SAL SWL350BT G2 Installation

IMPORTANT: IN THE INTEREST OF PRODUCT PERFORMANCE AND SAFETY PLEASE READ THESE INSTALLATION AND WARRANTY INSTRUCTIONS BEFORE INSTALLING THE PRODUCT.
SAL products are designed in accordance with all mandatory International and Australian Standards, which require installation
MUST BE INSTALLED
DIY
by a qualified installer and regular cleaning and maintenance of the equipment. Products are sold in accordance with the
BY A LICENSED
ELECTRICIAN
following instructions and SAL standard terms and conditions of sale, which are available via www.sal.net.au.
PUSH BUTTON SMART SWITCH SWL350BT G2, product electrical and installation specification effective 15/04/2019.
Model No. Input (V)/(Hz)
SWL350BT G2 240/50
*Subject to product capability, this size load may require the inclusion of the LOAD capacitor included in the product carton.
Nominal frequency (Hz)
Operating ambient min/max (°C)
Operating humidity
Storage ambient limit (°C)
Storage humidity
IP rating for interior products: The designated IP rating is "from below the ceiling" unless otherwise specified.
IP rating ALL products: Termination of the product must be made in accordance with the IP rating.
MULTI-GANG DE-RATING (maximum 3 x gang configuration)
Resistive load
No. of switch (Incandescent lamp,
High voltage halogen lamp)
1 350W
2 280W
3 210W
General product application requirements (where applicable) :
1. CCT selection (where supplied) – IMPORTANT, where CCT colour temperature selection switching is provided, it is important to switch OFF the power before the CCT
selection is made, otherwise equipment damage may occur.
2. Recycling – SAL encourages recycling, please consider the environment when disposing off packaging and components.
3. Switching or test intervals – For optimum product performance, good design practice does not encourage 24/7 operation of lighting products without the provision of
a routine switching or regulatory test cycle. As a guide for continual operation installations, a twelve (12) hour duration for Industrial and Commercial applications and six
(6) hour duration for Residential applications should be considered.
4. Product maintenance – In line with the relevant design standards and to protect your investment, it is important to have in place a routine cleaning program that
reflects the installation environment and maintains the product in a clean and functional condition.
IMPORTANT - The supply must be isolated before any product maintenance or cleaning is conducted. In addition, damage to ANY cable or cord supplied with the
product must be addressed as follows; For attachment type X having a specially prepared cable, if the external flexible cable is damaged, it must be replaced by an
equivalent cable exclusively available from the manufacturer or authorised installer. For attachment type Y, if the external flexible cable is damaged, it must be
exclusively replaced by an equivalent cable by the manufacturer or authorised installer. For attachment type Z, if the external flexible cable is damaged, the cable
cannot be replaced and the luminaire must be destroyed.
5. Adverse, corrosive and coastal installation applications Unless the product is specifically designated for such applications in these installation instructions, which is
supported by a professional maintenance program; installation of equipment in such environments is not recommended.
6. Dimming products – Dimming circuits and product compatibility must be validated by the installer before installation; SAL cannot be responsible for third party
changes in dimmer compatibility.
7. Suspended products – For installation safety, any suspended products must NOT be installed in high air movement spaces or locations subject to impact.
8. Light source replacements – (non-replaceable light sources) - The light source of the product is deemed not replaceable, when the product reaches its end of life,
the complete product must be replaced by a qualified installer. (Non-user replaceable light sources) - The light source of the product must only be replaced by the
manufacturer or qualified installer.
9. Interior downlights and sensors with remote drivers – The mounting facilities provided for the transformer/driver (if any), need only be utilized if in the application of the
product is required by AS3000. Drivers are not designed for installation environments that restrict conventional airflow.
10. Floodlight products – Unless nominated aiming restrictions or installation parameters apply, products are designed for installation environments between ground and
15 metres in height, subject to the desired optical performance being achieved.
Min / Max loads
13*/350W
50
0 to 40
10% to 85% RH, NC
0 to 40
10% to 85% RH, NC
Capacitive load
(e.g. LED, CFL)
200V AC
150V AC
100V AC
Caution, risk of electric shock.
Colour Dimension L x W x H (mm)
White 40 x 38 x 24
Product installation orientation
Product application
Pixie connectivity
IP rating*
Attachment type - n/a
LOAD COMPATIBILITY
Compatible Loads
Inductive load
(e.g. exhaust
fan)
80V AC
60V AC
40V AC
SAL Nationwide Pty Ltd. 40 Biloela Street Villawood NSW 2163 ABN 45 144 501 020
Copyright SAL MAR V4/2018 |
Bluetooth Mesh Technology
Horizontal wall mount
Interior residential or commercial
Yes
20
Incandescent lamp
240V halogen lamp
Low voltage halogen with electronic transformer
Low voltage halogen with magnetic transformer
CFL
LED fixture
www.sal.net.au
Wireless
Yes
Yes
Yes
Yes
Yes
Yes
| Page 1 of 2
