Temtop S1+ User Manual

Air quality monitor
Hide thumbs

Advertisement

Quick Links

Download this manual
S1+
Air Quality Monitor
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the S1+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Temtop S1+

Summary of Contents for Temtop S1+

  • Page 1 Air Quality Monitor User Manual...

  • Page 2: Get More Information

    Get More Information Scan the QR code for multi-language manuals and more. Scan for multi-language manuals and more product support. Scannen Sie nach mehrsprachigen Handbüchern und mehr Produktsupport. Numérisez pour obtenir des manuels multilingues et plus d'assistance sur les produits. Scansione per manuali multilingue e maggiore supporto al prodotto.
  • Page 5 PM2.5 & AQI level Temperature & Humidity level Time Buzzer status ① ② ③ ④ Battery Level & Charging Status Work mode Bluetooth ⑤ ⑥ ⑦ Health Level Display Area Magnetic Back Vents Air inlet ⑧ ⑨ ⑩ ⑪...
  • Page 6 Mode button Power button Air outlet USB port ⑫ ⑬ ⑭ ⑮ Temperature and humidity detection port ⑯ Bracket ⑰...
  • Page 7 (0-100µg/m (0.1 )
  • Page 8 60 Days 30 Days 90%RH * When the product is charging, the data will keep refreshing every 1.5 seconds.
  • Page 10 1. Button a. Power button 1 ) Press and hold for 3s to turn on/o the monitor. 2 ) Click to switch the buzzer on/o . b. Mode button 1) Press and hold 2s to switch between the temperature unit (°F/°C). 2) Click to switch operating modes (2 di erent types).
  • Page 11 c. Mode 10s to refresh.
  • Page 12 d. Buzzer switch Icon Displayed: Buzzer sound on the device is turned on. Not displayed: The buzzer sound is turned o . 1) The buzzer chirps once when the buzzer function is turned on/o (APP operation is synchronised). 2) When the buzzer is switched on, the air quality level deterioration sounds twice. e.
  • Page 13 Reference PM2.5 PM2.5 AQI* NAAQS(2012) NAAQS(2024) Status Poor ＞55.4 ＞55.4 ＞150 Fair 12.1~55.4 9.1~55.4 51~150 Good 0~12 0~50 Note: Our app lets you toggle between the 2012 and 2024 EPA PM2.5 standards, catering to your specific needs. * Refers to EPA standards, with PM2.5 as the main responsible pollutant.
  • Page 14 (Bracket included)
  • Page 15 Bluetooth Connec�on 1. Temtop App Please search Temtop on App Store or Google Play, or simply scan the QR code below to download the app:...
  • Page 16 Add Device b. Enable your phone's Bluetooth with the app, which will automatically detect Temtop devices in range of Bluetooth. Please select the Temtop device you wish to add and click the Add button. When encountering issues connec�ng to the device, follow these steps to ensure a successful connec�on: Bring the device close to your phone, ensuring they are in close proximity to facilitate a successful Bluetooth connec�on.
  • Page 17 1)When using the app, make sure your device is within the Bluetooth range. Please avoid moving too far away from the device. 2)Due to the upgrading and upda�ng of Temtop APP, the actual opera�on may be slightly different from the above descrip�on, please follow the current guidelines within Temtop APP.
  • Page 18 Q: Why can't I receive the verification code when I sign up for an APP account? ① Please check the advertisement mails and spam mails, your mailbox may automatically. classify the CAPTCHA mails into advertisement mails and spam mails. ② Google Mail, Outlook, and other major mailboxes are recommended.
  • Page 19 Q: Is it true that AQI calculations are not scientific? A: We calculate the AQI based on PM2.5/PM10, which is MAX (AQI-PM2.5, AQI-PM10), and there are corresponding AQIs for O , CO, SO , NO , and so on, and the o cial one is released with the maximum of these AQI-PM2.5, AQI-PM10 and other 6 AQIs.
  • Page 20 ” segments because the device is in upgrade mode. The continuous display of “ ” is due to an incomplete software upgrade from the last attempt. Please log in to the Temtop app and go to " OTA Upgrade " in device management to complete the software upgrade.
  • Page 23 53 Norman Road,London, SE10 9QF Tel: (+1) 408-898-2866 Tel: (+44)208-858-1888 Tiktok: @Elitechus Youtube: @elitech_uk  Facebook: @Elitech Instagram: @elitechuk_ Twitter: @elitechusa  Facebook: @hvaccontrol Youtube: @ElitechTechnologyInc   Sales: sales@elitecheu.com Linkedin: @Elitech Technology, Inc Website: www.temtop.co.uk Sales: sales@temtopus.com Website: www.temtopus.com Elitech Brazil Ltda R.Dona Rosalina,90-Lgara, Canoas-RS 92410-695,Brazil Tel: (+55)51-3939-8634 Sales: brasil@e-elitech.com V1.0 Website: www.elitechbrasil.com.br...
