CHB_DIM0 √ √ √ √ √ P0_CHC_DIM0 √ √ √ √ √ √ P0_CHD_DIM0 √ √ √...
  • Page 152   Quantity of memory installed Dual CPU Installed (Reference Intel Memory Population #610826) √ P0_CHA_DIM0 √ √ √ √ √ √ P0_CHB_DIM0 √ √ √ √ √ P0_CHC_DIM0 √ √ √ √ √ √ P0_CHD_DIM0 √ √ √ √ √ P0_CHE_DIM0 √...
  • Page 153 Memory Installation Procedure Follow these instructions to install memory modules into the S7136. Unlock the clips as shown in the illustration. Insert the memory module firmly into the socket by gently pressing down until it sits flush with the socket. Lock the clips to secure the memory module into place.
  • Page 154: Attaching Drive Cables

    Attaching Drive Cables Attaching Serial ATA Cables S7136 is equipped with fourteen (14) Serial ATA (SATA) channel. Connections for the drives are very simple. There is no need to set Master/Slave jumpers on SATA drives. If you are in need of SATA/SAS cables or power adapters please contact your place of purchase.
  • Page 155: Installing Add-In Cards

    4.10 Installing Add-In Cards Before installing add-in cards, it’s helpful to know if they are fully compatible with your motherboard. For this reason, we’ve provided the diagrams below, showing the slots that may appear on your motherboard. Simply find the appropriate slot for your add-in card and insert the card firmly. Do not force any add-in cards into any slots if they do not seat in place.
  • Page 156: Connecting External Devices

    4.11 Connecting External Devices Connecting external devices to the motherboard is an easy task. The motherboard supports a number of different interfaces through connecting peripherals. See the following diagrams for the details. NOTE: Peripheral devices can be plugged straight into any of these ports but software may be required to complete the installation.
  • Page 157 Intel X710-AT2 10G (supports 2.5G, 5G) LAN LED Color Definition 100/1000 Mbps LAN Link/Activity LED Scheme Description Left LED (Link/Activity) Right LED (Speed) No Link Link Solid Yellow 100 Mbps Active Blinking Yellow Link Solid Green Solid Yellow 1/2.5/5 Gbps Active Blinking Green Solid Yellow...
  • Page 158: Installing The Power Supply

    4.12 Installing the Power Supply There are four (4) power connectors on your S7136 motherboard. The S7136 supports EPS 12V power supply. NOTE: You must unplug the power supply before plugging the power cables to motherboard connectors. Warning: The mainboard supports up to 350W CPU TDP with the use of 16AWG...
  • Page 159 J55 (PWR4): 4-Pin Power Connector Signal Signal VCC12_CPU_OTHERS VCC12_CPU_OTHERS http://www.tyan.com...
  • Page 160: Installing Ocp3.0 Rail Kit

    4.13 Installing OCP3.0 Rail Kit 1. Take out the OCP 3.0 Rail Kit and Screw Pack. 2. Install the OCP rail to the chassis. Then secure the rail using 1 screw. 2. Insert the server board into the chassis. 3. Use 9 screws (blue arrow) to secure the server board to the chassis. Then use another screw (red arrow) to secure the server board to OCP rail.
  • Page 161 NOTE 1: To avoid damage, when securing the server board, do not use torque force greater than 5~7 kgf/cm (4.35 ~ 6.09 lb/in). When securing the OCP rail screw, do not use torque force greater than 1.5~2 kgf/cm (1.30 ~ 1.73 lb/in). NOTE 2: For high temperature risk to damage OCP3.0 chipset under S5 state, a default threshold 100 degree C is to be set.
  • Page 162: Finishing Up

    4.14 Finishing Up Congratulations on making it this far! You have finished setting up the hardware aspect of your computer. Before closing up your chassis, make sure that all cables and wires are connected properly, especially IDE cables and most importantly, jumpers.
  • Page 163: Chapter 5: Bios Setup

    Chapter 5: BIOS Setup About the BIOS The BIOS is the basic input/output system, the firmware on the motherboard that enables your hardware to interface with your software. The BIOS determines what a computer can do without accessing programs from a disk. The BIOS contains all the code required to control the keyboard, display screen, disk drives, serial communications, and a number of miscellaneous functions.
  • Page 164: Getting Help

    5.1.2 Getting Help Pressing [F1] will display a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window, press [ESC] or the [Enter] key again. 5.1.3 In Case of Problems If you have trouble booting your computer after making and saving the changes with the BIOS setup program, you can restart the computer by holding the power button down until the computer shuts off (usually within 4 seconds);...
  • Page 165: Main Menu

    Main Menu In this section, you can alter general features such as the date and time. Note that the options listed below are for options that can directly be changed within the Main Setup screen. System Language Choose the system default language. English / Simplified Chinese / Japanese System Date Set the Date.
  • Page 166: Advanced Menu

    Advanced Menu This section facilitates configuring advanced BIOS options for your system. NOTE: This is a sample screenshot of the Advanced Menu. The HII network drivers displayed here depend on the card(s) you installed and the functions you enabled. Network Stack Configuration Network Stack Settings.
  • Page 167 Super IO Configuration System Super IO Chip Parameters. Hardware Health Configuration Hardware Health Configuration Parameters. PCI Subsystem Settings PCI, PCI-X and PCI Express Settings. NVMe Configuration NVMe Devices Information. Trusted Computing Trusted Computing Settings. CSM Configuration Enable/Disable, Option ROM execution settings, etc. Redfish Host Interface Settings Redfish Host Interface Parameters.
  • Page 168: Network Stack Configuration

    5.3.1 Network Stack Configuration NOTE: The BIOS will automatically read the onboard LAN controller. Network Stack Enable/Disable UEFI Network Stack. Disabled / Enabled NOTE: The following items are available when Network Stack is set to [Enabled]. IPv4 PXE Support Enable/Disable IPv4 PXE boot support. If disabled, IPv4 PXE boot option will not be available.
  • Page 169 IPv6 HTTP Support Enable/Disable IPv6 HTTP boot support. If disabled, IPv6 HTTP boot option will not be available. Disabled / Enabled PXE boot wait time Wait time to press ESC key to abort the PXE boot. Use either +/- or numeric keys to set the value.
  • Page 170: S5 Rtc Wake Settings

    5.3.2 S5 RTC Wake Settings Wake system from S5 Enable or disable System wake on alarm event. Select FixedTime, system will wake on the hr::min::sec specified. Select DynamicTime, system will wake on the current time + Increase minute(s). Disabled / Fixed Time / Dynamic Time When Wake system from S5 is set to [Fixed Time] Wake up hour Select 0-23.
  • Page 171: Serial Port Console Redirection

    5.3.3 Serial Port Console Redirection Console Redirection / Console Redirection EMS Console redirection Enable or Disable. Disabled / Enabled Legacy Console Redirection Settings Legacy Console redirection settings. Console Redirection Settings The settings specify how the host computer and the remote computer (which the user is using) will exchange data.
  • Page 172: Com1 Console Redirection Settings

