- Page 1 ® PWBH250A Electric Hoist User’s Manual / Manual de usuario...
-
Page 2: Technical Data
PWBH250A TECHNICAL DATA Model BH250A Voltage 230V , 50Hz Current (A) Input Power (W) 1300 Rated Load (Kg) Li�ing height (m) *Rated Speed (m/min) Cable Diameter (mm) Cable Tensile Strength ( N/mm >1870 Insula�ng Grade Protec�ng Grade IP54 *Work Rate... -
Page 3: Safety Instructions
PWBH250A 9.- The hoist is not designed for continuous use. The work rate is intermittent 10.- The rated capacity of the machine does not vary with the position of the load SAFETY INSTRUCTIONS 1.- Always check that the voltage corresponds to the voltage on the rating plate. In case the mains voltage is not suitable may cause working abnormally or personal or injury 2.- Your socket plug must be grounded and your electric system must be supplied with an earth leakage... - Page 4 PWBH250A Operating Instructions 1.- Before rst using, remove the adhesive tape from cable drum. 2.- The value of the A-weighted emission sound pressure level at the operator’s position os lower than 70dB. 3.- Supplying power need: voltage 230V + 10%, frequency 50Hz + 1%.
-
Page 5: Operation
PWBH250A Operation 1.- Check if the (emergency) stop switch is pressed. Tum the red stop switch clockwise to engage. 2.- Press the push button to lift the load- 3.- Press the push button to lower the load. 4.- For up limited system, when the hoisted load is almost in top posotion, the limit block will move the lever upward. -
Page 6: Periodic Inspection & Maintenance
PWBH250A PERIODIC INSPECTION & MAINTENANCE Always make sure that the machine is not connected to the mains electricity when you carry out any maintenance of the mechanism 1.- Hereinafter, per cycle means that the operator operates the load up and down one time. Periodically chec- king usually means it has checked after the hoist work per 100 cycles. - Page 7 PWBH250A...
-
Page 8: Part List
PWBH250A PART LIST Nº NAME Qty. Nº NAME Qty. FAN HOOD GRADE 2 GEAR FAN BLADE SHAFT OF ROPE HEX HEAD BOLTS (M6X176) GEAR BOX BRACKET GEAR COVER BEARING (6007-2RS) BEARING (6203-2RS) QUILL ROLLER BEARING BRAKE HOOP ROPE FASTENING SPRING... - Page 9 Lima, Peru www.prowinch.pe ® Av Mansiche 1586, Trujillo, La Libertad, Peru 51 44 618700 ventas@dezajacobs.com Equipos De Izaje www.dezajacobs.com Prowinch Chile Spa Www.prowinch.cl Parque Riesco 3407, Recoleta, Región Metropolitana, Chile Prowinch Colombia Sas +56-2-26218989 www.prowinch.co Cl. 163a #20-28, Bogotá Colombia (+57) 1 7034035 ®...
