sDot CB4 Series User Manual

Cc-link ie field basic integrated i/o

Hide thumbs

Table Of Contents

Quick Links

Download this manual

CC-Link IE Field Basic

CB4 Series Integrated I/O

User Manual

Nanjing Solidot Electronic Technology Co., Ltd.

Table of Contents

Need help?

Do you have a question about the CB4 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for sDot CB4 Series

Page 1 CC-Link IE Field Basic CB4 Series Integrated I/O User Manual Nanjing Solidot Electronic Technology Co., Ltd.
Page 2 CB4 Series Integrated I/O User Manual Copyright © 2023 Nanjing Solidot Electronic Technology Co., Ltd. All rights reserved. Without written permission of our company, no organization or individual may extract, copy or transmit part or all of this document. Trademark notice and other Solidot trademarks are all trademarks of Nanjing Solidot Electronic Technology Co., Ltd.
Page 3: Table Of Contents
CB4 Series Integrated I/O User Manual CONTENTS Product Overview..............................1 Products..............................1 Product Characteristics......................... 1 Destination Rules..............................2 Destination rules.............................2 Model List..............................3 Product Parameters............................. 4 General Parameters..........................4 Digital parameters..........................5 Analog parameters..........................6 3.3.1 Technical Parameters........................6 3.3.2 Voltage Input/Output Range Selection and Code Value Table..........8 3.3.3...
Page 4 CB4 Series Integrated I/O User Manual 6.3.6 CB4-0032B............................31 6.3.7 CB4-1600A............................32 6.3.8 CB4-1600B............................33 6.3.9 CB4-0016A............................34 6.3.10 CB4-0016B............................35 6.3.11 CB4-2408A............................36 6.3.12 CB4-2408B............................37 6.3.13 CB4-0824A............................38 6.3.14 CB4-0824B............................39 6.3.15 CB4-0808A............................40 6.3.16 CB4-0808B............................41 6.3.17 CB4-A80V............................42 6.3.18 CB4-A80I............................43 6.3.19...
Page 5 CB4 Series Integrated I/O User manual logs 7.3.3 Setting the IP address from the host c o m p u t e r GX Works3......... 62 7.3.4 Reset operation and restoration of factory settings............. 71 Application i n GX Works3 Software Environment................. 72...
Page 6: Product Overview
Product Overview 1.1 Products CB4 series Integrated I/O modules with CC-Link IE Field Basic industrial Ethernet bus interface are compatible with CC-Link IE Field Basic networks of multiple vendors, taking up little space, fast speed, quick wiring, pluggable terminals, and simple configuration, providing multiple choices for high- speed data acquisition, optimized system configuration, simplified on-site wiring, and improved system reliability.
Page 7: Destination Rules
CB4 Series Integrated I/O User's Manual 2 Destination Rules Destination Rules 2.1 Destination rules Model Meaning Product description number Bus protocol CB: CC-Link IE Field Basic Protocol Abbreviation Product Series 4: Integrated I/O I/O Type A: Analog D:Digital Input Signal...
Page 8: Model List
CB4 Series Integrated I/O User's Manual 2 Destination Rules 2.2 Model List Model number Product Description CB4-3200A 32-channel digital input Module, NPN Type CB4-3200B 32-channel digital input Module, PNP Type CB4-1616A 16-channel d i g i t a l in p u t /output module, NPN type...
Page 9: Product Parameters
3 Product Parameters CB4 Series Integrated I/O User Manual Product Parameters General Parameters Interface parameter Protocol CC-Link IE Field Basic Port number 61450 (periodic data), 61451 (search for nodes) Number of logical stations RX, RY 64 bits (at 1 logical station)
Page 10: Digital Parameters
