Sealey HT400LED Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
Instructions
1. SAFETY
1.1. GENERAL
Ensure the lamp is fully charged before initial use.
9
DO NOT turn the lamp on when it is being charged.
8
DO NOT shine directly into your, another person's or an animal's eyes.
8
DO NOT allow children to use the lamp.
8
DO NOT handle or move the lamp whilst it is being charged.
8
DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
8
DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
8
recharge the battery at least once every six months of non-use.
WARNING! To reduce the risk of burns or fire:
‰
DO NOT attempt to open, disassemble, modify or service the battery pack.
8
DO NOT crush, puncture, short external contacts or dispose of in fire or water.
8
DO NOT expose to temperatures above 60°C (140°F).
8
Replace only with the battery pack designated for this product.
9
Recycle or dispose of used battery as stipulated by local regulation.
9
If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
9
water and seek immediate medical attention.
WARNING: The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions and
‰
situations that may occur. It must be understood that common sense and caution are factors which must be applied by the operator.
2. INTRODUCTION
Super bright 5W COB LED spotlight provides up to 400lm in a focused beam and a 3W COB LED provides a wide spread of light.
On/off auto-sensor allows for easy hand free use without the need for pressing the on/off button. Head torch features 5 modes that
switches between: Front Light, Spotlight, Flashing, Red Light and Flashing Red Light. Inclination of the light source can be directed as
required and the elastic headband can be adjusted to fit all sizes. Easy to read charge indicator displays battery level while charging.
Charges via a USB Type-C cable (Supplied).
3. SPECIFICATION
Model No:
Battery:
Charging Time:
LED Type:
Lumen Output:
Nett Weight:
Operating Time:
4. OPERATION
4.1. Remove USB cover to reveal USB charging point. Insert cable (fig.1) red light will illuminate whilst charging.
4.2. Plug in the cable to an appropriate power source. Charging will take approximately 6hr.
4.3. When charged remove USB cable and replace the USB cover.
4.4. To switch on press on/mode change/off button (100%), press again to change mode (30%), Press again to change mode to white
flashing light (100%) press again red static light one further press and the red light will flash and once more to switch off.
4.5. To activate by hand movement, press sensor switch next to On/Off button which will turn on the main 100% light which will then make
the sensor operational. Then push the On/Off switch to make this sensor operate in 30% mode. (It only operates in these two modes).
Follow the cycle with the On/ Off switch in order to turn off.
4.6. Charging light will illuminate red when it requires charging and turns green when charging is complete.
© Jack Sealey Limited
5W & 3W COB LED RECHARGEABLE HEAD TORCH
WITH AUTO-SENSOR
HT400LED
MODEL NO:
HT400LED
3.7V Li-ion 2Ah
2-3hrs
5W & 3W COB LED
400lm
0.160kg
5-6hrs
Original Language Version
On/Off Mode
Change/Off Button
USB cover
Sensor and charging light
Adjustable
head band
Sensor
switch
fig.1
HT400LED Issue 1 04/06/24
