Simmons Kids Portable Crib Manual

Hide thumbs

Advertisement

Available languages

Available languages

Table of Contents

Read all instructions
before assembly and use.
KEEP INSTRUCTIONS FOR
FUTURE USE.
EN
Style #:
___________
Lot:
___________
A
REV
Date:
___________
Before contacting Delta Consumer
Experience Center please ensure this
information matches the information
matches the information found on the
label on the product.
To Make Assembly Even
Easier Watch Video Here!
ADULT ASSEMBLY REQUIRED
Due to the presence of small parts during assembly,
keep out of reach of children until assembly is complete.
This product is not intended for institutional or commercial use.
Portable Crib
For Questions or
to Contact Us:
DeltaChildren.com/Help
If unable to access website, please
email wcs@SimmonsKids.com
Expect longer response times via
email.
March 15, 2024, 45135, R0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Portable Crib and is the answer not in the manual?

Questions and answers

Related Manuals for Simmons Kids Portable Crib

Summary of Contents for Simmons Kids Portable Crib

  • Page 1 Portable Crib Read all instructions For Questions or To Make Assembly Even before assembly and use. to Contact Us: Easier Watch Video Here! DeltaChildren.com/Help KEEP INSTRUCTIONS FOR If unable to access website, please FUTURE USE. email wcs@SimmonsKids.com Expect longer response times via email.
  • Page 2 Cuna portátil Lea todas las instrucciones Para preguntar o para Para facilitar más aun el antes de ensamblar y usar. contactarnos : ensamblaje ver el video aquí DeltaChildren.com/Help MANTENGA LAS INSTRUCCIONES PARA SU USO Si no puede acceder el sitio web, por favor envíenos un email a FUTURO.
  • Page 3 NOTES ON ASSEMBLY: -During the assembly process whenever using screws or bolts, check each by placing the screw/bolt on the diagram of the item which is drawn actual size and design. Be sure to use the proper size and shape specified in the instructions. -To assemble this unit you may be required to place the unit on it’s side and face.
  • Page 4 PARTS: MAKE SURE THAT ALL PRE-ASSEMBLED PARTS ARE TIGHT PIEZAS: ASEGÚRESE DE QUE TODAS LAS PIEZAS PRE-ENSAMBLADAS ESTÁN BIEN APRETADAS. Back Rail x 1 Right Headboard x 1 Left Headboard x 1 Cabecera derecha x 1 Barandilla posterior x 1 Cabecera izquierda x 1 45131 45130...
  • Page 5 PARTS: HARDWARE KITS PART#45134 PIEZAS: EL KIT DE HERRAMIENTAS - PIEZA #45134 M6 x 50 mm Bolt x 8 Perno M6 x 50 mm x 8 5467 No drills necessary. Do not use power screwdriver. No hace falta taladrar. No utilice destornilladores eléctricos M6 x 18 mm Bolt x 4 Perno M6 x 18 mm x 4 5763...
  • Page 6 B A B Y S A F E S L E E P T I P S Visit Deltachildren.Com/Pages/Crib-Safety-Tips for more information Read all warnings and DO NOT place any follow all instructions. items in the crib. The safest place for your Pillows and blankets have baby to sleep is in a caused infants to suffocate,...
  • Page 7 F U R N I T U R E S A F E T Y T I P S Visit Deltachildren.Com/Pages/Leaders-In-Safety for more information SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM FURNITURE TIP-OVER. NEVER open more than Read all warnings and one drawer at a time.
  • Page 8 C O N S E J O S P A R A U N S U E Ñ O S E G U R O P A R A L O S B E B É S Visite Deltachildren.Com/Pages/Crib-Safety-Tips para obtener más información Lea todas las NO coloque artículos advertencias y siga...
  • Page 9 C O N S E J O S D E S E G U R I D A D S O B R E M U E B L E S Visite Deltachildren.Com/Pages/Leaders-In-Safety para obtener más información PUEDEN PRODUCIRSE LESIONES GRAVES O MORTALES POR APLASTAMIENTO AL VOLCARSE MUEBLES.

