EASY TO RUN
Beginning With PB225225
Starting - - Engine Operation
S
Starting - - Standby Operation
S
Temperature Setpoint
S
Manual Defrost
S
Alarm Display
S
Alarm List
S
Alarm Reset
S
Stopping Unit
S
Integra 30S

Advertisement

loading
Need help?

Need help?

Do you have a question about the Integra 30S and is the answer not in the manual?

Questions and answers

Related Manuals for Carrier Integra 30S

Summary of Contents for Carrier Integra 30S

  • Page 1 EASY TO RUN Integra 30S Beginning With PB225225 Starting - - Engine Operation Starting - - Standby Operation Temperature Setpoint Manual Defrost Alarm Display Alarm List Alarm Reset Stopping Unit...
  • Page 3 EASY TO START TARTING - - NGINE PERATION 1. Press key. (Start-up is time--delayed for 40 seconds) 2. Check if box temperature is displayed. 3. Check if road operation light is on. If not, unplug power cord from receptacle. NOTE: If standby power cord is plugged in, the unit will run in standby mode.
  • Page 4 EASY TO START TARTING - - TANDBY PERATION 1. Press the key and plug in power supply. 2. Press the key. (Start-up is time--delayed for 40 seconds) 3. Check that the standby operation light is on.
  • Page 5 EASY TO SET EMPERATURE ETPOINT 1. Press 2. Press + (plus) key to increase setpoint or press -- (minus) key to decrease setpoint. 3. Press key when desired setpoint is displayed to lock in new setpoint.

  • Page 6: Manual Defrost

    EASY TO SELECT ANUAL EFROST 1. Check that box temperature is 1. Check that box temperature is 40_F or lower. 40_F or lower. 2. Press Manual Defrost key to initiate 2. Press Manual Defrost key to initiate manual defrost. manual defrost.

  • Page 7: Alarm Display

    EASY TO CHECK LARM ISPLAY 1. When an Alarm is activated, the light flashes red. light flashes green when the unit is operating correctly. 2. Press the key for 5 seconds to display alarms. 3. Press key to view additional alarms.

  • Page 8: Alarm List

    EASY TO READ LARM Alarm DESCRIPTION Number No Malfunction High or Low Pressure Switch Open High or Low Pressure Switch Open Standby Compressor Overheated (Standby Only) Road Compressor Clutch Malfunction Standby Contactor (high amp draw) (Standby Only) Condenser Fan Motor (hight amp draw Evaporator Fan Motor (high amp draw) Hot Water Relay or Electric Heat Contactor (high amp draw) (Standby Only)
  • Page 9 EASY TO RESET LARM ESET 1. Press the key to clear Active Alarm list. Unit can now be restarted if no Active Alarm condition remains.
  • Page 10 EASY TO STOP TOPPING 1. Press the key.
  • Page 11 TIPS Carrier Transicold wants you to get optimum performance from you truck refrigeration unit. The way to get that performance is to review the checklist below before each trip. Do this and you’ll be well on your way to ensuring maximum refrigeration efficiency with a minimum of trouble.
  • Page 12 For additional information, including function and unit data display codes, refer to operat- ing instructions inside unit front doors. In an emergency, call Carrier Transicold Action Line 1-800-448-1661. Carrier Transicold A member of the United Technologies Corporation family. Stock symbol UTX.