    5.3.3.1 COM1 Console Redirection Settings Terminal Type Emulation: ANSI: Extended ASCII char set. VT100: ASCII char set. VT100+: Extends VT100 to support color, function keys, etc. VT-UTF8: Uses UTF8 encoding to map Unicode chars onto 1 or more bytes.  VT100+ / VT100 / VT-UTF8 / ANSI Bits per Second Selects serial port transmission speed.
  • Page 173 Stop Bits Stop bits indicate the end of a serial data packet. (A start bit indicates the beginning). The standard setting is 1 stop bit. Communication with slow devices may require more than 1 stop bit. 1 / 2 Flow Control Flow Control can prevent data loss from buffer overflow.
  • Page 174 5.3.3.2 COM2 Console Redirection Settings Terminal Type Emulation: ANSI: Extended ASCII char set. VT100: ASCII char set. VT100+: Extends VT100 to support color, function keys, etc. VT-UTF8: Uses UTF8 encoding to map Unicode chars onto 1 or more bytes.  VT100+ / VT100 / VT-UTF8 / ANSI Bits per Second Selects serial port transmission speed.
  • Page 175 Stop Bits Stop bits indicate the end of a serial data packet. (A start bit indicates the beginning). The standard setting is 1 stop bit. Communication with slow devices may require more than 1 stop bit. 1 / 2 Flow Control Flow Control can prevent data loss from buffer overflow.
  • Page 176 5.3.3.3 Legacy Console Redirection Settings Legacy Serial Redirection Port Select a COM port to display redirection of Legacy OS and Legacy OPROM Messages.  COM1 / COM2 Resolution On Legacy OS, the Number of Rows and Columns supported redirection. 80x24 / 80x25 Redirect After POST When BootLoader is selected, then Legacy Console Redirection is disabled before booting to legacy OS, When Always Enable is selected, then Legacy Console...
  • Page 177 5.3.3.4 Serial Port for Out-Of-Band Management/Windows Emergency Services (EMS) Console Redirection Settings Out-of-Band Mgmt Port Microsoft Windows Emergency Management Services (EMS) allows for remote management of a Windows Server OS through a serial port. COM1 / COM2 Terminal Type VT-UTF8 is the preferred terminal type for out-of-band management. The next best choice is VT100+ and then VT100.
  • Page 178 Flow Control Flow Control can prevent data loss from buffer overflow. When sending data, if the receiving buffers are full, a ‘stop’ signal can be sent to stop the data flow. Once the buffers are empty, a ‘start’ signal can be sent to restart the flow. Hardware flow control uses two wires to send start/stop signal.
  • Page 179: Pcie Device Configuration

    5.3.4 PCIe Device Configuration http://www.tyan.com...
  • Page 180 5.3.4.1 Option ROM Dispatch Policy LAN1 & LAN2 (X710) Enable or Disable X710 LAN1 and LAN2 Option ROM. Enabled / Disabled LAN2 Option ROM Enabled or Disabled LAN2 Option ROM. Enabled / Disabled PCIE#1~5 Option ROM Enable or Disable Option ROM execution for selected Slot. Enabled / Disabled http://www.tyan.com...
  • Page 181: Usb Configuration

    5.3.5 USB Configuration Legacy USB Support Enables USB legacy support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications. Disabled / Enabled / Auto 格式化: 字型色彩: 黑色 XHCI Hand-off This is a workaround for OSes without XHCI hand-off support.
  • Page 182 USB transfer time-out The time-out value for Control, Bulk and Interrupt transfers. 1 sec / 5 sec / 10 sec / 20 sec Device reset time-out USB mass storage device Start Unit command time-out. 10 sec / 20 sec / 30 sec / 40 sec Device power-up delay Maximum time the device will take before it properly reports itself to the Host Controller.
  • Page 183: Onboard Device Configuration

    5.3.6 Onboard Device Configuration Onboard VGA Enable/Disable ASPEED VGA. Enabled / Disabled Primary Display Select active Video type. Onboard / External NMI Function Enable or Disable NMI function. Enabled / Disabled Chassis Intrusion Detection Enabled: When a chassis open event is detected, the BIOS will display the event. Enabled / Disabled http://www.tyan.com...
  • Page 184: Super Io Configuration

    5.3.7 Super IO Configuration Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA). Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB). http://www.tyan.com...
  • Page 185 5.3.7.1 Serial Port 1 Configuration Serial Port Enable or disable Serial Port (COM). Enabled / Disabled Device Settings Read only. Change Settings Select an optimal setting for Super IO Device. Auto / IO=3F8h; IRQ=4; / IO=2F8h, IRQ=4; / IO=3E8h, IRQ=4; / IO=2E8h, IRQ=4;...
  • Page 186 5.3.7.2 Serial Port 2 Configuration Serial Port Enable or disable Serial Port (COM). Enabled / Disabled Device Settings Read only. Change Settings Select an optimal setting for Super IO Device. Auto / IO=3F8h; IRQ=3; / IO=2F8h, IRQ=3; / IO=3E8h, IRQ=3; / IO=2E8h, IRQ=3;...
  • Page 187: Hardware Health Configuration

    5.3.8 Hardware Health Configuration Fan Speed Control Fan Speed Control. Automatic / Manual / Full Speed NOTE 1: Change the Fan Speed Control BIOS setting from [Manual] to [Full Speed] when installing the Nvidia GeForce / Quardro GPU and any VGA card. NOTE 2: The following items are available when Fan Speed Control is set to [Manual].
  • Page 188 Number of PSU User can select PSU number for needed. 2 / 1 http://www.tyan.com...
  • Page 189 5.3.8.1 Sensor Data Register Monitoring Here shows a sample screenshot of PC Health Status. http://www.tyan.com...
  • Page 190 NOTE: SDR can not be modified. Read only. http://www.tyan.com...
  • Page 191: Pci Subsystem Settings

    5.3.9 PCI Subsystem Settings Above 4G Decoding Enables or Disables 64bit capable Devices to be Decoded in Above 4G Address Space (Only if System Supports 64 bit PCI Decoding). Enabled / Disabled SR-IOV Support If system has SR-IOV capable PCIe Devices, this option Enables or Disables Single Root IO Virtualization Support.
  • Page 192: Pci Express Settings

    5.3.9.1 PCI Express Settings Max Payload Set Maximum Payload of PCI Express Device or allow System BIOS to select the value. Auto / 128 Bytes / 256 Bytes / 512 Bytes / 1024 Bytes / 2048 Bytes / 4096 Bytes http://www.tyan.com...
  • Page 193: Nvme Configuration

    5.3.10 NVMe Configuration This page shows the Devices you installed. Read only. http://www.tyan.com...
  • Page 194: Trusted Computing

    5.3.11 Trusted Computing Security Device Support Enables or Disables BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. Enabled / Disabled http://www.tyan.com...
  • Page 195: Csm Configuration

    5.3.12 CSM Configuration CSM support Enable/Disable CSM Support Enabled / Disabled Option ROM Messages Set display mode for Option ROM Force BIOS / Keep Current Network Controls the execution of UEFI and Legacy PXE OpROM UEFI / Legacy Storage Controls the execution of UEFI and Legacy Storage OpROM UEFI / Legacy http://www.tyan.com...
  • Page 196 Video Controls the execution of UEFI and Legacy Video OpROM UEFI / Legacy Other PCI devices Determines OpROM execution policy for devices other than network, storage, or video. UEFI / Legacy http://www.tyan.com...
  • Page 197: Redfish Host Interface Settings

