- Page 1 EN 50131-1 EN 50131-10 EN 50136-1 EN 50136-2 EN 50130-4 EN 50130-5 Sol-LAN/S, Sol-WIFI LAN interfaces Installation and programming manual...
-
Page 2: Table Of Contents
Table of contents 1. Description of Sol-LAN/S and Sol-WIFI 1.1 Technical specifications 1.2 ATS Categories 2. Installation 2.1 Installing internal modules 2.2 Installing optional internal boards 3. Programming of Sol-LAN/S and Sol-WIFI 3.1 Programming IP parameters 3.2 Connection to a LAN network 3.3 Network connection test 4. General information 4.1 About this manual 4.2 Manufacturer's details 4.3 Simplified EU Declaration of Conformity 4.4 Warranty 4.5 Limited warranty 4.6 Processing of personal data 4.7 Documents for the users 4.8 Disposal of the product Installation and programming manual - 100... -
Page 3: Description Of Sol-Lan/S And Sol-Wifi
Connectivity to the network allows the installer to remotely program and supervise the system via LAN using the Sol/STUDIO software, supervision apps or connection to the cloud. Attention! The installation of both connection modules does not allow their simultaneous operation. In particular, the installation of the Sol-LAN/S, even without the Ethernet cable connected, excludes the use of Sol-WIFI. Description of parts [A] Ethernet connector [B] Antenna [C] ... -
Page 4: Ats Categories
1. Description of Sol-LAN/S and Sol-WIFI SPT (Supervised Premises Transceiver) con- sumptions Consumptions Sol-LAN/S Sol-WIFI Peak current 30 mA 100 mA Hourly average current 31 mA 105 mA 1.2 ATS Categories Sol control panels used alone or together with any of the following described optional devices constitutes an SPT (Supervised Premises Transceiver) which can be used to create an ATS (Alarm transmission System) as defined in EN 50136-1 and EN 50136-2 standards. The maximum ATS categories achievable with SPT configurations and the main communication channel used together with the respective parameters are shown in the following tables. ATS categories based on configurations SPT Configurations ATS categories SPT primary network inter-... -
Page 5: Installation
2.1 Installing internal modules 2. Installation 2.1 Installing internal modules The installation of Sol-PSTN, Sol-2G/3G/4G and Sol-LAN/S optional connectivity modules can be achieved using the connectors integrated into the PCB board and hooks on the back of the control panel enclosure. This operation can be carried out while the control panel is powered (<hot=), without disconnecting the mains power supply or battery. 1. Open the control panel enclosure. 2. Locate the relative connector and placement for the module concerned. [A] Securing hooks for Sol-LAN/S module [B] Terminals for Sol-LAN/S module [C] Securing hooks for Sol-PSTN module [D] Terminals for Sol-PSTN module [E] Securing hooks for Sol-2G/3G/4G module [F] Terminals for Sol-2G/3G/4G module [G] Blocking hooks Sol © 2022 Inim Electronics S.r.l. -
Page 6: Installing Optional Internal Boards
2. Installation 3. Position the rear side of the module on the appropriate hooks on the back of the enclosure, then push the module downwards until it clicks into place. 4. For hot installation, push the SERV-FACT / CLOUD REG button on the main board. 5. Close the control panel. 2.2 Installing optional internal boards The installation of Sol-WIFI and SmartLogos30M optional boards can be achieved via the connectors inte- grated into the PCB. This operation must be carried out when the mains power supply and battery are disconnected: 1. Remove all power from the control panel by disconnecting the primary power supply to the control (230V~). 2. Open the control panel enclosure. 3. Disconnect the backup battery from its connector on the motherboard [A]. 4. Insert the board into the appropriate connector: [B], for the Sol-WIFI board, use the appropriate slot [C], for the SmartLogos30M board ... -
Page 7: Programming Of Sol-Lan/S And Sol-Wifi
3.1 Programming IP parameters 3. Programming of Sol-LAN/S and Sol- WIFI 3.1 Programming IP parameters Connectivity to the LAN network is subject to the configuration of the network itself. The manufacturer strongly recommends that you contact the network administrator for the correct con- figuration. IP connection Installer User menu Software section Parameter menu sec- section tion IP Address IP connection parameters, Con- Settings, Other para- Subnet mask nection para- IP Par.and... -
Page 8: Connection To A Lan Network
3. Programming of Sol-LAN/S and Sol-WIFI Installer User menu Parameter Software section menu sec- section tion expressed in seconds, that elap- ses between successive time updates. This section allows the programming of the parameters of the IP IP connection connection test. parameters, IP connection test IP address Pv4 Address and port connection attempts are parameters directed to. Port Time, expressed in seconds, between con- nection tests. If 809 is set, the connection test Range will be disabled. Number of Number of connection attempts for each test. attempts 3.2 Connection to a LAN network The Sol control panel can connect to a LAN network, both cabled via an Ethernet port of the optional Sol-... -
Page 9: Network Connection Test
Press OK to confirm and exit. Note The use of Sol-LAN/S, Sol-WIFI board excludes the connection to a LAN network via cable. The connection password can have up to 32 characters. Connection to a Wi-Fi network is only possible when the network SSID is not hidden. - Page 10 If a Sol-LAN/S module is present on the control panel, the test relating to the LAN channels will be started regard- less of whether the Ethernet connector is connected or not to a network.
