- Page 1 DA-7 Motorsport Display Manual V1.4 KMS DA-7 manual Version 1.4...
-
Page 2: Table Of Contents
Contents KMS (Kronenburg Management Systems) ................. 3 Installing the Motorsport Display ....................5 Pinout main connector ......................5 Connecting the DA-7 Motorsport Display ................6 Install the GPS antenna ....................... 6 Technical data ..........................7 Functions ............................8 ECU data ..........................8 Navigating pages ......................... -
Page 3: Kms (Kronenburg Management Systems)
Built to thrive in the demanding environment of the track, the KMS DA-7 boasts an array of features designed to provide real-time insights into your vehicle's performance. With integrated GPS functionality, you can track speed and lap times with unparalleled accuracy, allowing you to push your limits and shave seconds off your lap times. - Page 4 Do not use a battery booster or a 24V charger. Do not reverse the polarity of the battery or the charging unit. Do not change the battery with the engine running. The peak power supply could severely damage the KMS Components and other electrical devices.
-
Page 5: Installing The Motorsport Display
2 Installing the Motorsport Display 2.1 Pinout main connector Pin nr. DA-7 Colour Diameter Function Black 0.75 mm² Ground Yellow/Red 0.5 mm² Button 1 Yellow/Black 0.5 mm² Button 2 Yellow/Green 0.5 mm² Button 3 White 0.5 mm² CAN High Green 0.5 mm²... -
Page 6: Connecting The Da-7 Motorsport Display
2.2 Connecting the DA-7 Motorsport Display Determine position of the DA-7 Motorsport display in your car Determine the length of the cable by guiding them to their final position. Leave a margin of 10 cm for safety purpose. Connect the cables: 1+7: Connect the ground cables to a ground point in the car closest to the Display. -
Page 7: Technical Data
800 x 480 high resolution 7” full color display Connector Type: DT06-12SB Amount of pins: 12 Software DA-7 update tool by KMS * Please note that when your using voltage options in the DA-7, that they are ECU voltages, not display voltages. KMS DA-7 manual Version 1.4... -
Page 8: Functions
4 Functions 4.1 ECU data To connect your KMS ECU to your DA-7 display, navigate to the “Setup” tab and change your “Ecu type” to the ECU you are using. Next change the “CAN bitrate” to correspond to the bitrate your ECU is sending. You can find this in the settings of your ECU. -
Page 9: Lap Timer, Recognizing Circuits And Finding Nearest Circuit
On the top of the display is a shift light bar. It builds up from left to right and when it is near max RPM it starts blinking. There are multiple settings available that change the behavior of the shift light. Refer to 3.2 Settings for more detailed information. KMS DA-7 manual Version 1.4... -
Page 10: Settings
Enable this if you have a gearbox sensor fitted in the vehicle. Border color of Data page Allows the user to select one of three colors available Layout of race page Allows the user to change between race page layouts KMS DA-7 manual Version 1.4... -
Page 11: Supported Ecus
Aswell as the OBD2 protocol. The usual bitrate for this is 500Mbit/s and is used by vehicles of 2008 and newer. In the future more ecu’s will be supported. Check our update page of the DA-7 for more information KMS DA-7 manual... -
Page 12: Led Assign
“High EGT 7” “Pit limiter on or off” “High EGT 8” “Low Inj. Corr. Grp1” “Low Inj. Corr. Grp2” “LED Disabled” --- This will turn the led off. Available colors Green Blue Yellow Purple Orange KMS DA-7 manual Version 1.4... -
Page 13: Warnings
Yellow and Green states both allow the usage of the lap timer and GPS speed 4.8.2 Saving configuration settings Upon exiting of the configuration screen, the current settings will be saved to the KMS DA-7 display, however some changes will only take effect after a restart KMS DA-7 manual... -
Page 14: Software Updates
5 Software updates The KMS Motorsport Display is sold with the latest version of the software. When a new version of software is available you can find this in the download section on the website: https://kms.vankronenburg.nl/downloads. Make sure to have our display connected to your laptop when installing the software, this will configure the driver correctly. -
Page 15: Supported Tracks
Lelystad - RDW Netherlands Raceway Venray Netherlands Arctic Circle Raceway Norway Rudskogen Norway Valerbanen Norway Red Bull Ring Austria Salzburgring Austria Silesia Ring Poland Algarve Portugal Estoril Portugal Slovakia Ring Slovakia Circuit de Barcelona-Catalunya Spain KMS DA-7 manual Version 1.4... - Page 16 Turkey Silverstone Brands Hatch Cadwell Park Donington Park Knockhill Racing Oulton Park Snetterton Goodwood Castle Combe Thruxton Anglesey Bedford Blyton Park Croft Circuit Anderstop way Sweden Gotland Ring Sweden Karlskoga Motorstadion Sweden Linkopings Motorstadion Sweden KMS DA-7 manual Version 1.4...
-
Page 17: Troubleshooting
If the issue persists, contact us at: techkms@vankronenburg.nl or send us a WhatsApp at: +31 (0)620700270. If necessary, our support department will ask you to send the KMS DA-7 Display to our technicians to resolve the issue. KMS DA-7 manual...
