- Page 1 AC7914 2-Port HDMI 4K@60Hz KVM switch dual monitor...
-
Page 2: Table Of Contents
Congratulations with the purchase of this high-quality ACT product! This product has undergone extensive testing by ACT’s technical experts. Should you experience any problems with this product, you are covered by ACT warranty. Please keep this manual and the receipt in a safe place. -
Page 3: Specifications
2.0 Specifications Technical HDMI Compliance HDMI 2.0 HDCP Compliance HDCP 2.3 Audio Latency No Latency Video Resolution Up to 4K@60Hz, 2K@120Hz/144Hz, 1080P@240Hz IR Level 5Vp-p IR Frequency Fixed frequency 38KHz Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0 Color Depth 8/10/12bit HDR, HDR10, HDR10+, Dolby Vision, HLG HDMI IN / OUT... -
Page 4: Act 2-Port Hdmi 4K@60Hz Kvm Switch Dual Monitor
3.0 ACT 2-Port HDMI 4K@60Hz KVM Switch Dual Monitor The ACT AC7914 2-Port HDMI 4K@60Hz KVM Switch Dual Monitor can control two HDMI® computers with a single keyboard, mouse and 2 hdmi monitors. It supports HDMI 2.0, is HDCP 2.3 compatible and supports resolutions up to 4K@60Hz 4:4:4 8 Bit. The built in USB-hub can transmit USB 3.0 up to 5Gbps. -
Page 5: Operation Controls And Functions
4.0 Operation Controls and Functions 4.1 Front Panel Name Function Description USB 3.2 Gen 1 device ports to connect USB 3.0 usb drive, camera, printer etc. USB 3.0 ports ▪ When Hotkey switch is set to OFF mode these two ports support USB 3.2 Gen 1. USB 3.0 ports (with hotkey ▪... -
Page 6: Rear Panel
4.2 Rear Panel Name Function Description HDMI: HDMI signal input ports PC 1, connected to HDMI source device such as PC with HDMI cable. PC 1 ports USB HOST: USB Host port, connected to PC 1. It can be used for firmware upgrade. HDMI: HDMI signal input ports PC 2, connected to HDMI source device such as PC with HDMI cable. -
Page 7: Ir Pin Definition
5.0 IR Pin Definition IR Receiver pin definition is as below: 6.0 IR Remote ① Power on or Standby: Press this button to power on the switcher or set it to standby mode. ② Auto: Press this button to enable/disable the auto switching function. ③... -
Page 8: Mode Functions
7.0 Mode functions The AC7914 has two modes: Single PC mode and Dual PC mode. In the Single PC Mode, both monitors display the output from either PC 1 or PC 2, with seamless USB device control following the active PC. In Dual PC Mode, each monitor is dedicated to a different PC, allowing you to simultaneously view and manage two computers with ease. -
Page 9: Hotkey Function
USB 1.1 mouse and keyboard which can be used for hotkey switching. 9.0 Keyboard & Mouse Hotkey Function When the hotkey mode is enabled you can use keyboard and mouse hot keys to operate and control the AC7914. 9.1 Keyboard Hotkeys 9.2 Mouse Hotkeys... -
Page 10: Ascii Commands
10.0 ASCII Commands The AC7914 also supports ASCII commands control. Connect the RS-232 port of the product to a PC with a 3-pin phoenix connector cable and a RS-232 to USB cable. The connection method is as following; Use a Serial Command tool program on a PC to send ASCII commands to control the AC7914. -
Page 11: Setup Example
11.0 Setup Example... -
Page 12: Service And Support
ACT warranty. Products are not covered by the ACT warranty when exposed to incorrect/improper use, external influences or when opening the service parts of the product by parties other than ACT. - Page 13 AC7914 | 06-2024...
