Page 2
BNWAS150 - Bridge Navigational Watch Alarm System This Page Intentionally Blank Page 1 of 21 Operational Guide BNWAS150 Iss01 Rev00...
Page 3
BNWAS150 - Bridge Navigational Watch Alarm System Document Date Modification Number (where applicable) Revision Brief Record of Change and Reason for Change Iss1 Rev0 06.02.12 Original Issue NOTE: All alterations must be verified by re-authorisation and approval of the complete document.
Page 4
BNWAS150 - Bridge Navigational Watch Alarm System This page Intentionally Blank Page 3 of 21 Operational Guide BNWAS150 Iss01 Rev00...
This manual is for informational use only, and may be changed without notice. This manual should not be construed as a commitment of AMI Marine (UK) Ltd. Under no circumstances does AMI Marine (UK) Ltd assume any responsibility or liability for any errors or inaccuracies that may appear in this document.
Page 6
BNWAS150 - Bridge Navigational Watch Alarm System This page Intentionally Blank Page 5 of 21 Operational Guide BNWAS150 Iss01 Rev00...
LCD display. These might include RADAR or ECDIS. External valid reset inputs must be approved by the appropriate approval body before being used. AMI Marine (UK) Ltd will assist with recommendations wherever possible from previous experience but will not accept responsibility if not accepted.
Page 10
BNWAS150 - Bridge Navigational Watch Alarm System Wheel house / Bridge Equipment - Control display, Stage 1 Alarm sounders, Alarm Beacon, Directional PIR’s, and push button reset switches. Push buttons can be mounted on the Bridge wing, and are IP rated accordingly.
- BNWAS 150 Controls and Functions DC-150 Display and Control The BNWAS DC-150 Display Control Panel is the user interface and display for the BNWAS150 The display control panel is to be mounted at a suitable location within the ship bridge preferably at a...
Page 12
BNWAS150 - Bridge Navigational Watch Alarm System RI-150 Illuminated Reset Pushbutton and RE-150 Illuminated Reset Pushbutton with Buzzer The RI-150 reset pushbutton unit can be used to reset the BNWAS system’s timer before or during the stage alarm. The RE-150 unit performs the same function but also has an audible alarm making it ideal for use on the bridge wings.
BNWAS150 - Bridge Navigational Watch Alarm System - Software Setup and Operation Switching On The BNWAS 150 SETUP Menu The SETUP mode allows the user to access the SETUP MENU and customise the timing parameters within the BNWAS 150 menus.
BNWAS150 - Bridge Navigational Watch Alarm System BNWAS150 Startup On first power up a message from the system designers will De s i g n e d a n d b u i l t appear on the display. A MI Ma r i n e...
BNWAS150 - Bridge Navigational Watch Alarm System Mode Selection Pressing the SELECT button again, will change Do r ma n t 0 3 : 0 0 P e r i o d S E T U P If the key is now turned to the RUN position and removed, the C a b i n system is now in the ON mode.
BNWAS150 - Bridge Navigational Watch Alarm System Operational Sequence When the BNWAS countdown reaches 0 0 : 0 0 S T A GE 0 0 : 0 0 message will appear. A L A RM S T A GE A L A RM The display and the remote reset buttons will now flash.
BNWAS150 - Bridge Navigational Watch Alarm System Selecting Duty Cabins and Using Cabin Call Selecting Duty Cabins for Stage 2 Alarm The Selecting and De-selecting Cabins function can only be accessed when the system is in MODE. Press and hold the SELECT button until appears.
BNWAS150 - Bridge Navigational Watch Alarm System External Reset (if external equipment connected) message will be shown when the RADAR is in RA DA R RE S E T 0 3 : 0 0 use by an operator and the BNWAS timer will reset.
BNWAS150 - Bridge Navigational Watch Alarm System Unacknowledged Alarms (if external equipment connected) This will be displayed if an unacknowledged RA DA R A L A RM. 0 0 : 0 0 alarm is received from the Radar. S T A GE A L A RM 2...
BNWAS150 - Bridge Navigational Watch Alarm System - System Faults Power Error If the main power fails the standby power will be used to power the system. This is indicated by the MAIN POWER FAIL being displayed on the LCD screen until the main power is restored to the system.
BNWAS150 - Bridge Navigational Watch Alarm System - Maintenance guide The BNWAS 150 system requires periodic (annually) confirmation that all sensors are active, and conduct a full system integrity check. Any damaged/inactive peripherals MUST be replaced by a suitable spare part by an approved engineer.
