- Page 1 POE-SW805G5U-Solar User Manual Updated on January 4, 2024...
-
Page 2: Important Notification
Introduction Having the features that power generation by solar energy, intelligent PoE power supply and control on auto charging and discharging, 5+1 high-power solar energy charging switch can more effectively solve the network application and power supply demand in complicated environments such as in remote mountainous areas, scenic spots, network electricity off shore and outdoor construction. -
Page 3: Display & Description
Display & Description Port LED Indicators Function Switch LED Indicators Status Description Always ON Powered devices connected and power supply normal Orange (PoE) Always OFF No powered devices connected or no power supply Port LED 1-3 Always ON Network signal communicated Green (Link) Always OFF Network signal not communicated... -
Page 4: Back Panel Connection
Back Panel Connection Ground Wire Screw LED Indicator Status Description Always ON System crashed Always OFF System unsuccessfully started CPU: System Operation 1/2S: battery normal Flicker 1/4S: battery failure Always ON Battery in charging, electricity<98% Always OFF Battery charging finished or not in charging BIN: Battery Charging Flicker To be fully charged, electricity≥98%... -
Page 5: Technical Specification
Annotate: Battery Type DIP 1 DIP 2 DIP 3 DIP 4 Panel 12V Lead Acid Battery ON/OFF 24V Lead Acid Battery ON/OFF 12.6V Linthium Battery 14.8V LiFePO4 Linthium Battery 25.2V Linthium Battery 29.6V LiFePO4 Linthium Battery Technical Specification Solar & UPS Management Flexible Power Supply and Priority Solar Power >... - Page 6 PoE Switch (5) 10/100/1000Base-T RJ45 Ports Interfaces (1) 1.25G SFP Slot Port 1: 802.3bt PoE++ 60W (Pin 1/2/4/5+, 3/6/7/8-) PoE Outputs Port 2-3: 802.3af/at PoE 30W (Pin 1/2+, 3/6-) Port 4-5: 802.3af/at PoE 30W (Pin 1/2+, 3/6-) or Passive 24V PoE 24W (Pin 4/5+, 7/8-) Total PoE Budge Exchange Capacity 12Gbps...
