Camsat CDS-EasyIP/SMA User Manual

External wireless video and audio transmission system for ip cameras hd and uhd in the band 5.1 - 5.8 ghz
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CDS-EasyIP
CDS-EasyIP/SMA
ver. 1.3
User`s Manual
External wireless video and audio transmission system
for IP cameras HD and UHD in the band 5.1 - 5.8 GHz
www.camsat.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDS-EasyIP/SMA and is the answer not in the manual?

Questions and answers

Related Manuals for Camsat CDS-EasyIP/SMA

Summary of Contents for Camsat CDS-EasyIP/SMA

  • Page 1 CDS-EasyIP CDS-EasyIP/SMA ver. 1.3 User`s Manual External wireless video and audio transmission system for IP cameras HD and UHD in the band 5.1 - 5.8 GHz www.camsat.com...

  • Page 2: Safety Tips

    Thank you for choosing the CDS-EasyIP. We trust that its unique features will come in very handy. Please, read this instruction manual to ensure safe operation and maximise efficiency of the device. 1. Safety and maintenance tips In order to safely use our device, you should read and observe the tips contained in this instruction manual.
  • Page 3 The CDS-EasyIP module is compliant with provisions related to the safety in using electrical devices. Observe the following guidelines: the power outlet must be earthed in compliance with applicable provisions, • before transferring the device or performing any other technical operations, di- •...
  • Page 4 CDS-EasyIP System for transmission of video and audio from IP cameras. Key features of the module CDS-EasyIP: Easy configuration by the switches, no need to connect a computer • Power output 48V / 15.4W for IP Camera PoE • CDS-EasyIP can work both as a receiver and transmitter •...

  • Page 5: Preparation For Operation

    Preparation for operation It is recommended that the first start-up and configuration of the system is done on the desk at small distances. This can save a lot of valuable time with the configuration of many dif- ferent cameras. Function SETTINGS Operating mode: Receiver (MASTER)
  • Page 6 Multipoint Configuration CDS-EasyIP can be connected in Point-to-Multipoint configuration with up to 4 transmit- ters to one receiver. These settings are configured by switches 7 and 8 in each transmit- ter according to the following formula: After 90 seconds since power start equipment will make a transparent interconnection sending all IP addresses connected to the ports of the device.
  • Page 7 WARNING The device manufacturer is not responsible for the devices that are not properly protected and for related damage of the equipment and other network infrastructure.

  • Page 8: Connection And Start-Up

    Connection and start-up It is recommended that the first start-up and configuration of the system is done at the desk at small distances. This can save a lot of valuable time with the configuration of many different cameras. Transmitter (IP camera): Set the dipswitch No.
  • Page 9 Receiver powered by PoE (NVR). Set the dipswitch No. 1 to ON (receiver mode), set the operating channel by a table • identical to the transmitter, set DIP7 and DIP8 to ON (up) Connect NVR with the network cable to the PORT 1 or LAN port in PoE power supply. •...

  • Page 11: Examples Of Application

    Examples of application...
  • Page 13 Table of available operating frequencies Table of frequencies outside the EU and the US and paid Use of specific channels according to their purpose: CE - Europe • FCC - US • Using other frequencies depends on the legal regu- lations of the country where you are.
  • Page 14 Supplement A: Applies to version with SMA antenna connectors: Connection of CDS-EasyIP / SMA module without connected external antenna may result in device damage, which is not covered by the warranty. If you use the CDS-EasyIP / SMA module adjust the output power of the device to gain of used antenna. EIRP power must not exceed the permissible power, as described in the regulations of the country where you install the devices.

  • Page 15: General Warranty Terms

    Camsat grants a 24 month warranty for the CDS-EasyIP transmission kit 1. If the device is not be operating properly, make sure, before returning the device for servicing, that everything was done according to the operating manual 2.
  • Page 16 4. Marks created during usage, such as scratches, soiling and localised wear are not covered by warranty. In cases not regulated by the terms of this warranty sheet, the appropriate provisions of the Civil Code are applicable.

  • Page 18: Device Disposal

    Device disposal The mark presented to the left informs that this electrical or electronic device, after its use has ended, cannot be thrown together with household refuse The device should be delivered to a specialised collection point Detailed information about the closest collection point is available from local authorities.
