- Page 1 1.2 User`s manual External wireless video and audio transmission system for IP cameras HD and UHD in the band 5.1 - 5.8 GHz www.camsat.com...
-
Page 2: Safety Tips
Do not approach the device when it is on at the distance below 30 cm. The contents of this manual comprise proprietary information of CAMSAT and are in- tended only for use by purchasers of the equipment described herein. In order to... -
Page 3: R&Tte Declaration Of Conformity
(Directi- ve 1999/5/CE of the European Parliament and the Council of Europe, March 1999). The CDS-EasyIP eco module is compliant with provisions related to the safety in using electrical devices. Observe the following guidelines: the power outlet must be earthed in compliance with applicable provisions, •... - Page 4 System for transmission of video and audio from IP cameras. Key features of the module CDS-EasyIP eco: Easy configuration on switches without the need of a PC • CDS-EasyIP eco can work both as a receiver and a transmitter • Ensures continuous and stable transmission •...
-
Page 5: Preparation For Operation
Preparation for operation It is recommended that the first start-up and configuration of the system is done on the desk at small distances. This can save a lot of valuable time with the configuration of many different cameras. MASTER receiver and all SLAVE transmitters must be set to the same operating channel to establish a connection. - Page 6 Multipoint Configuration CDS-EasyIP eco can be connected in Point-to-Multipoint configuration with up to 4 transmitters to one receiver. These settings are configured by switches 7 and 8 in each transmitter according to the following formula: After 90 seconds since power start equipment will make a transparent interconnection sending all IP addresses connected to the ports of the device.
-
Page 7: Montage
3. Start the web browser and enter the IP address of the wireless device (see table p. 3). Login Information: User: camsat password: camsat Note: The device manufacturer is not responsible for the devices that are not properly... -
Page 8: Connection And Start-Up
Connection and start-up It is recommended that the first start-up and configuration of the system is done at the desk at small distances. This can save a lot of valuable time with the configuration of many different cameras. Transmitter (IP camera): Set DIPswitch No. - Page 9 Receiver powered by PoE (NVR). Set the dipswitch No. 1 to ON (receiver mode), set the operating channel by a table • identical to the transmitter, set DIP7 and DIP8 to ON (up) Connect NVR with the network cable to the PORT 1 or LAN port in PoE power supply. •...
-
Page 10: Examples Of Application
Examples of application Transmitter Transmitter 192.168. 116.2 192.168.120.2 Channel: 149 Channel: 165 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 2500m 2500m Receiver Receiver The minimum distance between the devices 192.168. 116.1 192.168.120.1 50-100 cm Channel: 149... - Page 11 Transmitter 192.168.118.5 Channel: 157 1 2 3 4 5 6 7 8 Transmitter 192.168.116.2 2500m Channel: 149 1 2 3 4 5 6 7 8 Transmitter 192.168.120.5 Channel: 165 1 2 3 4 5 6 7 8 The minimum distance Receiver between the devices 50-100 cm...
- Page 12 Table of available operating frequencies Table of frequencies outside the EU and the US and paid Use of specific channels according to their purpose: CE - Europe • FCC - US • Using other frequencies depends on the legal regu- lations of the country where you are.
-
Page 13: General Warranty Terms
Camsat grants a 24 month warranty for the CDS-EasyIP eco transmission kit 1. If the device is not be operating properly, make sure, before returning the device for servicing, that everything was done according to the operating manual 2. -
Page 15: Device Disposal
Improper waste disposal is subject to penalties provided for in the appropriate regulations Producer CAMSAT Gralak Przemysław Ogrodowa 2a 86-050 Solec Kujawski Poland O#er and information: www.camsat.com Service: serwis@camsat.com.pl Technical support Mon–Fr 8.00 AM–4.00 PM tel. +48 52 387 10 97...