3 Product Parameters CB4 Series Integrated I/O User Manual 3.2 Digital parameter Digital input Rated voltage 24 VDC (18V~30V) Number of signal points 8, 16, 24, 32 Signal Type NPN/PNP "0" signal voltage -3~+3 V (PNP) 15~30 V "1" signal voltage (PNP) "0"...
Page 11: Analog Parameters
CB4 Series Integrated I/O User Manual 3 Product Parameters 3.3 Analog parameter 3.3.1 Technical Parameters Analog Input Input Points 4, 8 Input signal (voltage type) 0: -10 to +10 V (-32768 to 32767) 1: 0~+10 V (0~65535) 2: -10 to +10 V (-32000 to 32000)
Page 12 CB4 Series Integrated I/O User Manual 3 Product Parameters analog output Output points 4, 8 0: -10 to +10 V (-32768 to 32767) Output signal (voltage 1: 0~+10 V (0~65535) type) 2: -10 to +10 V (-32000 to 32000) 3: 0~+10 V (0~32000)
Page 13: Voltage Input/Output Range Selection And Code Value Table
CB4 Series Integrated I/O User Manual 3 Product Parameters 3.3.2 Voltage Input/Output Range Selection and Code Value Table Voltage input/output range selection and code value range 1 Range Selection -10~+10 V 0~+10 V -10~+10 V 0~+10 V 0~+5 V Measurem...
Page 14 CB4 Series Integrated I/O User Manual 3 Product Parameters Table 3- 1 Voltage Code Values Table Range Selectio -10~+10 V 0~+10 V -10~+10 V 0~+10 V 0~+5 V n Range code value code value code value code value code value...
Page 15 CB4 Series Integrated I/O User Manual 3 Product Parameters Voltage input/output range selection and code value range 2 Range Selection Measurem 1~+5 V -10~+10 V 0~+10 V 0~+5 V 1~+5 V ent range Code 0~32000 0~4000 0~4000 0~4000 0~4000 Value...
Page 16 CB4 Series Integrated I/O User Manual 3 Product Parameters Table 3- 2 Voltage Code Value Table Range Selectio 1~+5 V -10 ~+10 V 0~+10 V 0~+5 V 1~+5 V n Range code value code value code value code value code value...
Page 17: Current Input/Output Range Selection And Code Value Table
CB4 Series Integrated I/O User Manual 3 Product Parameters 3.3.3 Current Input/Output Range Selection and Code Value Table Analog Current Input/Output Range Selection and Code Value Range Range Selection 4~20 mA 0~20 mA 4~20 mA 0~20 mA Measurement range 0~65535...
Page 18 CB4 Series Integrated I/O User Manual 3 Product Parameters Form 3- 3 Current Code Values Table 0 (default) Range Selectio 4-20 mA 0-20 mA 4-20 mA 0-20 mA n Range code value code value code value code value amps 3277...
Page 19: Parameters Of The Public Side Expansion Module
CB4 Series Integrated I/O User Manual 3 Product Parameters 3.4 Parameters of the public side extension module common terminal rated voltage 125 VDC/AC 250V rated current Number of public terminals 4 groups (10P/group) All rights reserved © Nanjing Solidot Electronic Technology Co., Ltd.
Page 20: Panel
CB4 Series Integrated I/O User Manual 4 Panel Panel 4.1 Product mix Name and function description of each part of the product Serial Name (of a thing) Description number ① Power connector 3P terminal ② bus interface 2×RJ45 (iii) Operation Indicator Light Module Operational Status ➃...
Page 21: Indicator Light Function
CB4 Series Integrated I/O User Manual 4 Panel For DIN 35mm rail fixing (vi) Guideway slotting Labeling information such as module model, type, and MAC (vii) modular labeling address Ⓑ Channel Signal Indicator Indicates the corresponding channel status ⑨ Network Port Indicator Link and data sending and receiving status ⑩...
Page 22 CB4 Series Integrated I/O User Manual 4 Panel No signal output or abnormal signal output from Channel module channel Status Indicator signal light All rights reserved © Nanjing Solidot Electronic Technology Co., Ltd.
Page 23: Rotary Switch
CB4 Series Integrated I/O User Manual 4 Panel 4.3 Rotary switch Rotary Dial Description The method of setting the module IP address can be specified using the rotary switch, which is shown below: Set value (decimal) Realm 001 to 254 Sets the IP address to 1 Byte lower.
Page 24: Mounting And Disassemble
