HYTOBP S177 User Manual

Hide thumbs

Advertisement

Table of Contents

Drone User Manual
E-mail Address: hytobp@htwlkj.net
Official Website: https://www.hytobp.net
YouTube Account: @HYTOBP (Includes tutorial videos)
Facebook Account: @Hytobp Ht
Phone Number: +�(���) ���-����
�.Please read this manual carefully before using the product.
�.Try to fly in a windless, clear and well-lit environment.
�.Make sure the drone battery is fully charged before flying.
S���
14 +

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S177 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HYTOBP S177

Summary of Contents for HYTOBP S177

  • Page 1 Drone User Manual S��� E-mail Address: hytobp@htwlkj.net Official Website: https://www.hytobp.net YouTube Account: @HYTOBP (Includes tutorial videos) Facebook Account: @Hytobp Ht Phone Number: +�(���) ���-���� �.Please read this manual carefully before using the product. �.Try to fly in a windless, clear and well-lit environment.
  • Page 2 Introduction of the remote control Speed adjustment Headless mode Camera up Camera down Obstacle Photo/Video avoidance Horizontal Fine-tuning calibration One-button Light control takeoff/landing Switch Calibration and Frequency-pairing Introduction of the drone The drone adopts �.�G frequency band, which can be operated by multiple people at the same time without interfering with each other.

  • Page 3: Accessory List

    Accessory list Remote control x � Drone x � (battery included) Blade A x �, B x � Instruction manual x � USB charging Screwdriver x � cable x � Note: Please carefully count the accessories and their quantities (e.g. Accessory list). If found incomplete, please provide proof of purchase and contact the seller in time for replacement.
  • Page 4 Accessory list (can be purchased separately) Blade Battery Note: If any of the above accessories are damaged during operation, you can contact the seller to purchase them by yourself.

  • Page 5: Pre-Flight Preparation

    Pre-flight Preparation Choose the flight environment: Flying indoors: Please choose to fly in an open space with no obstacles, people or pets nearby. Flying outdoors: Please choose a clear and windless weather or a light wind to fly. Please keep the drone within line of sight when flying and away from obstacles, high voltage lines, trees, crowds, etc.

  • Page 6: Blade Installation

    Opening the arms Order of opening the arms: ➀ Open the front arms first. (Camera side) ➁ Then open the rear arms. Fold them in the reverse order. Open the arms Blade Installation Install the blade against the motor shaft and tighten the screws clockwise (The logo of the arm and the blade should be the same, i.e.
  • Page 7 Charging method for the drone body Press the position indicated by the arrow to pull the battery outward and remove the battery. USB Charging USB charging cable connects the battery to the USB charging port. Charging: Plug the USB port of the USB charging cable into the computer's USB port (or use a power adapter with an output of �V=�A) and connect the other end of the USB charging cable to the battery socket.
  • Page 8 Precautions related to the use of batteries The use of lithium batteries involves certain risks and may cause significant damage to people and property, so please use with caution and assume all related responsibilities. If the battery leaks, avoid contact of the liquid with skin and eyes.

  • Page 9: Battery Installation

    Battery Installation ➀ Open the battery cover. ➁ Install the batteries. Open the battery cover and insert � AA batteries as indicated by the electrodes. (Batteries need to be purchased separately) Note: �. When loading batteries, you must recognize the positive and negative poles of the batteries, and can not be installed in reverse.
  • Page 10 Frequency pairing between remote control and drone ➀ Place the drone on a horizontal surface after turning on the power switch of the drone. Then turn on the switch of the remote control and it will automatically pair-frequency with the drone, and the LED light of the drone will be flashing.

  • Page 11: Start Flying

    Start flying �. One-button takeoff and landing Press the "One-button takeoff" button, then the blades of the drone will rotate and the drone will automatically fly to a height of �.� meters. Press the button again to land the drone. �.

  • Page 12: Light Control

    Hovering After allowing the drone to rise with the left joystick, release the left joystick and the drone will still hover at the height it was at when the joystick was released. Left joystick Speed (Slow, Medium and Fast) The default speed of the drone is low. Press the button to control the speed of the drone.

  • Page 13: Headless Mode

    Headless mode When the drone has finished the frequency pairing, the drone defaults to the normal mode, and at this time, the indicator light of the drone is always on. Short press the "Headless mode" button on the remote control, the remote control will make a "di"...
  • Page 14 Obstacle avoidance mode Press the button to turn on the obstacle avoidance mode, then press it again to turn it off. Obstacle avoidance on three sides and the drone would back up in the opposite direction of the obstacle. It is recommended to turn on the obstacle avoidance function in the indoor flight environment of more than �m x �m in length and width.
  • Page 15 Problem Solving and Guidance Problem Cause Solution The battery of Connect the battery the drone is not in the right way. connected. Malfunction Never fly in windy of the conditions. Windy remote conditions can be a control. The wind is limitation to the too strong.
