Before installing or starting this unit for the first
time, this manual should be studied carefully to
obtain a working knowledge of the unit and or the
duties to be performed while operating and
maintaining the unit.
RETAIN THIS MANUAL WITH UNIT. This Technical
manual contains IMPORTANT SAFETY DATA and
should be kept with the unit at all times.
More Than Air. Answers.
Online answers: http://www.air.irco.com
System Modbus Gateway Box
Ingersoll Rand
System Automation
Operator's Manual
C.C.N. : 80444557
REV.
DATE : MARCH 2009
: C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X8I and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ingersoll-Rand X8I

Summary of Contents for Ingersoll-Rand X8I

  • Page 1 Ingersoll Rand System Automation System Modbus Gateway Box Operator’s Manual Before installing or starting this unit for the first time, this manual should be studied carefully to obtain a working knowledge of the unit and or the duties to be performed while operating and maintaining the unit.

  • Page 2: Table Of Contents

    SecTIOn 1 - TABLe OF cOnTenTS Section 1 - tABLe oF contentS ......2 Refer to Section Indicated Section 2 - intRoDUction ........3 Section 3 -SAFety ............3 note INSTALLATION ................3 Important or caution, Safety OPERATION ..................3 MAINTENANCE AND REPAIR ..........3 Section 4 - coMPReSSoR connection AnD contRoL .................5 SYSTEM MODBUS GATEWAY BOX ........6 UNIT LOCATION ................6...

  • Page 3: Section 2 - Introduction

    SecTIOn 2 - InTRODUcTIOn The System Modbus Gateway (SMG) Box is designed to provide a RS485 Modbus connection to the X8I or X12I Automation System. SecTIOn 3 -SAFeTy Safety Precautions OPeRATIOn • The SMG Box must only be operated by competent WARNING : Risk of Danger personnel under qualified supervision.
  • Page 4 Attach labels to the isolator switch and to the • The SMG Box must only be cleaned with a damp unit stating “WORK IN PROGRESS - DO NOT APPLY cloth, using mild detergents if necessary. Avoid the VOLTAGE”. Do not switch on electrical power or use of any substances containing corrosive acids or attempt to start the SMG Box if such a warning alkalis.

  • Page 5: Section 4 - Compressor Connection And Control

    The Compressor 24VAC Control Voltage Reference X8I Application and Interconnect Guide For From Air Wiring connections Between The X8I, The ir-485 or irV-485 The RS485 Network is a Serial, Point to Point Compressors Gatewayand The Compressor, S3 Direct Connects,...

  • Page 6: System Modbus Gateway Box

    The System Modbus Gateway (SMG) Box is designed A fused switching isolator must be installed to the main to provide a RS485 Modbus connection to the X8I or X12I incoming power supply, external to the SMG Box. The Automation System.

  • Page 7: Modbus Rs485 Connection To Remote Modbus Device (Customer Computer, Plc. Dcs)

    MODBUS RS485 cOnnecTIOn TO ReMOTe IR485 cOnnecTIOn TO X-SeRIeS MODBUS DeVIce AUTOMATIOn SySTeM neTWORK (cUSTOMeR cOMPUTeR, PLc, DcS) MODBUS RS485 Wire polarity is important Use 2-wire, 24 gauge (Belden 9841 or equivalent), twisted pair, earth shielded, data cable with a total system Wire polarity is important network length no greater than 4000ft (1219m).

  • Page 8: Operational Indications

    OPeRATIOnAL InDIcATIOnS RS485 neTWORK RS485 data communications and other low voltage signals can be subject to electrical interference. This potential can result in intermittent malfunction or anomaly that is difficult to diagnose. To avoid this possibility always use earth shielded cables, securely bonded to a known good earth at one end.

  • Page 9: System Modbus Gateway Overview

    SySTeM MODBUS GATeWAy OVeRVIeW...

  • Page 10: Section 5 - Parts List

    SecTIOn 5 - PARTS LIST ITeM PART nO. DeScRIPTIOn 39266093 KIT, System Modbus Gateway 80444490 Manual Reference Sheet 42659359 Module, System Modbus Gateway 39265913 Unit, XPM-TAC24 39036703 Gland, Set - Pg13.5 23243009 System Enclosure 20mm ITeM PART nO. DeScRIPTIOn 39265962 IEC Fuse T1.0A 39265970 IEC Fuse T1.6A...

  • Page 11: Wiring Diagram

    WIRInG DIAGRAM System Modbus Gateway BLÅ SORT BRUN ORANGE RØD HVID GRØN VIOLET SPÆNDINGSOMSKIFTER...