CB4 Series Integrated I/O User Manual 5 Installation and disassembly Installation and disassembly Precautions for installation\dismantling ⚫ Ensure that the cabinet is well ventilated (e.g., the cabinet is fitted with an exhaust fan). ⚫ Do not install this equipment next to or above equipment that may cause overheating.
Page 25: Overall Dimension
CB4 Series Integrated I/O User Manual 5 Installation and disassembly dismountin Minimum distance Module protection level is IP20, need to be installed in the box or cabinet, when installing, module and other modules or heat generating equipment, module up and down and other equipment or wiring slot, please follow the minimum spacing shown in the figure below (unit: mm).
Page 26: Installation And Disassembly
CB4 Series Integrated I/O User Manual 5 Installation and disassembly 5.2 Installation and disassembly Mounting Move Push the snap on the bottom of the module outward, as shown in Fig. ①, and then push the snap to the position as shown in Fig.
Page 27 CB4 Series Integrated I/O User Manual 5 Installation and disassembly Push the snap in the direction of the rail and hear the ringing sound to complete module installation, shown in Figure 6. ⑥ Move Dismantle Insert the flat head into the s n a p and...
Page 28: Wiring
6 Wiring CB4 Series Integrated I/O User Manual Wiring 6.1 Wiring terminal Wiring terminal extremity 2*20 P Signal Line Terminal wire diameter 22~17 AWG 0 .3~1.0 mm² extremity Power supply terminal wire diameter 22~16 AWG 0 .3~1.5 mm² Bus interface...
Page 29 6 Wiring CB4 Series Integrated I/O User Manual Wiring Method For single stranded hard wires, after stripping the corresponding length of wire, press down the button while inserting the wire into the terminal. For multi-stranded flexible wires, after stripping the...
Page 30 6 Wiring CB4 Series Integrated I/O User Manual Power Wiring The module power supply uses DC24V, the power cable is recommended to use twisted-pair cable, the power wiring is shown in the following figure. Bus Wiring Adopts standard RJ45 network interface with standard crystal connector, and the pin assignment is shown in the figure below.
Page 57: Common Expansion Module Wiring Diagram
6 Wiring CB4 Series Integrated I/O User Manual 6.4 Common Expansion Module Wiring Diagram All rights reserved © Nanjing Solidot Electronic Technology Co., Ltd.
Page 58: Use
7 Use CB4 Series Integrated I/O User Manual 7.1 Module Soft Component Description 7.1.1 Soft component allocation The module soft components are assigned in the following table: Station type Number of Soft component Clarification occupied stations 64 bits (8 bytes)
Page 59: Module Channel And Soft Component Correspondence List
7 Use CB4 Series Integrated I/O User Manual 7.1.2 Module Channel and Soft Component Correspondence List 16-channel digital input module Signal direction: Input module -> Master Soft Component No. Input signal Corresponding Input Channel DI digital input RX0~RXF Channel 0~F...
Page 60 7 Use CB4 Series Integrated I/O User Manual 32-channel digital output module Signal direction: master -> output module Corresponding Output Soft Component No. output signal Channel RX0~RX3F nothave prohibition on use DOa digital output RY0~RYF Channel 0~F Output signals Y0~YF...
Page 61 7 Use CB4 Series Integrated I/O User Manual 24-channel digital input, 8-channel digital output module Signal direction: input module -> master, master -> output module Corresponding Soft Component No. Input/Output Signal input/output channels DI digital input RX0~RX17 Channel 0~23 Input signals X0~X17...
Page 62 7 Use CB4 Series Integrated I/O User Manual RWr0~RWr3F RWw0~RWw3F 12 Channel Relay Output Module Signal direction: master -> output module Corresponding Output Soft Component No. output signal Channel RX0~RX3F nothave prohibition on use DO digital output RY0~RYB Channel 0~B...
Page 63 7 Use CB4 Series Integrated I/O User Manual RWw4 Channel 4 Filter Configuration D4 RWw5 Channel 5 Filter Configuration D5 RWw6 Channel 6 Filter Configuration D6 RWw7 Channel 7 Filter Configuration D7 RWw8~RWw3F prohibition on use 8-channel analog output module Signal direction: master ->...