  • Page 10: Section 1: Crib Assembly, Step

    SECTION 1: CRIB ASSEMBLY, STEP 1 SECCIÓN 1: MONTAJE DE LA CUNA, PASO 1 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso M4 Allen Wrench (included) Llave Allen M4 (incluido) M6 x 25 mm Bolt x 4 Perno M6 x 25 mm x 4 Front Rail x 1 Barandilla frontal x 1...
  • Page 11 GG x 4 HH x 3...
  • Page 12 SECTION 1: CRIB ASSEMBLY, STEP 2 SECCIÓN 1: MONTAJE DE LA CUNA, PASO 2 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso M4 Allen Wrench (included) Llave Allen M4 (incluido) Right Headboard x 1 Cabecera derecha x 1 Left Headboard x 1 Cabecera izquierda x 1...
  • Page 13 CC x 4 AA x 4...
  • Page 14 SECTION 1: CRIB ASSEMBLY, STEP 3 SECCIÓN 1: MONTAJE DE LA CUNA, PASO 3 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso From Step 2 Desde el paso 2 M6x12mm Nut x 1 Tuerca M6x12mm x 1 Wrench Llave inglesa...
  • Page 16 SECTION 1: CRIB ASSEMBLY, STEP 4 SECCIÓN 1: MONTAJE DE LA CUNA, PASO 4 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso From Step 3 Desde el paso 3 M4 Allen Wrench (included) Llave Allen M4 (incluido) Back Rail x 1 Barandilla posterior x 1...
  • Page 17 CC x 4 AA x 4...
  • Page 18 SECTION 1: CRIB ASSEMBLY, STEP 5 SECCIÓN 1: MONTAJE DE LA CUNA, PASO 5 Parts and tools required to complete step Piezas y herramientas necesarias para completar este paso From Step 4 Desde el paso 4 M4 Allen Wrench (included) x 2 Llave Allen M4 (incluido) x 2 M6 x 18 mm Bolt x 4 Free Caster x 2...
  • Page 19 DD x 4 BB x 4 DD x 2 Locking Mechanism Mecanismo de bloqueo BB x 2...

  • Page 20: Section 2: Adjusting Mattress Board Height

    SECTION 2: ADJUSTING MATTRESS BOARD HEIGHT SECCIÓN 2: AJUSTE DE LA ALTURA DEL TABLÓN DEL COLCHÓN STEP 1 PASO 1 Push handle to the left to release Mattress Board. Presionar la manija hacia la izquierda para soltar el tablón del colchón. STEP 2 PASO 2 Lift Mattress Board.
  • Page 21 SECTION 2: ADJUSTING MATTRESS BOARD HEIGHT SECCIÓN 2: AJUSTE DE LA ALTURA DEL TABLÓN DEL COLCHÓN STEP 3 PASO 3 Lower Mattress Board. Push in Mattress Board Bajar el tablón para supports. colchón. Presionar sobre los soportes del tablón para colchón.

  • Page 22: Section 3: Folding Portable Crib

    SECTION 3: FOLDING PORTABLE CRIB SECCIÓN 3: PLIEGUE DE LA CUNA PORTÁTIL STEP 1 PASO 1 Push handle to the left to release Mattress Board. Presionar la manija hacia la izquierda para soltar el tablón del colchón. STEP 2 PASO 2...
  • Page 23 SECTION 3: FOLDING PORTABLE CRIB SECCIÓN 3: PLIEGUE DE LA CUNA PORTÁTIL STEP 3 PASO 3 STEP 4 PASO 4...
  • Page 24 CAUTION: ANY MATTRESS USED IN THIS CRIB SHALL BE AT LEAST 27 1/4 BY 51 5/8 IN. WITH A THICKNESS NOT EXCEEDING 6 WARNING: *Infants can suffocate on soft bedding. Never add a pillow or comforter. Never place additional padding under an infant.
  • Page 25 ATENCIÓN: CUALQUIER COLCHÓN QUE SE UTILICE EN ESTA CUNA DEBE TENER AL MENOS 69CM POR 131CM CON UN ESPESOR QUE NO EXCEDA LAS 15CM. ADVERTENCIA: *Niños pequeños y bebés pueden ahogarse en una cama blanda. Nunca añada una almohada ni un edredón. Nunca coloque almohadillado adicional debajo de un bebé.
  • Page 26 SAFETY LEADERS Visit Deltachildren.Com/Pages/Leaders-In-Safety for more information SAFE MATERIALS PRODUCTS YOU CAN TRUST WE GO ABOVE SLEEP SOUNDLY WITH & BEYOND DELTA CHILDREN...
  • Page 27 LÍDERES EN LA SEGURIDAD Visite Deltachildren.Com/Pages/Leaders-In-Safety para más información MATERIALES SEGUROS PRODUCTOS CONFIABLES ESTAMOS POR ENCIMA DUERME PROFUNDAMENTE Y MÁS ALLÁ CON DELTA CHILDREN...

  • Page 28: Limited Warranty

    Limited Warranty: This Delta Crib is warranted to be free from defects for a period of 1 year from the date of purchase under normal use. If a product is defective during this period, we will at our option repair or replace the defective part or product. This limited warranty extends only to the original retail purchaser and is valid only when supplied with proof of purchase, or if received as a gift, when the registration is on file with Delta.