    5.3.13 Redfish Host Interface Settings Redfish Enable/Disable AMI Redfish. Enabled / Disabled BMC Redfish Version / BIOS Redfish Version Read only. Redfish BMC Settings IP Address / IP Mask Address / IP Port Read only. http://www.tyan.com...
  • Page 198: Tis Auth Configuration

    5.3.14 TIs Auth Configuration Server CA Configuration Press <Enter> to configure Server CA. Client Cert Configuration Press <Enter> to configure Client Cert. http://www.tyan.com...
  • Page 199 5.3.14.1 Server CA Configuration Enroll Cert Press <Enter> to enroll cert. Delete Cert Press <Enter> to delete cert. http://www.tyan.com...
  • Page 200 5.3.14.1.1 Enroll Cert Enroll Cert Using File Enroll Cert Using File. Cert GUID Input digit character in 11111111-2222-3333-4444-1234567890ab format. Commit Changes and Exit Commit Changes and Exit. Discard Changes and Exit Discard Changes and Exit. http://www.tyan.com...
  • Page 201 5.3.14.1.2 Delete Cert FE9C6606-8B49-44A3-8B6B-DEA3A0E032 GUID for CERT. Disabled / Enabled http://www.tyan.com...
  • Page 202: Iscsi Configuration

    5.3.15 iSCSI Configuration Please follow the instructions to initiate the iSCSI function. Step 1. Select Advanced  CSM Configuration  Network  [UEFI]. Step 2. Select Advanced  Network Stack Configuration  Network Stack  [Enabled] Step 3. Save changes and reboot. Host iSCSI Configuration Host iSCSI Configuration http://www.tyan.com...
  • Page 203 5.3.15.1 Host iSCSI Configuration iSCSI Initiator Name The worldwide unique name of iSCSI Initiator. Only IQN format is accepted. IQN format [iqn.xxx]. xxx ranges from 4 to 223. For example: Enter [iqn.5] Add an Attempt Add an Attempt. Delete Attempts Delete one or more attempts.
  • Page 204 5.3.15.1.1 Add an Attempt The screen shows the network protocols installed. If no network protocols are installed, the screen displays the message “Necessary network protocols are not available to retrieve….” http://www.tyan.com...
  • Page 205 5.3.15.1.2 Delete Attempts Commit Changes and Exit Commit Changes and Exit. Discard Changes and Exit Discard Changes and Exit. http://www.tyan.com...
  • Page 206 5.3.15.1.3 Change Attempt Order Commit Changes and Exit Commit Changes and Exit. Discard Changes and Exit Discard Changes and Exit. http://www.tyan.com...
  • Page 207: Vlan Configuration (Mac:xxxxxxxxxxxx)

    5.3.16 VLAN Configuration (MAC:xxxxxxxxxxxx) Enter Configuration Menu Press ENTER to enter configuration menu for VLAN configuration. http://www.tyan.com...
  • Page 208 5.3.16.1 Enter Configuration Menu VLAN ID VLAN ID of new VLAN or existing VLAN, valid value is 0~4094. Priority 802.1Q Priority, valid value is 0~7. Add VLAN Create a new VLAN or update existing VLAN. Remove VLAN Remove selected VLANs. http://www.tyan.com...
  • Page 209: Mac:xxxxxxxxxxxx - Ipv6 Network Configuration

    5.3.17 MAC:xxxxxxxxxxxx - IPv6 Network Configuration Enter Configuration Menu Press ENTER to enter configuration menu for IPv6 configuration. http://www.tyan.com...
  • Page 210 5.3.17.1 Enter Configuration Menu Interface ID The 64 bit alternative interface ID for the device. The string is colon separated, e.g. ff:dd:88:66:cc:1:2:3 xx:xx:x:xx:xx:xx:xx:xx DAD Transmit Count The number of consecutive Neighbor Solicitation messages sent while performing Duplicate Address Detection on a tentative address. A value of zero indicates that Duplicate Address Detection is not performed.
  • Page 211 Save Changes and Exit Save Changes for interface ID, DAD transmit count, policy, and data in advanced configuration. http://www.tyan.com...
  • Page 212 5.3.17.1.1 Advanced Configuration New IPv6 address Manual IP address can only be configured under manual policy. Separate the IP address with blank space to configure more than one address. e.g. 2002::1/64 2002::2/64 New Gateway addresses Gateway IP address can only be configured under manual policy. e.g. 2002::3. Separate the IP address with blank space to configure more than one address.
  • Page 213: Mac:xxxxxxxxxxxx - Ipv4 Network Configuration

    5.3.18 MAC:xxxxxxxxxxxx - IPv4 Network Configuration Configured Indicate whether network address configured successfully or not. Disabled / Enabled Save Changes and Exit Save Changes and Exit. http://www.tyan.com...
  • Page 214: Cpu

    Processor Configuration Displays and provides option to change the Processor Settings. Common RefCode Configuration Common RefCode Configuration. Uncore Configuration Displays and provides option to change the Uncore Settings. Memory Configuration Displays and provides option to change the Memory Settings. IIO Configuration Displays and provides option to change the IIO Settings.
  • Page 215: Processor Configuration

    5.4.1 Processor Configuration Enabled LP (Global) Enabled Logical processor (Software Method to Enabled/Disabled Logical Processor threads) (Hyper-Threading). All LPs / Single LP Enable Intel® TXT Enable Intel® TXT. Disabled / Enabled Hardware Prefetcher =MLC Streamer Prefetcher (MSR 1A4h Bit [0]). Disabled / Enabled Adjacent Cache Prefetch =MLC Spatial Prefetcher (MSR 1A4h Bit [1]).
  • Page 216 Extended APIC Enabled/Disabled extended APIC support. NOTE: This will enable VT-d automatically if x2APIC is enabled. Disabled / Enabled AES-NI Enabled/Disabled AES-NI support. Disabled / Enabled http://www.tyan.com...
  • Page 217: Common Refcode Configuration

    5.4.2 Common RefCode Configuration Numa Enabled or Disabled Non uniform Memory Access (NUMA). Disabled / Enabled http://www.tyan.com...
  • Page 218: Uncore Configuration

    5.4.3 Uncore Configuration Uncore General Configuration Displays and provides option to change the Uncore General Settings. http://www.tyan.com...
  • Page 219 5.4.3.1 Uncore General Configuration Uncore Status Uncore Status Help. Link Speed Mode Select the UPI link speed as either the POR speed (Fast) or default speed (Slow). Slow / Fast Link Frequency Select Allows for selecting the UPI Link Frequency. 12.8GT/s / 14.4GT/s / 16.0GT/s / Auto / Use Per Link Setting Link L0p Enable Enable --- Set the c_l0p_en,...
  • Page 220 Link L1 Enable Enable --- Set the c_l1_en, Disable --- Reset it, Auto --- Auto decides based on Si Compatibility. Disabled / Enable / Auto Disabled supports 1-cluster and 4-IMC may interleave. Enabled SNC2 supports 2-clusters SNC and 2-way IMC interleave. Enabled SNC4 supports 4-clusters SNC and 1-way IMC interleave.
  • Page 221 5.4.3.1.1 Uncore Status Read only http://www.tyan.com...
  • Page 222: Memory Configuration