Page 64: Parameters And Functional Configurations
7 Use CB4 Series Integrated I/O User Manual RWr2 Channel 2 Input signal D2 RWr3 Channel 3 Input signal D3 RWr4~RWr3F prohibition on use RWw0 Channel 0 Filter Configuration D0 RWw1 Channel 1 Filter Configuration D1 RWw2 Channel 2 Filter Configuration D2...
Page 65 7 Use CB4 Series Integrated I/O User Manual one. For example, RY100 is the starting address, and the address of channel N for range configuration is: Y100+N*8~Y100+N*8+7. Configuration method "7.4 Application i n t h e GX Works3 Software Environment".
Page 66: Analog Filter Parameter Setting Function
CB4 Series Integrated I/O User manual 7 Use 7.2.3 Analog filter parameter setting function The analog input filter function averages the A/D converted data internally to reduce the effects of fluctuations in the input signal due to noise. Analog inputs are processed as moving averages with a specified number of A/D conversions.
Page 67: Changing The Ip Address With Conf_Testtool_Tomaster.exe Tool
CB4 Series Integrated I/O User Manual 7 Use 7.3.2 Modify IP address with Conf_TestTool_ToMaster.exe utility 1. After the hardware connection is completed and power is supplied, turn the rotary switch to the IP host position to be assigned, and set the IP address of the computer installing the tool to the same network segment as the IP of the module.
Page 69 CB4 Series Integrated I/O User Manual 7 Use Click "Convert" in the menu bar, click "Convert All", as shown below. Click "Online" in the menu bar, and then click "Write to Programmable Controller" to write the set parameters to the CPU module of the master station, as shown in the figure below.
Page 70 CB4 Series Integrated I/O User Manual 7 Use Pop-up box "Parameters already exist, do you want to overwrite them?" Select "Yes to all" as shown below. At this point, the download of setup parameters is complete, click "Close". Power the module back up after disconnecting it from the PLC.
Page 71 CB4 Series Integrated I/O User Manual 7 Use In the pop-up window of CC-Link IEF Basic Configuration, click "Automatic Detection of Connected Devices", a pop-up box will appear, select "Yes", as shown in the following figure. Select "Yes", as shown in the following figure.
Page 72 CB4 Series Integrated I/O User Manual 7 Use To modify the PLC to use the 50 segment, click Reflect Settings and Close as shown below. Under Setting item interface, set PLC as 50 network segment under IP address setting, double click "Network Configuration Settings - >...
Page 73 CB4 Series Integrated I/O User Manual 7 Use In the CC-Link IEF Basic Configuration window, change the IP address of the module to the 50 segment as well, as shown in the following figure. Right-click the slave device and select "Online -> Reflect communication settings of remote station"...
Page 74 CB4 Series Integrated I/O User Manual 7 Use The prompt box shown below pops up, click "OK". Or pop-up box as shown below, click "OK". All rights reserved © Nanjing Solidot Electronic Technology Co., Ltd.
Page 75 CB4 Series Integrated I/O User Manual 7 Use Click "Reflect settings and close" as shown below. After clicking "Apply", repeat steps d~i as shown below. After the PLC is re-powered, the network segments of the PLC and the module are in the same network segment, and the IP change setting is successful.
Page 76: Reset Operation And Restoration Of Factory Settings
CB4 Series Integrated I/O User Manual 7 Use 7.3.4 Reset operation and restoration of factory settings 1. If the IP address is forgotten, lost or other abnormal conditions occur during use, the IP address of the module can be reset through the reset function. Set the rotary switch to 0, press and hold the reset button for more than 1s until the RUN light and ERR light flash alternately.
Page 77: Application In Gx Works3 Software Environment
