Kubota 77700-VC5081 Installation Manual

Wire harness for single accessory

Download this manual

KUBOTA RTV-X900, RTV-X1120D, RTV-X1140, RTV-XG850

BEFORE INSTALLING SWITCH PANEL / FUSE BLOCK



Read all instructions and safety instructions in this manual.



Refer to your machine's operator's manual and safety instructions on your

machine's safety decals.



Wear appropriate personal protective equipment (PPE) when performing work.



Disconnect negative (-) terminal on battery before performing work.



Hang a "DO NOT OPERATE" tag in operator station.

Estimated assembly time: 15 minutes

PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2019

INSTALLATION MANUAL

WIRE HARNESS FOR SINGLE ACCESSORY

(77700-VC5081, VC5081)

This harness is to be used with one accessory only. For

multiple accessories with V5027, V5028, V5258, or V5259,

windshields are installed using one VC5081 Wire Harness

Kit per accessory.

Required for: VC5083A Heater Kit, VC5030 Wiper Kit,

VC5056 LED Strobe Light Kit, VC5057A 4-Way Flashers,

VC5050 Front LED Work Lights, and VC5051A Rear LED

Work Lights.

Code: 77700-05197 (Rev. G)

Need help?

Do you have a question about the 77700-VC5081 and is the answer not in the manual?

Page 1 Wear appropriate personal protective equipment (PPE) when performing work.  Disconnect negative (-) terminal on battery before performing work.  Hang a "DO NOT OPERATE" tag in operator station. Estimated assembly time: 15 minutes PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2019 Code: 77700-05197 (Rev. G)
Page 2 Follow Steering Lines Through Fender Follow Coolant Lines Inside Frame Rail Battery Compartment Wire Harness Fig. 1 PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2019 Code: 77700-05197 (Rev. G)
Page 3 10. Fasten the fuse holder and relay to the vehicle using the supplied self drill/tap screws. RELAY SERVICE PART: Kubota p/n: 70000-01214, Code No.: V4238P10, qty.: one, Relay PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2019 Code: 77700-05197 (Rev. G)
