(Not for use on RTV 500)
These instructions are for installation of the
complete cab as well as the modular components.
Description:
Part Number:
Complete Cab Kit
77700-11821 (this contains all 5 kits listed below)
Mount Kit
77700-V4310A (required to install any of the following individual kits)
Windshield Kit
77700-V4368
Rear Panel Kit
77700-11822
Roof Kit
77700-V4312
Door Kit
77700-11823
This cab has been modularly designed so that components may be quickly detached and attached depending upon conditions.
Any component may be used independently with the required Mount Kit (p/n: 77700-V4310A).
BEFORE INSTALLING CAB
Read all instructions and safety instructions in this manual.
Refer to your machine's operator's manual and safety instructions on your
machine's safety decals.
Wear appropriate personal protective equipment (PPE) when performing
work.
Hang a "DO NOT OPERATE" tag in operator station.
Estimated assembly time for entire cab: 1.5 hours (excluding any accessories)
PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020
INSTALLATION MANUAL
COMPLETE CAB KIT (77700-11821)
KUBOTA RTV 520
Code: 77700‐11999 (Rev. A)
Advertisement
Related Manuals for Kubota 77700-11821
Summary of Contents for Kubota 77700-11821
- Page 1 These instructions are for installation of the complete cab as well as the modular components. Description: Part Number: Complete Cab Kit 77700-11821 (this contains all 5 kits listed below) Mount Kit 77700-V4310A (required to install any of the following individual kits) Windshield Kit 77700-V4368...
- Page 2 NOTICE: The ROPS (Roll-Over Protective Structure) serial number label is covered by the cab and may be viewed by removing the rear panel. 5) WARNING - 77700-12001 PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020 Code: 77700‐11999 (Rev. A)
-
Page 3: Safety Labels
D. Use caution to avoid damaging the factory installed weld nuts or threaded inserts. Begin the bolt engagement by hand to avoid or correct potential cross threading. PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020 Code: 77700‐11999 (Rev. A) -
Page 4: Mount Kit
If installing just a roof, these two upper mounts are the only mount kit components necessary. Proceed directly to the roof section. Fig. 1.3 (view of inside rear corner of driver’s side) PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020 Code: 77700‐11999 (Rev. A) - Page 5 Fig. 1.7.1 (view of driver’s side front mount from driver’s seat) PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020 Code: 77700‐11999 (Rev. A)
- Page 6 77700-V4310A RTV 520 MOUNT KIT PARTS LIST HARDWARE RUBBER TYPES: 1/4” x 3/4” 5/8” REG. BULB EXPAND-A-FOAM 9PRO2 9PR30 PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020 Code: 77700‐11999 (Rev. A)
- Page 7 If the issue is with the seal against the hood, slotted adjust the pins up or down. adjust- ment use an Allen wrench here to adjust Fig. 2.3 (view from inside of driver’s side) PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020 Code: 77700‐11999 (Rev. A)
- Page 8 Gap along ROPS at bottom Move latches forward. Gap along ROPS at top Move upper pins forward. Gap along hood Move latches forward. Move lower pins down. Move upper pins up. PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020 Code: 77700‐11999 (Rev. A)
- Page 9 1/16” x 1/2” 5/8” REG. BULB 1” RND BULB 5/8” SIDE BULB FOAM TAPE HARDWARE* *HARDWARE ONLY RE- 9YR-DT 9PRO2 9PR19 9PR17 QUIRED WHEN REPLACING CLEAR WINDSHIELD PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020 Code: 77700‐11999 (Rev. A)
- Page 10 Fig. 3.4 (view of upper rear driver’s side) Gap along ROPS at bottom Move rear panel forward. Rear Panel and Mount Ass’y. Move lower mount outer do not line up bracket left or right. PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020 Code: 77700‐11999 (Rev. A)
- Page 11 77700-11822 RTV 520 REAR PANEL KIT PARTS LIST INSIDE VIEW RUBBER TYPES: 5/8” REG. BULB HARDWARE 9PRO2 PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020 Code: 77700‐11999 (Rev. A)
- Page 12 Too tight along top Move latches down. Move front pins down. Latch and pin doesn’t line up Move front pins forward or backwards. Move upper windshield pins backward. PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020 Code: 77700‐11999 (Rev. A)
- Page 13 77700-V4312 RTV 520 ROOF KIT PARTS LIST UNDERSIDE VIEW OF ROOF ASSEMBLY PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020 Code: 77700‐11999 (Rev. A)
- Page 14 Fig. 5.2 (view of outside rear corner of driver’s side) pine tree clips removed from here Fig. 5.3 (pine tree clips) relief for tube Fig. 5.3.1 (view from passenger’s side) PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020 Code: 77700‐11999 (Rev. A)
- Page 15 Fig. 5.5 (view of driver’s side) apply grease Restriction plate Fig. 5.9 (view of passenger’s side) Fig. 5.5.1 (view of driver’s side) PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020 Code: 77700‐11999 (Rev. A)
- Page 16 Latch and pin does not line up Move latch forwards or backwards. Loosen hinges and (front to back) move door forwards or backwards. Door does not seal Move latch out. PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020 Code: 77700‐11999 (Rev. A)
- Page 17 77700-11823 RTV 520 DOOR KIT PARTS LIST RUBBER TYPES: 5/8” SIDE BULB 1” FOAM TAPE HARDWARE 9PR17 9PR39 PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020 Code: 77700‐11999 (Rev. A)
-
Page 18: Care And Maintenance
4) Remove grease and oil with mineral spirits and a COTTON cloth or chamois. This manual is the property of the owner. Be sure to leave with the owner when installation is complete. PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2020 Code: 77700‐11999 (Rev. A)
