Model
S777p
p Specify Finish
Write purchased model number here.
You may need:
S777p
Overall size
2-Functions
• H2Okinetic Spray
• Mist Spray
worldwide.deltafaucet.com
115919
(125 mm)
(247 mm)
1524 mm
flexibel hose, anti-twist
G 1/2"
5" Multifunction Handshower w Hose
(33 mm)
165°
Swivel angle is 360°
1
(51 mm)
(38 mm)
4/23/2024
115919 Rev. B
