Bison ST85F CONVERTIBLE FLOOR Instruction Manual

—— Instruction Manual ——
ST85F CONVERTIBLE FLOOR MODEL
ST85B SPACE SAVER MODEL
S
PORT
Always check that your wheels roll freely and that they are clean before rolling the scoring table onto your
FLOOR MODEL:
1. Roll the scoring table to the desired location, lift the table top all the way up and swing out the table
legs on both sides. Lower the adjustable legs to rest on the floor. Lifting the table brace slightly will
allow the adjustable leg to become fully engaged and stabilize the scoring table. Lower the table top on
the table braces making sure that the table braces are secured into the locks on the lower surface of the
table top. (See Figure 2)
2. When placed in the bleachers, install a platform that fits securely in the bleacher seat, and will safely
hold the weight of the scoring table with a ledge to keep from rolling back. (See Figure 3) Remove the
pins, cotter keys, and the floor adjustable leg and install the bleacher adjustable leg, and reinstall the
pins and cotter keys. (See Figure 1) Hang adjustable legs not in use on hooks provided on the back
side of padding
The power strip is located on the backside of the front padding towards the top. (Note: The power strip
SPACE SAVER MODEL:
3. Roll the scoring table to the bleachers, lift the table top all the way up and swing out the table legs on
both sides. Lower the adjustable legs so they rest on the first bleacher seat. Lift the table brace to
engage the adjustable leg. Lower the table top on the table braces making sure that the table braces are
secured into the locks on the lower surface of the table top. (See Figure 4)
ALL MODELS:
4. When storing the score table, lift the table top, raise the adjustable leg up to the storage position, fold
the leg in, place the table top in the folded position.
5. Your new Scoring Table Graphic Padding is digitally
printed with UV curable inks to enhance durability
and image quality. Due to the nature of this product in
its intended application; you will experience normal
wear and tear from contact. You may attempt to re-
move light scuffmarks or stains with warm water and
mild dish soap wiping gently being certain to rinse
thoroughly. If mild dish soap and warm water does
not remove mark or stain, lightly spray with Windex
and wipe gently. (Note: Test the cleaning solution
on an inconspicuous area of the padding (ie: side
of pad) before trying on the original stain.) Do not
use harsh solvent type cleaners. Solvent type cleaners
cause cracking, hazing and general deterioration of
vinyl materials.
Date: 3/27/23 Rev: 2
AND
P G S
RIDE RAPHIC CORERS
WARNING!!!
floor. Failure to do so may scratch the floors finish.
does not provide surge protection)
N.J.C File: \\N:\INSTRUCTIONS\ST85INST
T
ABLES
NOTICE!!!
Figure 1
1
Customer Service
(800) 247-7668
Ref#:880017 L.M.
