Installation Guide
1. Installation Steps
EN
User Guide can be downloaded from: heating.danfoss.com.
1. Installation must be done by an authorised
electrician.
2. Remove and mount timer/programmer back plate
direct to wall or on wall box, and wire as required for
application, see g. 1 & 2 on page 16. The backplate
included within the product packaging should be
used for the installation.
3. Remove battery backup tab, see g. 3 on page 17.
4. Locate hooks at top of timer/programmer into top of
back plate, lower into position and tighten retaining
screws.
2. Dimensions and Wiring
See g. 4 for dimensions and g. 5 for wiring diagram
on page 18 and page 19.
4
TS710 - V2 & FP720 - V2
