Clas Ohlson WS-22001 Quick Start Manual

Selfie stick/tripod
Art. no. 39-2601 Model WS-22001
Please read the entire instruction manual before using the product and
then keep it for future reference. We accept no liability for any errors
in the text or images and we reserve the right to make any necessary
changes to technical data. If you experience any technical problems or
have questions, please contact our customer service team.
Safety
• Never expose the product to heavy vibration, impacts,
moisture or water.
• Do not let children play with the product.
Using the product
1. Swivel and tilt smartphone holder 1
2. Locking knob for smartphone
holder
2
3. Telescopic arm
4. Detachable remote control,
3
shutter button
5. Foldout tripod legs
4
5
Remote control
Pairing
1. Press and hold the button
on the remote control for
about 3 seconds until
the LED indicator starts
flashing blue.
2. Activate Bluetooth on the smartphone that you want to pair and begin
scanning for the remote control.
3. The remote control is called "Dispho". Select "Connect". When
the devices have been paired, the LED indicator goes out.
On/off switch
• To turn the remote control on, press and hold the button (4) for
around 3 seconds until the LED indicator light comes on for a couple
of seconds. The remote control will automatically connect to
the Bluetooth device it was last paired with and the LED light will go
out.
• Turn off the remote control by pressing and holding the button for four
seconds. The LED will flash quickly three times and then go out.
If the remote control is not used, it will automatically switch off
after 30 minutes.
Attaching a smartphone
2. Lift the bar on
the holder and fit
the smartphone
into it. Make
sure that
1. Undo the locking
the smartphone
knob and fold out
is securely in
the smartphone
place and switch
holder.
on the phone's
camera.
Taking photos or videos
• You can take selfies or videos of
yourself by attaching the remote
control to the handle and extending
the telescopic arm to the required
length.
• Rotate and tilt the smartphone
towards you.
• Fold out the tripod legs to use
the selfie stick as a stand.
• Remove the remote control from
the handle and you can take photos
from a distance of up to 10 m.
Note: Always put the stand on a flat, stable surface. If you are using
the stand outdoors, take care even if the weather is not windy.
Battery
The product comes with one CR1632 battery.
Remove the plastic tab to
activate the battery.
Replacing the battery
1. Remove the battery cover by
turning it anticlockwise using
a coin, screwdriver or a
similar tool.
2. Remove the old battery and
insert a new one. Make sure
that the positive terminal is
facing upwards.
3. Refit the battery cover.
Cleaning and maintenance
Clean the product by wiping it with a damp cloth. Use only mild cleaning
agents. Never use solvents or corrosive chemicals.
Troubleshooting guide
The remote The battery might be flat. Replace the battery.
control will not
switch on.
The camera • Make sure that it has been paired successfully.
will not take Refer to the Pairing section.
photos. • Is the camera on your smartphone switched on?
• Make sure that the volume button on
the phone is set to work as a shutter release
button.
Responsible disposal
This symbol indicates that the product should not be
disposed of with general household waste. This applies
throughout the entire EU. To prevent any harm to
the environment or health hazards caused by incorrect waste
disposal, the product must be handed in for recycling so
that the materials can be disposed of in a responsible way.
To recycle the product, take it to your local recycling facility
or contact the retailer. They will ensure that the product is
disposed of in a way that does not harm the environment.
Specifications
Remote control
Battery 1 × CR1632
Bluetooth
range 10 m
Output −6 to 4 dBm
Frequency range 2400−2483.5 MHz
Selfie stick/tripod
Smartphone holder 57−90 mm
Dimensions
Retracted 6.5 × 6 × 30.5 cm
Extended 150 cm
Weight 380 g