    5.4.4 Memory Configuration Memory Frequency Maximum Memory Frequency Selections in Mhz. If Enforce POR is disabled, user will be able to run at higher frequencies than the memory support (limited by processor support). Do not select Reserved. Auto / 4000 / 4400 / 4800 Memory Topology Displays memory topology with Dimm population information.
  • Page 223 5.4.4.1 Memory Topology Read only. http://www.tyan.com...
  • Page 224 5.4.4.2 Memory RAS Configuration Dynamic ECC Mode Selection Enabled/Disabled Dynamic ECC Mode Selection. Disabled / Enabled Mirror Mode Full Mirror Mode will set entire 1LM memory in system to be mirrored, consequently reducing the memory capacity by half. Partial Mirror Mode will enable the required size of memory to be mirrored.
  • Page 225 Patrol Scrub Enabled/Disabled Patrol Scrub. Disabled / Enabled Patrol Scrub Interval Selects the number of hours (1-24) required to complete full scrub. A value of zero means auto! http://www.tyan.com...
  • Page 226: Iio Configuration

    5.4.5 IIO Configuration Intel® VT for Directed I/O (VT-d) Press <Enter> to bring up the Intel® VT for Directed I/O (VT-d) Configuration menu. Intel® VMD Technology Press <Enter> to bring up the Intel® VMD for Volume Management Device Configuration menu. PCIe Hot Plug Enabled/Disabled PCIe Hot Plug globally.
  • Page 227 5.4.5.1 Socket 0 Configuration IOU0 (IIO PCIe Port 1) Selects PCIe port Bifurcation for selected slot(s). Port Format: xDxCxBxA The port can further be x2x2. Auto / x4x4x4x4 / x4x4_x8 / x_x8x4x4 / x_x8x_x8 / x_x_x_x16 IOU1 (IIO PCIe Port 2) Selects PCIe port Bifurcation for selected slot(s).
  • Page 228 IOU4 (IIO PCIe Port 5) Selects PCIe port Bifurcation for selected slot(s). Port Format: xDxCxBxA The port can further be x2x2. Auto / x4x4x4x4 / x4x4_x8 / x_x8x4x4 / x_x8x_x8 / x_x_x_x16 Port 1A/1C/1E/1G/2A/2E/3A/4A/4C/4E/4G/5A/5C/5E/5G Settings related to PCI Express Ports (0/1A/1B/1C/1D/2A/2B/2C/2D/3A/3B/3C/3D/4A/4B/4C/4D/5A/5B/5C/5D).
  • Page 229 5.4.5.1.1 Port 1A/1C/1E/1G/2A/2E/3A/4A/4C/4E/4G/5A/5C/5E/5G PCI-E Port In auto mode the BIOS will remove the EXP port if there is no device or errors on that device and the device is not HP capable. Enabled/Disabled is used to enable/disable the port and expose/hide its CFG space. Auto / No / Yes Hot Plug Capable This option specifies if the link is considered Hot Plug capable.
  • Page 230 Override Max Link Width Override the max link width that was set by bifurcation. Auto / x1 / x2 / x4 PCI-E Port DeEmphasis De-Emphasis control (LNKCON2[6]) for this PCIe port. -6.0 dB / -3.5 dB PCI-E ASPM Support This option can disable ASPM support in a PCIe root port. ‘Auto’ keeps hardware default.
  • Page 231 5.4.5.2 Socket 1 Configuration IOU0 (IIO PCIe Port 1) Selects PCIe port Bifurcation for selected slot(s). Port Format: xDxCxBxA The port can further be x2x2. Auto / x4x4x4x4 / x4x4_x8 / x_x8x4x4 / x_x8x_x8 / x_x_x_x16 IOU1 (IIO PCIe Port 2) Selects PCIe port Bifurcation for selected slot(s).
  • Page 232 IOU4 (IIO PCIe Port 5) Selects PCIe port Bifurcation for selected slot(s). Port Format: xDxCxBxA The port can further be x2x2. Auto / x4x4x4x4 / x4x4_x8 / x_x8x4x4 / x_x8x_x8 / x_x_x_x16 Port 1A/1C/1E/1G/2A/2E/3A/4A/4C/4E/4G/5A/5C/5E/5G Settings related to PCI Express Ports (0/1A/1B/1C/1D/2A/2B/2C/2D/3A/3B/3C/3D/4A/4B/4C/4D/5A/5B/5C/5D).
  • Page 233 5.4.5.2.1 Port 1A/2A/2C/2E/3A/4A/4C/4E/4G/5A/5C/5E/5G PCI-E Port In auto mode the BIOS will remove the EXP port if there is no device or errors on that device and the device is not HP capable. Enabled/Disabled is used to enable/disable the port and expose/hide its CFG space. Auto / No / Yes Hot Plug Capable This option specifies if the link is considered Hot Plug capable.
  • Page 234 Override Max Link Width Override the max link width that was set by bifurcation. Auto / x1 / x2 / x4 PCI-E Port DeEmphasis De-Emphasis control (LNKCON2[6]) for this PCIe port. -6.0 dB / -3.5 dB PCI-E ASPM Support This option can disable ASPM support in a PCIe root port. ‘Auto’ keeps hardware default.
  • Page 235 5.4.5.3 Intel® VT for Directed I/O (VT-d) Intel® VT for Directed I/O (VT-d) Enabled/Disabled Intel® Virtualization Technology for Directed I/O (VT-d) by reporting the I/O device assignment to VMM through DMAR ACPI Tables. Disabled / Enabled Pre-boot DMA Protection Enabled DMA Protection in Pre-boot environment (If DMAR table is installed in DXE and if VTD_INFO_PPI is installed in PEI.) Disabled / Enabled PCIe ACSCTL...
  • Page 236 Translation Blocking When set, the component blocks all upstream Memory Requests whose Address Translation (AT) field is not set to the default value. Disabled / Enabled P2P Request Redirect This bit determines when the component redirects peer-to-peer Requests upstream. Disabled / Enabled P2P Completion Redirect Determines when the component redirects peer-to-peer Completions upstream, applicable only to Read Completions whose Relaxed Ordering Attribute is clear.
  • Page 237 5.4.5.4 Intel® VMD Technology http://www.tyan.com...
  • Page 238 5.4.5.4.1 Intel VMD for Volume Management for Socket 0 VMD Config for IOU0 Enable/Disable VMD Enabled/Disabled VMD in this Stack. Disabled / Enabled VMD Config for IOU1 Enable/Disable VMD Enabled/Disabled VMD in this Stack. Disabled / Enabled VMD Config for IOU2 Enable/Disable VMD Enabled/Disabled VMD in this Stack.
  • Page 239 VMD Config for IOU4 Enable/Disable VMD Enabled/Disabled VMD in this Stack. Disabled / Enabled NOTE: The following items are available when Enabled/Disable VMD is set to [Enabled]. VMD Port A/B/C/D/E/F/G/H Enable/Disable Intel® Volume Management Device Technology on specific root port. Disabled / Enabled Hot Plug Capable Enabled/Disabled Hot Plug for PCIe Root Ports.
  • Page 240 5.4.5.4.2 Intel VMD for Volume Management for Socket 1 VMD Config for IOU0 Enable/Disable VMD Enabled/Disabled VMD in this Stack. Disabled / Enabled NOTE: The following items are available when Enabled/Disable VMD is set to [Enabled]. VMD Port A/B/C/D/E/F/G/H Enable/Disable Intel® Volume Management Device Technology on specific root port.
  • Page 241 CfgBar size Setup VMD Config BAR size (in bits Min=20, Max=27), ex: 20bits=1MB, 27bits=128MB. CfgBar attribute Set up VMD Config Bar attribute, like 64-bit or prefetchable. 32-bit non-prefetchable / 64-bit prefetchable / 64-bit prefetchable MemBar1 size Setup VMD Memory BAR1 size (in bits Min=20), ex: 20bits=1MB, 22bits=4MB, 26bits=64MB.
  • Page 242 CfgBar size Setup VMD Config BAR size (in bits Min=20, Max=27), ex: 20bits=1MB, 27bits=128MB. CfgBar attribute Set up VMD Config Bar attribute, like 64-bit or prefetchable. 32-bit non-prefetchable / 64-bit prefetchable / 64-bit prefetchable MemBar1 size Setup VMD Memory BAR1 size (in bits Min=20), ex: 20bits=1MB, 22bits=4MB, 26bits=64MB.
  • Page 243 CfgBar size Setup VMD Config BAR size (in bits Min=20, Max=27), ex: 20bits=1MB, 27bits=128MB. CfgBar attribute Set up VMD Config Bar attribute, like 64-bit or prefetchable. 32-bit non-prefetchable / 64-bit prefetchable / 64-bit prefetchable MemBar1 size Setup VMD Memory BAR1 size (in bits Min=20), ex: 20bits=1MB, 22bits=4MB, 26bits=64MB.
  • Page 244 VMD Port B/D/E/F/G/H Enable/Disable Intel® Volume Management Device Technology on specific root port. Disabled / Enabled Hot Plug Capable Enabled/Disabled Hot Plug for PCIe Root Ports. Disabled / Enabled CfgBar size Setup VMD Config BAR size (in bits Min=20, Max=27), ex: 20bits=1MB, 27bits=128MB.
  • Page 245 VMD Port A/B/C/D/E/F/G/H Enable/Disable Intel® Volume Management Device Technology on specific root port. Disabled / Enabled Hot Plug Capable Enable/Disable Hot Plug for PCIe Root Ports. Disabled / Enabled CfgBar size Setup VMD Config BAR size (in bits Min=20, Max=27), ex: 20bits=1MB, 27bits=128MB.
  • Page 246: Advanced Power Management Configuration

