HYTOBP S189-MAX Instruction Manual

Drone takes off quickly outdoors
1.1 Drone frequency matching with the remote control
1) Press about 3 seconds the switch to turn on the drone, until the drone plays specific music and all
indicators lights are flashing.
2) Then Press and hold (about 3 seconds) the remote control button. The remote control display will
light up and the red indicator light is always on.
3) Wait for the remote control and the drone to be automatically linked. The drone's indicator light
went from flashing to constant, indicating successful linking.
1.2 Calibrate the drone
Push both levers to the southeast, and then the drone's lights are flashing rapidly.
When the indicator light stays on, remove your hand and the calibration is completed.
Note：The drone needs to be placed on the ground.
1.3 Geomagnetic calibration required before flight
1) Press the "Geomagnetic Calibration" function button for 3 seconds, the remote control will make a
"beep" sound, the front and rear lights of the fuselage will be extinguished, and it will enter the
geomagnetic calibration mode.
2) Horizontal calibration: Pick up the drone, with its nose facing forward, about 50cm above the
ground, and rotate it horizontally about 3-5 times until the remote control prompts a "Beep" sound,
indicating successful calibration.
3) Vertical calibration: Pick up the drone, with its nose facing up, about 50cm above the ground, and
rotate it vertically about 3-5 times until the remote control prompts two beeps of "Beep~Beep",
followed by a long beep of "Beep~~~". Indicates calibration successful.
S189-MAX
