D-Link DCS-5300G Quick Installation Manual

D-Link DCS-5300G Quick Installation Manual

Wireless internet camera with pan and tilt
Hide thumbs Also See for DCS-5300G:

Advertisement

This product can be set up
using Internet Explorer 6.x
or above

Before You Begin

You must have at least the following:
• Windows 98/Me/2000/XP
• A CD-ROM drive
• An available Ethernet connection

Check Your Package Contents

These are the items included with your purchase:
If any of the below items are missing, please contact your reseller.
©2004 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of
their respective holders. Software and specifications subject to change without notice. DCS-5300G.07292004
DCS-5300G Internet Camera with Remote Control
CD-ROM with Manual and Installation Wizard
A/V Cable
2 Antennas
CAT5 Ethernet Cable
Camera Stand
12V AC Power Adapter
DCS-5300G
Wireless Internet Camera
with Pan and Tilt
Using a power supply
with a different voltage
rating will damage this
product and void the warranty.