    5.4.6 Advanced Power Management Configuration CPU P State Control P State Control Configuration Sub Menu, include Turbo, XE and etc. Hardware PM State Control Hardware P-State setting. CPU C State Control CPU C State setting. Package C State Control Package C State setting. CPU Advanced PM Tuning Setting Energy Per Bias, Pwr_Ctl, PP0 Current SWLTD, SAPM etc.
  • Page 247 5.4.6.1 CPU P State Control SpeedStep (Pstates) Enabled/Disabled EIST (P-States). Disabled / Enabled Boot performance mode Select the performance state that the BIOS will set before OS hand off. Max Performance / Max Efficient / Set by Intel Node Manager Energy Efficient Turbo Energy Efficient Turbo Disable, MSR 0x1FC [19].
  • Page 248 CPU Core Flex Ratio Non-Turbo Mode Processor Core Ratio Multiplier. Available if CPU Flex Ratio Override is set to [Enabled]. http://www.tyan.com...
  • Page 249 5.4.6.2 Hardware PM State Control Hardware P-States Disable: Hardware chooses a P-state based on OS Request (Legacy P-States). Native Mode: Hardware chooses a P-state based on OS guidance. Out of Band Mode: Hardware autonomously chooses a P-state (no OS guidance). Disabled / Native Mode / Out of Band Mode / Native Mode with No Legacy Support http://www.tyan.com...
  • Page 250 5.4.6.3 CPU C State Control CPU C1 auto demotion Allows CPU to automatically demote to C1. Takes effect after reboot. Disabled / Enabled CPU C6 report Enabled/Disabled CPU C6 (ACPI C3) report to OS. Disabled / Enabled / Auto Enhanced Halt State (C1E) Core C1E auto promotion Control.
  • Page 251 5.4.6.4 Package C State Control Package C State Package C State limit. C0/C1 state / C2 state / C6 (non Retention) state / C6 (Retention) state / No Limit / Auto http://www.tyan.com...
  • Page 252 5.4.6.5 CPU Advanced PM Tuning Power Performance Tuning Options decides who controls EPB. In OS mode: IA32_ENERGY_PERF_BIAS is used In BIOS mode: ENERGY_PERF_BIAS_CONFIG is used In PECI mode: PCS53 is used OS Controls EPB / BIOS Controls EPB / PECI Controls EPB http://www.tyan.com...
  • Page 253: Current Limitation

    5.4.6.6 Package Current Config Current Limit Override Disable --- Default, do nothing; Enable, override current limitation in 1/8 A increments. Disabled / Enabled Current Limitation Current limitation in 1/8 A increments. This field is locked by VR_CURRENT_CONFIG [LOCK]. Value <=CURRENT_LIMIT Available if Current Limit Override is set to [Enabled].
  • Page 254 5.4.6.7 SOCKET RAPL Config PL1 Limit PL1 Power Limit is Watts. The value may vary from 0 to Fused Value. If the value is 0, the fused value will be programmed. A value greater than fused TDP value will not be programmed.
  • Page 255 PL2 Time Window PL2 value in seconds. The value may vary from 0 to 0.438. Indicates the time window over which TDP value should be maintained. 0.001 / 0.0012 / 0.0015 / 0.0017 / 0.002 / 0.0024 / 0.003 / 0.0034 / 0.004 / 0.005 / 0.006 / 0.007 / 0.008 / 0.01 / 0.012 / 0.014 / 0.016 / 0.02 / 0.023 / 0.027 / 0.031 / 0.039 / 0.047 / 0.055 / 0.063 / 0.078 / 0.094 / 0.109 / 0.125 / 0.156 / 0.188 / 0.219 / 0.25 / 0.313 / 0.375 / 0.438...
  • Page 256: Chipset

    Chipset PCH-IO Configuration PCH Parameters. Server ME Configuration Configure Server ME Technology Parameters. http://www.tyan.com...
  • Page 257: Pch-Io Configuration

