- Page 1 Operating instructions for BioMant-Mini Weed control machine Manufacturer: Mantis ULV Sprühgeräte GmbH Vierlander Strasse 11a 21502 Geesthacht, Germany Tel: +49 (0) 4152 8459-0 www.mantis-ulv.com Mantis-ULV Sprühgeräte GmbH – 2022...
-
Page 2: Table Of Contents
Table of Content Introduction .......................... 3 1.1. Symbols and pictograms ..................... 3 1.2. Intellectual property rights ................... 3 1.3. EC- Declaration of Conformity ..................3 1.4. Operation by third parties .................... 3 Description of the BioMant-Mini weed control machine ............4 2.1. -
Page 3: Introduction
1. Introduction These Operating Instructions include all pieces of information needed for the correct and safe working with the BioMant-Mini. Before the commissioning of the BioMant-Mini , you are required to have read and understood these Operating Instructions. You must familiarise yourself with the functioning and the safety instructions before the commissioning of the BioMant-Mini. -
Page 4: Description Of The Biomant-Mini Weed Control Machine
2. Description of the BioMant-Mini weed control machine The BioMant-Mini is a weed control system that works without the use of chemical products or herbicides. This chapter describes the functions and the operation of the BioMant-Mini. 2.1. Design of the BioMant-Mini The BioMant-Mini is hot-water low-and high-pressure unit, comprising a plastic housing with wheels, electric motor, burner unit for generating hot water, diesel oil tank, vent duct for exhaust... -
Page 5: Technical Specifications
2.2. Technical Specifications • Electric motor (2.2 kW) • Diesel burner • Maximum ambient temperature: 40 °C - Minimum ambient temperature: +2 °C • Maximum humidity: 80%... -
Page 6: Operating Regulations
3. Operating regulations The BioMant-Mini is only allowed to be used for the intended purpose, this being weed control and cleaning or disinfection. Unauthorised persons are not allowed to change the settings of the BioMant-Mini . If you want to change the settings, please contact your authorised BioMant- Service centre, or contact the manufacturer directly. -
Page 7: Safety Instructions
4. Safety instructions The BioMant-Mini is equipped with different safety measures. Despite these safety measures there will be residual risks left in various places and situations. The following chapter contains some safety instructions referring to these residual risks. For safe working with the BioMant- Mini, all persons working on or with the BioMant-Mini must make themselves familiar with these instructions. - Page 8 In high-pressure mode,water sprays out of the lance at high pressure. Never point this high-pressure jet at persons or animals. Water at high pressure can cause serious injuries. Never leave the machine unattended during operation. During extended brekas, the machine must be switched off. The weed control machine BioMant-Mini is not permitted to be used in an environment with explosion risk.
-
Page 9: Pictograms
4.2. Pictograms The pictograms warn of hazards that cannot be avoided. Never remove the pictograms! Damaged or missing pictograms must be replaced immediately. Meaning Position Pictogram Risk of burning On the burner exhaust outlet Read the Operating On the control panel Instructions Smoking and open flames are strictly... -
Page 10: Commissioning
5. Commissioning This chapter includes instructions for the commissioning of the BioMant-Mini. Before starting work, it is strictly required to thoroughly familiarise yourself with these instructions. Only competent and authorised persons are allowed to excecute assembly and commissioning of the BioMant-Mini. For lifting of the machine use an approved lifting device with sufficient capacity. -
Page 11: Replacement Of Components
5.2. Replacement of components For the replacement of components only use parts that comply with the manufacturer's spare parts specification. These Operating Instructions include a list of attached as Annex. 5.3. Electrical Equipment electrical circuit diagram These Operating Instructions include an attached as is the Annexe. -
Page 12: Use Of The Machine
6. Use of the machine 6.1. Use of the machine You must not start the machine operation if you detected any deficiencies during the assembly and before the commissioning. Operate this BioMant-Mini outdoors in a well ventilated environment only. The exhaust gas that comes out of the heating boiler is a health hazard. -
Page 13: Switching Off The Machine
6.2. Switching off the machine As soon as you have finished working with the machine: • Set the machine to “cold” (page 5, ref. 2)) • Open the spray gun and allow the water to flow for 1 minute (until the temperature drops and cold water comes out •... -
Page 14: Regular Maintenance
7. Regular Maintenance Before starting any maintenance works on the BioMant-Mini, you must disconnect the machine from the power supply and secure it against accidental restarting. Also close the water supply and release any remaining pressure from the system by engaging the spray gun until no more water flows. All persons, who work with or on the BioMant-Mini , must have made themselves sufficiently familiar with these Operating Instructions and especially with these safety instructions. -
Page 15: Troubleshooting
8. Troubleshooting Malfunctions can occur during machine operation. For troubleshooting follow the instructions in this section. If the malfunction cannot be eliminated as described below, contact the manufacturer or an authorised BioMant-Service Centre. In the event of a fault and/or malfunctioning of the machine or an oil or water leak, switch off the machine immediately. -
Page 16: Transport, Storage And Disassembly
9. Transport, Storage and Disassembly 9.1. Transport The machine is designed to be used on its own as it stands. Should you transport the machine in a vehicle or on a vehicle platform, you need to make sure the BioMant-Mini is placed on a stable, flat surface and is secured against shifting, tilting, or falling over. -
Page 17: Annexes
10. Annexes EU-Declaration of conformity Council Directive 2006/42/EG Mantis ULV-Sprühgeräte GmbH, Vierlander Straße 11 a, 21502 Geesthacht declares under our sole responsibility that the following products are in conformity with the provisions of the following Council Directive: 2006/42/EG Machine Model: BioMant-Mini... - Page 18 BioMant-Mini Schaltplan / electrical wiring diagram / schéma électrique / Schakelschema...
- Page 19 BioMant-MINI Explosionszeichnung und Ersatzteilliste Explosion drawing and spare parts list...
- Page 20 BioMant-MINI Explosionszeichnung und Ersatzteilliste Explosion drawing and spare parts list...
- Page 21 BioMant-MINI Explosionszeichnung und Ersatzteilliste Explosion drawing and spare parts list...
- Page 22 BioMant Mini Ersatzteile / Spare Parts list Artikel Nr. Pos. Bezeichnung Deutsch Bezeichnung Englisch Bezeichnung Niederländisch Mantis Expl. 112401 Grundrahmen, lackiert, Mini Painted frame base Spicejet Basisframe Mini 112402 Lenkrolle Ø125mm, Mini Pivoting wheel D.125 mm Zwenkwiel diam. 125mm WS- mini...
- Page 23 BioMant Mini Ersatzteile / Spare Parts list Artikel Nr. Pos. Bezeichnung Deutsch Bezeichnung Englisch Bezeichnung Niederländisch Mantis Expl. 112453 Kraftsstofrücklaufschlauch 6X12 L = Fuel recycle hose 6x12 L=380 mm Brandstof retourslang 6X12 L=380mm 380mm 112454 Kraftsstofschlauch (Vorfilter) 6X12 L =...