CB4 Series Integrated I/O User Manual 7 Use 7.4 Application in GX Works3 software environment 1. Preparations ⚫ Hardware environment ⮚ Module preparation This description uses the CB4-A80V module as an example ⮚ One computer with GX Works3 software pre-installed ⮚...
Page 78 CB4 Series Integrated I/O User Manual 7 Use In the pop-up box, select the CSP file you want to add and click "Login" to complete the installation, as shown below. Note: Configuration files do not need to be unpacked, you need to close the project when installing;...
Page 79 CB4 Series Integrated I/O User Manual 7 Use List of supported masters for CB4 module: MELSEC iQ-R Brand name model number CPUR00CPU, R01CPU, R02CPU, R04CPU, R04ENCPU, R08CPU, Programmable controller R08ENCPU, R16CPU, R16ENCPU, R32CPU, R32ENCPU, R120CPU, R120ENCPU C Controller Module R12CCPU-V...
Page 80 CB4 Series Integrated I/O User Manual 7 Use 4. Setting up to use CC-Link IE Field Network Basic In the left navigation interface, select "Parameter -> CPU Module Model", double click "Module Parameter", set the IP address of CPU under IP Address Setting, and select "Use" in the drop-down box of "Use or not use"...
Page 81 CB4 Series Integrated I/O User Manual 7 Use In the pop-up window of CC-Link IEF Basic Configuration, click "Auto Detection of Connected Devices" to automatically add the connected modules to the network, as shown in the following figure. 5. Refresh side setting In the left navigation interface, select "Parameter ->...
Page 82 CB4 Series Integrated I/O User Manual 7 Use Configure the relevant parameters, after the configuration is complete, click "Apply", as shown in the following figure. 6. Download setup parameters Click "Convert" in the menu bar, click "Convert All", as shown below.
Page 83 CB4 Series Integrated I/O User Manual 7 Use Click "Online" in the menu bar, and then click "Write to Programmable Controller" to write the set parameters to the CPU module of the master station, as shown in the figure below.
Page 84 CB4 Series Integrated I/O User Manual 7 Use A pop-up box "Completed", click "OK". At this point, the download of setup parameters is complete, click "Close". Power the module back up after disconnecting it from the PLC. All rights reserved © Nanjing Solidot Electronic Technology Co., Ltd.
Page 85 CB4 Series Integrated I/O User Manual 7 Use 7. Adding soft components or buffer memory Select "Online -> Monitor -> Monitor Start" as shown below. Select "Online -> Monitor -> Bulk Monitor for Soft Components/Cache Storage" as shown in the following figure.
Page 86 CB4 Series Integrated I/O User Manual 7 Use ⮚ Analog process data For analog process data, as shown below, add D1000, each channel occupies 16 bits, D1000 corresponds to channel 0, D1001 corresponds to channel 1, and so on; When used in cascade, RWr occupies 32 words (64 bytes) in each station, as shown in the figure below, the starting address of the first module is D1000, and the starting address of the second module is D1032.
Page 87 CB4 Series Integrated I/O User Manual 7 Use ⮚ Analog range configuration function For analog range selection parameters, as shown in the following figure, add Y100, each channel occupies 8 bits, Y100 corresponds to channel 0, Y110 corresponds to channel 1, and so In the following figure, channel 0 is configured as range 0, channel 1 is configured as range 1, channel 2 is configured as range 2, and channel 7 is configured as range 7.
Page 88 CB4 Series Integrated I/O User Manual 7 Use ⮚ Analog filter parameter setting function The analog input filter parameters, as shown in the following figure, add D2000, each channel occupies 16 bits, D1000 corresponds to channel 0, D2001 corresponds to channel 1, and so on;...
Page 89: Faq
CB4 Series Integrated I/O User Manual 8FAQ 1. Is it possible to change the IP address of the module through the host computer? When the rotary switch is not 0, the IP address can also be changed by the host computer, but after...