    5.5.1 PCH-IO Configuration PCI Express Configuration PCI Express Configuration settings. SATA And RST Configuration Device Option Settings. Restore AC Power Loss Specify what state to go to when power is re-applied after a power failure (G3 state). Power On / Power Off / Last State http://www.tyan.com...
  • Page 258 5.5.1.1 PCI Express Configuration PCI Express Root Port 1 ~ Port 16 PCI Express Root Port 1~ Port 16. http://www.tyan.com...
  • Page 259 5.5.1.1.1 PCI Express Root Port 1 ~ Port 16 PCI Express Root Port 1~16 Control the PCI Express Root Port. Disabled / Enabled ASPM PCI Express Active State Power Management settings. Disabled / L1 L1 Substates PCI Express L1 Substates settings. Disabled / L1.1 / L1.2 / L1.1 &...
  • Page 260 5.5.1.2 SATA And RST Configuration Controller 1 SATA And RST Configuration SATA Controller 1 Device Options Settings. Controller 2 SATA And RST Configuration SATA Controller 2 Device Options Settings. Controller 3 SATA And RST Configuration SATA Controller 3 Device Options Settings. http://www.tyan.com...
  • Page 261 5.5.1.2.1 Controller 1 SATA And RST Configuration SATA Controller Enabled/Disabled SATA Device. Disabled / Enabled SATA Mode Selection Determines how SATA controller(s) operate. AHCI / RAID Port 4/5/6/7 Enabled or Disabled SATA Port. Disabled / Enabled Hot Plug Designates this port as Hot Pluggable. Disabled / Enabled http://www.tyan.com...
  • Page 262 Spin Up Device If enabled for any of ports Staggered Spin Up will be performed and only the drives witch have this option enabled will spin up at boot. Otherwise all drives spin up at boot. Disabled / Enabled SATA Device Type Identify the SATA port is connected to Solid State Drive or Hard disk Drive.
  • Page 263 5.5.1.2.2 Controller 2 SATA And RST Configuration SATA Controller Enabled/Disabled SATA Device. Disabled / Enabled SATA Mode Selection Determines how SATA controller(s) operate. AHCI / RAID Port 2/3/4/5/6/7 Enabled or Disabled SATA Port. Disabled / Enabled Hot Plug Designates this port as Hot Pluggable. Disabled / Enabled http://www.tyan.com...
  • Page 264 Spin Up Device If enabled for any of ports Staggered Spin Up will be performed and only the drives witch have this option enabled will spin up at boot. Otherwise all drives spin up at boot. Disabled / Enabled SATA Device Type Identify the SATA port is connected to Solid State Drive or Hard disk Drive.
  • Page 265 5.5.1.2.3 Controller 3 SATA And RST Configuration SATA Controller Enabled/Disabled SATA Device. Disabled / Enabled SATA Mode Selection Determines how SATA controller(s) operate. AHCI / RAID Port 0/1/2/3 Enabled or Disabled SATA Port. Disabled / Enabled Hot Plug Designates this port as Hot Pluggable. Disabled / Enabled http://www.tyan.com...
  • Page 266 Spin Up Device If enabled for any of ports Staggered Spin Up will be performed and only the drives witch have this option enabled will spin up at boot. Otherwise all drives spin up at boot. Disabled / Enabled SATA Device Type Identify the SATA port is connected to Solid State Drive or Hard disk Drive.
  • Page 267 5.5.1.3 Deep Sx Configuration Deep Power Policies Configure the DeepSx Mode configuration. Disabled / Enabled in S5 / Enabled in S4-S5 / Enabled in S3-S4-S5 Platform Deep S5 Mode Enabled – Enabled Platform Deep S5 mode, Disable – Disable Platform Deep S5 mode, Hardware –...
  • Page 268: Server Me Configuration

    5.5.2 Server ME Configuration Read only. http://www.tyan.com...
  • Page 269: Server Management

    Server Management FRB-2 Timer Enable or Disable FRB-2 timer (POST timer). Enabled / Disabled FRB-2 Timer timeout Enter value Between 3 to 12 min for FRB-2 Timer Expiration. Not available if FRB-2 Timer is disabled. 3 minutes / 4 minutes / 5 minutes / 6 minutes / 12 minutes FRB-2 Timer Policy Configure how the system should respond if the FRB-2 Timer expires.
  • Page 270 OS Wtd Timer timeout Enter the value Between 5 to 20 min for OS Boot Watchdog Timer Expiration. Not available if OS Boot Watchdog Timer is disabled. 5 minutes / 10 minutes / 15 minutes / 20 minutes OS Wtd Timer Policy Configure how the system should respond if the OS Boot Watchdog Timer expires.
  • Page 271: System Event Log

    5.6.1 System Event Log SEL Components Change this to enable or disable event logging for error/progress codes during boot. Disabled / Enabled NOTE: When SEL Components is set to [Disabled], the following items are read only. Erase SEL Choose options for erasing SEL. No / Yes, on next reset / Yes, on every reset Log EFI Status Codes Disable the logging of EFI Status Codes or log only error code or only progress code...
  • Page 272: Bmc Network Configuration

    5.6.2 BMC Network Configuration http://www.tyan.com...
  • Page 273 Configure IPv4 support Management Port 1 Configuration Address Source Select to configure LAN channel parameters statically or dynamically (by BIOS or BMC). Unspecified option will not modify any BMC network parameters during BIOS phase. Unspecified / Static / DynamicBmcDhcp / DynamicBmcNonDhcp Management Port 2 Enable/Disable BMC Share NIC.
  • Page 274 Configuration Address Source Select to configure LAN channel parameters statically or dynamically (by BIOS or BMC). Unspecified option will not modify any BMC network parameters during BIOS phase. Unspecified / Static / DynamicBmcDhcp Management Port 2 IPV6 Support Enable or Disable LAN2 IPv6 Support. Enabled / Disabled Configuration Address Source Select to configure LAN channel parameters statically or dynamically (by BIOS or...
  • Page 275: Bmc User Settings

    5.6.3 BMC User Settings Add User Press <Enter> to Add a user. Delete User Press <Enter> to Delete a user. Change User Settings Press <Enter> to change User Settings. http://www.tyan.com...
  • Page 276: User Password

    5.6.2.1 Add User User Name Enter BMC User Name. User Password Enter New Password to change. Password at least 8 characters. User Access Enable/Disable the BMC User’s Access. Enabled / Disabled Channel No Enter BMC Channel Number. N/A / 1 / 8 User Privilege Limit Enter BMC User Privilege Limit for Selected Channel.
  • Page 277 5.6.2.2 Delete User User Name Enter BMC User Name. User Password Enter New Password to change. Password at least 8 characters. http://www.tyan.com...
  • Page 278: Change User Settings

    5.6.2.3 Change User Settings User Name Enter BMC User Name. User Password Enter New Password to change. Password at least 8 characters. Change User Password Enter New Password to change. Password at least 8 characters. User Access Enable/Disable the BMC User’s Access. Enabled / Disabled Channel No Enter BMC Channel Number.
  • Page 279: Security

    Security Administrator Password Set administrator password in the Create New Password window. After you key in the password, the Confirm New Password window will pop out to ask for confirmation. User Password Set user password in the Create New Password window. After you key in the password, the Confirm New Password window will pop out to ask for confirmation.
  • Page 280: Secure Boot

