TRENDnet TEG-S240TX - DATA SHEETS Datasheet

FEATURES
• 24 10/100/1000Mbps Auto Negotiation and Auto-MDIX Ethernet Ports
• Full/Half duplex transfer mode for each port (full duplex mode for 1000Base-T only)
• Store and Forward switching method
• 20Gbps Backplane
• Integrated address Look-Up Engine, supports 32k absolute MAC Address
• Supports 2 Mbytes RAM for data buffering
• Extensive Front Panel Diagnostic LEDs
• Broadcast Storm protection
• IEEE 802.3x flow control for full-duplex
• Back Pressure flow control for half-duplex
• Standard 19" rack-mount size
• 5-year Warranty
BENEFITS
Performance:
Top performance for gigabit network solutions.
Easy Upgrade:
Current Ethernet workgroups are able to upgrade to Fast Ethernet by changing adapters and hubs without
changing switches.
Flexibility:
All ports automatically negotiate 10/100/1000 Mbps network speed, half/full-duplex mode, and Auto-MDIX;
easy uplink with any port.
Cost Effective:
Provide 10/100/1000Mbps of Fast Ethernet at an affordable rate.
24-Port 10/100/1000Mbps Copper Gigabit
Switch
TEG-S240TX
TRENDnet's TEG-S240TX is a high performance 24-port rack
mountable Copper Gigabit Switch. With auto-negotiation
technology, the TEG-S240TX automatically negotiates between
10Base-T, 100Base-TX and 1000Base-T network speeds, as well
as half and full duplex modes. The Auto-MDIX feature on each port
automatically detects and adjusts connection type with either
straight-through or crossover cable. Providing simple migration,
scalability, and flexibility to handle new applications and data types,
TRENDnet's TEG-S240TX is a highly reliable and cost effective
solution for high-speed network applications.
TEG-S240TX
rev:09.20.2006
