CAM-9
Wireless system for simultaneous transmission of
video, audio and control for PTZ cameras
IP65
5,8
VIDEO:
GHz
869
DATA:
MHz
Operating manual
Warranty Terms
SMA
9 V DC
ANTENNA
14 V DC
CONNECTOR
25
PAL
FM
mW
NTSC
300
GFSK
RS-485
mW
-20ºC
÷
÷
+55ºC
BNC
BNC
UTP
VIDEO
VIDEO
VIDEO
10
CHANNELS
8
CHANNELS
Advertisement
Table of Contents
Related Manuals for Camsat CAM-9
Summary of Contents for Camsat CAM-9
- Page 1 CAM-9 Wireless system for simultaneous transmission of video, audio and control for PTZ cameras 9 V DC -20ºC IP65 ÷ ÷ ANTENNA +55ºC 14 V DC CONNECTOR VIDEO: VIDEO VIDEO VIDEO NTSC CHANNELS GFSK RS-485 DATA: CHANNELS Operating manual Warranty Terms...
-
Page 2: Table Of Contents
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Removing a transmitter from the CAM-9 Rx receiver memory . -
Page 3: Product Features
. kit only after the previous kit has been set up precisely . 2 . It is recommended to install CAM-9 receivers at least 7 m away from Kit contents digital receivers (CDS-5021, CDS-5IP and other) . -
Page 4: Technical Data
R×D Power supply voltage 9–14 V** ENTER Maximum power consumption 310 mA** Case protection class IP65 (external application) BNC VIDEO CAM-9 WIRELESS VIDEO & TELEMETRY Operating temperature from −20°C to +55°C RX-M RX-S MENU Warranty 2 years BASIC: F1 - baud rate set | F2 - data format set... -
Page 5: Switch Settings
Switch settings Basic settings Operating the dip-switch SWITCH 1 [J] – enables / disables the 120 Ω resistor (terminator) in parallel with the RS-485 interface terminals . This resistor should always be added at the end of every RS-485 line to avoid interference . In order to enable the resistor (RS-485 line terminator), it should be set to the ON position;... -
Page 6: Advanced Settings
. device memory . Then, the device will return to the main MENU . 4 . The procedure from section 3 should be repeated for each CAM-9 Tx transmitter . Setting the data format 5 . -
Page 7: Setting The Video Operating Channel Remotely
- If there is a need to turn one of the transmitters off permanently Setting the data transmission parameters remotely (removal, damage), it should be deleted from the CAM-9 M Rx receiver memory . In order to do this, select the... -
Page 8: General Warranty Terms
General warranty terms - Mechanical damage of devices and failures occurring due to Camsat grants a 24 month warranty for the Cam-9 transmission kit fortuitous events, such as: fire, power grid overvoltage, electrical discharges, power supply, effects of chemical substances. - Page 9 Manufacturer: CAMSAT Gralak Przemysław Ul . Ogrodowa 2a 86-050 Solec Kujawski Product offer and information: www.camsat.com Service: service@camsat.com...
