Summary of Contents for ACT AC7912
- Page 1 AC7912 2-Port HDMI 4K@60Hz KVM switch...
-
Page 2: Table Of Contents
Congratulations with the purchase of this high-quality ACT product! This product has undergone extensive testing by ACT’s technical experts. Should you experience any problems with this product, you are covered by ACT warranty. Please keep this manual and the receipt in a safe place. -
Page 3: Act 2-Port Hdmi 4K@60Hz Kvm Switch
3.0 ACT 2-Port HDMI 4K@60Hz KVM switch The ACT AC7912 2-port KVM HDMI switch can control two HDMI® computers with a single keyboard, mouse and monitor. It supports HDMI 2.0, is HDCP 2.3 compatible and supports resolutions up to 4K@60Hz 4:4:4 8 Bit. The built in USB-hub can transmit USB 3.0 up to 5Gbps. -
Page 4: Specifications
4.0 Specifications Technical HDMI Compliance HDMI 2.0 HDCP Compliance HDCP 2.3 Audio Latency No Latency Video Resolution Up to 4K@60Hz, 2K@120Hz/144Hz, 1080P@240Hz IR Level 5Vp-p IR Frequency Fixed frequency 38KHz Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0 Color Depth 8/10/12bit HDR, HDR10, HDR10+, Dolby Vision, HLG HDMI IN / OUT... -
Page 5: Operation Controls And Functions
5.0 Operation Controls and Functions 5.1 Front panel Name Function Description USB 3.0 ports USB 3.2 Gen 1 device ports to connect USB 3.0 usb drive, camera, printer etc. ▪ When Hotkey switch is set to OFF mode these two ports support USB 3.2 Gen 1. USB 3.0 ports (with hotkey mode) ▪... -
Page 6: Rear Panel
5.2 Rear panel Name Function Description HDMI: HDMI signal input port, connected to HDMI source device such as PC with HDMI PC 1 ports cable. USB HOST: USB Host port, connected to PC 1. It can be used for firmware upgrade. HDMI: HDMI signal input port, connected to HDMI source device such as PC with HDMI PC 2 ports cable. -
Page 7: Ir Pin Definition
5.3 IR Pin Definition IR Receiver pin definition is as below: 5.4 IR Remote ① Power on or Standby: Press this button to power on the switcher or set it to standby mode. ② Auto: Press this button to enable/disable the auto switching function. ③... -
Page 8: Hotkey Function
USB 1.1 mouse and keyboard which can be used for hotkey switching. 7.0 Keyboard & Mouse Hotkey Function When the hotkey mode is enabled you can use keyboard and mouse hot keys to operate and control the AC7912. 7.1 Keyboard Hotkeys 7.2 Mouse Hotkeys... -
Page 9: Ascii Commands
8.0 ASCII Commands The AC7912 also supports ASCII commands control. Connect the RS-232 port of the product to a PC with a 3-pin phoenix connector cable and a RS-232 to USB cable. The connection method is as following; Use a Serial Command tool program on a PC to send ASCII commands to control the AC7912. -
Page 10: Setup Example
9.0 Setup Example... -
Page 11: Service And Support
ACT warranty. Products are not covered by the ACT warranty when exposed to incorrect/improper use, external influences or when opening the service parts of the product by parties other than ACT. - Page 12 AC7912 | 06-2024...