    3.7.1 Secure Boot Secure Boot Secure Boot feature is Active if Secure Boot is Enabled. Platform Key (PK) is enrolled and the System is in User mode. The mode change requires platform reset. Enabled / Disabled Secure Boot Mode Secure Boot mode options: Standard or Custom. In Custom mode, Secure Boot Policy variables can be configured by a physically present user without full authentication.
  • Page 281 Key Management Enables expert users to modify Secure Boot Policy variables without full authentication. http://www.tyan.com...
  • Page 282 5.7.1.1 Key Management Factory Key Provision Install factory default Secure Boot keys after the platform reset and while the System is in Setup mode. Enabled / Disabled Restore Factory Keys Force System to User Mode. Install factory default Secure Boot key databases. Press ‘Yes’...
  • Page 283 Export Secure Boot variables Copy NVRAM content of Secure Boot variables to files in a root folder on a file system device. 格式化: 字型: 9 點, 字型色彩: 黑色 Platform Key (PK) Enroll Factory Defaults or load certificates from a file: 1.
  • Page 284 2. Authenticated UEFI Variable 3. EFI PE/C0FF Image (SHA256) Key source: Factory, External, Mixed Update / Append Authorized TimeStamps 格式化: 字型色彩: 黑色 Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2.
  • Page 285: Boot

    Boot Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535 (0xFFFF) means indefinite waiting. Bootup NumLock State Select the keyboard NumLock state. Off / On Quiet Boot Enables or disables Quiet Boot option. Enabled / Disabled Wait for ‘ESC’...
  • Page 286 Endless Boot Enabled: BIOS try bootable devices constantly in loop until finding a bootable device (Excluding Built-in EFI Shell). Enabled / Disabled Boot Option Priorities Boot Option #1~#5 Sets the system boot order. Device Name / Disabled Hard Drive BBS Priorities Set the order of the legacy devices in this group.
  • Page 287: Hard Drive Bbs Priorities

    5.8.1 Hard Drive BBS Priorities Boot Option #1~Boot Option #4 Sets the system boot order. Device Name / Disabled http://www.tyan.com...
  • Page 288: Cd/Dvd Rom Drive Bbs Priorities

    5.8.2 CD/DVD ROM Drive BBS Priorities Boot Option #1 Sets the system boot order. Device Name / Disabled http://www.tyan.com...
  • Page 289: Add New Boot Option

    5.8.3 Add New Boot Option Add boot option Create new boot option. Path for boot option Enter the path to the boot option in the format fs0:\path\filename.efi Create Creates the newly formed boot option. http://www.tyan.com...
  • Page 290: Delete Boot Option

    5.8.4 Delete Boot Option Delete Boot Option Remove an EFI boot option from the boot order. Select one to delete / Device Name http://www.tyan.com...
  • Page 291: Save & Exit

    Save & Exit Save Changes and Exit Exit system setup after saving the changes. Discard Changes and Exit Exit system setup without saving any changes. Save Changes and Reset Reset the system after saving the changes. Discard Changes and Reset Reset system setup without saving any changes.
  • Page 292 Save as User Defaults Save the changes done so far as User Defaults. Restore User Defaults Restore the User Defaults to all the setup options. Boot Override Read only. http://www.tyan.com...
  • Page 293: Chapter 6: Diagnostics

    Chapter 6: Diagnostics NOTE: if you experience problems with setting up your system, always check the following things in the following order: Memory, Video, CPU By checking these items, you will most likely find out what the problem might have been when setting up your system.
  • Page 294: Amibios Post Code (Aptio)

    AMIBIOS Post Code (Aptio) The POST code checkpoints are the largest set of checkpoints during the BIOS pre-boot process. The following table describes the type of checkpoints that may occur during the POST portion of the BIOS: Checkpoint Ranges Status Code Range Description 0x01 –...
  • Page 295 Status Code Description 0x0A OEM initialization after microcode loading 0x0B Cache initialization http://www.tyan.com...
  • Page 296 SEC Error Codes 0x0C – 0x0D Reserved for future AMI SEC error codes 0x0E Microcode not found 0x0F Microcode not found SEC Beep Codes None PEI Phase Status Code Description Progress Codes 0x10 PEI Core is started 0x11 Pre-memory CPU initialization is started 0x12 Pre-memory CPU initialization (CPU module specific) 0x13...
  • Page 297 Status Code Description 0x35 CPU post-memory initialization. Boot Strap Processor (BSP) selection 0x36 CPU post-memory initialization. System Management Mode(SMM) initialization 0x37 Post-Memory North Bridge initialization is started 0x38 Post-Memory North Bridge initialization (North Bridge module specific) 0x39 Post-Memory North Bridge initialization (North Bridge module specific) 0x3A Post-Memory North Bridge initialization (North Bridge module specific) 0x3B...
  • Page 298 Status Code Description S3 Resume Error Codes 0xE8 S3 Resume Failed 0xE9 S3 Resume PPI not Found 0xEA S3 Resume Boot Script Error 0xEB S3 OS Wake Error 0xEC – 0xEF Reserved for future AMI error codes http://www.tyan.com...
  • Page 299 Recovery Progress Codes 0xF0 Recovery condition triggered by firmware (Auto recovery) 0xF1 Recovery condition triggered by user (Forced recovery) 0xF2 Recovery process started 0xF3 Recovery firmware image is found 0xF4 Recovery firmware image is loaded 0xF5 – 0xF7 Reserved for future AMI progress codes Recovery Error Codes 0xF8 Recovery PPI is not available...
  • Page 300 Status Code Description 0x71 South Bridge DXE SMM initialization is started 0x72 South Bridge devices initialization 0x73 South Bridge DXE initialization (South Bridge module specific) 0x74 South Bridge DXE initialization (South Bridge module specific) 0x75 South Bridge DXE initialization (South Bridge module specific) 0x76 South Bridge DXE initialization (South Bridge module specific) 0x77...
  • Page 301 Status Code Description 0xA5 SCSI Reset 0xA6 SCSI Detect 0xA7 SCSI Enable 0xA8 Setup Verifying Password 0xA9 Start of Setup 0xAA Reserved for ASL (see ASL Status Codes section below) 0xAB Setup Input Wait 0xAC Reserved for ASL (see ASL Status Codes section below) 0xAD Ready To Boot event 0xAE...
  • Page 302 Status Code Description 0xD9 Error loading Boot Option (LoadImage returned error) 0xDA Boot Option is failed (StartImage returned error) 0xDB Flash update is failed 0xDC Reset protocol is not available ACPI/ASL Checkpoints Status Code Description 0x01 System is entering S1 sleep state 0x02 System is entering S2 sleep state 0x03...
  • Page 303: Appendix I: How To Recover Uefi Bios

    Appendix I: How to recover UEFI BIOS Important Notes: The emergency UEFI BIOS Recovery process is only used to rescue a system with a failed or corrupted BIOS image that fails to boot to an OS. It is not intended to be used as a general purpose BIOS flashing procedure and should not be used as such.
  • Page 304 The system will boot to BIOS setup. A new menu item will appear at the far right of the screen. Scroll to the 'Recovery' tab, move the curser to “Proceed with flash update” and press the "Enter" key on the keyboard to start the BIOS recovery process.
  • Page 305: Appendix Ii: Installing Ocp Card

