Simmons Airflow
Auto Motion
Bassinet
ADULT ASSEMBLY REQUIRED
701500
WARNING:
CHOKING HAZARD
Adult assembly required because of
small parts. Keep assembly parts out
of reach of children under 3 years.
Read all instructions BEFORE assembly and USE of product
Customer Experience Center
email: gcs@DeltaChildren.com
INSTRUCTION MANUAL
KEEP INSTRUCTIONS FOR FUTURE USE.
www.DeltaChildren.com
STYLES AND COLORS MAY VARY
DCP-IM-12152020-F2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Simmons Kids Airflow Auto Motion Bassinet
Summary of Contents for Simmons Kids Airflow Auto Motion Bassinet
- Page 1 Simmons Airflow Auto Motion Bassinet INSTRUCTION MANUAL ADULT ASSEMBLY REQUIRED STYLES AND COLORS MAY VARY 701500 WARNING: CHOKING HAZARD Adult assembly required because of small parts. Keep assembly parts out of reach of children under 3 years. Read all instructions BEFORE assembly and USE of product KEEP INSTRUCTIONS FOR FUTURE USE.
- Page 2 Consumer Information WARNING WARNING: Do not use this bassinet if you cannot exactly follow the accompanying instructions. Failure to follow these warnings and instructions could result in serious injury or death. • Read all instructions before assembling unit. KEEP INSTRUCTIONS FOR FUTURE USE. DO NOT USE THIS UNIT IF THE INSTRUCTIONS CANNOT BE STRICTLY FOLLOWED.
- Page 3 Before returning this product to the store! Let’s see if we can assist you! • Not sure how to assemble our product? Visit our site for easy to follow instructions along with some Tricks and Tips assembly video’s https://www.deltachildren.com/pages/instructions • If you are missing a piece or have a damaged part Please contact our Consumer Experience Center for assistance at gcs@DeltaChildren.com.
- Page 4 LIMITED MANUFACTURER WARRANTY This Delta product is warranted to be free from defects for a period of 90 days from the date of purchase under normal use. This warranty extends only to the original retail purchaser and is valid only when supplied with proof of purchase, or if received as a gift, when the registration is on file with Delta.
- Page 5 PARTS IMPORTANT! Please remove all parts from the package and identify them before assembly. Power Housing Frame Rear Front Mattress Board Rear Base Front Base Leg with Wire Leg(X1) Connection (X1) (For Music Module and Power Cord Attachment) Mattress Pad Bottom Support Tubes (x4) Sheet...
- Page 6 TOP FRAME ASSEMBLY NOTE: You may need the help of another adult for assembly. FRAME Fig. 1 Fig. 1A *Completed top frame assembly “CLICK” Fig. 1B ATTACHING FRAME TO MATTRESS BOARD • Place the frame on a flat surface and extend the support legs out (Fig. 1). •...
- Page 7 Attaching Power Housing to Top Frame Assembly *Screw is actual size to scale *Screw is actual size to scale M4 (2.5cm) (X2) M6 (3.5cm) (X2) Power Housing Mattress Board Fig. 1 Cross Tubes ATTACHING POWER HOUSING TO TOP FRAME ASSEMBLY •...
- Page 8 Front Base Leg and Frame Assembly *Screw is actual size to scale M6 (1.7cm) (X4) FRONT REAR REAR BASE LEG FRONT BASE LEG FRAME Fig. 1A FRAME Fig. 1 *Fully Assembled Base Legs ATTACHING BASE LEGS TO TOP ASSEMBLY • Locate the two (x2) M6 screw, a Phillips screwdriver, and the front base leg.
- Page 9 Storage Basket Assembly Slide Support Tube Into Fabric Storage Liner Support Tube Fig. 2 Support Tube Support Tube Joint *Support Tube Fully Connected Fabric Storage Liner Side View Fabric Storage Liner Facing Upward *Screw is actual size to scale M6 (1.7cm) (X8) Support Tube •...
- Page 10 Consumer Information WARNING Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR FUTURE USE. CAUTION - Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a class B digital device.
- Page 11 Attaching Fabric Fig. 1 Fig. 3 FASTENING SNAPS ON FABRIC LINER • Lift the skirt on the liner, snap all (8) of the straps around the top tube of the frame and all (4) snaps to the underside of the mattress boards (Fig.
- Page 12 Attaching Music Module Screw Button Hole Front Section of Fabric Liner Up Plug Button FRONT Hole Screw Button Hole Fig. 1A Fig. 1 Plug Button Hole Wire 2 Wire 1 • Align music module to the front end of the bassinet and lift up the front section of fabric liner before attaching music module (Fig. 1). •...
- Page 13 Wire Connection Assembly FRONT Fig. 1 Fig. 2 Fig. 2A CONNECTING WIRE TO FRONT BASE LG • Locate wire on the music module and connect it to top plug connection 2 on the front base leg (Fig. 2). • Locate the power cord and connect it to the bottom power cord connection of the front base leg (Fig.
- Page 14 Music Module Operation LIGHT AUTO GLIDE MUSIC Auto Glide Volume UP Speed 1 Auto Glide Volume DOWN Speed 2 • Press Auto Glide button to start 60 minute cycle of auto glide. • Press again to stop auto glide. • Auto glide speed can be adjusted with two speed buttons &...
- Page 15 Care and Maintenance • The frame, mattress pad, storage basket, music module may be wiped clean using a mild cleaning solution and a damp cloth. Do not use bleach. Do not use harsh or abrasive cleaners. Rinse clean with water to remove residue. Do not immerse the frame.
- Page 16 Delta Children's Products Corp. 114 West 26 Street New York, NY 10001 gcs@DeltaChildren.com www.DeltaChildren.com © 2020 Delta Children's Products. All rights reserved.