-
Page 11: General Information
Production plant: Centobuchi, via Dei Lavoratori 10 63076 Monteprandone (AP), Italy Tel.: +39 0735 705007 Fax: +39 0735 734912 E-mail info@inim.biz Web: www.inim.biz The persons authorized by the manufacturer to repair or replace the parts of this system have authorization to work only on devices marketed under the brand Inim Electronics. 4.3 Simplified EU Declaration of Conformity Hereby, Inim Electronics S.r.l. declares that the radio equipment type Sol-LAN/S, Sol-WIFI is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following inter- net address: www.inim.biz. 4.4 Warranty Inim Electronics S.r.l.. (Seller, Our, Us) warrants the original purchaser that this product shall be free from defects in materials and workmanship under normal use for a period of 24 months. As Inim Electronics does not install this product directly, and due to the possibility that it may be used with other equipment not approved by Us;Inim Electronics does not warrant against loss of quality, degradation of performance of this product or actual damage that results from the use of products, parts or other replace- able items (such as consumables) that are neither made nor recommended by Inim Electronics. Seller oblig- ation and liability under this warranty is expressly limited to repairing or replacing, at Seller's option, any product not meeting the specifications. In no event shall Inim Electronics be liable to the purchaser or any other person for any loss or damage whether direct of indirect or consequential or incidental, including without limitation, any damages for lost profits, stolen goods, or claims by any other party caused by defect- ive products or otherwise arising from the incorrect or otherwise improper installation or use of this product. This warranty applies only to defects in parts and workmanship relating to normal use. It does not cover dam- age arising from improper maintenance or negligence, damage caused by fire, flood, wind or lightning, van- dalism, fair wear and tear. Sol © 2022 Inim Electronics S.r.l. -
Page 12: Limited Warranty
4. General information Inim Electronics S.r.l. shall, at its option, repair or replace any defective products. Improper use, that is, use for purposes other than those mentioned in this manual will void the warranty. Contact Our authorized dealer, or visit our website for further information regarding this warranty. 4.5 Limited warranty Inim Electronics S.r.l. shall not be liable to the purchaser or any other person for damage arising from improper storage, handling or use of this product. Installation of this Product must be carried out by qualified persons appointed by Inim Electronics. Install- ation of this Product must be carried out in accordance with Our instructions in the product manual. 4.6 Processing of personal data Sol control panels, by attributing them to installers and users registered with the Inim Cloud service, can be managed through dedicated web pages and/or apps available to both the installer and the end user. In order to allow management of the control panel via Inim Cloud an explicit request is required from the users to whom the control panel is to be associated. As soon as a control panel is connected to a LAN or a GSM/LTE network, it will be available on the Inim Cloud, however, until the association is explicitly requested by a user the data exchanged are: purely technical (in order to allow an association to a user in the future) and do not include any per- sonal data always encrypted free from any correlation with personal data that may already be present in the Inim Cloud The control panel events log becomes available only after associating the control panel with the users and can be viewed chronologically from the moment of such an association. If you do not want to manage the control panel via Inim Cloud and/or do not want to allow any type of con- nection to Inim Cloud in advance, simply disable the connection with the service via programming. 4.7 Documents for the users Declarations of Performance, Declarations of Conformity and Certificates concerning to Inim Electronics ... - Page 13 4.8 Disposal of the product hand over the equipment you wish to dispose of to a dealer when purchasing new equipment of the same type. You are also entitled to convey for disposal small electronic-waste products with dimensions of less than 25cm to the premises of electronic retail outlets with sales areas of at least 400m2, free of charge and without any obligation to buy. Appropriate differentiated waste collection for the subsequent recycling of the discarded equipment, its treatment and its environmentally compatible disposal helps to avoid possible neg- ative effects on the environment and on health and favours the re-use and/or recycling of the materials it is made of. Sol © 2022 Inim Electronics S.r.l.
- Page 14 4. General information Installation and programming manual - 100...
- Page 15 4.8 Disposal of the product Sol © 2022 Inim Electronics S.r.l.
- Page 16 Inim Electronics S.r.l. Via dei Lavoratori 10, Loc. Centobuchi 63076 Monteprandone (AP) I TALY Tel. +39 0735 705007 _ Fax +39 0735 704912 info@inim.biz _ www.inim.biz DCMIINE0SOLLAN-100-20220701...
