Clas Ohlson APL-D11 Quick Start Manual

Selfie stick/tripod
Art. no. 39-3574 Model APL-D11
Please read the entire instruction manual before using the
product and then keep it for future reference. We accept no
liability for any errors in the text or images and we reserve the
right to make any necessary changes to technical data. If you
have technical problems or other questions, please contact our
customer service team.
Safety
• Never expose the product to powerful
vibration, impacts, moisture or water.
• Do not let children play with the product.
Using the product
1. Rotatable magnetic phone holder
2. Locking knob for the holder
3. Telescopic arm
4. Detachable remote control
5. Fold-out tripod legs
Remote control
Pairing
1. Activate the remote
ON
control by pushing
the on/off switch
upwards. The LED
indicator light will
begin to flash blue.
2. Activate Bluetooth on
the smartphone that
you want to pair and begin scanning for the remote control.
3. The remote control is called Selife. Select "Connect". When
the devices have been paired, the LED indicator
light will go out.
• When the remote control is switched on, it will
automatically connect to the Bluetooth device that
it was last connected to.
• If the remote control is not used for about 5
minutes, it will automatically go into standby mode.
Switch the remote control off completely by pushing
the on/off switch downwards.
Attaching a smartphone
1. Loosen the locking knob and fold out
the smartphone holder. Undo the locking
knob.
2. Remove the cover from the phone, if it
has one, and attach the phone to the
magnetic holder. Make sure that the
phone is held securely in place.
3. Activate the camera on the phone and
check that the volume button is set to
work as a shutter release button.
1
Taking photos or videos
• Extend the telescopic shaft to the
length you want.
• Rotate/angle the phone towards you.
2
• You can take selfies or videos of
yourself by leaving the remote control
3
on the handle.
• Fold out the tripod legs to use the
selfie stick as a stand.
4
5
• Remove the remote control from
the handle and press the shutter
release button to take photos from a
distance of up to 10 m.
Cleaning and maintenance
Clean the product by wiping it with a
Bluetooth
damp cloth. Use only mild detergents.
Devices
Never use solvents or corrosive
Selfie
chemicals.
Replacing the battery
1. Undo the screw on the battery cover on
the back of the remote control.
2. Remove the cover by sliding it upwards.
3. Take out the old battery and insert a
new CR1632 battery. Make sure that the
OFF
positive side of the battery is facing the
battery cover.
4. Screw the cover back on.
Troubleshooting guide
The remote The battery might be flat. Replace the
control will not battery.
switch on.
The camera will • Make sure that it has been paired
not take photos. correctly. See the section Pairing.
• Is the camera on your smartphone
switched on?
• Make sure that the volume button on the
phone is set to work as a shutter release
button.
Responsible disposal
This symbol indicates that the product should not be
disposed of with general household waste. This applies
throughout the entire EU. To prevent any harm to the
environment or health hazards caused by incorrect
waste disposal, the product must be handed in for
recycling so that the materials can be disposed of in
a responsible way. To recycle the product, take it to your local
recycling facility or contact the retailer. They will ensure that
the product is disposed of in a way that does not harm the
environment.
Specifications
Remote control
Battery CR1632
Bluetooth
Range 10 m
Output max. 10 dBm
Frequency range 2402−2480 MHz
Selfie stick/tripod
Dimensions Retracted – 54 × 58 × 210 mm
Extended – 54 × 58 × 1045 mm
Weight 186 g
+
Simplified EU Declaration Of Conformity
Clas Ohlson AB hereby declares that the radio equipment type
CR1632
APL-D11 is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available on
the following website: www.clasohlson.com
English
