- Page 1 Freestanding Water Chiller Installation and Maintenance Instructions DFSA120 DFSA121 I00026_31May23 1300 369 273 | info@enware.com.au enware.com.au...
-
Page 2: Product Description
Enware water chillers supply chilled water on demand. Suitable for public areas such as gyms, building sites and office buildings. KEY FEATURES • Flow rate of up to 18 litres/hour of chilled water • 4 Litre storage tank •... -
Page 3: Technical Data
IMPORTANT - This must be read before proceeding with installation 1. Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500. Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions. Reference should also be made to the ABCB and Local Government regulations when considering the choice of, and the installation of these products. - Page 4 WARNING: • Enware water chillers are not suitable for outdoor use. The appliance must not be exposed to rain. • Stainless steel panel (non-powder coated) chillers are not designed or recommended for use in corrosive environments such as enclosed chlorinated pool areas.
-
Page 5: Installation
Drinking bubbler can be deleted or temporarily removed if it is not required. Plug and fitting are not included - they can be purchased separately. (Enware part no. 677077 - blanking plug, 673159 - elbow) 1. Loosen and remove the back nut from under the bubbler. - Page 6 Replace front panel of the water chiller and secure the panel using screws provided. Connect power cable and turn power back on. Remove protective film from stainless steel panels. Call 1300 369 273 www.enware.com.au...
- Page 7 To loosen, unscrew nut (up). To tighten, screw the nut in (down). Go back to step 1. IMAGE 7 IMAGE 8 www.enware.com.au Call 1300 369 27...
-
Page 8: Operation
SPOUT 3. Replace the push button and hex dress nut, and tighten. BODY 4. Re-test bubbler fountain for correct operation. TYPE 61 SPANNER FOR CARTRIDGE RETAINING NUT (892530) INLET SCREEN MESH (892531) Call 1300 369 273 www.enware.com.au... -
Page 9: Components & Spare Parts
& spare parts BUBBLER PART ENWARE SALES CODE HEX DRESS NUT Cartridge BUB294 (892537) Bubbler complete BUB290 PUSH BUTTON CARTRIDGE FLOW ADJUSTMENT RETAINING NUT SCREW CARTRIDGE (BUB294) SPOUT BODY TYPE 61 SPANNER FOR CARTRIDGE RETAINING NUT (892530) INLET SCREEN MESH (892531) WATER CHILLER REFRIGERATION SYSTEM - The entire refrigeration system is hermetically sealed. -
Page 10: Service And Maintenance
Enware product should be cleaned with a soft damp cloth using only mild liquid detergent or soap and water. Do not use cleaning agents containing a corrosive acid, scouring agent or solvent chemicals. -
Page 11: Troubleshooting
Water supply turned off Turn water on outlet Debris fouling inlet or outlet Remove blockage ports of cartridge Rubbish/debris fouling outlet Remove blockage Water discharge from top Cartridge is damaged Replace cartridge BUB294 of bubbler www.enware.com.au Call 1300 369 27... -
Page 12: Making A Claim
All notifications and accompanying forms must be sent to us marked for the attention of the Enware Pty Ltd, Except as provided or referred to in this document, we 9 Endeavour Road, Caringbah NSW 2229. We can also be...