    Appendix II: Installing OCP Card Follow these instructions to install the IO rail and OCP Card. Here is a sample showing how to install the IO rail for the dual-port LAN card M7062-I599-2T. 1. Take out the OCP rail assembly from the AK box. 2.
  • Page 306 3. Insert the LAN card into the OCP slot and secure the LAN card to the chassis with four screws. 4. Push forwards the OCP card into the OCP slot. http://www.tyan.com...
  • Page 307: Appendix Iii: Installing The M.2 Card

    Appendix III: Installing the M.2 Card Follow these instructions to install the M.2 latch and M.2 Card. 1. Take out the M.2 Latch from the AK box. 2. Insert the M.2 latch into the M.2 latch screw hole. 3. Insert the M.2 card into the slot. Close the latch to lock the M.2 card. http://www.tyan.com...
  • Page 308 4. Insert the second M.2 card into the slot. Pull the latch as shown to lock the M.2 card. http://www.tyan.com...
  • Page 309: Appendix Iv: Cable Connection Tables

    Appendix IV: Cable Connection Tables B7136T70AV12E8HR & B7136T70AV12E8HR-2T SKU 1. MCIO Cable Front Backplane (BP) Board to S7136GM2NRE-2T-B/MB HDD BP Cable Connect to S7136GM2NRE-2T-B/MB M1322T70A-BPE-8 MCIO 8I To 2*MCIO 4I MCIO1  MCIO5, MCIO6 MCIO 8I To 2*MCIO 4I MCIO2 ...
  • Page 310 2. System FAN cable Connect to HDD BP M1322T70A-BPE-8 FAN1  FAN1 FAN2  FAN2 HDD BP Connect to M1321T70A-BP12-8 FAN3  FAN1 FAN4  FAN2 3. Front Panel USB Cable Front Panel Connect to S7136GM2NRE-2T-B/MB M1717T65-USB  USB3_FPIO1 4. Front Panel Control Cable Front Panel Connect to S7136GM2NRE-2T-B/MB...
  • Page 311 7. Power Supply Cables M7126T65-PDB Connect to S7136GM2NRE-2T-B/MB PWR1  PWR1  PWR2  PWR3  PWR4 PSMI  PSMI_HD1 8. Power Supply Cables M7126T65-PDB Connect to HDD BP M1318T65-BP12E-2  REAR HDD BP M7126T65-PDB Connect to M1318T65-BP12E-2  9. SWITCH CABLE Chassis Connect to S7136GM2NRE-2T-B/MB...
  • Page 312 B7136T70V10E4HR & B7136T70V10E4HR-2T SKU MCIO Cable Front Backplane (BP) Board to S7136GM2NRE-2T-B/MB HDD BP Connect Cable S7136GM2NRE-2T-B/MB M1320T70-BP12E-12 MCIO 8I To 2*MCIO 4I MCIO1  MCIO5, MCIO6 MCIO 8I To 2*MCIO 4I MCIO2  MCIO7, MCIO8 Mini-SAS HD to Mini-SAS SATA0_3 ...
  • Page 313 FAN Ctrl Cable HDD BP Connect to S7136GM2NRE-2T-B/MB M1320T70-BP12E-12  FAN_HD1 Power Supply Cables HDD BP M7126T65-PDB Connect to M1320T70-BP12E-12   Power Supply Cables M7126T65-PDB Connect to S7136GM2NRE-2T-B/MB PWR1  PWR1  PWR2  PWR3  PWR4 PSMI  PSMI_HD1 Power Supply Cables M7126T65-PDB...
  • Page 314 NOTE http://www.tyan.com...
  • Page 315: Appendix Iv: Fan And Temp Sensors

    Appendix IV: Fan and Temp Sensors This section aims to help readers identify the locations of some specific FAN and Temp Sensors on the motherboard. A table of BIOS Temp sensor name explanation is also included for readers’ reference. Figure 1: Sensor Location NOTE: The red spot indicates the sensor.
  • Page 316 BIOS Temp Sensor Name Explanation: http://www.tyan.com...
  • Page 317 http://www.tyan.com...
  • Page 318 BIOS Temp Sensor Name Explanation CPU0_Temp CPU0 Tempterature CPU1_Temp CPU1 Tempterature SYS_Air_Inlet Sensor connected to the Front Panel MB_Air_Inet Temperature of the M/B Air Inlet Area SYS_Air_Outlet Temperature of the System Air Outlet Area PCH_Temp Temperature of the PCH P0_MOSFET Max Temperature of CPU0_MOSFET P1_MOSFET Max Temperature of CPU1_MOSFET...
  • Page 319 SYS_FAN_9 Fan Speed of SYS_FAN_9 SYS_FAN_10 Fan Speed of SYS_FAN_10 SYS_FAN_11 Fan Speed of SYS_FAN_11 SYS_FAN_12 Fan Speed of SYS_FAN_12 PSU0_STATUS Current status of PSU0 PSU0_Temp Temperature of PSU0 PSU0_FAN Fan Speed of PSU0 PSU1_STATUS Current status of PSU1 PSU1_Temp Temperature of PSU1 PSU1_FAN Fan Speed of PSU1...
  • Page 320 NOTE http://www.tyan.com...
  • Page 321: Appendix V: Fru Parts Table

    Appendix V: FRU Parts Table TS70(A)-B7136 FRU Parts Item Model Number Part Number Picture Description Power Supply FRU-PS-0321 471100000517 POWER SUPPLY 1200 W Heatsink & FRU-TH-0450 343B00600002 Heatsink Cooler M7136T70-L28-3F 411B01000068 Riser Card M7136T70-R24-2F 411B00900035 Riser Card M1718T65-FPB 411T60100046 Front Panel Board M1717T65-USB 411T60900071 USB Board...
  • Page 322 FRU-CS-0510 422T53400005 MINI-SAS HD CABLE, 700 mm FRU-CS-1040 422T53400018 MINI-SAS HD CABLE, 600 mm FRU-CS-2130 422T56400010 SATA CABLE(SAS WIRE), 300 mm MCIO 8i TO 2*MCIO 4i CABLE, 600 FRU-CS-2110 422B01000015 MCIO 8i TO 2*MCIO 4i CABLE, 700 FRU-CS-2100 422B01000016 FRU-CS-0560 422T56100002 MINI-SAS HD CABLE, 600 mm MINI-SAS HD TO 2*SATA CABLE,...
  • Page 323: Appendix Vi: Technical Support

    Appendix VI: Technical Support If a problem arises with your system, you should first turn to your dealer for direct support. Your system has most likely been configured or designed by them and they should have the best idea of what hardware and software your system contains. Hence, they should be of the most assistance for you.
  • Page 324 Returning Merchandise for Service During the warranty period, contact your distributor or system vendor FIRST for any product problems. This warranty only covers normal customer use and does not cover damages incurred during shipping or failure due to the alteration, misuse, abuse, or improper maintenance of products.

Table of Contents
