Installation Guide

User Guide can be downloaded from: heating.danfoss.com.

1 . Installation must be done by an authorised

electrician .

2 . Remove and mount timer/programmer back plate

direct to wall or on wall box, and wire as required for

application, see fig . 1 & 2 on page 22 . The backplate

included within the product packaging should be

used for the installation .

3 . Locate hooks at top of timer/programmer into top of

back plate, lower into position and tighten retaining

screws .

See fig .3 for dimensions and fig .4 for wiring diagram

on page 23 .

TS710 & FP720

VISUS14F
